How to do RESTful
web services right
   Kerry Buckley & Paul Moser

         BT DevCon2

         9 March 2010
w ay
 ne
O How to do RESTful
   web services right
w ay
 ne
O How to do RESTful
   web services right
     (for some value of ‘right’)
What is REST?



REST is an architectural style, not a protocol or a standard. Hence many values of “right” (and
much disa...
‘A style of software
              architecture for
          distributed hypermedia
            systems such as the
     ...
Not SOAP



Seems to be a common (but wrong) definition.
Constraints
• Client-server
• Stateless
• Cacheable
• Layered system
• Uniform interface
Principles
• Identification of resources
• Manipulation of resources through these
  representations

• Self-descriptive messages
• Hy...
Goals
• Scalability of component interactions
• Generality of interfaces
• Independent deployment of components
• Intermediary c...
Shop example
• List products
• View a product
• Create an order for a number of products
• Cancel order
• Pay for order
XML-RPC
(URI-tunnelling)
GET /api?action=list_products

      GET /api?action=view_product&product_id=123

      GET /api?action=create_order&produ...
GET /list_products

     GET /view_product?product_id=123

     GET /create_order?product_id=123&product_id=456…

     GET...
GET /list_products

      GET /view_product?product_id=123

      POST /create_order?product_id=123&product_id=456…

     ...
POST /pay_order?order_id=42&card_number=1234…

      def pay_order(order_id, card_number) {
        …
      }




Request ...
✓Easy to understand
✓Works well for simple procedure calls
✓Simple to implement
✓Interoperable
✗ Brittle
          ✗ Tightly coupled
          ✗ Failure cases require manual handling
          ✗ No metadata


Need to ...
But is it REST?
✗ Identification of resources
✗ Manipulation of resources through these
   representations
✗ Self-descripti...
POX
(plain old XML)
Request

     POST /create_order

     <create_order_request>
      <line>
        <product_id>123</product_line>
        ...
✓Simple to implement
✓Interoperable
✓Allows complex data structures
✗ Tightly coupled
✗ No metadata
✗ Doesn’t use web for robustness
✗ Doesn’t use SOAP for robustness either
But is it REST?
✗ Identification of resources
✗ Manipulation of resources through these
   representations
✗ Self-descripti...
CRUD
GET /products

GET /products/123

POST /orders

PUT /orders/42

DELETE /orders/42

POST /orders/42/payment
Representations
•   Hypermedia              •   Non-hypermedia

    -   XHTML                   -   Generic XML

    -   A...
✓Makes good use of HTTP
          ✓Uniform interface
          ✓Good for database-style applications


Because each resour...
✗ Ignores hypermedia
✗ Tight coupling through URI templates
✗ Not self-describing
But is it REST?
✓ Identification of resources
✓ Manipulation of resources through these
   representations
✗ Self-descripti...
REST
API root
Request

GET /
API root
            Response

            200 OK
            Content-Type: application/vnd.rest-example.store+xml

      ...
View products
             Request

             Get /products




Following the link with a relation of ‘products’ (link ...
View products
             Response

             200 OK
             Content-Type: application/vnd.rest-example.products+...
View orders
Request

Get /orders
View orders
            Response

            200 OK
            Content-Type: application/vnd.rest-example.orders+xml

  ...
Place order
            Request

            POST /orders
            Content-Type: application/vnd.rest-example.order+xml...
Place order
            Response

            201 Created
            Content-Type: application/vnd.rest-example.order+xml...
Clients only need know

• The root URI (‘home page’) of the API
• Definitions for the media types used
 - eg schemas or exa...
✓Makes full use of HTTP
           ✓Self-describing
           ✓Loosely coupled


Only need to know entry URI and media ty...
✗ More complex to implement
          ✗ Transition links can lead back to RPC-style



Frameworks help. Tempting to just a...
But is it REST?
✓ Identification of resources
✓ Manipulation of resources through these
   representations
✓ Self-descripti...
This is not the One
                    True Way


As mentioned before, REST is just an architectural style. There are oth...
An alternative:
‘Web site is your API’
• No separation between web site and API
• Representations are HTML
• Data submitte...
Using HTTP features
Response codes
•   200 OK                  •   400 Bad request

•   201 Created             •   403 Forbidden

•   202 Acc...
Restricting transitions
      Request                 Response


OPTIONS /orders/123             200 OK
   (an open order)...
Restricting transitions
      Request                Response


DELETE /orders/123
                           100 Continue...
Prevent race conditions
 Request
 PUT /orders/123
 If-Unmodified-Since: Tue, 9 Mar 2010 11:00:00 GMT
 Response
 200 OK
 or
...
Prevent race conditions
 Request
 GET /orders/123
 Response (partial)
 200 OK
 ETag: 686897696a7c876b7e
 Request
 PUT /ord...
Security

• HTTP basic
• HTTP digest
• Shared secret (OAuth etc)
• SSL
• Selective encryption
More

• Jim Webber tutorial
      http://tinyurl.com/rest-tutorial
• Restfulie framework (Rails & Java):
      http://tiny...
