Lessons learnt in 2009
         Pratik Naik



                       Jobless
Lessons learnt in 2009
         Pratik Naik

                       Freelancer/
                       ActionRails

      ...
And some hobby apps


   http://planetrubyonrails.com



     http://tweetmuffler.com
• My first ever presentation.
• Usually don’t like any conferences
• But it’s Brazil!!
So if I screw up...




DONT Tweet FFS
Overview
•   Using Ruby Enterprise Edition

•   Testing

    •   Faster tests

    •   Factory v/s Fixtures

•   Security
...
This talk is targeted at
      Ruby Web Developers
      Not everything may apply to things outside the web




Also if th...
Lesson 1



Always use REE
What is REE ?
Ruby + COW GC
 And a bunch of other cool patches
Maintained by




(Photo acquired by the use of force)
                                                       (That was ju...
Who uses REE ?



   And many others
Who uses REE ?



   And many others

  In Production
Why should you use it
      for the
  development ?
Topmost Reason

Super Fast Tests
MRI - Ruby 1.8.6
    $ time rake

    real
 1m45.293s
    user
 0m54.341s
    sys
 0m33.008s
REE - Ruby 1.8.6
    $ time rake

    real
 1m30.219s
    user
 0m40.290s
    sys
 0m25.433s
That’s15 seconds faster
       Completely Free

          YMMV
Only Catch
 Twitter’s GC Settings
.profile

   RUBY_HEAP_MIN_SLOTS=500000
   RUBY_HEAP_SLOTS_INCREMENT=250000
   RUBY_HEAP_SLOTS_GROWTH_FACTOR=1
   RUBY_GC_M...
Second Reason
ruby-prof & Rails Performance Tests
What are Rails Performance tests ?
      Integration Tests + ruby-prof
http://guides.rubyonrails.org/performance_testing.html
$ script/generate performance_test Home
       exists test/performance/
       create test/performance/home_test.rb



cla...
MRI




$ rake test:profile
HomeTest#test_homepage (29 ms warmup)
        wall_time: 25 ms
          memory: 0.00 KB
      ...
REE




$ rake test:profile
HomeTest#test_homepage (48 ms warmup)
        wall_time: 16 ms
          memory: 698.18 KB
    ...
Lesson 2
       Efficient Testing

• Faster Tests
• Factory
• More Integration Tests & Less Unit Tests
Faster Tests




        Tickle
http://github.com/lifo/tickle
$ script/plugin install git://github.com/lifo/tickle.git
Benchmarks
  ( they’re real )

$ time rake

real
 1m30.219s
user
 0m40.290s
sys
 0m25.433s
Benchmarks
   ( they’re real )

$ time rake tickle

real
 0m55.691s
user
 0m37.532s
sys
 0m22.563s
That’s another 35
            seconds
( On top of the 15 seconds initially saved by REE )
To get the Best of Tickle


• Experiment with the number of processes
• Create more test databases


          It’s all in...
Parallel Specs
http://github.com/jasonm/parallel_specs
Faster Tests




    fast_context
http://github.com/lifo/fast_context
Problem




That’s 5 DB Queries and 5 GET Requests
Solution




That’s 1 DB Query and 1 GET Request
   5x Faster w/ one word change
Catch ?

• Tests no longer atomic
• Developers should not need to care about
  atomicity of the tests
• It’s an optimizati...
Writing more effective tests in less time
Factory v/s Fixtures
★ Slow                   ★ Fast
★ Very easy to manage    ★ Hard to manage
★ Describes the data     ★ ...
Example : Fixtures



      What can go wrong ?
• Someone could change users(:lifo) to be no
    longer a ‘free’ account h...
Example : Factory



 What can go wrong ?


   Not much
Factory + Faker
Awesome Development Data
  (Clients and Designers Love it)
Writing Good Factories


• Should be able to loop
  10.times { Factory(:user) }


• No associations in the base Factory
  ...
Integration Tests > Unit Tests
Lesson 3
Improved Security
To know more




http://guides.rubyonrails.org/security.html
rails_xss
http://github.com/NZKoz/rails_xss
 By Michael Kozkiarski of http://therailsway.com/
rails_xss
 Without rails_xss                           With rails_xss



<%= “<script>alert(‘foo’)</script>” %>   <%= “<sc...
rails_xss

• Built in Rails 3
• Enabled by the rails_xss plugin in Rails
  2.3.next
• Requires Erubis
rails_xss
Introduces the concept of SafeBuffer




         ( * just the relevant bits )
rails_xss
>> buffer = ActionView::SafeBuffer.new
=> ""

>> buffer << "Hello ! "
=> "Hello ! "

>> buffer << "<script>"
=> ...
rails_xss

• Uses Erubis hooks to make <%= %> tags to
  always return a SafeBuffer
• Modifies all the relevant Rails helper...
rails_xss
       When you don’t want to escape


<%= "<a href='#{foo_path}'>foo</a>".html_safe! %>
MessageVerifier
http://api.rubyonrails.org/classes/ActiveSupport/MessageVerifier.html
MessageVerifier

Secret                       Ruby Data




            Signed Message



(Derived from Cookie Session Stor...
MessageVerifier
>> verifier = ActiveSupport::MessageVerifier.new("my super secret")
=> #<ActiveSupport::MessageVerifier:0x2d55...
MessageVerifier

      Example use case
 “Remember Me” Functionality
MessageVerifier
    When you store the ‘remember me’ tokens in the db



• Extra column
• More maintenance
 Expiring tokens...
MessageVerifier
# User.rb
def remember_me_token
 User.remember_me_verifier.generate([self.id, self.salt])
end

# Controller ...
MessageVerifier

• Use a different secret for every use of
  MessageVerifier
  rake secret

• Make sure to use the ‘salt’ fo...
bcrypt
http://bcrypt-ruby.rubyforge.org
bcrypt
             Bcrypt                          MD5/SHA1



★ Designed for generating password ★ Designed for detectin...
bcrypt

• bcrypt-ruby gem by Coda Hale works great
• Reduces the need of ‘salt’ column by
  storing the salt in the encryp...
Lesson 4
Background processing
     with the DJ
      http://github.com/tobi/delayed_job
What is DJ ?
                                                                  DJ
                                        ...
How to use DJ ?




Minimal Example using Delayed::Job.enqueue
How to use DJ ?




  More practical example
How to use DJ ?




   Using send_later
How to use DJ ?




Using handle_asynchronously
Batch Processing w/ DJ
Batch Processing w/ DJ
              Tweetmuffler Requirement




That’s average 4-10 external calls per user. Every 2 minu...
Batch Processing w/ DJ
     Initial Implementation




          1 job/user
Batch Processing w/ DJ


      Problems with that ?
Batch Processing w/ DJ

     DID NOT SCALE

   • Too Slow
   • Way too much memory required
   • Too many workers required
Batch Processing w/ DJ

             Solution


     Fork based workers w/ REE
Batch Processing w/ DJ
Batch Processing w/ DJ

  Has scaled great so far

     • 10x faster
     • Uses 40% less memory
     • Just 1 worker need...
Batch Processing w/ DJ
General things to remember when forking w/ Ruby

     • Always reset the database
       connection...
Batch Processing w/ DJ
REE Specific things to remember when forking


   • Call GC.start before you fork
   • Call GC.copy_...
Lesson 5
  Scaling
http://modporter.com




Scaling file uploads
Mod Porter
            What’s the problem ?


• Rails processes are resource intensive
• Multipart parsing for large files ...
Mod Porter
       How does mod_porter work ?

• mod_porter is an apache module built on
  top of libapreq
• libapreq does ...
Mod Porter
                    Apache Config File

<VirtualHost *:8080>
  ServerName actionrails.com
  DocumentRoot /Users/...
will_paginate
   Does not scale
will_paginate
        The common pattern




SELECT * FROM `posts` LIMIT 10,10
will_paginate
            Scaling Problems

• Large OFFSET are harder to scale
• Problems clear when you have more rows
  ...
How to scale Pagination?
Scalable Pagination




       Github
Scalable Pagination




       Twitter
Scalable Pagination
   What’s common with Github and Twitter ?

• Don’t show all the page links
• Don’t show the total cou...
Scalable Pagination
                         Page 1
page1 = SELECT * FROM `posts` LIMIT 10 WHERE id > 0 ASC id
           ...
Scalable Pagination
                  Benefits ?

• Using no OFFSET is much faster
• Plays great with caching. No records e...
Source
http://www.scribd.com/doc/14683263/Efficient-Pagination-Using-MySQL
                         By the Yahoo folks
That’s all !
Thank you.
Blog http://m.onkey.org

        @lifo
