MEP BIM
1.
上海南汇工业园区 智城研发基地 地库综合管线布置 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
2.
地库综合管线布置 地库环境概况 地下汽车库覆盖范围从1#至10#,车库总建筑面积25881.79㎡,总体建 筑高度5200mm,其中覆土区域顶板高差1200mm,平均梁高700,覆土区 域可利用高度为3300mm。 本次深化目的 本次深化主要在于解决狭小走廊及主行车道的各专业管线交叉相碰以 及覆土区域管线标高过低问题。 本次深化原则 本次深化原则是在经济合理的前提下,调整各专业管线走向,减少因 管线布置不合理造成的返工损失。 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
3.
地库综合管线布置 本次深化涉及到的管线 消防(消火栓干管、喷淋干管) 给排水(给水管、热媒管、热水管、污水管、压力排水管) 暖通(送风管、排烟管、空调供回水管) 电气(强电桥架、弱电线槽) 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
4.
地库综合管线布置 优先考虑管线 生活污水管——考虑室外污水井标高及管道坡度 成排管道及大直径主管——考虑翻越成本 能源中心供回水管道——影响整条管线标高 调整策略 单根管道及多层桥架贴着车道边和柱走 减少管道的弯管数量,减少局部阻力 最大程度利用梁底高差,减少层高浪费 为避免管道积气,弯管采用下翻形式U弯 大管放最上层,便于检修 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
5.
地库综合管线布置 剖面编号 位置 轴线 最低标高 A-A 地库1#核心筒走廊 1-2轴/1-F轴 3320 B-B 地库1#核心筒走廊 1-2轴/1-K轴 2474 C-C 地库1#主车道 1-3轴/1-K轴 2900 D-D 地库1#主车道 1-4轴/1-F轴 4010 E-E 地库1#主车道 1-8轴/1-E轴 2960 F-F 地库1#至2#主车道 1-8轴/1-C轴 2420 G-G 地库2#热水泵房 2-3轴/2-H轴 2790 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
6.
地库综合管线布置 剖面编号 位置 轴线 最低标高 H-H 地库2#主车道 2-4轴/2-H轴 3460 I-I 地库3-10#主车道 3-1轴/2-H轴 2260 J-J 地库3-10#主车道 3-4轴/2-H轴 2460 K-K 地库3-10#主车道 3-8轴/2-H轴 2810 L-L 地库3-10#主车道 3-14轴/2-H轴 2450 X-X 地库2#核心筒停车位 2-4轴/2-J轴 2510 Z-Z 地库2#核心筒过道 2-4轴/2-J轴 3408 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
7.
地库综合管线布置 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
8.
地库综合管线布置 B-B C-C A-A D-D 上海南汇工业园区智城研发基地–地库综合管线布置 E-E 上海市安装工程有限公司 梁文鉴
9.
地库综合管线布置|A-A 碰撞位置1 强电桥架300×100 送风管1200×630 碰撞位置2 强电桥架300×100 送风管400×200 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
10.
地库综合管线布置 B-B C-C A-A D-D 上海南汇工业园区智城研发基地–地库综合管线布置 E-E 上海市安装工程有限公司 梁文鉴
11.
地库综合管线布置|B-B 碰撞位置1 强电桥架300×100 送风管1200×630 碰撞位置2 强电桥架300×100 送风管400×200 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
12.
地库综合管线布置 B-B C-C A-A D-D 上海南汇工业园区智城研发基地–地库综合管线布置 E-E 上海市安装工程有限公司 梁文鉴
13.
地库综合管线布置|C-C 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
14.
地库综合管线布置 B-B C-C A-A D-D 上海南汇工业园区智城研发基地–地库综合管线布置 E-E 上海市安装工程有限公司 梁文鉴
15.
地库综合管线布置|D-D 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
16.
地库综合管线布置 B-B C-C A-A D-D 上海南汇工业园区智城研发基地–地库综合管线布置 E-E 上海市安装工程有限公司 梁文鉴
17.
地库综合管线布置|E-E 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
18.
地库综合管线布置 F-F X-X G-G H-H I-I Z-Z J-J 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
19.
地库综合管线布置|F-F 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
20.
地库综合管线布置 F-F X-X G-G H-H I-I Z-Z J-J 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
21.
地库综合管线布置|G-G、H-H、Z-Z G-G H-H Z-Z 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
22.
地库综合管线布置 F-F X-X G-G H-H I-I Z-Z J-J 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
23.
地库综合管线布置|I-I 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
24.
地库综合管线布置 K-K I-I L-L 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
25.
地库综合管线布置|K-K 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
26.
地库综合管线布置 K-K I-I L-L 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
27.
地库综合管线布置|L-L 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
28.
地库综合管线布置 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
29.
地库综合管线布置|管线交叉部位 上海南汇工业园区智城研发基地–地库综合管线布置 上海市安装工程有限公司 梁文鉴
