LM1450A
•
0 likes•3,253 views
The LM1450A universal milling machine has a rotary table that allows 45 degrees of processing, three-axis automatic feeds, and a powerful 1.5kW spindle for fast 2000mm/min movement. It has a ISO 50 spindle taper, table size of 1630x360mm, and table travel of 1000x320x405mm. The machine can be used to mill complex shapes and special parts with features like a dividing head, boring device, and clamping kit.
