This document discusses various topics related to integrating Java applications with CICS including: defining common areas in Java, data types, handling null values, refactoring CICS classes, COMP and COMP3 data types, logging applications with CICS data, and automated CICS testing.

1. Integração com CICS

2. Denifição da CommonArea no Java
Tipo de Dado
Dados Nulos
Refatoração da classe CICS
Dismistificando tipo COMP e COMP3
Log da aplicação com dados do CICS
AUTO-TesteCics

3. Denifição da CommonArea no Java
000 00000000 ^k
000000000
0000000000000000000000000000000000000000000000000000000000
0000000000 00000000000000000
0000000000000000000000000000000000
000011 05 GCCS1150-CODIGO-RETORNO PIC 9(03).
000012 05 GCCS1150-SINAL-SQLCODE PIC X(01).
000013 05 GCCS1150-SQLCODE PIC 9(04).
000014 05 GCCS1150-SQLERRML PIC 9(04).
000015 05 GCCS1150-SQLERRMC PIC X(70).
000016 05 GCCS1150-TABELA-ERR PIC X(18).
000017 05 GCCS1150-DESCRICAO-ERR PIC X(30).

4. Denifição da CommonArea no Java
@CicsGateway
public class SIAW0550_1 extends CTGProgramImpl {
private static final String PGM_NAME = "SIAW0550";
private static final String TRAN_NAME = "SW55";
private static final CommonAreaMetaData COMM_AREA = new CommonAreaMetaData(
new FieldType[] {
new StringFieldType("AREA", 350)
});

5. Denifição da CommonArea no Java
private static final CommonAreaMetaData COMM_AREA_IN = new
CommonAreaMetaData(
new FieldType[] {
new IntegerFieldType("B1040-SUC", 4),
new IntegerFieldType("B1040-RMO", 4),
new IntegerFieldType("B1040-CIA", 4),
new IntegerFieldType("B1040-APO", 8),
new IntegerFieldType("B1040-ITEM", 4),
new IntegerFieldType("B1040-ENDOSSO", 8),
new IntegerFieldType("B1040-NR-PRESTACAO", 3),
new DoubleFieldType("B1040-VL-PARC", 15, 2),
new DoubleFieldType("B1040-PERC-FRACION", 7, 4),
new DoubleFieldType("B1040-VL-ADIC-FRACION ", 15, 2),
new DoubleFieldType("B1040-VL-IOF", 15, 2),
new DateFieldType("B1040-DT-VENC", 8, "ddMMyyyy"),
new DateFieldType("B1040-DT-PGTO", 8, "ddMMyyyy"),
new IntegerFieldType("B1040-TIPO-COBR", 2),
new StringFieldType("FILLER-OUT", 245)
});

6. Denifição da CommonArea no Java
private static final CommonAreaMetaData COMM_AREA_OUT = new
CommonAreaMetaData(
new FieldType[] {
new StringFieldType("FILLER_IN", 105),
new DoubleFieldType("B1040-VL-PARC-CALC", 15, 2),
new DoubleFieldType("B1040-VL-IOF-CALC", 15, 2),
new DateFieldType("B1040-DT-CALC-PARC", 8, "ddMMyyyy"),
new IntegerFieldType("B1040-ERRO", 1),
new StringFieldType("B1040-MSG-ERRO", 50),
new StringFieldType("FILLER", 156)
});

7. Denifição da CommonArea no Java
private static final CommonAreaMetaData COMM_AREA = new
CommonAreaMetaData(
new FieldType[] {
new IntegerFieldType("B1040-SUC", 4),
new IntegerFieldType("B1040-RMO", 4),
new IntegerFieldType("B1040-CIA", 4),
new IntegerFieldType("B1040-APO", 8),
new IntegerFieldType("B1040-ITEM", 4),
new IntegerFieldType("B1040-ENDOSSO", 8),
new IntegerFieldType("B1040-NR-PRESTACAO", 3),
new DoubleFieldType("B1040-VL-PARC", 15, 2),
new DoubleFieldType("B1040-VL-IOF-CALC", 15, 2),
new DateFieldType("B1040-DT-CALC-PARC", 8, "ddMMyyyy"),
new IntegerFieldType("B1040-ERRO", 1),
new StringFieldType("B1040-MSG-ERRO", 50),
new StringFieldType("FILLER", 156)
});

8. Denifição da CommonArea no Java
 private static final CommonAreaMetaData COMMON_AREA = new
CommonAreaMetaData(
 HEADER,
 new FieldType[] {
 new StringFieldType("DADO1",30),
 new StringFieldType("DADO2", 30)
 }
 );
 public static final FieldType[] HEADER = new FieldType[] {
 new StringFieldType("HEADER",10),
 new IntegerFieldType("FUNCAO",2)
 };

9. Tipo de Dado
IntegerFieldType
LongFieldType
DoubleFieldType
DateFieldType
StringFieldType
IndexedFieldType
TIPOS BÁSICOS
PIC 9(9)
PIC 9(17)
PIC 9(13)V99
PIC X(10) / PIC 9(10)
PIC X(200)
OCCURS 20

10. Tipo de Dado
CompFieldType
Comp3FieldType
SignedDoubleFieldType
SignedLongFieldType
TIPOS AVANÇADOS
PIC S9(4) COMP
PIC S9(5) COMP-3

11. Dados Nulos
03 B1040-SUC PIC X(04).
03 B1040-SUC-R REDEFINES B1040-SUC.
05 B1040-SUC-N PIC 9(04).
03 B1040-RMO-IND-NULL PIC X(1).
03 B1040-RMO PIC 9(04).

12. Dismistificando tipo COMP e COMP3
TIPO COMP
COBOL: 05 ECPO-COMP PIC S9(4) COMP.
JAVA: new CompFieldType(ECPO_COMP, 2),
Setando Valor: is.setInteger(ECPO_COMP, 1234);
Obtendo Valor: rs.getInteger(SCPO_COMP);

13. Dismistificando tipo COMP e COMP3
TIPO COMP3
COBOL: 05 ECPO-COMP-3 PIC S9(5) COMP-3.
JAVA: new Comp3FieldType(ECPO_COMP_3, 4),
Setando Valor: is.setDouble(ECPO_COMP_3, 1234);
Obtendo Valor: rs.getDouble(SCPO_COMP_3);

14. Refatoração da classe CICS
COMPARANDO COM O DAO
EXEMPLO DA CLASSE CICS
EXEMPLO DA CLASSE FACADE / BO

15. Log da aplicação com dados do CICS
<appender name="CONSOLE"
class="ch.qos.logback.core.ConsoleAppender">
<encoder>
<pattern>%-40(%d{ISO8601} [%thread])
${applicationName} %-5level %-60logger - %msg%n</pattern>
</encoder>
</appender>

16. Log da aplicação com dados do CICS
<logger name="br.com.bradseg.bsad.framework" level="TRACE" />
<logger name="br" level="TRACE" />
<root level="TRACE">
<appender-ref ref="CONSOLE" />
<appender-ref ref="FILE" />
</root>

17. AUTO-TesteCics
http://198.162.60.76:9080/AUTO-TesteCics/testaCics.do
http://provider-it.ddns.info:9080/AUTO-
TesteCics/testaCics.do
