Architectures styles and deployment on the hadoop
- 1. Architectural Patterns and Best Practices : #BigData #Hadoop Srividhya Balasubramaniam @ Data and Information Management Consultant Srividhya.logic@gmail.com
- 3. Agenda • Why are enterprises re-thinking on their data strategy • Modernizing Enterprise Data Warehouses • Architectural Patterns and Design Consideration • Best Practices Analytics Architecture Application Architecture Platform Architecture
- 4. “Because we have been doing stuff this way for ages!…… ” is not the norm Re-Think!
- 5. Drivers of Change What Has not changed DATA QUALITY AND GOVERNANCE INFORMATION SECURITY METADATA MANAGEMENT DATA SOURCES DATA STORE DATA ACCESS ORCHESTRATION AND SCHEDULING
- 6. Challenges? Velocity , Variety and Volume
- 7. What is the Right Tool? How should I use the tool Reference Architecture? What Language and tool should I learn Why?Why? Why? Why? What's like data modelling in Hadoop Buy or build?
- 8. Core Design Principles What Business Problem is being Solved? Define Tool Selection Criteria Decouple processing store and systems Hybrid Architecture Leverage Batch and Stream Scalable, Reliable, Fit for Purpose, Secure Available, Very low Admin Cost Supportable and Operations Monitoring Best Design is cheap
- 9. Typical Data Pipeline Data Source Ingest •RDBMS •SEARCH •FILES/API •MESSAGING •IOT/STREAM Store Raw •DATABASE •SEARCH DOCUMENTS •DIST FILE STORAGE •QUEUE •STREAM STORE Process for Analysis •BATCH •INTERACTIVE •STREAMING •MESSAGING •MACHINE LEARNING Store •Key Value •Graph •Document •Queue •MPP Insights •Analytical Models •Visualization •Self Service BIStorage of Messaging and Streaming Criteria 1. How Distributed Services are managed 2. Guaranteed Ordering 3. Data Delivery 4. Data Retention Period 5. Availability 6. Scalability 7. Throughput 8. Parallel Clients 9. Object Size 10.Stream Map Reduce 11.Cost Eg: Apache Kafka • Guranteed Ordering, Parallel Client and Stream MR • Configurable Data Retention, Availability, Object Size • Low cost but more admin
- 10. Typical Data Pipeline Data Source Ingest •RDBMS •SEARCH •FILES/API •MESSAGING •IOT/STREAM Store Raw •DATABASE •SEARCH DOCUMENTS •DIST FILE STORAGE •QUEUE •STREAM STORE Process for Analysis •BATCH •INTERACTIVE •STREAMING •MESSAGING •MACHINE LEARNING Store •Key Value •Graph •Document •Queue •MPP Insights •Analytical Models •Visualization •Self Service BI Databases What DB Export to choose 1. File Size 2. Network Bandwidth 3. Partitioning 4. Bulk Loading 5. CDC and Delta Data Transfers 6. Native connectors and specific connectors for Distribution Adaptors and Golden Gate etc.
- 11. Typical Data Pipeline Data Source Ingest •RDBMS •SEARCH •FILES/API •MESSAGING •IOT/STREAM Store Raw •DATABASE •SEARCH DOCUMENTS •DIST FILE STORAGE •QUEUE •STREAM STORE Process for Analysis •BATCH •INTERACTIVE •STREAMING •MESSAGING •MACHINE LEARNING Store •Key Value •Graph •Document •Queue •MPP Insights •Analytical Models •Visualization •Self Service BI Data Storage – Distributed Files Criteria 1. Average Latency 2. Typical Data Stored 3. Typical Item Size 4. Request Rate 5. Storage Cost PerGB / timeframe 6. Durability 7. Availability 8. Native support for toolsets 9. Active community and open source Enterprise Distributions Selection Clouders, Hortonworks, MapR
- 12. Typical Data Pipeline Data Source Ingest •RDBMS •SEARCH •FILES/API •MESSAGING •IOT/STREAM Store Raw •DATABASE •SEARCH DOCUMENTS •DIST FILE STORAGE •QUEUE •STREAM STORE Process for Analysis •BATCH •INTERACTIVE •STREAMING •MESSAGING •MACHINE LEARNING Store •Key Value •Graph •Document •Queue •MPP Insights •Analytical Models •Visualization •Self Service BI Data Storage Selection Criteria Data Structure : Fixed , Key Value, JSON Access Patterns : Hierarchical, Structured, Search, Publish etc Data Temperature : Hot, Warm Cold TCO : Low Elastic Cache
- 13. Typical Data Pipeline Data Source Ingest •RDBMS •SEARCH •FILES/API •MESSAGING •IOT/STREAM Store Raw •DATABASE •SEARCH DOCUMENTS •DIST FILE STORAGE •QUEUE •STREAM STORE Process for Analysis •BATCH •INTERACTIVE •STREAMING •MESSAGING •MACHINE LEARNING Store •Key Value •Graph •Document •Queue •MPP Insights •Analytical Models •Visualization •Self Service BI Data Storage Selection Criteria Cache NoSQL SQL Search 1. Average Latency (ms, sec, min, hours) 2. Typical Volume Stored (GB, TB, PB) 3. Typical Item Size (B, KB, TB, PB) 4. Query Request Rate (High to Very Low) 5. Storage and Maintenance Cost (High – Low) 6. Durability (Low – Very High) 7. Availability (High – Very High) Data Structure : Fixed , Key Value, JSON Access Patterns : Hierarchical, Structured, Search, Publish etc Data Temperature : Hot, Warm Cold TCO : Low
- 14. Typical Data Pipeline Data Source Ingest •RDBMS •SEARCH •FILES/API •MESSAGING •IOT/STREAM Store Raw •DATABASE •SEARCH DOCUMENTS •DIST FILE STORAGE •QUEUE •STREAM STORE Process for Analysis •BATCH •INTERACTIVE •STREAMING •MESSAGING •MACHINE LEARNING Store •Key Value •Graph •Document •Queue •MPP Insights •Analytical Models •Visualization •Self Service BI BATCH INTERACTIVE STREAMING MESSAGING Machine Learning Spark ML EMR etc Criteria 1. Programming Language Support 2. Availability 3. Speed 4. Scale 5. Latency Query 6. Data Volume 7. Storage Support 8. SQL? Temperature of Data
- 15. Typical Data Pipeline Data Source Ingest •RDBMS •SEARCH •FILES/API •MESSAGING •IOT/STREAM Store Raw •DATABASE •SEARCH DOCUMENTS •DIST FILE STORAGE •QUEUE •STREAM STORE Process for Analysis •BATCH •INTERACTIVE •STREAMING •MESSAGING •MACHINE LEARNING Store •Key Value •Graph •Document •Queue •MPP Insights •Analytical Models •Visualization •Self Service BI Buy Vs Build ETL Decision?
- 16. Typical Data Pipeline Data Source Ingest •RDBMS •SEARCH •FILES/API •MESSAGING •IOT/STREAM Store Raw •DATABASE •SEARCH DOCUMENTS •DIST FILE STORAGE •QUEUE •STREAM STORE Process for Analysis •BATCH •INTERACTIVE •STREAMING •MESSAGING •MACHINE LEARNING Store •Key Value •Graph •Document •Queue •MPP Insights •Analytical Models •Visualization •Self Service BI Create Analytical Application Make Insights Available Via API Analysis and Visualization Zepplin, HUE etc Publish to Queue
- 17. Data Modelling in Hadoop & Architectural Patterns
- 18. Not only ER and Dimension Models (NoERDM) Data Storage Format Text Sequence Avro Parquet RC/ORC Know strength and weakness of each format in terms of Supporting Distributions Processing requirements – Write, partial read, full read Schema Evolution Extract Requirements Storage Requirements – How big are your files How important is file splitability Does block compression matter Does the file format support indexing? How easy it is to parse Does it support column Stats? Failure behavior for various file formats.
- 19. Not only ER and Dimension Models (NoERDM) Compression Codecs ZLIB LZO LZF Snappy Gzip Bzip Considerations How much the size reduces How fast it can compress decompress How can I split my compressed files? File splitbility to make use of parallelism Compression types Uncompressed Record compressed. Block Compressed. ` We trade I/O Loads for CPU Loads
- 20. Other Practices 1. Structure and Organize your repository a. Standard directory structure b. Access quota controls c. Stage area conventions 2. Location of HDFS files a. Directory structure should simplify the assignment of permissions to be grated. b. Eg /user, /etl , /tmp, /data, /app, /metadata, 3. Partitioning, Bucketing and denormalization.
- 21. Data Lake / Reservoir / Refinery Exploratory Data Analysis Application Level Analytics Batch and Stream Analytics – Lambda Architecture Enterprise Data Pipeline
Editor's Notes
- Broken Promise – No single version of truth At least we can persist raw data
- Obstacles with Big Data
- Obstacles with Big Data
- Obstacles with Big Data
- Obstacles with Big Data
- Obstacles with Big Data
- Obstacles with Big Data
- Obstacles with Big Data
- Obstacles with Big Data
- Obstacles with Big Data
- 1.1.1 Data Storage formats Considerations File Format Know strength and weaknesses of each format in terms of Supporting Distributions Processing requirements – Write, partial read, full read Schema Evolution Extract Requirements Storage Requirements – How big are your files How important is file splitability Does block compression matter Does the file format support indexing? How easy it is to parse Does it support column Stats? Failure behavior for various file formats.
- Compression consideration Any codec can be made splittable using a container format. Enable compression for mapreduce intermediate steps to enhance performance. Pay attention to how data is ordered. Compression happens in chunks so the entropy of these chunks are important. Ordering and storing data will enable better compression. Use compact fixle format with support for splitabbility eg: seq and avro.
