This document provides specifications for an ATDR-404 security camera system. It has 4 channel video inputs and 1 channel video output. It supports H.264 video compression and embedded Linux OS. It can record in D1, HD1, and CIF resolutions from the 4 video inputs in real time to 2 SATA hard drives with up to 2TB storage each. It also supports features such as schedule and motion detection recording, playback, backup to USB drives, remote access via browser or mobile apps, PTZ camera control, and alarm inputs and outputs.

1. Specifications Model:- ATDR-404
System Compression Format H-264 Embedded Linux OS
Input 4CH BNC Inputs
Video
Output 1 BNC Output, 1VGA
Audio Input 4CH
Audio
Audio Output 1CH
Resolution NTSC :D1 (704x576), HD1 (704x288), CIS (352x288) PAL :
Recording Frames D1 (704x480), HD1 (704x240), CIF (352x240)
Recording Mode Real time D1 recording and playback
Schedule, Manual, Motion, Sensor
Playback Channel 1/4CH
Playback
Search Mode Time, Event list
USB 2.0 USB Flash disk, USB hard disk, USB CD/DVD-RW
Backup USB Disk
burner
Browser IE Browser, Firefox, Chrome
Remote Application
CMS Free CMS Firmware Support
User Access 10 user online with professional authority management
Alarm Input 4CH
Alarm
Alarm Output 1 CH
2 SATA HDDs, up to 2TB for each
Storage HDD
1 RS485 port, support PELCO-p, PELCO-D Portocol
PTZ
PTZ pan, tilt, zoom, preset, cruise, trace
PTZ Control
Ethernet 10/100 Mbps Ethernet (RJ-45)
Protocol TCP/IP, DHCP, DDNS, NTP, SMTP
Mobile phone Support window OS, system OS, iphone, Blackberry and
Network
Android operation
3G 3g network card support
Mouse included
Power Supply DC 12V/4A
Others Operating Temperature -10 c to 55 c
Humidity -10 c to 90% Humidity
Dimension L x W x H (DVR) 324 *222*51 mm
