MapStudy talk
- 1. Introducing MapStudy a survey design framework for 21st Century Cartography Carl M. Sack Kristen Vincent Robert E. Roth University of Wisconsin-Madison
- 2. MapStudy – NACIS 2016 The Skinny What is MapStudy? Why MapStudy? Architecture Dance Break Setup Case Study
- 3. MapStudy – NACIS 2016 MapStudy: What is it? “MapStudy is an integrated, modularized framework for the creation of survey applications designed to test cartographic design and interaction hypotheses in a modern web map environment.” –Documentation
- 4. MapStudy – NACIS 2016 MapStudy: What is it? “MapStudy is an integrated, modularized framework for the creation of survey applications designed to test cartographic design and interaction hypotheses in a modern web map environment.” –Documentation
- 5. MapStudy – NACIS 2016 MapStudy: What is it? “MapStudy is an integrated, modularized framework for the creation of survey applications designed to test cartographic design and interaction hypotheses in a modern web map environment.” –Documentation
- 6. MapStudy – NACIS 2016 Why MapStudy? Do the same design principles apply to online maps? What about UI/UX design for interactive web maps?
- 7. MapStudy – NACIS 2016 Architecture (yep, this figure is too large)
- 8. MapStudy – NACIS 2016 Window Sections
- 9. MapStudy – NACIS 2016 Window Sections header map questions footer
- 10. MapStudy – NACIS 2016 Pages
- 11. MapStudy – NACIS 2016 Pages
- 12. MapStudy – NACIS 2016 Map Library Currently only Leaflet Coming (soon?): D3, MapboxGL, image, REST service, iframe
- 13. MapStudy – NACIS 2016 Map Interactions
- 14. MapStudy – NACIS 2016 Map base layers Layers that cannot be interacted with except to swap (if enabled)
- 15. MapStudy – NACIS 2016 Map data layers
- 16. MapStudy – NACIS 2016 Questions
- 17. MapStudy – NACIS 2016 Question Pages
- 18. MapStudy – NACIS 2016 Question Sets
- 19. MapStudy – NACIS 2016 Question Blocks
- 20. MapStudy – NACIS 2016 Question Inputs
- 21. MapStudy – NACIS 2016 Question Inputs
- 22. MapStudy – NACIS 2016 Question Inputs
- 23. MapStudy – NACIS 2016 Question Input Options and Items
- 24. MapStudy – NACIS 2016 Question Buttons
- 25. MapStudy – NACIS 2016 Question Timers Set
- 26. MapStudy – NACIS 2016 Question Timers Page
- 27. MapStudy – NACIS 2016 Conditions Each user assigned a condition Each condition defines a page order Pages can be grouped and randomized Condition weights determine frequency of assignment
- 28. MapStudy – NACIS 2016 Server Data Tables: Table Rows Columns Master Participants Participant ID, time last updated, question block/item labels, submission point timestamps Page Participants Participant ID, time last updated, question block/item labels, submission point timestamps Participant Question block/item Question label, question text, input answer
- 29. MapStudy – NACIS 2016 Server Interaction Tables: Table Rows Columns Master Participants Participant ID, interaction hit counts, interaction string Page Participants Participant ID, interaction hit counts, interaction string Participant Timestamps Interaction, page, set
- 30. MapStudy – NACIS 2016 Dance Break
- 31. MapStudy – NACIS 2016 Downloading and Installing
- 32. MapStudy – NACIS 2016 Configuration http://grad.geography.wisc.edu/cmsack/mapstudy/setup/
- 33. MapStudy – NACIS 2016 Configuration Files GitHub Docs describe config files and list all config file options Also includes links to setup and demo apps github.com/uwcart/mapstudy
- 34. MapStudy – NACIS 2016 Case Study: MapStudy 1
- 35. MapStudy – NACIS 2016 Case Study: MapStudy 1 Designed to test different map techniques at two scales using fake Twitter data Feedback so far: Relatively easy to set up using setup app and docs Picky about data formatting, attribute names Requires some trial and error Needs more documentation of possible hacks
- 36. MapStudy – NACIS 2016 Future Goals Add and continue to update map libraries Add additional interactions Expand flexibility of questions Build developer and user communities to give it legs
- 37. MapStudy – NACIS 2016 Thank you. Carl M. Sack – cmsack@wisc.edu Kristen Vincent – kvincent2@wisc.edu Robert E. Roth – reroth@wisc.edu University of Wisconsin-Madison A portion of this research was funded by NSF Grant #1555267
