Final capstone presentation
- 1. ONLINE GLOBAL JOBTRAINING AND CAREER NETWORK APPLICATION MENTORS: GRACE FENG DANIEL TANG PROFESSOR: DR. KEWEI SHA TEAM MEMBERS: VIKRAM KUMAR GOSHIKA SRIHITA RAMANAN HARSH JIVANI SAIPAVAN TEJA KOPPULA
- 2. OUTLINE 2 Introduction System Architecture Tools and Technologies Design of Database Implementation FunctionalitiesSecurity Milestones Roles and Responsibilities Conclusion & Future Work
- 3. INTRODUCTION 3 EXPLORE DATABASE, WEBAPPLICATION AND SECURITY. CREATING A WEB APPLICATION THAT CAN MODIFY THE DATABASE. INCLUDES COMPANY, TRAINING SCHOOL AND SUPPORT CENTER. WILL GIVE EASY ACCESS TO COMPANY IN ORDER TO VIEW THEIR STATISTICS. WILL HAVE SECURITY TO KEEP THE DATA SAFE.
- 4.
- 5. TOOLS AND TECHNOLOGIES Software •C# .NET • SQL Server in AWS RDS • MS SQL Server • GitHub 5 Hardware • Processor: i3 and above. • RAM: 2Gb and above. • Hard Disk: 50Gb and above. • Operating System: Windows 7 and above.
- 6. DESIGN OF DATABASE 6 Signinto the AWS Management Console and open the Amazon RDS console Database creation method: Select engine options, version, edition and templates Setting up master password and sever configuration Create database After creating database, the data is inserted into database via user input
- 7.
- 8. IMPLEMENTATION – WELCOMEPAGE • Welcome page where users can navigate for LogIn. 8
- 9. LOG-IN PAGE 9 • Allusers can navigate to different log-in pages from left sidebar • Every users have option to forgot password • Admin can register but the existing admin needs to approve the request for register.
- 10. REGISTER PAGE FORADMIN • Registration available for Admin profile with verification and approval. 10
- 11. FORGOT PASSWORD • Requiresvalid email. • User gets error message if email is not available in database. • If user enters valid email, user will get OTP. 11
- 12. FORGOT PASSWORD- EMAILFOR OTP 12 • User will get OTP to change password in registered email. • The OTP will be valid until user request for new OTP.
- 13. FORGOT PASSWORD –AFTER GETTING EMAIL FOR OTP 13 • After verifying OTP user can view text fields to enter new password. • Password and confirm password must be same.
- 14. ADMIN - HOMEPAGE •Add Company • Add Training Center • Add Support Center • Manage Company • Manage Training Center • Manage Support Center 14
- 15. ADMIN - REGISTRATIONFOR COMPANY • Main Admin can add company here, • Validations are added for accurate values. 15
- 16. ADMIN - REGISTRATIONFOR TRAINING CENTER 16 • Main Admin can add Training Center here. • Checkbox to select training type • Validations are added for accurate values.
- 17. ADMIN - REGISTRATIONFOR SUPPORT CENTER 17 • Main Admin can add Support Center here. • Validations are added for accurate values. • Password and confirm password must be same.
- 18. ADMIN - MANAGECOMPANY 18 • Admin can view all companies registered. • Admin can edit or delete companies' profile • Admin cannot change email as email is used for LogIn
- 19. ADMIN - MANAGETRAINING CENTER 19 • Admin can view all registered Training Center. • Admin can edit or delete Training Centers' profile • Admin cannot change Email as Email is used for LogIn
- 20. ADMIN - MANAGESUPPORT CENTER 20 • Admin can view all registered Support Center. • Admin can edit or delete Support Centers' profile • Admin cannot change email as email is used for LogIn
- 21. COMPANY ADMIN HOMEPAGE • Add Worker • Add Training Center • Post Job • Manage Worker • Manage Training Center • Assign Training Center to Worker 21
- 22. COMPANY ADMIN ASSIGNTRAINING CENTER TO WORKER • Training Center Admin can select Training Center name and Worker name to assign Training Center to Worker 22
- 23. COMPANY ADMIN POSTJOB • Training Center Admin can post job and all jobs must have industry and job type. 23
- 24. WORKER HOMEPAGE • Postresume • Apply for job 24
- 25. WORKER POST RESUME •Worker can post resume by browse file from computer. • Worker can also watch the last resume uploaded by him. 25
- 26. TRAINING CENTER ADMINHOMEPAGE • Add Student • Add Teacher • Add Mentor • Manage Student • Manage Teacher • Manage Mentor 26
- 27. TEACHER HOMEPAGE • AddStudent to Course • Add Course • Manage student in course • Manage Course 27
- 28. TEACHER ADD COURSE •Teacher can add course and course requirements and course fees are required field. 28
- 29. TEACHER ADD STUDENTIN COURSE • Teacher can add students in the course offered by him • Teacher can select course name and student name form dropdown list 29
- 30. MENTOR HOMEPAGE 30 • Listof Mentees • List of Courses
- 31. STUDENT HOME PAGE 31 •Courses to enroll • Enrolled courses • Make payment
- 32. • Companies to Support •Training centers to Support • Workers to Support • Supported Company List • Supported Training center List • Supported Worker List • Post job SUPPORT CENTER ADMIN HOME PAGE 32
- 33. INVESTOR HOMEPAGE 33 • HelpWorker • Invest on Company • Invest on Training Center • Invest on Support Center
- 34. FUNCTIONALITIES – EDITPROFILE • Edit option is available for all the users. • Email cannot be edited. 34
- 35. FUNCTIONALITIES - ENCRYPTION •The encrypted password is stored in the database. • The encryption algorithm used here is 35
- 36. FUNCTIONALITIES – CHANGEPASSWORD • In Admin change password, we enter the new password and submit. • The new encrypted password will be stored in the database. 36
- 37. FUNCTIONALITIES - OPERATIONS • Themanage pages include the edit and delete operations. • When clicked on edit, the row changes to an editable format • After changing the data we can click update. • If we do not wish to make any changes we just click cancel. 37
- 38. FUNCTIONALITIES – SESSIONHANDLING 38 Technique used to make the Stateless HTTP protocol that supports Session state. Doesn’t allow the user until Login into the application. Redirects back to the Login Page.
- 39. MILESTONES (1 OF3) 39 S.NO DATE MILESTONE STATUS 1 01/29/2020 Project website Completed 2 01/29/2020 Hosting project website on the server Completed 3 02/05/2020 E-R Diagram Document Completed 4 02/11/2020 Attribute Suggestions and Empty Tables Completed 5 02/17/2020 Database Design Document Completed 6 02/18/2020 Requirement Specifications Document Completed 7 02/20/2020 Rough UI Flow Diagram Completed 8 02/27/2020 Rough UI Flow Diagram - Document Completed 9 03/05/2020 Empty Tables on SQL Sever Completed 10 03/05/2020 Architecture Diagram Completed
- 40. MILESTONES (2 OF3) 40 S.NO DATE MILESTONE STATUS 11 03/11/2020 Log-In Module Completed 12 03/11/2020 Register Module Completed 13 03/23/2020 Mid-Term Presentation Completed 14 03/26/2020 LogIn and Register Backend Completed 15 04/01/2020 Remote Desktop Using EC2 Tool Completed 16 04/04/2020 Manage Pages for Admin modules Completed 17 04/07/2020 Manage Pages for Company modules Completed 18 04/10/2020 Manages Pages for all modules Completed 19 04/14/2020 Navigation bar in every module Completed 20 04/14/2020 Password Encryption For Security Completed
- 41. MILESTONES (3 OF3) 41 S.NO DATE MILESTONE STATUS 21 04/21/2020 Session Handling Completed 22 04/21/2020 Welcome Page Completed 23 04/27/2020 Status Report Completed 24 04/27/2020 Forgot Password Function Completed 25 05/05/2020 Final Report Completed 26 05/05/2020 Final Presentation Completed
- 42. ROLES AND RESPONSIBILITIES 42 VikramKumar Goshika Team Leader Front-End Design Back-End Design AWS Database Project Website Srihita Ramanan Front-End Design Back-End Design Database Design Documentatio n Harsh Jivani Front-End Design Back-End Design Database Design AWS Database Saipavan Teja Koppula Front-End Design Back-End Design Project Website Documentatio n
- 43. CONCLUSION & FUTUREWORK 43 The search feature can be improved. Doubt clarification feature can be improved in the mentor-mentee relationship Teacher can have a feature to chose a mentor to help with his course. Report generation in each module for various details like investor, company, training center, support center activities can be done.
- 44.
- 45.
