AKD Industrial Systems WLL is a joint venture established in Qatar that specializes in the manufacture and service of various types of plate heat exchangers and related products. The company is ISO-certified and has been operational since 2005, serving major clients in the oil and gas sector. Their extensive capabilities include services such as complete reconditioning and cleaning of heat exchangers, as well as a range of replacement parts and accessories.

1. Company confidential
AKD INDUSTRIAL SYSTEMS WLL
RLIC,Qatar

2. COMPANY CONFIDENTIAL
CONTENTS
COMPANY
ABOUT US
PRODUCTS
SERVICES
TECHNICAL PARTNERS
PARTIAL REFERENCES
OF EXPERIENCES
INFRASTRUCTURE

3. AKD Industrial systems is the Joint venture
company established between
Al Khor & Dakira Schemes and Services QSC-Qatar
&
Adhiam Thermal Systems & Solutions Pvt Ltd .India
COMPANY CONFIDENTIAL
Company

4. Al-Khor and Dakhira Schemes & Services (AKD)
Established in Year 2005.
IMS certified company i.e. ISO 9001:2008, ISO 140001:2004, BS OHSAS 18001:2007
by BV .
AKD is registered with major oil and gas companies inside Qatar, such as Qatar
Petroleum, Ras Gas and Qatar Gas. AKD and is already providing various services to
Operators and contractors in RLIC.
Adhiam is well established Plate Heat Exchanger Service company , Registered under
company Act since 2005 .
ISO 9001-2008 certified by TUV sud for Manufacture, Supply and Service of Plate Heat
Exchangers.
having People with experiences of more than two decades in Plate Heat Exchangers.
COMPANY CONFIDENTIAL
About Us

5. AKD Industrial systems is having technical partners for
Qatar..
Technical Partner for PHE:
Technical Partner for Desco Coil
Technical Partners
COMPANY CONFIDENTIAL

6. COMPANY CONFIDENTIAL
Company- Infrastructure- floor plan

7. Major equipment's :
1. Over head Crane – 10 Ton capacity
2. SS Tank for Dipping plates- size– 3 mtr length*1 mtr width, 1.3 mtr
height--- 2nos
3. SS tank– 1 mtr*1 mtr * 0.8 mtr -- 1 no
4. Light Box test Kit– 2 nos
5. Air compressor
6. Oven-27KW--- 35 ft length.
7. TIG welding machine
8. Screw Press
9. Water jet cleaning machine- 2 nos
10. CIP pump Kit-2 nos
COMPANY CONFIDENTIAL
Company- Infrastructure

8. Major equipment's :
1. Hydrotest Pump- Centrifugal Pump-3 hp– 1 no
2. Hand Pump for Hydrotest-1 no
3. Hydraulic tightening device- to hold 56 mm dia and more.
4. Measuring instruments
5. Ratchet Spanners
6. Other tools and tackles for PHE.
COMPANY CONFIDENTIAL
Company- Infrastructure

9. 10 Ton Overhead
crane
Factory at RLIC ,
Qatar
COMPANY CONFIDENTIAL
Company- Infrastructure- 1

10. Chemical Tanks for Plate Immersion
COMPANY CONFIDENTIAL
Company- Infrastructure- 2

11. Hydraulic Tightening Device 60 Ton
capacity , 8 inch stroke Length
Oven for Curing -27 KW– 10 mtr
Depth ,3.5 mtr width approx
COMPANY CONFIDENTIAL
Company- Infrastructure- 3

12. Working table/ screw press/ Ratchet
spanners of various sizes
Light Box Test Kit
COMPANY CONFIDENTIAL
Company- Infrastructure- 4

13. Water Jet cleaning Pump 125 bar
pressure
CIP Pump with PH reading
COMPANY CONFIDENTIAL
Company- Infrastructure- 5

14. Products –:
1. Plate heat exchanger- Gasketted
2. Free flow Plate heat exchanger
3. Semiwelded plate heat exchanger
4. Brazed plate heat exchanger
5. Spiral Heat exchanger.
6. Welded Plate Heat Exchangers
7. Titanium Fabrication Products
COMPANY CONFIDENTIAL
Company- Products - 1

15. Plates For Any Task
Most Extensive Plate Portfolio in the world
Plate and shell Heat exchangers
Plates for condensers and evaporators
SFD plates for
fresh water distillers
Brazed Plate heat exchangers
SF plates for free flow heat exchangers
Sonder safe plates
SW semi welded plates
SAW all welded
Standard plates
Spiral HE
Inflated Coils
COMPANY CONFIDENTIAL
Company- Products - 2

16. Products – Spares and accessories :
1. Replacement Spare Gaskets for Plate Heat Exchanger- All Models and
Brand
2. Replacement Spare Plates for plate heat exchanger- All models and Brand.
3. Replacement Plate pack for the existing models meeting the dimension in
the same frame.
4. Ratchet Spanners
5. Hydrualic Tightening Devices
COMPANY CONFIDENTIAL
Company- Services - 1

17. Services :
1. Plate Heat Exchanger- Complete Reconditioning.
2. CIP cleaning of plate heat exchangers
3. Chemical cleaning of other shell and tube heat exchangers.
4. Tube bundle replacement.
5. Titanium and other exotic metals piping and repair services.
COMPANY CONFIDENTIAL
Company- Services - 2

18. COMPANY CONFIDENTIAL
Past Experiences - Engineering

19. COMPANY CONFIDENTIAL
Past Experiences - Chemicals

20. COMPANY CONFIDENTIAL
Past Experiences – Edible Oils

21. COMPANY CONFIDENTIAL
Past Experiences – Power

22. COMPANY CONFIDENTIAL
Past Experiences – Dairies

23. COMPANY CONFIDENTIAL
Past Experiences – Sugars & Distilleries

24. COMPANY CONFIDENTIAL
Past Experiences – Beverages

25. Thank you very much
AKD Industrial Systems
P.O.Box : 60789
AL-KHOR-QATAR
Office : + 974 4472 4499
Fax : + 974 4472 2655
Mob : + 974 6617 5822
Email : info@akdindus.com
Web : www.akdindus.com
