Electricity and Electronic

  1. 1. Electricity and Electronic Lesson 2, Technology Sección bilingüe Xosé M. Rodríguez
  2. 2. Electrical magnitudes <ul><li>Voltage ( sometimes also called electric potential difference or electrical tension ) is the electrical potential difference between two points of an electrical or electronic circuit, expressed in volts . </li></ul><ul><li>Electric current is the flow of electrical charge. The amount of electric charges flowing through a section in a second. The SI unit of electric current is the ampere . </li></ul><ul><li>Electrical resistance is a measurement of the difficulty encountered by an electric current through an electrical circuit. Resistance is measured in ohms (Ω). </li></ul>
  3. 3. Ohm's law. <ul><li>The direct current flowing in an electrical circuit is directly proportional to the voltage applied to the circuit. The constant of proportionality R, called the electrical resistance , is given by the equation below, </li></ul>
  4. 4. Resistors association <ul><li>Resistors in a parallel: In this configuration each resistor has the same voltage. To find their total equivalent resistance (Req): </li></ul>
  5. 5. Resistors association <ul><li>Resistor in Series: the current through resistors in series stays the same, but the voltage across each resistor can be different. The sum of the potential differences (voltage) is equal to the total voltage. To find their total resistance: </li></ul>
  6. 6. Electronic devices http://www.bbc.co.uk/schools/gcsebitesize/design/electronics/materialscomponentsrev1.shtml
  7. 7. Resistors A resistor is a two-terminal electronic component designed to oppose an electric current by producing a voltage drop between its terminals in proportion to the current. Color code of resistors
  8. 8. Variable resistors A potentiometer is a three-terminal resistor with a sliding contact to change the value. Potenciometer . LDR (Light Dependent Resistor) Is a resistor whose resistance decreases with increasing incident light intensity Temperature Dependent Resistors NTC PTC Is a resistor whose resistance increases with increasing temperature. Is a resistor whose resistance decreases with increasing temperature.
  9. 9. Semiconductors <ul><li>A diode is the simplest form of semiconductor. Diodes are a discrete component that allows current to flow in one direction only . </li></ul><ul><li>The direction that current is allowed to pass is called the forward bias. The direction that current is not allowed to pass is called the reverse bias. A diode has two leads: for forward bias, the current comes in at the anode (positive lead) and out at the cathode (negative lead). </li></ul>Forward Reverse
  10. 10. LED A LED is a semiconductor diode that emits light when an electric current is applied in the forward direction of the device.
  11. 11. Transistor <ul><li>Electronics began with the development of the transistor in the 1950s. Transistors are essentially tiny semiconductor amplifiers and/or switches , several thousands of which can be put on a 1mm2 piece of silicon. </li></ul><ul><li>Transistors have three leads: </li></ul><ul><li>emitter , </li></ul><ul><li>collector </li></ul><ul><li>base . </li></ul><ul><li>The base lead controls the transistor: applying an electrical current to the base lead switches the transistor on . When the transistor is on, current flows from the collector to the emitter - but when it is off no current will flow. </li></ul>NPN PNP
  12. 12. Transistors are easily damaged, so it is important not to mix up the three leads. To help identify the leads some transistors have a dot near the collector, and/or a tab near the emitter. Each type of transistor is identified by a code printed on the side and then you can learn about it in the datasheet .
  13. 13. Transistors: regions of operation <ul><li>Active . I c = GAIN . I B </li></ul><ul><li>Saturation : the base electrical current (I B ) is high, then the collector electrical current (I C ) is constant, I sat , called saturation current. </li></ul><ul><li>Cutoff : the base electrical current is zero, I B =0 A, or very low, then there is no current in the collector, I C =0 A. The transistor doesn´t allow the flow of charges. </li></ul>
  14. 14. Some transistors
  15. 15. Darlington pairs Some transistors can take a very low current flowing in the base and amplify it to give a much higher current in the collector (called gain ). Other transistors can output a large current at the collector - but without very much gain. Single transistors cannot have both high gain and high collector current. To overcome this problem, a high-gain transistor is paired up with a high-current transistor in what is called a Darlington pair . The combined transistors allows both a higher gain and a larger amount of current to flow than would be possible with a single transistor . Darlington pairs are often used to drive motors.
  16. 16. Transistor <ul><li>http://www.ieee-virtual-museum.org/media/Transistor_final.swf </li></ul>
  17. 17. Capacitor <ul><li>A capacitor is a discrete component which can store an electrical charge for a period of time. The larger the capacitance the more charge it can store. </li></ul><ul><li>The unit of measurement of a capacitor is the farad . Often you will see capacitors of much less than a farad. These will be measured in microfarads (one millionth of a farad or 1/1,000,000) or picofarads (one million-millionth of a farad or 1/1,000,000,000,000). </li></ul><ul><li>There are two types of capacitor: </li></ul><ul><li>polarised or electrolytic capacitors, and </li></ul><ul><li>non-polarised or non-electrolytic capacitors </li></ul>
  18. 18. Some capacitors
  19. 19. Relay <ul><li>Relay : is an electrical switch that opens and closes under the control of another electrical circuit. The switch is operated by an electromagnet to open or close one or many sets of contacts. </li></ul>
  20. 22. Very simple circuit Light sensor
  21. 23. Vin Potential divider
  22. 24. I Base Cutoff : I BASE = 0 A => I Collector = 0 A Saturation : I BASE is high => I Collector = I CSAT I collector BC548 I CSAT = 10 mA Look for this data in the web (datasheet) I emitter
  23. 26. Humidity sensor

×
