MONTREAL 1/3 JULY 2011ERRestPascal RobertConatus/MacTI
The Menu•   Whats new in ERRest        •   Debugging•   Security                    •   Caching (Sunday!)•   Versioning   ...
Whats New in ERRest
Anymous updates•   No need to send the ids of nested objects anymore•   Call ERXKeyFilter.setAnonymousUpdateEnabled(true)•...
Anonymous update      protected ERXKeyFilter filter() {       ERXKeyFilter filter = ERXKeyFilter.filterWithAttributes();  ...
Sort ordering on 1:N•   You can now sort a 1:N relationship•   Call ERXKeyFilter.setSortOrderings()
Sort orderingERXKeyFilter filter = ERXKeyFilter.filterWithAttributes();ERXKeyFilter categoryFilter = ERXKeyFilter.filterWi...
Ignoring unknow keys•   By default, returns status 500 if unknow attribute is found in    request•   To ignore those error...
ERXRouteController.performActi         onName That method have been split in 5 methods to make it easier to override on th...
ERXRestContext•   Hold a userInfo dict + the editing context•   Can pass a different date format per controller•   Overrid...
ERXRestContext   public class BlogEntryController extends BaseRestController {...  @Override  protected ERXRestContext cre...
Other new stuff•   More strict HTTP status code in responses•   Support for @QueryParam, @CookieParam and    @HeaderParam ...
Security
What other REST services uses?•   Twitter and Google: OAuth•   Amazon S3: signature•   Campaign Monitor: Basic Authenticat...
Security•   Basic Authentification•   Sessions•   Tokens
USE SSL!
Basic Auth
Basic Auth•   Pros:    •   99.9% of HTTP clients can work with it    •   Easy to implement•   Cons:    •   Its just a Base...
Implementing Basic Auth    protected void initAuthentication() throws MemberException, NotAuthorizedException {    String ...
Implementing Basic Auth    @Overridepublic WOActionResults performActionNamed(String actionName, boolean throwExceptions) ...
Sessions•   Pros:    •   Can store other data on the server-side (but REST is suppose to be        stateless)    •   Easy ...
Login with a session     curl -X GET http://127.0.0.1/cgi-bin/WebObjects/App.woa/ra/users/login.json?username=auser&passwo...
Login with a sessionprotected void initAuthentication() throws MemberException, NotAuthorizedException {  if (context().ha...
Tokens•   Pros:    •   No timeout based on inactivity (unless you want to)•   Cons:    •   More work involved    •   Clien...
Login with a token curl -X GET http://127.0.0.1/cgi-bin/WebObjects/App.woa/ra/members/login.json?username=auser&password=m...
Login with a token   public static final ERXBlowfishCrypter crypter = new ERXBlowfishCrypter();protected void initTokenAut...
Browser vs System-to-System  It near impossible to have a REST backend with security that  works well with both browsers-b...
Handling HTML and routes auth    @Overrideprotected WOActionResults performHtmlActionNamed(String actionName) throws Excep...
Other options•   OAuth•   Custom HTTP Authentication scheme•   Digest Authentification•   OpenID•   API Key (similar to tok...
Versioning
Versioning•   Try hard to not having to version your REST services...•   ... but life is never as planified•   Use mod_rewr...
VersioningIn Apache config:  RewriteEngine On  RewriteRule ^/your-service/v1/(.*)$ /cgi-bin/WebObjects/YourApp-v1.woa/ra$1...
Versioning: the gotchaWatch out for schema changes or other changes that can breakold versions if all versions use the sam...
HTML routing
HTML routing?•   Power of ERRest + WO/EOF + clean URLs!•   Like DirectActions, but with a lot of work done for you•   Usef...
Automatic routing: damn easy•   Create a REST controller for your entity and set    isAutomaticHtmlRoutingEnabled() to tru...
Passing data to the componentUse the ERXRouteParameter annotation to tag methods toreceive data:@ERXRouteParameter public ...
Automatic HTML routingIf the <EntityName><Action>Page component is not found, it will defaultback to the controller and tr...
HTML routing gotchas•   When submitting forms, youre back to the stateful request    handler•   ERXRouteUrlUtils doesnt cr...
Manual HTML routingThats easy: same as a DirectAction: public WOActionResults indexAction() throws Throwable {     return ...
100% RESTpublic Application() {    ERXRouteRequestHandler restRequestHandler = new ERXRouteRequestHandler();    requestHan...
HTML routing: demo
Cool trick: Application Cache              Manifest•   Let you specify that some URLs of your app can be available    offli...
Cache Manifest   In your DirectAction class:  public WOActionResults manifestAction() {    EOEditingContext ec = ERXEC.new...
Debugging
Debugging REST problems•   curl -v : will display all headers and content, for both request and    response•   Firebug and...
Debugging Demo
MONTREAL 1/3 JULY 2011Q&A
