    SharePoint Saturday The Conference 2011 - SP2010 Performance SharePoint Saturday The Conference 2011 - SP2010 Performance Presentation Transcript

    • Boost the Performance of SharePoint Today!
    • Welcome to SharePoint Saturday—The Conference Thank you for being a part of the first SharePoint Saturday conference • Please turn off all electronic devices or set them to vibrate. • If you must take a phone call, please do so in the hall so as not to disturb others. • Open wireless access is available at SSID: SPSTC2011 • Feel free to “tweet and blog” during the session • Thanks to our Diamond and Platinum Sponsors:
    • About Brian Culver– SharePoint Solutions Architect for Expert Point Solutions– Based in Houston, TX– Author • SharePoint 2010 Unleashed • Various White Papers– Speaker and Blogger
    • Session Agenda• What is Performance?• Infrastructure Performance• Hardware Performance• SharePoint Performance• Testing Performance
    • What is Poor Performance?• Increased end user response time• Reduced overall system throughput
    • Infrastructure Performance• Active Directory• Exchange• Desktops• Network Topology• SharePoint Farm – Web Front Ends – Application Servers – Database Servers
    • SharePoint Farm Performance• 3-4 Web Servers per DC• 8 Web Servers per SQL Server• Bandwidth and Latency<1 ms• Workflow Running• Search: Indexing – iFilters – # of servers – Scheduling and throttling of crawling
    • Search PerformanceCrawl Time: How long does the overall time the crawltakes?Corpus Size: How big is the corpus size?Indexing Speed: How many documents are beingindexed per second?
    • Search Performance• Grouping content sources by speed – Tuning crawling – Protocol – Authentication• Choosing multithreaded iFilters – Adobe ($) vs FoxIt ($$$)• Proper infrastructure – Dedicated Query Apps vs Distributed Query Apps
    • SharePoint Farm Performance• Authentication Performance – # of round trips – Processing speed of provider• Fastest to Slowest – Anonymous – Kerberos – NTLM – Basic – Forms and WebSSO
    • SharePoint Farm Performance• Which Machines cause the bottleneck?• New 2010 Performance Counters• Watch – CPU – Memory – Disk I/O – Network
    • SharePoint Farm Performance• Requests per Second (RPS): How many requests you can service? RPS is used for measuring how many pages are delivered. It can measure how many searches are executed.• Requests per Hour (RPH): Average user requests in an hour.• Page Time (TTLB): How long it takes to deliver a page back to the client? Used in conjunction with RPS• For example, our farm needs to deliver 100 RPS and pages should reach the client within 5 seconds.
    • SharePoint Farm Performance• Currency Rate: 10%• Active Requests: 1%• Usage profiles – Light (20 RPH) – Readers/Visitors – Typical (36 RPH) – Readers/Writers (discussions/lists/etc.) – Heavy (60 RPH) - Readers/Writers (Upload some/ MySites/publishing/libraries/etc.) – Extreme (120 RPH) – Lite Readers/Constant Writers (Upload/MySites/publishing/RSS/Many Sites/etc.)
    • SharePoint Farm Performance• How many RPS are needed for your farm?• Actual: Use historical data – IIS Logs, Web Trends, etc.• Estimate: Number of Active Users – (# users) x (# operations per usage profile) – Factor in concurrency
    • SharePoint Farm Performance• Example:• 100k users, 20k active, concurrency 5% to 10% peak• 10% light, 70% typical, 15% heavy, 5% extreme – 20k x 20 x .1 = 40,000 RPH – 20k x 36 x .7 = 504,000 RPH – 20k x 60 x .15 = 180,000 RPH – 20k x 120 x .05 = 120,000 RPH – 844,000 / 3600 = 235 RPS – 235 x .1 = 23.5 RPS required
    • SharePoint Farm Performance• What can our farm support?• Input/Output Operations Per Second (IOPS): Storage vendors publish IOPS for their hardware. – Derive speed needs from RPS calculations – Derive backup needs from content size – 1 IOP per RPS  1 IOP = 1 RPS• Measured with tools such as Iometer (originally developed by Intel), Iozone, FIO and Data Test Program (dt).
    • SharePoint Farm Performance• Example:• 100k users, 20k active, concurrency 5% to 10% peak• 10% light, 70% typical, 15% heavy, 5% extreme – Our farm requires 23.5 RPS (IOPS) – Our farm supports 200 IOPS – Success! Our farm is well above the required. Plan for 10 IOPS per AVG hourly RPS – Handle peak loads! – Success! Our farm can handle peak loads.
    • SharePoint Farm Performance• Understand SharePoint workload – Use RAID 10 over other RAID ## – And yes, RAID 10 for SharePoint is better than RAID 5• Separate your database files – ** Tempdb is the most heavily used DB ** – Place different databases on different volumes – Log files separate from data files – SQL Server files separate from other uses (e.g. OS files) – Separate your files according to I/O workload. • A single volume may be fast enough to handle several databases.
    • Common Performance Problems• Large Lists• Lots of Web Parts importing non-cached data from various places• Cross-List queries and CBQ Web Parts• Too Deep Site Structures• Too many sites in a site collection• Too many site collections in a Content DB• Too many ACLs
    • SharePoint PerformanceWe will discuss the following:• Large List Control• Performance Throttling• Developer Dashboard – Good for IT Pros and Developers alike• Caching• IIS 7.0• Content Query Web Part
    • Large List ControlSo what is new?• Lists and Libraries hold 50,000,000 items• Recommended List View Size: – Why 2000 or 5000?• Server Overload• Solution: List View Throttling
    • List View Throttling• Limits the number of list items returned per view. – Operations that exceed this limit are prohibited.• Recommended to configure at the Web Application level.• Default List View Threshold values: – 5000 for Users – 20000 for Auditors and Administrator
    • List View Throttling• List can be configured individually via API• Daily Time Window for Large Queries: Turn off Throttling during a daily window – Comes with a Warning• List View Lookup Threshold: How many complex fields are allowed – Lookup, Person/Group, or workflow status fields – Result in JOINs
    • Performance Throttling• HTTP Request Monitoring and Throttling: Throttle Performance during high server load – SharePoint monitors performance counters and uses threshhold values – Get 503 request errors – Timer Job fails to start – PUT request still allowed• Search can trigger performance throttling and cause issues
    • Performance Throttling• Protects the server during peak loads. Monitors: – Available Memory – CPU % – ASP.NET Queue – Wait time in queue• Checked every 5 seconds – 3 over limit start throttling, logs events – 1 below limit stop throttling• Configure via PowerShell and Object Model• Adds/Remove counters via Object Model
    • DEMOList View Throttling and Load Performance Throttling
    • List View Throttling
    • List View Throttling
    • List View Throttling
    • List View Throttling
    • List View Throttling
    • Caching• Page Output Cache: for generated HTML markup for future requests – Cache frequently used Lists and reduce round trips to the database• Object Cache: for common objects and query results – Content Query Web Part – List Views – Tune using “Cache API Hit Ratio”; aim for 90%• Disk-Based (BLOB) Cache: for commonly requested files on WFE disks – Automatically cache BLOBs and reduce round trips to the content databases
    • Caching• Configure caching via the Site Settings• Configure caching via web.config for Web Applications. – Web.config overrides the Site Settings.
    • DEMOCaching
    • IIS 7.0 Performance• Design pages for fast downloading and rendering• Lazy loading of large JavaScript files• Clustering images – Reduce image requests• Reduce the number of secured items in pages – Each secured request results in two roundtrips • Validate credentials • Enumeration of groups the user belongs to• Leverage IIS Compression
    • IIS 7.0 Performance• Reduce amount of data sent to client and reduce the number of trips a browser makes.• View State Caching and Reduce Payload. – Cache View State to be used in subsequent post- backs – Minify JavaScript • Remove redundant white spaces and new lines – Reduce File Requests • Merge multiple JavaScript/CSS files in one request
    • IIS 7.0 Performance• Increase static compression level to 9 and dynamic to 5 Appcmd.exe set config -section:httpCompression - [name=gzip].staticCompressionLevel:9 - [name=gzip].dynamicCompressionLevel:9• Change dynamic compression CPU utilization threshold range from 20-75%• APPCMD.EXE set config –section:httpCompression /dynamicCompressionDisableCpuUsage:75 APPCMD.EXE set config –section:httpCompression /dynamicCompressionEnableCpuUsage:20• Enable caching before insertion into page output cache APPCMD.EXE set config –section:urlCompression /dynamicCompressionBeforeCache:true
    • Content Query Web Part• Powerful web part for aggregating and rolling up information from various sources.• Designed to leverage the object cache by caching the query results. – In MOSS 2007, Disabled by default – In SP 2010, Enabled by default• Best performance when content shares the same permissions and doesn’t change often.
    • But performance still sucks• Look at everything• Performance is based on the entire farm, including content• Lets share some stories!
    • But performance still sucks• Less than 500 “actual” users• Web Application is going to sleep• Default idle timeout is 20 minutes• Does 0 for infinite actually work?
    • Custom Code• Common cause for poor performance• Custom inefficient features
    • Plan for Software Boundaries• Helps understand the tested performance and capacity limits of SharePoint Role Specifications 1 dual core Intel Xeon 2.8 gigahertz Stand-alone computer (GHz) 64-bit processor, 2 gigabytes (GB) RAM 2 dual core Intel Xeon 2.8 GHz 64-bit Web server computer processors, 4 gigabytes (GB) RAM Database computer running 4 dual core Intel Xeon 2.8 GHz 64-bit Microsoft SQL Server processors, 32GB RAM Pentium III 1.2 GHz processor, 1 GB Client computers RAM
    • Testing Performance• SharePoint Load/Performance Testing• population tools, performance tuning techniques
    • Developer Dashboard• Allows monitoring page loads and performance• Information: – Times to render page – Page checkout level – DB query info – Web part processing time – Any critical events or alerts
    • Developer Dashboard Always ON for all users ON stsadm -o setproperty -pn developer-dashboard -pv on Completely OFF for all users OFF stsadm -o setproperty -pn developer-dashboard -pv off Available to Site Administrators (Toggle on top-right)On-Demand stsadm -o setproperty -pn developer-dashboard -pv ondemand
    • DEMODeveloper Dashboard
    • Visual Studio Test Suite• Test throughout your testing lifecycle of planning, testing and tracking your progress• Use with TFS to automate builds, deployments and testing
    • Fiddler• Great, light weight tool. Provides quick overview of the website performance.• Free• It can also records scripts that you can use in VSTS.• neXpert: Fiddler Add-on that checks for classic performance best practices and produces a HTML report on the issues found in a Fiddler capture.
    • YSlow• Analyzes web pages and • Suggests performance suggests ways to improve improvements, summarizes their performance based on a page components, statistics set of rules for high for the page, and provides performance web pages. tools for performance• Grades web page based analysis. rulesets.
    • Welcome to SharePoint Saturday—The Conference Thanks to our SponsorsThanks to Our Other Sponsors!
    • Questions
    • Brian Culver,
    • Welcome to SharePoint Saturday—The Conference Session Evaluation Please complete and turn in your Session Evaluation Form so we can improve future events. Survey can be filled out at: and add the Session number to the URL Presenter: Brian Culver Session Name: Boost the Performance of SharePoint Today! Session No.: Fri-S3A-102
