    Erlang开发及应用 - Presentation Transcript

    1. Erlang 开发及应用 [email_address]
    2. What is Erlang?
        •   ER icsson LANG uage?
        • 函数式编程语言 (FP)
        • 面向并发 (OC), 基于消息
        • Ericsson 创建 , 最初用于电信系统开发
        • 成熟 , 稳定 , 具有 20 多年历史
        • 适于电信系统 , 分布式系统 , 高并发服务器
        • Open Source, 跨平台 , GC
      •        不适于底层系统开发
    3. History
        • 1980s Ericsson 实验室思考如何轻松开发电信系统应用
        • 1987 年左右 , Erlang 浮出水面
        • 1989 年 JAM 虚拟机 C 语言实现
        • 1996 年 OTP 项目启动 , 融合开发经验 , 提供易用 , 强大的 Erlang 开发库
        • 1998 年开源
        • 2007 年《 Programming Erlang 》出版
        • 目前版本 Erlang R13B1 (5.7.2)
    4. Erlang 优势
        • 多核 SMP 支持
        • 内建分布式支持
        • 基于轻量进程及消息的高并发模型
        • 代码热替换
        • 开发速度快 , 高性能 , 高稳定性
        • FP 编程 , 代码灵活高效 , 副作用小
        • 丰富的分析及监控程序
        • 经过商业产品 , 长久大规模验证
        • OpenSource, 代码面前无秘密
    5. Erlang Hello World
      • 代码 hello.erl:
      • 1 -module(hello).
      • 2 -compile([export_all]).
      • 3 4 main() ->
      • 5    io:format("hello world!~n").
      • 编译 :
      • $ erlc hello.erl
      • 运行 :
      • $ erl
      • Eshell V5.7.1  (abort with ^G) 1> hello:main(). hello world! ok
      •
    6. Erlang Hello World CON'T
      • 1 -module(hello).
      • 声明模块名称 , 其必须和文件名一致 . 模块是 Erlang 项目中代码组织的基本方式 .
      • 2 -compile([export_all]).
      • 指明编译选项 ,export_all 用来导出所有本模块中的函数 ,exported function 是模块的接口 , 其他模块只能调用 exported function
      • 4 main() ->
      • 为函数头 (head), 包含函数名称和参数 , 后紧随一个 '->' 分割符
      • 5    io:format("hello world!~n").
      • 为函数体 (body), 包含 Erlang 表达式 , 这里调用 io 模块的 format 函数在默认输出中打印 "hello world!"
      • 在上面的运行结果中 , 最后有一个 "ok", 这是 io:format/1 的返回值 , 表示打印成功 ,Erlang 中任何函数都有返回值 .
    7. Erlang 语法
        • Data Types
      •      8 种基本类型
        • integer - 4,  -4, 2#100, 16#4, 920828990801238101010..
        • float - 3.0, 3.5e2, 6.5e-2, (IEEE754 64bit)
        • atom - hello, your_name, root@host, 'IsAtom'
        • binary - <<&quot;some text&quot;>>
        • reference - make_ref(), 一个随机值
        • fun - fun() -> some_expr end
        • port - 与外部应用进行交互的接口
        • pid - process identifier, 用来操作 process
      •      2 种复合类型
        • tuple - {foo, male, 28, china, <<&quot;i love erlang&quot;>>}
        • list - [{ip, any}, {port, 1234}, binary]
    8. Erlang 语法 CON'T
        • Pattern Match
      •     语言层级的模式匹配 , 代码更加简洁 .
      •     适用于函数调用 , case, receive, try 表达式及 &quot;=&quot; 操作
      •     case Value of
      •        N when is_integer(N) -> N;
      •        _ when is_list(Value) -> list_to_integer(Value)
      •     end
        •   变量
        • 大写字母或 &quot;_&quot; 开头 , 只能包含数字 , 字母 ,&quot;_&quot;, &quot;@&quot;.
        • 如 X, Name1, _Phone, _, Host@
        • 变量分为 Unbound 和 Bound, Unbound 变量只能用在模式匹配中 .
        • 变量 Bound 后 ,Value 就不可修改
        • 变量只能单次赋值 ( 并发及调试考虑 )
        • N = 3 (ok)
        • N = 4 ( oops! not match)
      •
    9. Erlang 语法 CON'T
        • Binary 匹配
        • 使用 binary 可以轻松的实现二进制协议 .
        • (1) 解析 IP 包 :
        • -define(IP_VERSION, 4).
        • -define(IP_MIN_HDR_LEN, 5). ... DgramSize = size(Dgram), case Dgram of <<?IP_VERSION:4, HLen:4, SrvcType:8, TotLen:16, ID:16, Flgs:3, FragOff:13, TTL:8, Proto:8, HdrChkSum:16, SrcIP:32, DestIP:32, RestDgram/binary>> when HLen >= 5, 4*HLen =< DgramSize -> OptsLen = 4*(HLen - ?IP_MIN_HDR_LEN), <<Opts:OptsLen/binary,Data/binary>> = RestDgram,
      •
    10. Erlang 语法 CON'T
        •   (2) 自定义协议
        • 假如我们 定义了一个协议 , 前 2 bytes(16 位 ) 标记消息体的长度 , 后面为消息体 , 最后为占用 1 个 byte 的结尾符 0xef, 示意图如下 :
        • [--- length ---][--------- payload ------][ef]
        • |------ 2 -------|---------- Length -------|-1-| ( 单位 byte)
        • 则对应的 binary 匹配表达式如下 :
        • ...
        • Packet = ...
        • case Packet of
        •     <<Len:16,  PayLoad:Len/binary, 16#ef>> ->
        •         {body, PayLoad};
        •     _ ->
        •         {error, invalid_packet}
        • end.
      •
    11. Erlang 语法 CON'T
        • 序列化与反序列化
        • Erlang 中序列化非常简单
        • term_to_binary/1 - 将任意数据转化为二进制序列
        • binary_to_term/1 - 将编码的二进制数据转化为 Erlang 数据
        • 比如 :
        • Obj = {apple, {price, 2.0}, {origin, shandong}},
        • Bin = term_to_binary(Obj),
        • Obj = binary_to_term(Bin)
        • CouchDB 中大量使用 erlang 的序列化相关函数,完成数据的存储与加载 .
      •
    12. Erlang 语法 CON'T
        • 函数
      •      一切皆函数 , 每个调用都有 return, 函数可以作为基本数
      •     据类型 .
        • 作为返回值 :
        • op_fun('+') ->
        •     fun(N1, N2) -> N1 + N2 end;
        • op_fun('-') ->
        •      fun(N1, N2) -> N1 - N2 end.
        • 作为参数 :
        • > FIsEven = fun(E) -> E band 2#1 =:= 0 end.
        • > lists:filter(FIsEven, [1, 2, 3, 4, 5, 6]).
        • > [2, 4, 6]
      •
    13. Erlang 语法 CON'T
        • Tail Recursion 尾递归
        • Erlang 中没有 for, while 关键字
        • 可以利用递归实现循环
        • 在 server 开发中 , 确保使用尾递归 :
        • server_loop(Args) ->
        •     ...some action...
        •     server_loop(Args).
        • 使用尾递归 , 可以消耗很少的内存 , 仅仅是一个地址跳转 .
        • server_loop(Args) ->
        •     ...some action...
        •     server_loop(Args),
        •     other_fun().
    14. Erlang 语法 CON'T
        •   发送 Message &quot;!&quot;
      •      基于消息通信 ,No Lock! No Shared Memroy!      Pid ! {msg, &quot;hello, I love erlang&quot;}
      •      向 Pid( 本地或远程主机 ) 代表的进程发送消息
        • receive
      1, 阻塞等待任意消息 : receive      Msg -> ok end 3, 等待消息 , 超时为 5 sec: receive       Msg -> ok after 5000 ->      timeout end 2, 实现 sleep: receive after Time ->     ok end 4, 检测是否存在消息 : receive      SomeMsg -> exist after 0 ->       no_exist end
    15. Erlang 并发
      • 关于 Process
        • 每个 Process 拥有一个 mailbox ,保存消息
        • Processes 之间通过发送异步 Message 进行交互 , 无共享状态
        • 轻量 , 兼有 OS Process 的隔离及 OS Thread 的高效
        • Process 具有自己 Stack, Heap, GC
        • Process 可以位于 Local, 也可以位于 Remote Machine
        • Process 能够进行多种形式的管理及控制 (link, monitor, exit signal)
        • Process 为 erlang 高并发 , 高容错 , 分布式的基础
        • 并发 Process 数 : default 32768, max 268435456
    16. Erlang 并发 CON'T
        • 创建 Process
        • spawn(Fun), 比如
        • > spawn(fun() -> io:format(&quot;i'm ~p~n&quot;, [self()]) end).
        • i'm <0.33.0> <0.39.0>
        • spawn(Mod, Fun, Args), 比如
        • > spawn(io, format, [&quot;i'm ~p~n&quot;, [self()]]).  i'm <0.33.0> <0.41.0>
        • spawn_link,  spawn_opt, spawn_monitor ...
        • 销毁 Process
        • 进程内部调用 exit(Reason), 比如 exit(normal), 正常退出
        • 进程内部发生异常导致程序退出
        • 其他进程调用 exit(PidBeTerminate, Reason)
      •
    17. Erlang 并发 CON'T
      • 基于 Process 的 http server 框架
      • (one loop process, per conection per process):
      •
      • setup up listen socket,
      • spawn(listen_process).
      • in listen_process:
      •    while can accept new  client connect
      •         accept ,
      •         spawn(client_process)
      •    loop
      • in client_process:
      •     process protocol,
      •     close socket.
      •
    18. Erlang 并发 CON'T
      • 使用 Erlang 我们可以 :
      • 以清晰的风格开发高并发的应用
      •
      • 我们将不在受困于 :
      • 线程池的复杂
      • 死锁 , 竞赛的窘迫
      • 内存泄露
      • 局部问题 , 导致的全局崩溃
      • 与跨平台多核 SMP 的格格不入
      •
      •
    19. Erlang 分布式
        • Erlang Node 是分布式通讯的基本单元 , 可以位于同一机器 or 多台机器 , 实现了原语级的节点通讯
        • Erlang Node 通过 erl -sname Name  or erlang -name Name 启动 , 同一台机器可以启动多个 Node
        • 每台机器上启动 Erlang Node 时 , 都会启动一个 epmd(Erlang Port Mapper Daemon, port 4396), 用来进行 Node 和 Machine 之间的映射
        • 不同机器的 Node 之间通过 Tcp 连接进行 Message 传输 ( 可以自定义分布式通讯实现 , 如通过 ssh)
        • global 维护一个全局的 Nodes 网络
        • spawn[_link|_opt] 都具有分布式版本 , 可以再其他节点创建 Process
    20. Erlang 分布式 CON'T
        • rpc 模块可以在其他 Node 上执行操作
        • slave, remsh, remote shell 等方式启动 , 连接 Erlang Node
        • Erlang 中进程具有位置透明性
        • 通过 message 及 receive 表达式 , 轻松实现同步 or 异步 , timeout 等网络通信中多种机制
        • Erlang 本身提供 tcp,udp 等常规的网络编程方式
        • 使用 Erlang 内建分布式机制 , 可以快速开发多种应用 , 也可以基于 socket 开发各种专有应用
    21. Erlang 分布式 CON'T
    22. Erlang 分布式 CON'T
      • 节点 A2 连接节点 B2 步骤
        • Node A2, B2 启动 , 绑定一个本机端口 , 并注册到本机的 epmd(default port 4396)
        • A2 连接 HostB epmd, 请求获取 B2 节点的绑定端口
        • HostB epmd 将 B2 的 bind port 及 dist 协议版本等信息返回给 A2
        •   A2 与 B2 协商 , 建立 tcp 连接 , 如果连接成功 , 维护一个 tick, 来定期检测 B2 节点
        • A2 与 B2 节点之间的消息 , 通过此连接进行发送
      •
    23. Erlang OTP
        • OTP(Open Telecom Platform) ,其定义了一系列项目开发中需要的模式及部署升级策略,为提高开发效率,构建高效,稳定系统提供了巨大的帮助。
        • 同最初时的专有电信平台应用已没有太多关系
        • 当前系统都是采用 OTP 进行开发
        • Erlang 中各种 lib 都是基于 OTP 开发
        • 可以理解成某种轻量的框架,或者具体化的设计模式
        • behaviours 包含 :application, supervisor, gen_server, gen_fsm, gen_event
        • application , release , release handling
        • 提供应用的部署,升级,回退等实现
    24. Erlang OTP CON'T
      • Behaviours
      • 通过定义一些简单的 callback 模块实现特定功能 .
        • application - 定义 application ,实现某种功能,由其他 behaviours 组成
        • supervisor - 定义一个 supervisor tree ,实现各种策略的任务重启机制
        • gen_server - 定义一个通用的 server 模型,一个 process loop ,提供同步异步接口
        • gen_fsm - 实现一个状态机
        • gen_event - 实现一个 event manager 及 event handler 模型
    25. 与其它语言的交互
        • External App
        • 外部应用崩溃不会影响 Erlang 虚拟机
          • Ports - 通过 port 与外部应用交互 (stdin/stdout)
          • Erl_Iterface - 提供 c 的封装,方便开发 port 应用
        • Link in Driver
        • shared library (SO in Unix, DLL in Windows) ,影响 Erlang 虚拟机稳定性(不推荐)
        • Port dirvers - 提供 c 封装,运行在 erlang 虚拟机内部
        • C Nodes
        • 遵照 erlang 的交互协议, 使用 c 实现的一个 erlang node
        • Jinterface
        • 提供一系列与 Erlang 进行交互的 Java 包
    26. Erlang 代码片段
        • 求某个数的阶乘
      •                   factorial(0) -> 1;          factorial(N) -> N * factorial(N-1).
        • 获取远程机器的 issue 信息( linux)
      •        -module(issue).        -compile([export_all]).
      •        %% start server        server() ->             register(issue_server, spawn(fun server_loop/0)).        server_loop() ->             receive                   {From, {get, issue}} ->                   From ! {issue, get_issue()};             _ ->                 ok             end,            server_loop().
      •
    27. Erlang 代码片段 CON't
      • get_issue() ->     {ok, Bin} = file:read_file(&quot;/etc/issue&quot;),     Bin. %% start client client(ServerNode) ->     true = net_kernel:connect_node(ServerNode),     {issue_server, ServerNode} ! {self(), {get, issue}},     receive         {issue, Issue} ->             io:format(&quot;server issue:~s~n&quot;, [Issue])     after 1000 ->             io:format(&quot;receive issue time out~n&quot;)     end.
      • 调用: $ erl -sname server (server@litao)1> issue:server(). true $ erl -sname client (client@litao)1> issue:client('server@litao'). server issue:Ubuntu 9.04 l
      •
    28. 产品开发流程
        • 架构设计
        • 单台 or 分布式? Master-Slave or Grid?  Monitor,     Failover, Net Comunication, Database, Replica ...
        • OTP Behaviour how many application? use supervisor, gen_server, gen_fsm, gen_event
        • Coding, 及单元测试用例 . 每个 module 都经过测试 (eunit)
        • 编写系统测试框架,覆盖测试,确保系统正确 (common test)
        • 压力测试,分析性能瓶颈,进行优化 (fprof)
        • 系统上线,监控功能 (ganglia, nagios, monit)
        • 新的功能或需求,重复 2-7
    29. 一些工具
      • appmon - OTP application 监控工具
      • cover -  erlang 代码覆盖测试
      • ntop - 显示 Node 中进程信息 (unix top)
      • make - erlang 中的 make 工具
      • pman - erlang 中进程管理器
      • tv - ets 和 mnesia 查看器
      • fprof -  erlang 系统性能分析
      • common_test - erlang 测试框架
      • dialyzer - 代码静态分析
      • debugger - 单步调试工具,基于 (tcl/tk )
    30. 学习资源
      • Erlang 官方网站
      • http://www.erlang.org/doc
      • Erlang China
      • http://www.erlang-china.org/
      • Erlang Mailist
      • http://www.nabble.com/Erlang-Questions-f14096.html
      • Erlang Planet
      • http://www.planeterlang.org/
      • Erlang 非业余研究
      • http://mryufeng.javaeye.com/
      • Erlang Display
      • http://erlangdisplay.javaeye.com/
    31. 开源项目
      • ejabberd - the Erlang Jabber/XMPP daemon
      • RabbitMQ - AMQP server
      • CouchDB - schema-free document database
      • Tsung - multi-protocol distributed load testing
      • Scalaris - distributed key-value store
      • Disco - MapReduce Framework
      • Mochiweb - Powerful Http Server Tookit
      • 自己动手发起 erlang 开源项目 !
    32. 案例
        • AXD301
        • 高并发的电信交换机
        • 99.9999999% 可靠性 (~3ms 故障 / 年 )
        • 超过 100 万行 Erlang 代码
        • 软实时系统
        • 高容错
    33. 案例
        • WEB IM 后台 (mochiweb)
        •   7+ 百万活跃用户
        • ~ 100 server
        • ajax + comet(long-polling)
    34. 更多应用
