For several years, LinkedIn has been using Kafka MirrorMaker as the mirroring solution for copying data between Kafka clusters across data centers. However, as LinkedIn data continued to grow, mirroring trillions of Kafka messages per day across data centers uncovered the scale limitations and operability challenges of Kafka MirrorMaker. To address these, we have developed a new mirroring solution, built on top our stream ingestion service, Brooklin. Brooklin’s mirroring solution aims to provide improved performance and stability, while facilitating better management via finer control of data pipelines. Through flushless Kafka produce, dynamic management of data pipelines, per-partition error handling and flow control, we are able to increase throughput, better withstand consume and produce failures and reduce overall operating costs. As a result, we have eliminated the major pain points of Kafka MirrorMaker. In this talk, we will dive deeper into the challenges LinkedIn has faced with Kafka MirrorMaker, how we tackled them with Brooklin and our plans for iterating further on this new mirroring solution.

1. More Data, More Problems:
Scaling Kafka Mirroring Pipelines at LinkedIn
Celia Kung
Engineering Manager

2. Agenda
Use Cases & Motivation
Kafka MirrorMaker at LinkedIn
Brooklin Mirroring
Future

3. Use Cases & Motivation

4. • Aggregating data from all data centers
• Moving data from offline data stores into online
environments
• Moving data between LinkedIn and external
cloud services
Use Cases

5. Motivation
● Kafka data at LinkedIn continues to grow rapidly

6. Motivation
● Kafka MirrorMaker (KMM) has not scaled well
● KMM is difficult to operate and maintain

7. Kafka MirrorMaker
at LinkedIn

8. Kafka MirrorMaker at LinkedIn
100+ 9pipelines data centers

9. Kafka MirrorMaker at LinkedIn
100+clusters
6K+hosts
2T+messages/day

10. Topology
Datacenter B
aggregate
tracking
tracking
KMM KMM
Datacenter A
aggregate
tracking
tracking
KMM KMM
• Each pipeline:
○ mirrors data from 1 source cluster to 1
destination cluster
○ constitutes its own KMM cluster

11. Topology
Datacenter B
aggregate
tracking
tracking
Datacenter A
aggregate
tracking
tracking
KMM
aggregate
metrics
metrics
aggregate
metrics
metrics
Datacenter C
aggregate
tracking
tracking
aggregate
metrics
metrics
...
KMM KMM
KMM KMM KMM
KMM KMM KMM KMM KMM KMM
KMM KMM KMM KMM KMM KMM
... ... ...

12. KMM does not scale well
● # of KMM clusters = (# of data centers)2 x # of Kafka clusters
● More consumer-producer pairs → need to provision more hardware

13. KMM is difficult to operate
● Static configuration file per KMM cluster
● Changes require deploying to 100+ clusters

14. Topology
Datacenter B
aggregate
tracking
tracking
Datacenter A
aggregate
tracking
tracking
KMM
aggregate
metrics
metrics
aggregate
metrics
metrics
Datacenter C
aggregate
tracking
tracking
aggregate
metrics
metrics
...
KMM KMM
KMM KMM KMM
KMM KMM KMM KMM KMM KMM
KMM KMM KMM KMM KMM KMM
... ... ...

15. KMM is fragile
● Poor failure isolation
● Increased latency
● Unable to catch up with traffic

16. Brooklin Mirroring

17. Brooklin Mirroring
● Optimized for stability and operability
● Built on top of our streaming data pipelines service, Brooklin
● Brooklin Kafka mirroring has been in production for 1+ years
● Open-sourced Brooklin last month

18. Mirroring pipelines at LinkedIn
100+ 9pipelines data centers

19. Kafka MirrorMaker
100+clusters
6K+hosts
2T+messages/day

20. Kafka MirrorMaker
100+clusters
6K+hosts
2T+messages/day

21. Brooklin Mirroring
9clusters
<2Khosts
2T+messages/day

22. Topology
Datacenter B
aggregate
tracking
tracking
Datacenter A
aggregate
tracking
tracking
Brooklin
• A single Brooklin cluster
encompasses multiple pipelines
○ 1 cluster per data center
Brooklin

23. Topology
Datacenter A
aggregate
tracking
tracking metrics
aggregate
metrics
Datacenter B
aggregate
tracking
tracking metrics
aggregate
metrics
Datacenter C
aggregate
tracking
tracking metrics
aggregate
metrics
...Brooklin BrooklinBrooklin

24. Brooklin Mirroring Architecture
Brooklin

25. Kafka mirroring built on Brooklin
DestinationsSources
Messaging systems
Microsoft
EventHubs
Messaging systems
Microsoft
EventHubs
Databases Databases

26. Kafka mirroring built on Brooklin
DestinationsSources
Messaging systems
Microsoft
EventHubs
Messaging systems
Microsoft
EventHubs
Databases Databases

27. Kafka mirroring built on Brooklin

28. Kafka mirroring built on Brooklin
Brooklin
Engine
Kafka src
connector
Kafka dest
connector
Management
Rest API
Diagnostics
Rest API
ZooKeeper
Management/
monitoring
portal
SRE/op
dashboards

29. Kafka mirroring built on Brooklin
Brooklin
Engine
Kafka src
connector
Kafka dest
connector
Management
Rest API
Diagnostics
Rest API
ZooKeeper
Management/
monitoring
portal
SRE/op
dashboards

30. Dynamic Management
Brooklin
Engine
Kafka src
connector
Kafka dest
connector
Management
Rest API
Diagnostics
Rest API
ZooKeeper
Management/
monitoring
portal
SRE/op
dashboards

31. Creating a pipeline
Brooklin
Engine
Management
Rest API
ZooKeeper
create POST /datastream
name: mm_DC1-tracking_DC2-aggregate-tracking
connectorName: KafkaMirrorMaker
source:
connectionString: kafkassl://DC1-tracking-vip:12345/topicA|topicB
destination:
connectionString: kafkassl://DC2-aggregate-tracking-vip:12345
metadata:
num-streams: 5

32. Creating a pipeline
ZooKeeper
Brooklin
host
Brooklin
host
Brooklin
host
Brooklin
host
Brooklin
host

33. Updating a pipeline
Brooklin
Engine
Management
Rest API
ZooKeeper
update PUT /datastream/mm_DC1-tracking_DC2-aggregate-
tracking
name: mm_DC1-tracking_DC2-aggregate-tracking
connectorName: KafkaMirrorMaker
source:
connectionString: kafkassl://DC1-tracking-vip:12345/topicA|topicB|topicC|topicD
destination:
connectionString: kafkassl://DC2-aggregate-tracking-vip:12345
metadata:
num-streams: 10

34. Updating a pipeline
ZooKeeper
Brooklin
host
Brooklin
host
Brooklin
host
Brooklin
host
Brooklin
host

35. Dynamic Management
Brooklin
Engine
Kafka src
connector
Kafka dest
connector
Management
Rest API
Diagnostics
Rest API
ZooKeeper
Management/
monitoring
portal
SRE/op
dashboards

36. On-demand Diagnostics
Brooklin
Engine
Diagnostics
Rest API
ZooKeeper
getAllStatus GET /diag?datastream=mm_DC1-tracking_DC2-aggregate-tracking
host1.prod.linkedin.com:
datastream: mm_DC1-tracking_DC2-aggregate-tracking
assignedTopicPartitions: [topicA-0, topicA-3, topicB-0, topicB-2]
autoPausedPartitions: [{topicA-3: {reason: SEND_ERROR, description: failed to produce messages from this
partition}}]
manuallyPausedPartitions: []
host2.prod.linkedin.com:
datastream: mm_DC1-tracking_DC2-aggregate-tracking
assignedTopicPartitions: [topicA-1, topicA-2, topicB-1, topicB-3]
autoPausedPartitions: []
manuallyPausedPartitions: []

37. Error Isolation
● Manually pause and resume mirroring at every level
○ Entire pipeline, topic, topic-partition
● Brooklin can automatically pause mirroring of partitions
○ Auto-resumes the partitions after configurable duration
● Flow of messages from other partitions continue

38. Processing Loop
while (!shutdown) {
records = consumer.poll();
producer.send(records);
if (timeToCommit) {
producer.flush();
consumer.commit();
}
}

39. Producer flush can be expensive
while (!shutdown) {
records = consumer.poll();
producer.send(records);
if (timeToCommit) {
producer.flush();
consumer.commit();
}
}

40. Long Flush
producer.flush() can take several minutes
200
100
0

41. Rebalance Storms
consumers rebalance after max.poll.interval.ms
3
2
1
0

42. Increase max.poll.interval.ms?
● Reduces chances of consumer rebalance
● Risk detecting real failures late

43. Flushless Produce
consumer.poll() → producer.send(records) → producer.flush() → consumer.commit()

44. Flushless Produce
Only commit “safe” acknowledged checkpoints:
consumer.poll() → producer.send(records) → consumer.commit(offsets)

45. Flushless Produce
sp0 consumer producer
checkpoint
manager
o1, o2 o1, o2 o1, o2
o1
o2
Source
Destination
ack(sp0, o2)
dp0
dp1
● Checkpoint manager maintains producer-acknowledged offsets for each
source partition
Source partition sp0
in-flight: []
acked: []
safe checkpoint: --

46. Flushless Produce
sp0 consumer producer
checkpoint
manager
o1, o2 o1, o2 o1, o2
o1
o2
Source
Destination
ack(sp0, o2)
dp0
dp1
● Checkpoint manager maintains producer-acknowledged offsets for each
source partition
Source partition sp0
in-flight: [o1, o2]
acked: []
safe checkpoint: --

47. Flushless Produce
sp0 consumer producer
checkpoint
manager
o1, o2 o1, o2 o1, o2
o1
o2
Source
Destination
ack(sp0, o2)
dp0
dp1
● Checkpoint manager maintains producer-acknowledged offsets for each
source partition
Source partition sp0
in-flight: [o1, o2]
acked: []
safe checkpoint: --

48. Flushless Produce
sp0 consumer producer
checkpoint
manager
o1, o2 o1, o2 o1, o2
o1
o2
Source
Destination
ack(sp0, o2)
dp0
dp1
● Checkpoint manager maintains producer-acknowledged offsets for each
source partition
Source partition sp0
in-flight: [o1, o2]
acked: []
safe checkpoint: --

49. Flushless Produce
sp0 consumer producer
checkpoint
manager
o1, o2 o1, o2 o1, o2
o1
o2
Source
Destination
ack(sp0, o2)
dp0
dp1
● Checkpoint manager maintains producer-acknowledged offsets for each
source partition
Source partition sp0
in-flight: [o1, o2]
acked: []
safe checkpoint: --

50. Flushless Produce
sp0 consumer producer
checkpoint
manager
o1, o2 o1, o2 o1, o2
o1
o2
Source
Destination
ack(sp0, o2)
dp0
dp1
● Checkpoint manager maintains producer-acknowledged offsets for each
source partition
Source partition sp0
in-flight: [o1]
acked: [o2]
safe checkpoint: --

51. Flushless Produce
sp0 consumer producer
checkpoint
manager
o1, o2 o1, o2 o1, o2
o1
o2
Source
Destination
ack(sp0, o2)
dp0
dp1
● Checkpoint manager maintains producer-acknowledged offsets for each
source partition
Source partition sp0
in-flight: [o1]
acked: [o2]
safe checkpoint: --

52. Flushless Produce
sp0 consumer producer
checkpoint
manager
o3, o4 o3, o4 o3, o4
o3
o4
Source
Destination
ack(sp0, o1)
dp0
dp1
● Update safe checkpoint to largest acknowledged offset that is less than
oldest in-flight (if any)
Source partition sp0
in-flight: [o3, o4]
acked: [o1, o2]
safe checkpoint:

53. Flushless Produce
sp0 consumer producer
checkpoint
manager
o3, o4 o3, o4 o3, o4
o3
o4
Source
Destination
ack(sp0, o1)
dp0
dp1
● Update safe checkpoint to largest acknowledged offset that is less than
oldest in-flight (if any)
Source partition sp0
in-flight: [o3, o4]
acked: []
safe checkpoint: o2

54. Brooklin Mirroring Performance
● Use same consumer/producer configs as KMM
● Single host: 64 GB memory, 24 CPU (12 cores each)
● Metrics:
○ Throughput (output compressed bytes/sec)
○ Memory utilization %
○ CPU utilization %

55. Throughput

56. Memory Utilization

57. CPU Utilization

58. Brooklin Mirroring Performance
● Brooklin mirroring is CPU-bound
● Metrics (20 consumer-producer pairs):
○ Throughput: up to 28 MB/s
○ Memory utilization: 70%
○ CPU utilization: 97%

59. • 70%+ CPU time spent in decompression & re-
compression
○ GZIPInputStream.read(): ~10%
○ GZIPOutputStream.write(): ~61%
• Introduced “Passthrough” mirroring
Performance

60. Future

61. • Rebalances cause drop in availability
• Brooklin-controlled partition assignment &
Kafka low-level consumer
Stability

62. • Auto-scaling: adjust number of consumers
based on throughput needs
• Smarter (throughput-based) partition
assignment
Scalability

64. Thank you
