The document outlines exercises for learning Jenkins Scriptler, which allows administering Jenkins scripts to troubleshoot, diagnose, and automate tasks. The exercises include writing a "Hello World" script, hooking into Jenkins to retrieve and print job names, using the Jenkins Java API to find necessary methods, putting a script into the Scriptler catalog, and learning Groovy loops and closures. References for the Scriptler catalog, Groovy, and Jenkins scripting guidelines are also provided.

1. Larry cai <larry.caiyu@gmail.com>

2. Agenda







What is Jenkins Scriptler ?
Exercise 1: Hello World in Jenkins script console
Exercise 2: Hook into Jenkins
Exercise 3: Jenkins Java API
Exercise 4: Find the needed Jenkins Java method
Exercise 5: Put into Jenkins Scriptler
Exercise 6: Learn more Groovy
2
Jenkins Scriptler in 90 minutes

3. Jenkins Scriptler



Administering your jenkins scripts, which is used to
trouble-shooting and diagnostics or routing tasks in
jenkins
Provides a way to share scripts between users via hosted
script catalogs on the internet.
Install plugin
https://wiki.jenkins-ci.org/display/JENKINS/Scriptler+Plugin

Use
http://<jenkins job>/scriptler/
or
Jenkins -> Scriptler (system menu)
3
Jenkins Scriptler in 90 minutes

4. Jenkins script



Jenkins script can access to Jenkins instance data and
manipulate directly
Jenkins script use Groovy, which is an agile and dynamic
language for the Java Virtual Machine
a.k.a java-like script language over JVM
4
Jenkins Scriptler in 90 minutes

5. Exercise 1 – Hello World

Jenkins Console the place to exercise the Jenkins script
https://wiki.jenkins-ci.org/display/JENKINS/Jenkins+Script+Console
5
Jenkins Scriptler in 90 minutes

6. Exercise 2 – Hook into Jenkins



Get the jenkins java instance
ji = jenkins.model.Jenkins.instance
All the items (include jobs)
jobs = ji.items
Printout the job names started with “test”
6
Jenkins Scriptler in 90 minutes

7. Exercise 3: Jenkins Java API



Script use jenkins JAVA API to access internal data
http://javadoc.jenkins-ci.org/
Jenkins instance is
http://javadoc.jenkins-ci.org/jenkins/model/Jenkins.html
Then locate “getAllItems()” API
7
Jenkins Scriptler in 90 minutes

8. Exercise 4 – Find the needed method

Find the Item API and try to printout the url for the jobs

If needed, check the source code if java developers
https://github.com/jenkinsci/jenkins/blob/master/core/src/main/
Otherwise Check samples ;-)

8
Jenkins Scriptler in 90 minutes

9. Exercise 5: Put into Jenkins Scriptler

Now put the scripts into Jenkins Scriptler
Id & Name: geturl

Add parameter for “job_prefix”, use “$name”

9
Jenkins Scriptler in 90 minutes

10. Exercise 6: learn more Groovy



Install Groovy Console
http://groovy.codehaus.org/
Learn loop syntax
http://groovy.codehaus.org/Looping
List string in closures way
10
Jenkins Scriptler in 90 minutes

11. Reference

Market place



Groovy


http://scriptlerweb.appspot.com/catalog/list
https://github.com/jenkinsci/jenkins-scripts/tree/master/scriptler
http://groovy.codehaus.org
Small guideline

11
http://earlyandoften.wordpress.com/2013/03/11/masteringjenkins-making-bulk-updates-to-jobs/
Jenkins Scriptler in 90 minutes
