Drupal world domination
   Translating interface and content in Drupal



       Gábor Hojtsy, Acquia Inc.
       December...
About the presenter
 Web developer since 1999,
 building open communities and
 contributing to open source
 projects ever ...
Will demo with Acquia Drupal
 Curated distribution of Drupal 6
 Connects to the Acquia Network
 Not a fork in any way of t...
About you
 Built non-Drupal
 multilanguage site?
 Built Drupal based site?
 Built Drupal based
 multilanguage site?

 “Dec...
Drupal 6 language
   subsystem
Two worlds, one family
 Text from inside module and theme code is
 translated for you
 –These can be pre-translated by int...
And there is a lot more to do
 Relating translations (complete copies, subsites)
 Different permissions, lifecycles
 Settin...
Drupal 6 language subsystem
The installer
Install in your language
 After pro le is selected, Drupal
 looks for available translations
 Offers translations to use
 L...
Start screen of the default pro le
Some languages extracted to Drupal




                                In the le system.
On the installer interface.
Translated (almost)!
Translated (almost)!
Translated (almost)!
Translated (almost)!
Translated (almost)!
Imports translations automatically
The runtime knows
 about languages
Properties of languages known
 The default language for the website
 English and native language names
 Writing direction ...
Adding new languages
 Extract interface translations to Drupal root
 Add language from prede ned list if possible
Automated translation import
 Modules and themes also have ./translations
 subdirectories
 When you add a language, all en...
The language to use to display the page
 Can be set to be always the site default
 Or pick the rst identi ed from this lis...
Example language setups
 Using path pre xes
 –German language set up with /deutsch path pre x
 –Hungarian language set up ...
Server setup for multiple domains
 Make sure that all domains point to the same
 virtual host in your webserver con gurati...
Language is known, now what?
 Drupal selects the language, but it is up to the rest
 of the modules used to act accordingl...
Right-to-left (sub)theme support




           Remember admin/settings/language to revert.
Right-to-left (sub)theme support
 Drupal itself includes RTL support for all its
 functionality
 All CSS le additions are ...
Language dependent path aliases
Language dependent e-mails
 Users have their preferred language set up
 Those registering on a translated page get that as...
Language comes to
     content
Associate language to content
 As soon as locale module is enabled, content types
 can be language enabled
 Shows a langua...
Associate language to content
                        Setting up the
                        Page content type




       ...
Consequences
 Post will have URL with language speci c part
 included (domain, path pre x), if set up
 The associated lang...
Translate content
The content translation module
 Once the Content translation (core) module is
 enabled, a new language option is available
Translation functionality is exposed
Title and body pre lled for translation
                               Add Hungarian
                               transl...
Each translation is a different node
 Great, so that you can have different work ows for
 these nodes (eg. publish only if a...
Basic work ow support in core
 The source node of the translation set can be set to
 be changed signi cantly, marking tran...
Basic work ow support in core




            On a translation. Uncheck if not true anymore.
So far so long for
Drupal 6 core itself
Review of the runtime architecture
Drupal 6 cannot translate
 Site settings
 Taxonomy (vocabularies, terms)
 User de ned menus (menus, items)
 Aggregator cat...
So look for contributed
  modules to add on
Interface translation
       tweaks
String overrides
 http://drupal.org/project/stringoverrides
 Replace text available for interface translation
 Less resour...
String overrides
Localization client
 http://drupal.org/project/l10n_client
 Drupal 6 allows collecting strings used on the page
 Tool buil...
Localization client
Localization server
 http://drupal.org/project/l10n_server
 Making interface translation for language groups a
 lot easier...
Web service based
content translation
Google translate
 http://drupal.org/project/gtrans
 Google operates an online translation service
 This module just passes...
Translatable comments
 http://drupal.org/project/translatablecomments
 Uses Google AJAX Translation API (legal)
 Completel...
Machine translation is hard (and funny)
Machine translation is hard (and funny)
Extended content
translation work ow
       support
Support computer aided humans
 Computer Aided Translation (CAT) tools take HTML,
 Word, etc. documents and allow translati...
XLIFF Tools module example
 http://drupal.org/project/xliff
 XML Localisation Interchange File Format is a
 format maintain...
AWTW module
http://drupal.org/project/awtw
AWTW is Automated Web Translation Work ow
Works very similar to XLIFF Tools, bu...
Translation overview
 http://drupal.org/project/translation_overview
 Works with the core translation system
 Modi es exis...
Translation overview screen
Team work ow with permissions
 http://drupal.org/project/work ow
 Actions and work ow modules allow you to set up
 work ow...
What about content
      views?
Views
 http://drupal.org/project/views
 Views supports languages, translation sets and
 translation status values
 Easily ...
Views
Views
Translate more!
Internationalization (i18n) module
 Supports multilingual variables
 Language based listing with extended options for
 cor...
Settings (variables) translation setup
                                         In your site’s
                           ...
Site settings (variables) translation
                                        On your
                                    ...
And submodules do a lot more
i18nstrings module
 Base (API) module for most custom translation tools
 Implements strings translation API via the Drupal...
i18nblocks.module example
i18nblocks.module example
Share/sync data
between translations
i18nsync, i18npoll modules
 Helps you sync values between content translations
 Taxonomy terms, CCK elds are not shared am...
Other contributed modules
 The direction is to be able to attach behaviors to
 both individual nodes and translation sets
...
Look at your own
  requirements
Look at your own requirements
 People meet lots of different requirements
 You need to build your own solution according to...
Questions?
Thanks
         Gábor Hojtsy
     gabor@acquia.com
Acquia Inc., http://acquia.com/
