This document provides information on different types of physical terminations for networking including optical fiber connectors like SC and LC, copper connectors like RJ-45 and RJ-11, and small form-factor pluggable (SFP) modules. It lists common optical and copper termination standards and their applications for technologies such as 1000Base-SX/LX, 1000Base-T, and 10Gig X2.

1. PHYSICAL TERMINATIONS packetlife.net
Optical Terminations Copper Terminations GBICs
RJ-45
ST (Straight Tip)
1000Base-SX/LX
RJ-11
SC (Subscriber Connector)
1000Base-T
RJ-21 (25-pair)
LC (Local Connector)
Cisco GigaStack
MT-RJ
Wireless Antennas DE-9 (Female)
1000Base-SX/LX SFP
RP-TNC 1000Base-T SFP
DB-25 (Male)
RP-SMA
DB-60 (Male)
X2 (10Gig)
by Jeremy Stretch v1.1
