Tapping into Mobile UI     with HTML5      Luke Melia + Yael Sahar
Mobile UXprinciples
Direct manipulation
Ergonomics:Operated with a single hand.      Finger tip size.
Immediate feedback
Be consistentwith platform conventions
“I should always know     where I am”
“Show me what I want to seewhen I need it”
“Don’t make me type”
The HTML5 tradeoff
You get a single code basein exchange for implementing    all UI elements yourself
Mobile UIpatterns
Buttons[ used for actions ]
Designer says:Touch target size: 44px on iOS, 48px on Android                    iOS             44px                     ...
Designer says:Position on screeniOS                  Android                               -------------------------------...
Designer says:Visual appearance (frames on iOSvs. no frame on   Android, use system fonts)   iOS                          ...
Designer says:Back / Cancel actions on iOSuse a button vs. the   hardware Back button on Android.    iOS                  ...
Designer tip: how to create an iOS looking button               Challenge: have a single button image background          ...
Developer says_The #1 reason that manymobile web apps feelslow:
Developer says_Instead,respond immediately!
Developer says_“What aboutdeveloping on my laptop???”Implement a mouse-friendly path... ...or emulate!
Developer says_                  Touch targets           Handle them case-by-case                   with CSS
Developer says_        Cross-platform visual            conventionsHelp yourself with some Javascript, and handle visual  ...
AlternativesDirect manipulation of content is usually betterCamera                       Flipboard                 ClearZo...
Tab bars[ used to navigate through the sections of your app]
Designer says:Position on screeniOS                  Android                               ---------------------------    ...
Designer says: Bar height.50px on iOS, 48px on Android  iOS                     Android50px                        48px   ...
Designer says:#of tabs in view: 5on iOS, 3 words on AndroidiOS                      Android                               ...
Designer says:       Do not use the tab         bar for actions
Developer says_   Position and size your tab bar for each platform                       using CSS
Developer says_         @font-face      A custom web font for your icons             can be good, bro.
Developer says_Tab bar icons works like“push” buttons.As soon as you tapthem, they highlight andactivate.Easy, right?
Developer says_Give the browser time to render the highlight.
Cross platform solution with CSSTwitterApp UI implementationon iOS and AndroidIdentifying commonelements andpositioning th...
Cross platform solution with CSSYappUI implementation oniOS and Android.Identifying commonelements andpositioning them inc...
AlternativesMain Menu page:               Facebook                       Pinterest:Creates more drill downs      Side menu...
Drilling down[ used to navigate to sub sections ]
[ Drill downs on iOS and Android]
Designer says:Show user’s path and current location (title barand Back button) iOS                        Android         ...
Designer says:#of drill downs (more than 2-3 feels like too much   drilling especially if you don’t use a tab bar to   nav...
Designer says:• Animated feedback• Information hierarchy                          --------------------------------        ...
Developer says_Title bar and body animatedifferently350mseaseInOutQuint
Developer says_Animation tips1) Avoid DOM changes or other callbacks firingduring animation2) Use hardware-accelerated ani...
Developer says_Show compositingbordersdefaults writecom.apple.SafariIncludeInternalDebugMenu 1
AlternativesFacebookModalSlide up toDrill intocontent
Segmented controls / tabs & spinners [ used to show different vies     of the same content]
Designer says:Use segmented controls to avoid a level ofdrill downs                                      -----------------...
[ Tab controls or drop down menus on Android ]                                            Spinner
Designer says:iOS: use on app’s main   sections where back   button is not needed   Highlight current   segment (no title ...
Developer says_                  Tab bar tips apply.     Use a scrolling library with snap-to for        horizontal scroll...
Interlude A word aboutSkeumorphic UI
Scrollbars
Designer says:          Scrollbars appear only         when you need them                            ---------------------...
Designer says:     Make sure scrollbar is visible on any   background. (ios uses a semi transparent     black scrollbar wi...
Designer says:        Overshoot animation (ios) vs.  overscrollcolor (android). Overshoot on ios    created a new UI layer...
Overshoot:below the ZERO line Pull to refresh             Yapp Gesture action discovered   Promo message at overshoot
Developer says_        Duuuude, really?                  Unfortunately, yes.         No usable native scrolling yet.
Developer says_                  Use a library.              iScroll, Zyngascroller
Text Fields
Designer says:• Auto-populate text field and auto-complete• Use text field Clear button                                   ...
Developer says_    No browser events for  keyboard hiding/showing.
Developer says_             Doesn’t work
Developer says_          Virtual keyboard     Resizes          Overlays    viewport          window
Developer says_                  Clear field  Position the icon with CSS, clear      the text with Javascript
Developer says_  When you need to implement your own        autocomplete (iOS only):
Q&A
@lukemelia @yaelsahar  @yapphttp://yapp.uswe are hiring!
ResourcesApple Human Interface Guidelines:https://developer.apple.com/library/ios/#documentation/UserExperience/Conceptual...
