Extending Groovys Swing User Interface in Builder to Build Richer Applications  Danno Ferrin, Intelligent Software Solutio...
<ul><ul><li>Learn how to customized Groovy’s SwingBuilder to add custom widgets and non-visual components. </li></ul></ul>
Not always an enterprise question… <ul><li>BUT WILL IT </li></ul><ul><li>S C A L E </li></ul><ul><li>? </li></ul>
Agenda <ul><li>Ways to Extend SwingBuilder </li></ul><ul><li>FactoryBuilderSupport Overview </li></ul><ul><li>Case Study: ...
Agenda <ul><li>Ways to Extend SwingBuilder </li></ul><ul><li>FactoryBuilderSupport Overview  </li></ul><ul><li>Case Study:...
Issues of Scale How you extend should be driven by how much the extension is used <ul><li>Magic Nodes </li></ul><ul><ul><l...
Magic Nodes <ul><li>bean(…)  </li></ul><ul><ul><li>Accepts any object  </li></ul></ul><ul><ul><li>Not added to parent  </l...
Magic Nodes <ul><li>An instance of the object must be passed in as the argument </li></ul><ul><li>Attributes are applied a...
Magic Nodes Example <ul><li>bean(model, propertyChanged: { panel.repaint() } ) </li></ul><ul><li>widget(new JXMonthPanel()...
Individual Factory Registration <ul><li>First, what are the characteristics of the Widget? </li></ul><ul><li>Well behaved ...
Individual Factory Registration <ul><li>Well behaved JavaBeans may use  registerBeanFactory(…) </li></ul><ul><ul><li>All l...
Builder Suite <ul><li>Logical progression from creating factories </li></ul><ul><li>How?  Subclass the SwingBuilder </li><...
Builder Suite <ul><li>But what if I want multiple suites? </li></ul><ul><ul><li>JideSplitButton  </li></ul></ul><ul><ul><l...
Composite Builder <ul><li>Coming Soon </li></ul><ul><ul><li>Won’t be in Groovy 1.6 core </li></ul></ul><ul><li>The Idea </...
The Vision <ul><ul><li>def builder = new CompositeBuilder( SwingBuilder,  ogb:ObjectGraphBuilder, jx:SwingXBuilder,  jide:...
The code as of Today <ul><li>Called ‘UberBuilder’ </li></ul><ul><ul><li>Available on SVN (only for the brave…) </li></ul><...
Agenda <ul><li>Ways to Extend SwingBuilder </li></ul><ul><li>FactoryBuilderSupport Overview </li></ul><ul><li>Case Study: ...
First some Terminology <ul><li>nodeName( argument, attr : value, attr2 : value) { … } </li></ul><ul><li>Node </li></ul><ul...
Factory Lifecycle
Delegate Closures <ul><li>Some steps can be intercepted without a Factory </li></ul><ul><ul><li>addPreInstantiateDelegate,...
Agenda <ul><li>Ways to Extend SwingBuilder </li></ul><ul><li>FactoryBuilderSupport Overview </li></ul><ul><li>Case Study: ...
SwingXBuilder <ul><li>Google Summer of Code 2007 project </li></ul><ul><ul><li>James Williams – Nova Southeastern Universi...
Summary <ul><li>SwingBuilder extension is easy </li></ul><ul><li>Choose your extension method based on frequency of use </...
For More Information <ul><li>TS-5098 </li></ul><ul><ul><li>Friday at 12:10 in EP 305 </li></ul></ul><ul><ul><li>Covers mor...
Danno Ferrin,  Intelligent Software Solutions, Inc. James Williams,  Spatial Networks, Inc.  BOF-5110 Speaker’s logo here ...
