1. DRIP BOX TEST CHAMBER
MODEL NO. - ACM- 65465DB
R
TECHNOCRACY PVT. LTD.

2. R
DRIP BOX TEST CHAMBER
Drip Box Test Chamber is applicable for the outer protection of exterior lighting, signal devices and car lamps.
The flow rate of drips is set and monitored by a user friendly touch screen controller that sets the water pressure to
the drip box. The drip box and the water system is fully enclosed and filtered to minimize clogging of any nozzles.
Weiber drip box chamber is supplied with a specimen turntable that rotates at 1 rpm. The base of the turntable is
500mm high. The turntable can be wheeled in and out from under the drip box for specimen loading and unloading.
The height of the box is electronically adjustable up to a height of 2500mm or 2000mm above the base of the
turntable.
TECHNOCRACY PVT. LTD.

3. R
CONSTRUCTION DETAILS
The guiding upright column is made of high-quality square steel pipe sprayed with plastic. The drip mold is made of
hi-quality stainless steel finish plate undergoing knurling. A level meter is applied to observe the level in the drip
mold.
SALIENT FEATURES
Ÿ Touch screen controller
Ÿ Choice of three drip box sizes
Ÿ Fully enclosed drip box and water system
Ÿ Stainless steel nozzles removable for cleaning or replacing
Ÿ 40L stainless steel water tank with water filter and pump
TECHNICAL SPECIFICATIONS
Test Bench 500×400(mm)
Rainfall 3~5mm/min
Drip Aperture 0.4mm
Hydraulic Control Flowmeter
Water Supply System Booster pump
Drip Mold Height 200~2000mm(adjustable)
TECHNOCRACY PVT. LTD.
