8. CLFR Trough
Area 1 1.5
Solar Receiver Linear Multi Tube
Method HTF Direct Steam
Tracking Power Lowest Medium
Structure Lightest Medium
Pipe Length Shortest Long
Insulator Min Moderate
Heat Losses Lowest Medium
Universal Joint Leakage None Yes
Receiver Glass Break None Yes
Reflector Twisting None Yes
Operation Time hrs 12 6
Minimum Working
Insolation
500 650
Price Lowest Medium
CLFR Chonburi, Thailand
Karnchanaburi, Thailand
การเปรียบเทียบ CLFR VS Trough
23. การออกแบบโครงสราง • Delta Truss
• Software Analysis
- Linear First Order
- Linear Second Order
- Non-linear First Order
- Non-linear Second Order
- Dynamic Harmonic
- Dynamic Seismic
- Dynamic Modal
- Bucking
- Stiffness
- Own weight
- Shell Stress
- Torsion
- Thermal expansion
- Moment
• Antirust treatment
• Easy to transport and erection
24. ระบบถูกออกแบบตามความตองการของทองถิ่น
Solar Steam Performance @ 1 MW
Temperature Up to 750 F (180 C)
Up to 900 F (200 C)
Pressure Up to 150 PSIa (10 BARa)
Up to 230 PSIa (16 BARa)
Annual Energy per
8 Rais (12,800 Sq.m)
1,500 MWh
@ 1,000 W/m2
สมรรถนะสูง
งายตอการกอสราง
มีความเสถียรสูง
งายตอการเพิ่มกําลังผลิต
งายตอการใชงาน
ใชรวมกับน้ํา (Hydrogen)
ใชรวมกับเชื้อเพลิงชุมชน
ไรมลภาวะ
System Efficiency 15 %
1,500 MWhr/300 = 5 MWhr/day = 1 MW for 5 hr
12,800 m2 @ 1 kW/m2 = 12.8 MWhrThermal = 2 MWhrelectric
Equivalent to 1 MWhrelectric for 10 hours
With Hydrogen Feed could increase fuel consumption 30 %
At Night Time Thermal Energy will use as fuel economizer to
preheat feed water from 80 C to 120 C
Use Back Up fuel 25 % for 8 hours 120 C to 180 C
Use Back Up fuel 100 % for 6 hours 120 C to 180 C
