This document describes the equipment installed at 15 different point of presence (POP) sites maintained by Higher Education Commission (HEC). It provides details of the servers, routers, switches, generators, UPS systems, air conditioners and other equipment located at each POP site, including HEC ISB, QAU ISB, AU ISB, and others. For each POP site, it lists the specific equipment installed, such as UPS systems, air conditioners, fiber distribution frames, firewalls, and fire safety equipment.

1. Made by Engineer Muhammad Muneeb Awan
Internee IT division

2. Pop site Purpose & Equipment Installed
 A point of presence is a physical location
where a communications carrier allows
other carriers to access its network.
 Pop site includes servers, routers
, switches and generators, ups for the
power backup and ATS panel. Air
conditioners for the cooling purpose.

3. HEC 15 Pop sites
1) HEC ISB
2) QAU ISB
3) AU ISB
4) FJWU ISB
5) HEC RC PESH
6) HEC RC LHR POP
7) PU POP LHR
8) GCU POP LHR
9) UAF FSB POP
10) BZU MLTN POP
11) HEC RC KHI POP
12) CPSP POP KHI
13) KU POP KHI
14) SU HYD POP
15) BUITEMS QUETTA

4. HEC POP ISB Equipment
Installed
 MGE Galaxy 5000 UPS 80 KVA
 Servo motor controlled stabilizer 150KVA
 Air conditioners
 Fire extinguisher 6Kg and Block diagram of power
distribution
 AC Stulz
 Fire alarm panel & Reptile Repeller
 10 KVA Ups with battery bank & Ac Stulz
 FM 200 Heptafluoropropane

5. HEC ISB POWER UNIT
2 Ups GALAXY 5000 (80 KVA ) 150 KVA servo motor controlled
stabilizer
Block diagram of power distribution in Air conditioners in power unit room
data center &
fire extinguisher 6 kg

6. HEC ISB DATA CENTER
AC Stulz Fire alarm panel &
Reptile repeller
10 KVA ups for NE 80 & AC stulz FM 200 Heptafluoropropane &
raise floor

7. QAU POP ISB Equipment
installed
 Fire extinguisher & 3 phase Line conditioner
36KVA
 Fire alarm panel & thermo controller
 2 Air conditioners automatic switching
 10 KVA UPS with Battery Bank
 Optical Fiber Distribution Frame(OFDF)
 Raise floor
 Bracket fan & emergency light

8. QAU POP ISB
Fire extinguisher & 3 phase
Fire panel & thermo controller
36 KVA Line conditioner
Air conditioner for cooling 10 KVA Ups for NE 40

9. QAU POP ISB
Optical Distribution Frame Raise floor
(ODF)
Bracket fan & Emergency Light

10. AU POP ISB Equipment
installed
 2 Air conditioners
 Au pop Pinger , UPS & fire extinguisher
 Fire Extinguisher
 6 KVA UPS with Battery Bank

11. AU POP
Air conditioner (2) Au pop Pinger , UPS &
fire extinguisher
Fire extinguisher 6 KVA UPS with Battery Bank

12. FJWU POP Equipment installed
 2 Air conditioners
 Bracket fan & Fire alarm Panel
 Fire Extinguisher
 10 KVA UPS with Battery Bank & raise floor

13. FJWU POP RWP
Air conditioner (2) Bracket fan and Fire Alarm panel
Fire extinguisher 10 KVA UPS with Battery Bank &
Raise floor

14. HEC RC PSH POP Equipment
Installed
 Raise floor
 10 KVA UPS with Battery Bank & Air conditioner
 Optical fiber distribution frame (OFDF)
 Fire Alarm Panel

15. HEC RC PSH
Raise Floor 10 KVA UPS with Battery Bank
Optical fiber distribution frame (OFDF) Fire alarm panel at right side to the entrance

16. HEC RC LHR POP Equipment
installed
 Fire Extinguisher & 30 KVA UPS with Battery Bank
 AC Stulz
 Business intelligence Server & Air Conditioner
 Raise floor

17. HEC RC LHR
fire extinguisher and 30 KVA
AC stulz
UPS with Battery Banks
Business intelligence Server & Raise floor
Air conditioner

18. PU POP LHR POP Equipment
installed
 Raise floor
 Air conditioners with thermo controlled sensor
 10 KVA UPS with Battery bank
 Fire Extinguisher, fire alarm panel , bracket fan &
emergency light
 Optical Fiber Distribution Frame

19. PU POP LHR
Raise floor Air conditioners with thermo
10 KVA UPS with Battery Bank
controlled sensor
Fire extinguisher, fire alarm panel
Optical Fiber Distribution Frame
, bracket fan & emergency light
(OFDF)

20. GCU POP Equipment
installed
 OFDF, Bracket fan ,Air conditioner & emergency
light
 10 KVA UPS Battery Bank
 Raise floor & T1/ E1 panel

21. GCU POP
OFDF, Bracket fan ,Air conditioner 10 KVA UPS Battery Bank
& emergency light
Raise floor & T1/E1 Panel

22. UAF FSB POP Equipment
installed
 Fire extinguisher, bracket fan , emergency light
, Air conditioner & raise floor
 Optical Fiber Distribution Frame
 10 KVA UPS For Router NE 40
 Battery Bank of UPS 10 KVA

23. UAF FSB POP
Fire extinguisher, bracket fan , emergency Optical Fiber Distribution Frame
light , Air conditioner & raise floor
10 KVA UPS For Router NE 40 Battery Bank of UPS 10 KVA

24. BZU MTLN POP Equipment
installed
 Raise floor
 Fire Alarm panel, bracket fan & AC DB panel
 Air conditioners with thermo sensor
 10 KVA UPS with Battery Bank
 Optical Fiber Distribution Frame (OFDF)

25. BZU MTLN POP
Raise floor Fire Alarm panel, bracket Air conditioners with
fan & AC DB panel thermo sensor
Optical Fiber Distribution
10 KVA UPS with Battery Bank

26. HEC RC KHI POP Equipment
installed
 Fire Extinguisher side View & fire panel
 AC Stulz
 OFDF & NE 40 Rack
 10 KVA UPS, AC DB Panel & Battery Bank

27. HEC RC KHI
Fire Extinguisher side View
AC Stulz
& fire panel
10 KVA UPS, AC DB Panel & Battery
OFDF & NE 40 Rack

28. CPSP POP KHI Equipment
installed
 OFDF & NE 40 Rack
 Fire Alarm Panel
 Bracket fans
 10 KVA UPS with Battery Bank
 Fire Extinguisher

29. CPSP POP KHI
OFDF & NE 40 Rack Fire Alarm Panel Bracket fans
10 KVA UPS with Battery Bank Fire Extinguisher

30. KU POP KHI Equipment
installed
 Fire extinguisher & raise floor
 Fire alarm panel
 Side view cover 10 KVA UPS with battery bank

31. KU POP KHI
Fire extinguisher & raise floor Fire alarm panel
Side view cover 10 KVA UPS with battery bank

32. SU HYD POP Equipment
installed
 Air conditioners with thermo sensor
 10 KVA UPS with battery bank & fire extinguisher
 Optical Fiber Distribution Frame
 Bracket fan

33. SU HYD POP
Air conditioners with thermo sensor 10 KVA UPS with battery bank &
fire extinguisher
Optical Fiber Distribution Frame
Bracket fan

34. BUITEMS QUETTA Equipment
installed
 Raise floor
 10 KVA UPS with Battery Bank
 Fire extinguisher & Emergency light
 Optical Fiber Distribution Frame
 Fire alarm Panel & Bracket fan
 Air conditioners with thermo Sensor

35. BUITEMS QUETTA
10 KVA UPS with Battery Bank Fire extinguisher &
Raise floor Emergency light
Optical Fiber Distribution Frame Fire alarm Panel & Air conditioners with thermo
Bracket fan Sensor
