ting and good hole fills with the higher temperatures of the the benefits. In other words, the U.S. has become compliant
no-lead process.” only because of the EU’s directive.
While not completely whisker-free, matte tin finish has “We no longer carry non-compliant products or components,”
shown significant reduced whisker formation and has become says SYSTIMAX’s Barnick. “If we can be environmentally
the finish of choice among many vendors. friendly after spending the money to reformulate and get to a
Aside from tin-lead whiskering, cable and connectivity man- RoHS-compliant state while still maintaining excellent per-
ufacturers have also had to retest all products for performance formance characteristics, then that’s where we are, and we’re
and safety requirements per standards, such as Underwriters better for it. Why go back? In the long run, we have finite re-
Laboratories fire-retardancy requirements. Meeting the stan- sources; we only have so much water, air, and land. We can’t
dards requirements was not overly difficult for vendors, but continue to abuse it.”
finding an orange colorant without cadmium was not as easy. Most agree that RoHS legislation is imminent in the U.S.
“Any time you change something in the insulation of a con- “As more states enact their own limited form of RoHS, I be-
ductor, it changes the electrical properties,” says Berk-Tek’s lieve that the impact on state-to-state commerce will cause
Harpel. “To find a new orange colorant that allowed us to con- the issue to be forced up to the federal level,” says ADC’s
tinue meeting electrical performance on the orange pair was Sauder. “In my opinion, the EPA [Environmental Protection
honestly the most difficult challenge we faced. The other col- Agency] would be smart to get ahead of the curve and adopt
orants were easy to replace.” According to Harpel, there is a something similar to the European and China RoHS for the
slight hue change from the original orange color, but it is so entire nation.”
subtle that most don’t notice it. Panduit’s Westapher agrees: “What the world doesn’t need
is a different RoHS. It’s common logic that we need a glob-
Affecting the homeland al standard, otherwise manufacturers would have to go
Because most cabling vendors have switched their product through everything we’ve been through all over again. Our
lines to be RoHS-compliant without maintaining non-com- hope, expectation, and communication are that one standard is
pliant versions, other countries, including the U.S., are reaping imperative.”
