Building Data Products at LinkedIn with DataFu

Building Data Products at LinkedIn with DataFu
©2013 LinkedIn Corporation. All Rights Reserved.

Matthew Hayes
Staff Software Engineer
www.linkedin.com/in/matthewterencehayes/

Tools of the trade

What tools do we use?
Languages:
 Java (MapReduce)
 Pig
 R
 Hive
 Crunch
Systems:
 Voldemort
 Kafka
 Azkaban

Pig: Usually the language of choice
 High-level data flow language that produces MapReduce jobs
 Used extensively at LinkedIn for building data products.
 Why?
– Concise (compared to Java)
– Expressive
– Mature
– Easy to use and understand
– More aproachable than Java for some
– Easy to learn if you know SQL
– Easy to learn even if you don't know SQL
– Extensible through UDFs
– Reports task statistics

Pig: Extensibility
 Several types of UDFs you can write:
– Eval
– Algebraic
– Accumulator
 We do this a lot.
 Over time we accumulated a lot of useful UDFs
 Decided to open source them as DataFu library

DataFu
Collection of UDFs for Pig

DataFu: History
 Several teams were developing UDFs
 But:
– Not centralized in one library
– Not shared
– No automated tests
 Solution:
– Packaged UDFs in DataFu library
– Automated unit tests, mostly through PigUnit
 Started out as internal project.
 Open sourced September, 2011.

DataFu Examples
Collection of UDFs for Pig

DataFu: Assert UDF
 About as simple as a UDF gets. Blows up when it encounters zero.
 A convenient way to validate assumptions about data.
 What if member IDs can't and shouldn't be zero? Assert on this
condition:
data = filter data by ASSERT((memberId >= 0 ? 1 : 0), 'member ID was negative, doh!');
public Boolean exec(Tuple tuple) throws IOException {
if ((Integer) tuple.get(0) == 0) {
if (tuple.size() > 1)
throw new IOException("Assertion violated: " + tuple.get(1).toString());
else
throw new IOException("Assertion violated.");
}
else return true;
}
 Implementation:

DataFu: Coalesce UDF
 Using ternary operators is fairly common in Pig.
 Replace null values with zero:
data = FOREACH data GENERATE (val IS NOT NULL ? val : 0) as result;
data = FOREACH data GENERATE (val1 IS NOT NULL ? val1 :
(val2 IS NOT NULL ? val2 :
(val3 IS NOT NULL ? val3 :
NULL))) as result;
 Return first non-null value among several fields:
 Unfortunately, out of the box there's no better way to do this in Pig.

DataFu: Coalesce UDF
 Simplify the code using the Coalesce UDF from DataFu
– Behaves the same as COALESCE in SQL
 Replace any null value with 0:
data = FOREACH data GENERATE Coalesce(val,0) as result;
 Return first non-null value:
data = FOREACH data GENERATE Coalesce(val1,val2,val3) as result;
public Object exec(Tuple input) throws IOException {
if (input == null || input.size() == 0) return null;
for (Object o : input) {
if (o != null) return o;
}
return null;
}
 Implementation:

DataFu: In UDF
 Suppose we want to filter some data based on a field equalling one
of many values.
 Can chain together conditional checks using OR:
data = LOAD 'input' using PigStorage(',') AS (what:chararray, adj:chararray);
dump data;
-- (roses,red)
-- (violets,blue)
-- (sugar,sweet)
data = FILTER data BY adj == 'red' OR adj == 'blue';
dump data;
-- (roses,red)
-- (violets,blue)
 As the number of items grows this really becomes a pain.

DataFu: In UDF
 Much simpler using the In UDF:
data = FILTER data BY In(adj,'red','blue');
public Boolean exec(Tuple input) throws IOException
{
Object o = input.get(0);
Boolean match = false;
if (o != null) {
for (int i=1; i<input.size() && !match; i++) {
match = match || o.equals(input.get(i));
}
}
return match;
}
 Implementation:

DataFu: CountEach UDF
 Suppose we have a system that recommends items to users.
 We've tracked what items have been recommended:
items = FOREACH items GENERATE memberId, itemId;
• Let's count how many times each item has been shown to a user.
• Desired output schema:
{memberId: int,items: {(itemId: long,cnt: long)}}

 Typically, we would first count (member,item) pairs:
items = GROUP items BY (memberId,itemId);
items = FOREACH items GENERATE
group.memberId as memberId,
group.itemId as itemId,
COUNT(items) as cnt;
 Then we would group again on member:
items = GROUP items BY memberId;
items = FOREACH items generate
group as memberId,
items.(itemId,cnt) as items;
• But, this requires two MapReduce jobs!

 Using the CountEach UDF, we can accomplish the same thing with
one MR job and much less code:
items = FOREACH (GROUP items BY memberId) generate
group as memerId,
CountEach(items.(itemId)) as items;
• Not only is it more concise, but it has better performance:
– Wall clock time: 50% reduction
– Total task time: 33% reduction

DataFu: Session Statistics
 Session: A period of sustained user activity
 Suppose we have a stream of user clicks:
pv = LOAD 'pageviews.csv' USING PigStorage(',')
AS (memberId:int, time:long, url:chararray);
 What session length statistics are we interested in?
– Median
– Variance
– Percentiles (90th, 95th)
 How will we define a session?
– In this example: No gaps in activity greater than 10 minutes

 Define our UDFs:
DEFINE Sessionize datafu.pig.sessions.Sessionize('10m');
DEFINE Median datafu.pig.stats.StreamingMedian();
DEFINE Quantile datafu.pig.stats.StreamingQuantile('0.90','0.95');
DEFINE VAR datafu.pig.stats.VAR();

 Sessionize the data, appending a session ID to each tuple
pv = FOREACH pv GENERATE time, memberId;
pv_sessionized = FOREACH (GROUP pv BY memberId) {
ordered = ORDER pv BY time;
GENERATE FLATTEN(Sessionize(ordered))
AS (time, memberId, sessionId);
};
pv_sessionized = FOREACH pv_sessionized GENERATE
sessionId, memberId, time;

 Compute session length in minutes:
session_times =
FOREACH (GROUP pv_sessionized BY (sessionId,memberId))
GENERATE group.sessionId as sessionId,
group.memberId as memberId,
(MAX(pv_sessionized.time) -
MIN(pv_sessionized.time))
/ 1000.0 / 60.0 as session_length;
 Computes session length statistics:
session_stats = FOREACH (GROUP session_times ALL) {
GENERATE
AVG(ordered.session_length) as avg_session,
SQRT(VAR(ordered.session_length)) as std_dev_session,
Median(ordered.session_length) as median_session,
Quantile(ordered.session_length) as quantiles_session;
};
DUMP session_stats

 Who are the most engaged users?
 Report users who had sessions in the upper 95th percentile:
long_sessions =
filter session_times by
session_length >
session_stats.quantiles_session.quantile_0_95;
very_engaged_users =
DISTINCT (FOREACH long_sessions GENERATE memberId);
DUMP very_engaged_users

DataFu: Left join multiple relations
 Suppose we have three data sets:
input1 = LOAD 'input1' using PigStorage(',') AS (key:INT,val:INT);
joined = JOIN input1 BY key LEFT,
input2 BY key,
input3 BY key;
 We want to left join input1 with input2 and input3.
 Unfortunately, in Pig you can only perform outer joins on two
relations.
 This doesn't work:

 Instead you have to left join twice:
data1 = JOIN input1 BY key LEFT, input2 BY key;
data2 = JOIN data1 BY input1::key LEFT, input3 BY key;
 This is inefficient, as it requires two MapReduce jobs!
 Left joins are very common
 Take a recommendation system for example:
– Typically you build a candidate set, then join in features.
– As number of features increases, so can number of joins.

 But, there's always COGROUP:
data1 = COGROUP input1 BY key, input2 BY key, input3 BY key;
data2 = FOREACH data1 GENERATE
FLATTEN(input1), -- left join on this
FLATTEN((IsEmpty(input2) ? TOBAG(TOTUPLE((int)null,(int)null)) : input2))
as (input2::key,input2::val),
FLATTEN((IsEmpty(input3) ? TOBAG(TOTUPLE((int)null,(int)null)) : input3))
as (input3::key,input3::val);
 COGROUP is the same as GROUP
– Convention: Use COGROUP instead of GROUP for readability.
 This is ugly and hard to follow, but it does work.
 The code wouldn't be so bad if it weren't for the nasty ternary
expression.
 Perfect opportunity for writing a UDF.

 We wrote EmptyBagToNullFields to replace this ternary logic.
 Much cleaner:
data1 = COGROUP input1 BY key, input2 BY key, input3 BY key;
data2 = FOREACH data1 GENERATE
FLATTEN(input1), -- left join on this
FLATTEN(EmptyBagToNullFields(input2)),
FLATTEN(EmptyBagToNullFields(input3));
