    JEST: REST on OpenJPA JEST: REST on OpenJPA Presentation Transcript

    • JEST: REST on OpenJPA Pinaki Poddar, PhD Java Persistence Evangelist [email_address]
    • Agenda Introduction to JEST Integration of REST and OpenJPA Resource Representation URI Syntax Transaction JEST in Action Conclusion Q&A
    • JEST: REST on OpenJPA JEST is RESTful interaction with OpenJPA Runtime http JDBC XML/JSON Java Object Graph
    • JEST: REST on OpenJPA Deploy-and-Play No annotation on persistent classes No browser plug-in No client knowledge of persistent schema KISS: Keep It Short and Simple
    • JEST: Primary Use Cases Access persistent object graph by language-neutral, domain-agnostic clients or Web Services Visualize OpenJPA runtime internals via Web Browser-based Admin console Transact with any OpenJPA application from language-neutral clients without violating REST principles
    • REST: RE presentational S tate T ransfer C0 C0 C1’ C1’ S1 S2 S1 renders C1 modifies C2 renders Response 1 Request 2 Request 1 Response 2 @ rest State Transition 1 2 3 4 5 6
    • REST Principles Identifiable Resource ( URI ) based, not API-based Document-oriented Resource Representation XML, JSON, … Stateless Server Standard Communication Protocol HTTP
    • Java Persistence API Persistence framework for Java Objects mapped to Relational database EntityManagerFactory EntityManager Persistence Unit Persistence Context Second-Tier Caches (optional) Relational Database User Application Data Cache META-INF/persistence.xml Java Object Graph
    • JPA is Model-View-Controller for Persistence View Control Model /** * A persistent entity **/ @Entity public class Actor { @Id private String name ; } /** * Find Actor by name **/ public Actor findByName( String name ) { EntityManager em = …; return em.find( Actor . class , name); } POJO sees uses updates modifies Java Persistence API Relational Database
    • JPA: access-detach-merge programming model C0 C0 C1’ C1’ em1 em2 renders C1 modifies C2 renders State Transition SELECT … detach find merge commit UPDATE/INSERT/DELETE … 1 2 3 5 6 4
    • REST and JPA: brothers separated at birth? Stateless Server Detached Transaction Identifiable Resource Persistent Identity Coherent Representation Persistent Closure Self-descriptive JPA 2.0 Metamodel REST JPA
    • JEST Resource Perisistent Object Graph Customizable Coherent
    • Customizable, Persistent Closure A persistence context as a graph managed entity as vertex persistent relation as edge Persistent Closure of an entity x is defined as set of entities C(x)={e} such that e is reachable from x in graph-theoretic sense. Every entity is reachable to itself, by definition . Customization is ability to define what is reachable at runtime. x a c1 b c2 d C(x) = {x, a, b, c1, c2, d} C(x) = {x, a, b, d} could be customized to and its complete closure C(x) = {x, b} or An object graph…
    • Identifiable Resource: URI for persistent object? Actor p1 = em1.find ( Actor . class , “ John ”); Actor p2 = em2.find ( Actor . class , “ John ”); name :” John ” hash : 56789 p1 name :” John ” hash : 56789 p2 p1.equals(p2) p1.hashCode() == p2.hashCode() p1 != p2 public class Actor { @Id String name ; } Persistent Identity carries the notion that both p1 and p2 refer to the same database record. EntityManager EntityManager … Robert … John ACTOR
    • Customizable, Persistent Closure: State of the art JEST response contains customizable, persistent closure JPA provides preliminary semantics on customized closure, statically OpenJPA FetchPlan already provides rich syntax and semantics to customize closure, dynamically . Future JPA specification will enhance support on this area. This feature had been the most sought after user requirement during JavaOne 2010.
    • OpenJPA Fetch Plan @Entity @FetchGroups ({ @FetchGroup ( name =" OnlyName ", attributes ={ @FetchAttribute ( name =" firstName "), @FetchAttribute ( name =" lastName ") }) }) public class Actor { @Id private String id ; private String firstName ; private String lastName ; private Gender gender ; private Date dob ; @OneToOne private Actor partner ; @OneToMany private Set<Movie> movies ; // getters and setters }
    • JEST Representation Theme Meta-meta-data driven as opposed to Domain-driven Content Customizable closure of persistent object graph Reference Resolution Coherent, not Chatty Format XML and JSON Thrift, Protobuf, Avro … (not right now, but tomorrow)
    • JPA Metamodel: Persistent Type System Class Type<X> ManagedType<X> BasicType<X> IdentifiableType<X> EmbeddableType<X> EntityType<X> MappedSuperclassType<X> package javax.persistence.metamodel package java.lang <X>: Type<X> represents Java class X
    • JPA Metamodel : Persistent Type System Field Attribute<X,Y> SingularAttribute<X,Y> PluralAttribute<X,C,E> ListAttribute<X,E> CollectionAttribute<X,E> SetAttribute<X> MapAttribute<X,K,V> package javax.persistence.metamodel package java.lang.reflect <X>: Attribute<X,Y> declared in Java class X <Y>: Attribute<X,Y> is of type Y <C>: PluralAttribute<X,C,E> is of Java collection type C <E>: PluralAttribute<X,C,E> contains elements of type E
    • JPA Metamodel: Persistent Scope java.lang.Class java.lang.reflect.Field Metamodel ManagedType<X> Attribute<X,Y> java.lang.ClassLoader A classloader defines a scope for a set of Java classes A metamodel defines a scope for a set of managed persistent types package javax.persistence.metamodel
    • Meta-Meta-Data Driven Representation < Actor > < id > 1234 </ id > < firstName > John </ firstName > < lastName > Doe </ lastName > </ Actor > Domain Driven Representation Domain-variant Schema < instance id = “Actor-1234” type =“Actor” > < id name = “ id ” type = “long” > 1234 </ id > < basic name = “firstName” type = “String” > John </ basic > < basic name = “lastName” type = “String” > Doe </ basic > </ instance > Model Driven Representation Domain-invariant Schema JPA 2.0 MetaModel based XML Schema compliant jest-instances.xsd Common Domain-based schema some-domain.xsd
    • JSON-based Representation in JEST JSON does not support cycles in graphs JEST supports cyclic object graph [ { "$id" : Actor-m2 , "id": "m2", "dob": "Tue May 14 1940", "firstName": "Robert", "lastName": "De Niro", "gender": "Male", "partner": { "$id" : Actor-f3 , "id": "f3", "dob": “Wed May 15 1960", "firstName": "Jodie", "lastName": "Foster", "gender": "Female“, “ partner”: { “ $ref” : Actor-m2 } } } ] dummy $id field dummy $ref field resolved circular reference JSON by JEST
    • JEST URI Syntax identifies JPA resources. maps to JPA operation decorates JPA operation JEST resolves argument strings to strong types, e.g. “ type=Actor ” to Actor .class . scheme authority path query context action qualifiers arguments OpenJPAEntityManager em = getPersistenceContext(); em.addFetchPlan(“ basic ”); Actor a = em.find( Actor . class , “m1”); find plan=basic type=Actor ? jest / / & id=m1 http 8080 openjpa.com / : ://
    • JEST URI Examples find an Actor with primary key m1 using fetch plan ‘basic’ http :// openjpa.com:8080 / jest / find / plan = basic ? type = Actor & m1 Query for a single Actor by name John http :// openjpa.com:8080 / jest / query / single ? q = select p from Actor p where p.name=:n & n = John Get the metamodel http :// openjpa.com:8080 / jest / domain
    • JEST translates HTTP verbs to JPA operations GET HTTP POST PUT DELETE find() getMetamodel() createQuery().getResultList() getProperties() /find / query / domain / properties merge() persist() remove() JEST Action JPA Operation non-transactional transactional
    • JEST Deployment < web-app > < servlet > < servlet-name > demo </ servlet-name > < servlet-class > demo.SimpleApp </ servlet-class > </ servlet > < servlet-mapping > < servlet-name > demo </ servlet-name > < url-pattern > /* </ url-pattern > </ servlet-mapping > <!-- Deployment descriptor for JESTServlet. --> < servlet > < servlet-name > jest </ servlet-name > < servlet-class > org.apache.openjpa.persistence.jest.JESTServlet </ servlet-class > < init-param > < param-name > persistence.unit </ param-name > < param-value > SimplePU </ param-value > </ init-param > </ servlet > < servlet-mapping > < servlet-name > jest </ servlet-name > < url-pattern > /jest/* </ url-pattern > </ servlet-mapping > </ web-app > Deployed as HTTP Servlet within the same module scope Identifies the module by persistence unit name
    • Deployment Modes for JEST Servlet JESTServlet emf Module X emf JESTServlet instantiates discovers instantiates or injected primary mode auxiliary mode default
    • JEST Client: An afterthought JEST works from navigation bar of a web browser A JEST client is developed as an afterthought for feature demonstration uses dojo JavaScript library Why dojo? everybody likes cool widgets validates JEST representation for XML/JSON with dojo parsers
    • Why JEST? Managed, persistent object graphs can not be effectively represented as REST resources without JPA knowledge JPA Metamodel is the right basis for self-describing REST representation Detached transaction support of JPA is the right model for stateless REST style server Internal states of OpenJPA runtime are useful information for administration console
    • JEST: JPA Detached Transaction C1 C1 C1’ C1’ S1 S2 S1 renders C1 modifies C2 renders A1 A1’ R1 Response 2 @ rest State Transition find() detach() represent() parse() merge() commit()
    • REST is successful in real world Success has many friends… “ Amazon has both SOAP and REST interfaces to their web services, and 85% of their usage is of the REST interface. ” Jeff Barr, Web Services Evangelist @ Amazon Reference: REST vs SOAP at Amazon
    • Does JEST pass the RESTness est? YES Q5 . Can server transfer logic to clients? NO Q4 . Can client determine the exact server endpoint? YES Q3 . Does response describe their cacheability for the client? NO Q2 . Does server store client context between requests? YES Q1 . Are clients separated from servers by a uniform interface?
    • Does JEST pass Uniform Interface Test? YES Q9 . Are related resources accessible via received representation? YES Q8 . Does representation carry enough information to be processed by the client? YES Q7 . Can client manipulate received resource representation? YES Q6 . Does request identify a resource?
    • Why JEST? JEST explores naturalness between REST and JPA for language-neutral, schema-agnostic clients to access and transact with OpenJPA based applications JEST solves representational issues for managed, persistent object graph using Metamodel Persistent Closure Fetch Plan
    • How JEST can help your effort? Similar work such as JAX-RS will benefit from model-driven, coherent representation in JEST in XML and JSON JEST and Fetch Plan will obviate extra annotations in persistent domain classes Dynamic customization of object graph is a powerful, distinctive feature of OpenJPA Explore JEST to your advantage.
    • Q&A In case, you are in SF on Feb 2011: http://www.sfjava.org/calendar/15592287/ JEST Documentation https://cwiki.apache.org/openjpa/jest.html
