Best Practices for Designing and Building the Services of an SOA Guido Schmutz Technology Manager, Oracle ACE Director for...
Abstract <ul><li>This session will present best practices for designing and building the services of an SOA. Different way...
Guido Schmutz <ul><li>Working for Trivadis for more than 14 years </li></ul><ul><li>Oracle ACE Director for Fusion Middlew...
Trivadis Facts & Figures <ul><li>11 Trivadis locations with more than 550 employees </li></ul><ul><li>Financially independ...
Agenda <ul><li>Principles of Service Design </li></ul><ul><li>Service Design </li></ul><ul><li>Service Model and Implement...
Principles of Service-Orientation
Service Design Principles <ul><li>Standardized Contract  – Implement a  standardized contract </li></ul><ul><li>Loose Coup...
Agenda <ul><li>Principles of Service Design </li></ul><ul><li>Service Design </li></ul><ul><li>Service Implementation </li...
Development Approaches <ul><li>Bottom up </li></ul><ul><li>Top Down </li></ul><ul><li>Meet in the  middle (agile) </li></u...
Contract-First Web Service Design <ul><li>Important for service-orientation is the  standardizing  and  decoupling  of the...
Contract-First is fine ….. <ul><li>But isn‘t it just too hard to get  … ? </li></ul><ul><li>Most SOA platforms  do not mak...
“ I like Contract First design, BUT  “ <ul><li>Lot of repetition </li></ul><ul><ul><li>Very talkative </li></ul></ul><ul><...
Alternative: UML with “WS profile” <ul><li>Enterprise Architect has a special profile for WSDL and XSD modelling </li></ul>
CBDI-SAE UML Profile  for SOA http://everware-cbdi.com Service Implementation Architecture Showing Services and Automation...
Using DSL to simplify WSDL generation <wsdl:definitions xmlns:tns=&quot;http://trivadis.com/service/credit-card/v1&quot;  ...
Domain Specific Language (DSL) <ul><li>A Domain Specific Language (DSL) is </li></ul><ul><ul><li>A small programming langu...
Prototype based on Eclipse XText available
Service Contract Template => DSL service  CreditCardValidation { version  : 1.0 namespace  : CreditCard business-propertie...
WS-I: check your contracts! <ul><li>An open industry effort promoting Web Services interoperability </li></ul><ul><ul><li>...
Message Exchange Patterns (MEP) <ul><li>There are four basic message exchange patterns (MEPs) used in Web services </li></...
Standardized Service Data Models –  Canonical Data Model Source: Enterprise Integration Patterns (www.eaipatterns.com)
Standardized Service Data Models –  Canonical Data Model
Service Usage Scope Level of coupling Typical WS-Attribute:  Granularity Scope Cross Organisational Document or RPC style,...
SOA Logical Architecture – Service Categorization Source: Oracle
Agenda <ul><li>Principles of Service Design </li></ul><ul><li>Service Design </li></ul><ul><li>Service Implementation </li...
<ul><li>PL/SQL in the database holds logic </li></ul><ul><li>Java holds business logic, data access is implemented in PL/S...
PL/SQL Implementation of Use Case <ul><li>PL/SQL Package specification </li></ul><ul><li>Object types </li></ul>
Java Implementation for Use Case <ul><li>Customer Service Interface in Java </li></ul><ul><li>Customer and Address DTO  </...
<ul><li>For  B and C a Java Web Service Facade can be written </li></ul><ul><li>How can deploy existing PL/SQL logic as a ...
Service Interface for Use Case
JAX-WS – WSDL First
JAX-WS – WSDL First Transformation JAXB Annotations JAX-WS Annotations EJB Annotations
Java with JAX-WS - Code First Determines XSD Determines WSDL
Native Database Web Service (11g) <ul><li>A servlet in the database (DBWS) acts as a gateway to: </li></ul><ul><ul><li>SQL...
Native Database Web Service (11g)
<ul><li>OSB adds a layer of indirection (virtualization) </li></ul><ul><ul><li>Mediation: Transformation, Filtering, Enric...
OSB and DB Adapter for request-driven access to information <ul><li>Problem </li></ul><ul><ul><li>Want to  directly access...
Demo: Database Adapter on OSB
<ul><li>OSB adds a layer of indirection (virtualization) </li></ul><ul><ul><li>Mediation: Transformation, Filtering, Enric...
OSB HTTP Transport to wrap JAX-WS service <ul><li>Problem </li></ul><ul><ul><li>Want to offer a contract-first SOAP-based ...
OSB HTTP Transport to wrap JAX-WS Code First service Proxy Service XQuery Transformation Business Service HTTP Transport  ...
OSB EJB Transport to call EJB <ul><li>Problem </li></ul><ul><ul><li>Want to  use an EJB session bean directly  without hav...
OSB EJB Transport to call EJB <ul><li>Proxy Service </li></ul><ul><li>Business Service EJB Transport </li></ul>
Service Enablement in BPEL/BPMN Application A Tables PL/SQL PL/SQL Resource Data Access Business Logic OSB Web Service  Fa...
Automatic Build & Deployment <ul><li>Goals </li></ul><ul><ul><li>Automate everything </li></ul></ul><ul><ul><ul><li>WLS Do...
Agenda <ul><li>Principles of Service Design </li></ul><ul><li>Service Design </li></ul><ul><li>Service Model and Implement...
Service Versioning <ul><li>Services once deployed can never be changed </li></ul><ul><ul><li>Stable endpoints, don‘t neces...
Service Versioning <ul><li>In software, major-minor versioning is used to accommodate two levels of change </li></ul><ul><...
Implementing Versioning on ESB <ul><li>Common Endpoint for all versions </li></ul><ul><li>One Endpoint per Major Version w...
Service Versioning <ul><li>WSDL Version 1.0 </li></ul>
Service Versioning <ul><li>WSDL 1.1 </li></ul>
Agenda <ul><li>Principles of Service Design </li></ul><ul><li>Service Design </li></ul><ul><li>Service Model and Implement...
Summary <ul><li>Standardized Service Contract => use contract-first design => wrap contract-last services </li></ul><ul><l...
My other sessions @ Kscope11 <ul><li>Reusing Existing Java EE Applications from Oracle SOA Suite 11g , Tuesday 1:45 – 2:45...
Best Practices for Designing and Building the Services of an SOA Please Fill Out Your Evaluations Guido Schmutz Technology...
