Walking Through Cloud Serving at Yahoo!

  1. 1. Yahoo Cloud Serving<br />Surendra Reddy<br />Cloud Computing Conference & ExpoNovember 3, 2009<br /> <br />
  2. 2. Imagining the Future of Cloud!<br />
  3. 3. Cloud is a Promise, But …<br />
  4. 4. Reference:<br /> Tussle in Cyberspace: Defining Tomorrow’s Internet<br /> http://conferences.sigcomm.org/sigcomm/2002/papers/tussle.pdf<br />
  5. 5. Customer Tussles:<br /><ul><li>Outages: 76% outages caused by change management
  6. 6. Unmet Needs: Rapidly changing needs</li></li></ul><li>Management Tussles:<br /><ul><li>Growing Costs and Complexity
  7. 7. Long Deployment Cycles: Inflexible, peak-provisioned infrastructure</li></li></ul><li>Operations Tussles:<br /><ul><li>Entangled in many day-to-day failures & troubleshooting
  8. 8. Crippled Infrastructure
  9. 9. Building on weak foundation</li></li></ul><li>Developers Tussles:<br /><ul><li>Bloated Operating System, App Stacks
  10. 10. Staggering Complexities of Dependencies
  11. 11. No time for QA – Bugs Creeping in all over</li></li></ul><li>Security Tussles:<br /><ul><li>Whose problem is it?
  12. 12. Auditability and Assurance
  13. 13. Governance
  14. 14. Compliance</li></li></ul><li>
  15. 15. As a Result: <br /><ul><li>More Friction, Waste, and Frustration
  16. 16. Less Innovation </li></li></ul><li>So, What is Cloud?<br /><ul><li>C – Customer Driven
  17. 17. L – Lean
  18. 18. O – Optimized
  19. 19. U – Utility
  20. 20. D – Demand-Driven</li></li></ul><li><ul><li>Cloudis NOT about Cost cutting
  21. 21. It is about Value Creation enabling Innovation</li></li></ul><li><ul><li>Cloud is an opportunity to clean up the Infrastructure mess!</li></li></ul><li>
  22. 22. Yahoo! is Perfect for Cloud Computing<br />600M<br />UNIQUE USERS / MONTH<br />300M+<br />YAHOO! MAIL USERS / MONTH<br />HUNDREDS<br />OF PROPERTIES / PRODUCTS<br />BILLIONS<br />OF OBJECTS STORED<br />HUNDREDS<br />OF PETABYTES OF STORAGE<br />PETABYTES<br />OF TRAFFIC DAILY<br />
  23. 23. <ul><li>Declarative language for specifying the full, end-to-end structure of a service
  24. 24. Includes multiple environments: Dev, QA, Staging, and production
  25. 25. Extreme Automation</li></li></ul><li>Yahoo! Cloud Serving - Principles<br /><ul><li>Metastructure: Abstracts concerns of the underlying infrastructure and the network communication
  26. 26. Declarative application structure
  27. 27. Continuous Integration, Continuous Deployment, & Continuous Compliance*
  28. 28. End-to-End Security</li></ul>* Rich Miller @RHM2K first coined “Continuous Compliance” <br />
  29. 29. Yahoo! Cloud Serving - Principles<br /><ul><li>Virtualized hardware
  30. 30. Standardized software stacks and packaging
  31. 31. Integrated service management
  32. 32. Containers vs. Machines</li></li></ul><li>Yahoo! Cloud Serving - Principles<br /><ul><li>Elastic serving of changing workloads
  33. 33. Controlled/Intelligent traffic direction
  34. 34. Controlled execution environment
  35. 35. Managed Communication
  36. 36. Service Associations, Bindings, and Access Controls</li></li></ul><li>Yahoo! Cloud: Tiers without Tears<br />Entrypoint<br />Naming<br />Presentation<br />Tier<br />Application Logic<br />Tier<br />Bindings<br />Connections<br />Database Tier<br />
  37. 37. Yahoo! Cloud: Tiers without Tears<br />Entrypoint<br />Naming<br />Load<br />Balancer<br />Presentation<br />Tier<br />Application Logic<br />Tier<br />node<br />node<br />node<br />Bindings<br />Connections<br />Database Tier<br />
  38. 38. Yahoo! Cloud: Extreme Automation<br />Abstracting Services<br />Component AnswersCore {<br /> Entry root;<br />Tier pres {<br /> app = “answers_web_tier”;<br /> Exit applogic;<br /> nsize = small;<br /> nnodes = 3;<br /> };<br />Tier applogic {<br /> app = “answers_al_tier”;<br /> Exit data;<br /> nsize = medium;<br /> nnodes = 3;<br /> };<br />Tier data;<br /> Connections {<br /> root -&gt; pres;<br /> pres.applogic -&gt; applogic;<br /> applogic.data -&gt; data;<br /> }<br />} <br />Presentation<br />Tier<br />Application Logic<br />Tier<br />Database Tier<br />
  39. 39. Yahoo! Cloud: Extreme Automation<br />QA Environment<br />Environment qa(ne1) {<br /> TrafficDirector root {<br /> name = “qa.answers.yahoo.com”;<br /> access = testing;<br /> };<br /> AnswersCore core;<br /> Connections {<br /> root -&gt; core;<br /> }<br />} <br />Presentation<br />Tier<br />Presentation<br />Tier<br />Application Logic<br />Tier<br />Application Logic<br />Tier<br />Testing Testing<br />Environment production(ac4,sk1) {<br /> TeeTrafficDirector root {<br /> name = “answers.yahoo.com”;<br /> access = public;<br /> split_percent = 10;<br /> split_destination = qa.root;<br /> };<br /> AnswersCore core;<br /> Connections {<br /> root -&gt; core;<br /> }<br />} <br />Database Tier<br />Database Tier<br />
  40. 40. Yahoo! Cloud: Extreme Automation<br />Apps written against rich stacks<br />Includes core infra and platforms<br /><ul><li>Infrastructure: Security, monitoring, metering, abuse prevention
  41. 41. Platforms: data, user info, ad systems, configuration bundles
  42. 42. All “auto configured”</li></li></ul><li>Serving Cloud Serving for Y!’s Cloud<br />
  43. 43. <ul><li>Infrastructure to Metastructure
  44. 44. Machines to Containers
  45. 45. Friction to Innovation
  46. 46. Tears to Tiers
  47. 47. Complexity to Simplexity
  48. 48. Costs to Revenue Streams</li></li></ul><li>Cloud is a Promise, Service is the fulfillment!<br />
  49. 49. OPEN CLOUD ACCESS PROTOCOL<br />
  50. 50. OPEN CLOUD ACCESS PROTOCOL<br /><ul><li>Definition, Deployment, and Life Cycle Management of Cloud Resources
  51. 51. Allocation, Provisioning, and Metering of Cloud Resources
  52. 52. Metadata/Registry for Cloud Resources
  53. 53. Virtual Infrastructure Management</li></li></ul><li>Yahoo! Submitted OpenCAP to IETF<br /><ul><li>Why IETF?
  54. 54. Specification behind Yahoo Implementation
  55. 55. Plan to open source implementation</li></li></ul><li>Open Cloud Access Protocol<br />Resource Model<br /><ul><li>All Infrastructure and Functional Components are modeled as Resources
  56. 56. Nodes, Networks, Storage Devices, Databases, Load Balancers, Identities, Key Value Store, Object Stores, Caching Services</li></ul>Resource Properties<br /><ul><li>Modeled as JSON objects
  57. 57. Standard Catalog of attributes, extensible</li></ul>Resource Operations<br /><ul><li>Operation, Control, and Notification</li></li></ul><li>Open Cloud Access Protocol<br />Management Operation Services<br /><ul><li>CREATE - Create an instance of a managed resource
  58. 58. DELETE - Delete an instance of a managed resource
  59. 59. GET - Request managed resource properties (for one resource or a set of resource)
  60. 60. CANCEL - Cancel an outstanding request
  61. 61. SET - Set managed resource properties
  62. 62. ACTION - Request an action to be performed on a managed resource</li></li></ul><li>Open Cloud Access Protocol<br />Management Notification Services<br /><ul><li>EVENT- Send events occurring on managed resources (VM events, VM stats etc, SNMP events etc)
  63. 63. ALERT- Send alerts for resource failures and exceptions</li></ul>Life Cycle Management Services<br /><ul><li>START- Starts the resource
  64. 64. TERMINATE – Stop the resource
  65. 65. SUSPEND – Suspend the resource
  66. 66. RESUME – Resume the resource
  67. 67. ARCHIVE – Archive the resource</li></li></ul><li>Yahoo! Open Source & Research<br />Open Source<br /><ul><li>Cloud Serving Platform, Yahoo Implementation of OpenCAP
  68. 68. Traffic Server</li></ul>Research Activities<br /><ul><li>Open Cloud Consortium
  69. 69. OpenCirrus & M45</li></li></ul><li>THANK YOU<br />Surendra Reddy<br />@sureddy twitter<br />sureddy@yahoo-inc.com email<br />yCloudBlog.com blog<br />
  70. 70. TUESDAY, 11/3<br />4:50pm – 5:35 pm<br />Hadoop @ Yahoo! – Internet<br />Scale Data Processing<br />Eric Baldeschwieler<br />VP, Hadoop Software Development<br />WEDNESDAY, 11/4<br />9:10 am - 9:55 am<br />Yahoo! Scalable Storage and<br />Delivery Services<br />Chuck Neerdaels<br />VP, Storage and Edge Services<br />VISIT BOOTH #103 <br />TO TALK WITH YAHOO! ENGINEERS AND LEARN MORE ABOUT YAHOO!’S VISION FOR CLOUD COMPUTING.<br />

×
