1. ISO 9001:2015
www.astTECS.com
*astTECS IP Phones available in three models - *ast520,
*ast550 and *ast600W (wi-fi phone), features are plug
and play deployment, HD voice, multiple line appearances,
contexual soft keys, phone books, DND and advanced
applications at attractive price to suit your budget.
The ergonomically designed phones are equipped with
essential features that the modern business
environments demand and suitable for both small
businesses and large office applications. The unit is
fully supports all of the major SIP based IP PBX /
softswitch / IMS platform.
*astTECS IP Phones
*ast520 *ast 550 *ast 600W (Wifi phone)
Call hold
Call Waiting
Call forward
Call return
Call transfer (blind/busy/ask)
Caller ID Display
Speed dial
Phone mute
SMS & Voicemail
DND
Dialed/received/missed calls
Auto- answer
3 way conference
Ringtone selection/import/delete
Message waiting indication LED
Tone configuration volume control
Multi-language
Direct IP call without SIP proxy
Blacklist
Hands free indicator
Soft keys programmable
Support POE
XML phonebook search and inputs & outputs
Supports PC control
FEATURES
*astT
E
C
S*astT
E
C
S*astT
E
C
S
2. ISO 9001:2015
www.astTECS.com
About *astTECS:
*astTECS is leader in end to end unified communications, offering wide
range of cutting edge enterprise telecom products based on open source
technology. We also provides world class 24X7 support to global customers
through our in-house Global Support Management Center (GSMC).
CORPORATE OFFICE:
iTECS Communications Pvt. Ltd.
# 35, K.R. Layout, Domlur, Bangalore – 560071.
Karnataka, India
Mobile : +91 9986654408
Land lines : 080 – 66406640
sales@asttecs.com
BRANCH OFFICE:
India: Mumbai | Hyderabad | Coimbatore | Delhi | Jaipur | Ahmadabad | Chennai | Pune | Indore
| Kolkata | Cochin | Nagpur | Goa | Lucknow | Chandigarh | Puducherry | Asia: Sri lanka |
Thailand | Cambodia | Afghanistan | Myanmar | Nepal | Middle East: UAE | Saudi Arabia | Bahrain
| Kuwait | Qatar | Fiji | Europe: Germany | Central America: Colombia | US: Illinois | Missouri |
Africa: Egypt | South Africa | Nigeria | Botswana | Ghana | Kenya | Ivory Coast | Palau
*ast520 *ast550 *ast600w (Wi-Fi phone)
TECHNICAL SPECIFICATIONS
132x64 graphic LCD.
2 SIP accounts, Hotline, 33 keys including
2 programmable keys, Functions
customizable keys, Support switching SIP
server & Second server, Phonebook (local
up to 1000 entries). Call history: dialed /
received / missed (100 -entries); One-key
back (C)
SIP v1 (RFC2543), v2 (RFC3261) SIP
connection: Proxy mode & Peering Points
mode; DNS SRV (RFC3263); Redundant
server support NAT Traversal: STUN
mode DTMF: In-Band, RFC2833, SIP Info,
Auto HTTP/HTTPS Web Management IP
Assignment: Static/DHCP/PPPoE
Bridge/Router mode for PC port
TFTP/DHCP/PPPoE client DNS client,
NAT/DHCP server Layer 3 ToS, DSCP
Supported
Supported
Power adapter: AC 100~240V input and
DC 5V/1A output;
Power over Ethernet ,IEEE 802.3af,class 0
power consumption: 1.4-2.6W
Net weight: 0.90kg
Dimension: 186x202x92mm
CE, FCC, RoHS
128x48 LCD dot-matrix
2 SIP accounts, Keypad: 31 keys, Call
Hold / Resume including, 4 Soft-keys, 7
Function keys, 4Navigation keys + 1 OK
key,12 Standard Phone Digits keys, 2
Volume Control keys, Up / Down,
1Hands-free key, Phonebook (500 entries)
Call log (100 entries, in/out/missed), HD Voice
SIP2.0 over
UDP/TCP/TLS,RTP/RTCP/SRTP,STUN,
DHCP, PPPoE, 802.1x, L2TP (Basic
Unencrypted), OpenVPN, SNTP,
FTP/TFTP, HTTP/HTTPS, TR069,
Auto-Provisioning via
FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP
Anonymous Call (Hide Caller ID)
PNP/TR06
Supported
Supported
DC Power Input: 5V / 0.6A, Power
Consumption: Idle –~1.3W, Peak –
~4.3W
Dimension - Net wt : 0.90 Kg
260x255x62mm (L x W x H)
CE , FCC, RoHS
132x64 graphic LCD.
3 SIP accounts. Hot line, Support 5.8G
WiFi.34 keys including 2 programmable
keys, 15 Paperless Programmable
keys.Functions customizable keys Support
switching SIP server & Second server.
Phonebook (local up to 1000 entries) .Call
history: dialed / received / missed (100
-entries); One-key back (C)
SIP v1 (RFC2543), v2 (RFC3261) SIP
connection: Proxy mode & Peering Points
mode; DNS SRV (RFC3263); Redundant
server support NAT Traversal: STUN mode
DTMF: In-Band, RFC2833, SIP Info, Auto
HTTP/HTTPS Web Management IP
Assignment: Static/DHCP/PPPoE
Bridge/Router mode for PC port
TFTP/DHCP/PPPoE client DNS client,
NAT/DHCP server Layer 3 ToS, DSCP
Supported
Supported
Power adapter: AC 100~240V input and
DC 5V/1A output;
Power over Ethernet ,IEEE 802.3af,class 0
Power consumption: 1.4-2.6W
Net weight: 0.90 kg
Dimension: 186x202x92mm
CE, FCC, RoHS
Display
Key features
Protocols
Wall
Mounted
QoS
Power
Efficiency
Physical
Compliance
