  • 1. Inside The Machine Derek CollisonThursday, October 27, 11
  • 2. What is Cloud Foundry? 2Thursday, October 27, 11
  • 3. The Open Platform as a Service 3Thursday, October 27, 11
  • 4. What is PaaS? 4Thursday, October 27, 11
  • 5. Or more specifically, aPaaS? 5Thursday, October 27, 11
  • 6. aPaaS • Application Platform as a Service • Applications and Services 6Thursday, October 27, 11
  • 7. aPaaS • Application Platform as a Service • Applications and Services • Not • VMs • Memory • Storage • Networks • CPU 7Thursday, October 27, 11
  • 8. What is OpenPaaS? 8Thursday, October 27, 11
  • 9. OpenPaaS • Multi-Language • Multi-Framework • Multi-Services • Multi-Cloud, Multi-IaaS • Hybrid - Public or Private or Both • OpenSource 9Thursday, October 27, 11
  • 10. OpenPaaS • Multi-Language • Ruby, Java, Scala, Node.js, Erlang, Python, PHP.. • Multi-Framework • Rails, Sinatra, Spring, Grails, Express, Lift • Multi-Services • MySQL, Postgres, MongoDB, Redis, RabbitMQ • Multi-Cloud, Multi-IaaS • vSphere, MicroCloud, OpenStack, AWS 10Thursday, October 27, 11
  • 11. The Open PaaS Ap pli Private ca ce tio rfa Data Clouds n e Services Int Se Public rvi er vid ce Msg Services Clouds ro Int dP e Micro rfa ou Clouds ce Other Cl Services 11Thursday, October 27, 11
  • 12. The Open PaaS Ap pli vFabric Private ca ce Postgres tio rfa Data Clouds n e Services Int Se Public rvi er vFabric vid ce RabbitMQTM Msg Services Clouds ro Int dP e Micro rfa ou Clouds ce Other Cl Services 11Thursday, October 27, 11
  • 13. What is our Goal? 12Thursday, October 27, 11
  • 14. What was our Goal? Raise the unit of currency to be the application and its associated services, not the infrastructure 13Thursday, October 27, 11
  • 15. What was our Goal? Best of breed delivery platform for all modern applications and frameworks 14Thursday, October 27, 11
  • 16. What was our Goal? Favor Choice and Openness 15Thursday, October 27, 11
  • 17. How was it Built? 16Thursday, October 27, 11
  • 18. How was it Built? • Kernel (CloudFoundry OSS) • Core PaaS System • Kernel and Orchestrator Shells • Layered on top of IaaS • Orchestrator • IaaS creation, management and orchestration 17Thursday, October 27, 11
  • 19. High Level Clients (VMC, STS, Browser) CF Kernel Orchestrator IaaS Hardware - CPU/Memory/Disk/Network 18Thursday, October 27, 11
  • 20. Basic Premises • Fail Fast • Self Healing • Horizontally Scalable Components • Distributed State • No Single Point of Failure • Should be as simple as possible 19Thursday, October 27, 11
  • 21. Basic Patterns • Event-Driven • Asynchronous • Non-blocking • Independent, Idempotent • Message Passing • Eventually Consistent 20Thursday, October 27, 11
  • 22. Basic Design • All components loosely coupled • Few “Classes”, many “Instances” • Messaging as foundation • Addressing and Component Discovery • Command and Control • JSON payloads • HTTP or File/Blob for data transport 21Thursday, October 27, 11
  • 23. Kernel Components • All dynamically discoverable • Launch and scale in any order • Can come and go as needed • Monitor via HTTP and JSON • Location independent 22Thursday, October 27, 11
  • 24. Kernel Components • Router • CloudController • DEA • HealthManager • Service Provisioning Agent • Messaging System 23Thursday, October 27, 11
  • 25. Logical View Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging 24Thursday, October 27, 11
  • 26. Architecture 25Thursday, October 27, 11
  • 27. Messaging 26Thursday, October 27, 11
  • 28. Messaging “The Nervous System” 27Thursday, October 27, 11
  • 29. Messaging Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging 28Thursday, October 27, 11
  • 30. Messaging • Addressing and Discovery • No static IPs or DNS lookups req’d • Just Layer 4 • Command and Control • Central communication system • Dial tone, fire and forget • Protects *itself* at all costs • Idempotent semantics 29Thursday, October 27, 11
  • 31. Router 30Thursday, October 27, 11
  • 32. Router “Traffic Cop” 31Thursday, October 27, 11
  • 33. Router Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging 32Thursday, October 27, 11
  • 34. Router • Handles all HTTP traffic • Maintains distributed routing state • Routes URLs to applications • Distributes load among instances • Realtime distributed updates to routing tables from DEAs 33Thursday, October 27, 11
  • 35. CloudController 34Thursday, October 27, 11
  • 36. CloudController “The King” 35Thursday, October 27, 11
  • 37. CloudController Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging 36Thursday, October 27, 11
  • 38. CloudController • Handles all state transitions • Deals with users, apps, and services • Packages and Stages applications • Binds Services to Applications • Presents external REST API 37Thursday, October 27, 11
  • 39. HealthManager 38Thursday, October 27, 11
  • 40. HealthManager “Court Jester” 39Thursday, October 27, 11
  • 41. HealthManager Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging 40Thursday, October 27, 11
  • 42. HealthManager • Monitors the state of the world • Initial value with realtime delta updates to “intended” vs “real” • Determines drift • Complains to the CloudControllers when something is not correct • No power to change state itself 41Thursday, October 27, 11
  • 43. DEA 42Thursday, October 27, 11
  • 44. DEA “Droplet Execution Agent” 43Thursday, October 27, 11
  • 45. DEA Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging 44Thursday, October 27, 11
  • 46. DEA (Droplet Execution Agent) • Responsible for running all applications • Monitors all applications • CPU, Mem, IO, Threads, Disk, FDs, etc • All apps look same to DEA • start and stop • Express ability and desire to run an application • runtimes, options, cluster avoidance, memory/cpu • Alerts on any change in state of applications • Provides secure/constrained OS runtime • Hypervisor, Unix File and User, Linux Containers* • Single or Multi-Tenant 45Thursday, October 27, 11
  • 47. How does it all Work? 46Thursday, October 27, 11
  • 48. Pushing an App • Client (VMC/STS) pushes meta-data to CC • Client optionally pushes resource signatures (diff analysis, sys wide) • Client pushes app resources to CC • CC puts app together • CC stages app asynchronously • CC binds and stages services • Droplet ready 47Thursday, October 27, 11
  • 49. Architecture 48Thursday, October 27, 11
  • 50. Running an App • CC asks DEAs for “help” • First DEA back wins! Simple • CC sends start request to selected DEA • DEA pushes the “green” button • DEA waits and monitors pid and ephemeral port for app to bind • When app is healthy, sends “register” message • Register message is seen by HM and Routers • Routers bind URL to host:port 49Thursday, October 27, 11
  • 51. DEAs answer? • DEAs first determine YES or NO • correct runtime, options, memory, etc • Then calculate a Delay Taint • SHA hash of application • memory • cpu • Taint allows balancing and selection 50Thursday, October 27, 11
  • 52. Scale up & down? • Exact steps as running the app the first time • SHA1 taint helps avoid clustering • memory/cpu taint helps distribute as evenly as possible • Nothing pre-computed • Nothing assumed 51Thursday, October 27, 11
  • 53. Crashes? • If your app stops and we did not tell it to, that is a crash • Crashed apps are immediately detected by DEA and messaged • Routers disconnect route instantly • HM will signal CC • something is wrong • CC will issue run sequence again 52Thursday, October 27, 11
  • 54. Architecture 53Thursday, October 27, 11
  • 55. Access to my App? • All routers understand where all instances of your application are running • Will randomly pick backend, not semantically aware. • Will remove routes that are stale or unhealthy • Session stickiness and replication available, but best to avoid if possible 54Thursday, October 27, 11
  • 56. What about Services? 55Thursday, October 27, 11
  • 57. Services Browser VMC client STS plugin (user app access) Routers CloudControllers App App HealthManager Services DEA Pool Messaging 56Thursday, October 27, 11
  • 58. Services • Service Advertisement • Service Provisioning • Gateway fronts multi-backends • Service Nodes scale independent • App and service talk directly • API to register into system • Closure for additional value 57Thursday, October 27, 11
  • 59. Provisioning VMC/STS 1 Routers 2 CloudControllers Services Gateway 3 5 6 4 Service Node Service Node Service Node Application MySQL Redis Redis Messaging 58Thursday, October 27, 11
  • 60. Access (Direct) Browser (user app access) 1 Routers CloudControllers Services Gateway Service Node Service Node Service Node Application MySQL Redis Redis 2 Messaging 59Thursday, October 27, 11
  • 61. Services VMware Dev Tools Partner Dev Tools Cloud Foundry consume Enterprise Services apps consume bind Data Director provision/bind service service broker controller SQLFire core services Relational DB vSphere 60Thursday, October 27, 11
  • 62. Learn more: www.cloudfoundry.org blog.cloudfoundry.com support.cloudfoundry.com 61Thursday, October 27, 11
  • 63. Thank You 62Thursday, October 27, 11
  • 64. Questions? dcollison@vmware.com derek.collison@gmail.com twitter: derekcollison 63Thursday, October 27, 11

×
