Creating fast, dynamic ACLs in Zend Framework (Zend Webinar)

13,950 views

Published on

Slides from the Zend Webinar on 'Creating fast and dynamic ACLs in Zend Framework' (15 June 2011).

Zend Framework's Access Control Layer system is simple and straight-forward; however, as the number of rules increase in size and complexity, maintenance and performance suffer. The solution: a dynamic, reflection-based ACL system, with built-in caching. Sound complicated?
Don't worry, it's easy to setup and a lot easier to manage! Join this webinar to learn how!

Presenter: Wim Godden

Published in: Technology
  • Be the first to comment

Creating fast, dynamic ACLs in Zend Framework (Zend Webinar)

  1. 1. Creating fast, dynamic ACLs in Zend Framework Wim Godden Cu.be Solutions
  2. 2. Who am I ? <ul><li>Wim Godden (@wimgtr)
  3. 3. Owner of Cu.be Solutions (http://cu.be)
  4. 4. PHP developer since 1997
  5. 5. Developer of OpenX
  6. 6. Zend Certified Engineer
  7. 7. Zend Framework Certified Engineer
  8. 8. MySQL Certified Developer </li></ul>
  9. 9. Talking about... <ul><li>Authentication </li><ul><li>-> Zend_Auth </li></ul><li>Auditing </li><ul><li>-> Zend_Log </li></ul><li>Authorization </li><ul><li>-> Zend_Acl </li></ul></ul>
  10. 10. Authorization <ul>Wikipedia : &quot;the function of specifying access rights to resources&quot; </ul>
  11. 11. What's a resource ? <ul><li>Object (Article, Invoice, Document, …)
  12. 12. Webpage
  13. 13. Database / table / row
  14. 14. ... </li></ul>
  15. 15. Standard ACL <ul><li>Access to resources is defined in privileges
  16. 16. Privileges are grouped together in roles
  17. 17. 2 types of roles : </li><ul><li>Anonymous / Unknown
  18. 18. Registered / Known </li></ul></ul>
  19. 19. Within Zend Framework : Zend_Acl <ul><li>Flexible
  20. 20. Uses standard role, resource principles </li></ul>
  21. 21. Zend_Acl : the good <ul><li>Recognizable -> easy to get started
  22. 22. No link to specific backend
  23. 23. Allow + deny
  24. 24. Proven, tested </li></ul>
  25. 25. Zend_Acl : the bad & ugly <ul><li>Complexity of rules rises quickly
  26. 26. Performance issues
  27. 27. All rules are in-code
  28. 28. -> maintainability becomes an issue </li></ul>
  29. 29. Evolution of a portal $acl = new Zend_Acl(); $acl->addRole( new Zend_Acl_Role( 'guest' )); $acl->addRole( new Zend_Acl_Role( 'member' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'admin' ), 'member' ); $acl->addResource( new Zend_Acl_Resource( 'cms' )); $acl->addResource( new Zend_Acl_Resource( 'report' )); $acl->allow( 'guest' , 'cms' , 'view' ); $acl->allow( 'admin' , 'cms' , 'edit' ); $acl->deny( 'guest' , 'report' ); $acl->allow( 'member' , 'report' );
  30. 30. Evolution of a portal $acl = new Zend_Acl(); $acl->addRole( new Zend_Acl_Role( 'guest' )); $acl->addRole( new Zend_Acl_Role( 'departmentA' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentB' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'admin' ), 'member' ); $acl->addResource( new Zend_Acl_Resource( 'cms' )); $acl->addResource( new Zend_Acl_Resource( 'report' )); $acl->allow( 'guest' , 'cms' , 'view' ); $acl->allow( 'admin' , 'cms' , 'edit' ); $acl->deny( 'guest' , 'report' ); $acl->allow( 'departmentA' , 'report' );
  31. 31. Evolution of a portal $acl = new Zend_Acl(); $acl->addRole( new Zend_Acl_Role( 'guest' )); $acl->addRole( new Zend_Acl_Role( 'departmentA' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentB' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentC_senior_staff' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentC_marketing' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'admin' ), 'member' ); $acl->addResource( new Zend_Acl_Resource( 'cms' )); $acl->addResource( new Zend_Acl_Resource( 'report' )); $acl->addResource( new Zend_Acl_Resource( 'newsletter' )); $acl->addResource( new Zend_Acl_Resource( 'photo' )); $acl->addResource( new Zend_Acl_Resource( 'faq' )); $acl->allow( 'guest' , 'cms' , 'view' ); $acl->allow( 'admin' , 'cms' , 'edit' ); $acl->deny( 'guest' , 'report' ); $acl->allow( 'departmentA' , 'report' ); $acl->deny('departmentC_senior_staff', 'newsletter'); $acl->allow('departmentC_marketing', 'newsletter'); $acl->allow('member', 'photo', 'view'); $acl->allow('departmentC_marketing', 'photo', 'upload'); $acl->allow('admin', 'photo', 'delete'); $acl->allow('guest', 'faq', 'view'); $acl->allow('member', 'faq', 'comment'); $acl->allow('departmentA', 'faq', 'edit'); $acl->allow('departmentC_senior_staff', 'faq', 'edit'); $acl->allow('admin', 'faq', 'edit');
  32. 32. Evolution of a portal $acl = new Zend_Acl(); $acl->addRole( new Zend_Acl_Role( 'guest' )); $acl->addRole( new Zend_Acl_Role( 'departmentA' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentB' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentC_senior_staff' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentC_marketing' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'cook' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'admin' ), 'member' ); $acl->addResource( new Zend_Acl_Resource( 'cms' )); $acl->addResource( new Zend_Acl_Resource( 'report' )); $acl->addResource( new Zend_Acl_Resource( 'newsletter' )); $acl->addResource( new Zend_Acl_Resource( 'photo' )); $acl->addResource( new Zend_Acl_Resource( 'faq' )); $acl->addResource( new Zend_Acl_Resource( 'invoicing' )); $acl->addResource( new Zend_Acl_Resource( 'stats' )); $acl->addResource( new Zend_Acl_Resource( 'lunchmenu' )); $acl->allow( 'guest' , 'cms' , 'view' ); $acl->allow( 'admin' , 'cms' , 'edit' ); $acl->deny( 'guest' , 'report' ); $acl->allow( 'departmentA' , 'report' ); $acl->deny('departmentC_senior_staff', 'newsletter'); $acl->allow('departmentC_marketing', 'newsletter'); $acl->allow('member', 'photo', 'view'); $acl->allow('departmentC_marketing', 'photo', 'upload'); $acl->allow('admin', 'photo', 'delete'); $acl->allow('guest', 'faq', 'view'); $acl->allow('member', 'faq', 'comment'); $acl->allow('departmentA', 'faq', 'edit'); $acl->allow('departmentC_senior_staff', 'faq', 'edit'); $acl->allow('admin', 'faq', 'edit'); $acl->allow('admin', 'photo', 'delete'); $acl->allow('guest', 'faq', 'view'); $acl->allow('member', 'faq', 'comment'); $acl->allow('departmentA', 'faq', 'edit'); $acl->allow('departmentC_senior_staff', 'faq', 'edit'); $acl->allow('admin', 'faq', 'edit'); $acl->allow('cook', 'lunchmenu', 'edit'); $acl->allow('member', 'lunchmenu', 'view'); $acl->allow('accounting', 'invoicing', 'edit'); $acl->allow('admin', 'invoicing', 'edit'); $acl->allow('departmentC_senior_staff', 'invoicing', 'report');
  33. 33. Evolution of a portal $acl = new Zend_Acl(); $acl->addRole( new Zend_Acl_Role( 'guest' )); $acl->addRole( new Zend_Acl_Role( 'departmentA' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentB' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentC_senior_staff' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'departmentC_marketing' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'cook' ), 'guest' ); $acl->addRole( new Zend_Acl_Role( 'admin' ), 'member' ); $acl->addResource( new Zend_Acl_Resource( 'cms' )); $acl->addResource( new Zend_Acl_Resource( 'report' )); $acl->addResource( new Zend_Acl_Resource( 'newsletter' )); $acl->addResource( new Zend_Acl_Resource( 'photo' )); $acl->addResource( new Zend_Acl_Resource( 'faq' )); $acl->addResource( new Zend_Acl_Resource( 'invoicing' )); $acl->addResource( new Zend_Acl_Resource( 'stats' )); $acl->addResource( new Zend_Acl_Resource( 'lunchmenu' )); $acl->allow( 'guest' , 'cms' , 'view' ); $acl->allow( 'admin' , 'cms' , 'edit' ); $acl->deny( 'guest' , 'report' ); $acl->allow( 'departmentA' , 'report' ); $acl->deny('departmentC_senior_staff', 'newsletter'); $acl->allow('departmentC_marketing', 'newsletter'); $acl->allow('member', 'photo', 'view'); $acl->allow('departmentC_marketing', 'photo', 'upload'); $acl->allow('admin', 'photo', 'delete'); $acl->allow('guest', 'faq', 'view'); $acl->allow('member', 'faq', 'comment'); $acl->allow('departmentA', 'faq', 'edit'); $acl->allow('departmentC_senior_staff', 'faq', 'edit'); $acl->allow('admin', 'faq', 'edit'); $acl->allow('admin', 'photo', 'delete'); $acl->allow('guest', 'faq', 'view'); $acl->allow('member', 'faq', 'comment'); $acl->allow('departmentA', 'faq', 'edit'); $acl->allow('departmentC_senior_staff', 'faq', 'edit'); $acl->allow('admin', 'faq', 'edit'); $acl->allow('cook', 'lunchmenu', 'edit'); $acl->allow('member', 'lunchmenu', 'view'); $acl->allow('accounting', 'invoicing', 'edit'); $acl->allow('admin', 'invoicing', 'edit'); $acl->allow('departmentC_senior_staff', 'invoicing', 'report');
  34. 34. Hard to ... <ul><li>maintain all rules
  35. 35. keep track of the rules
  36. 36. debug the rules </li></ul>
  37. 37. Possible solution : database <ul><li>Extend Zend_Acl to database driven design
  38. 38. Good : no code changes required
  39. 39. Bad : more load on DB </li></ul>
  40. 40. A different approach <ul><li>Not THE solution, merely A solution
  41. 41. Uses database, but...
  42. 42. Additional caching layer
  43. 43. ZF Conventional Modular Directory Structure
  44. 44. Backend interface for easy management </li></ul>
  45. 45. Different resources <ul><li>Zend_ACL : </li></ul>$acl->addResource( new Zend_Acl_Resource( 'cms' )); $acl->allow( 'guest' , 'cms' , 'view' ); $acl->allow( 'admin' , 'cms' , 'edit' ); <ul><li>Access to : </li><ul><li>Controller : cms
  46. 46. Action : view / edit </li></ul><li>Why not integrate with the request itself ? </li></ul>
  47. 47. Controller plugins
  48. 48. Zend_Acl as a controller plugin <?php class My_Plugin_Acl extends Zend_Controller_Plugin_Abstract { private $_acl = null; public function __construct(Zend_Acl $acl ) { $this ->_acl = $acl ; } public function preDispatch(Zend_Controller_Request_Abstract $request ) { $role = (Zend_Auth::getInstance()->hasIdentity()) ? 'user' : 'guest' ; //For this example, we will use the controller as the resource: $resource = $request ->getControllerName(); if (! $this ->_acl->isAllowed( $role , $resource , 'view' )) { //If the user has no access we send him elsewhere by changing the request $request ->setModuleName( 'auth' ) ->setControllerName( 'auth' ) ->setActionName( 'login' ) ->setDispatched(false); return false; } } }
  49. 49. Initializing the ACL Let's have a look
  50. 50. Zend_Acl manual rules <?php class My_Acl extends Zend_Acl { public function __construct() { //Add a new role called &quot;guest&quot; $this ->addRole( new Zend_Acl_Role( 'guest' )); //Add a role called user, which inherits from guest $this ->addRole( new Zend_Acl_Role( 'user' ), 'guest' ); //Add a resource called page $this ->add( new Zend_Acl_Resource( 'page' )); //Add a resource called news, which inherits page $this ->add( new Zend_Acl_Resource( 'news' ), 'page' ); //Finally, we want to allow guests to view pages $this ->allow( 'guest' , 'page' , 'view' ); //and users can comment news $this ->allow( 'user' , 'news' , 'comment' ); } }
  51. 51. Our ACL id role_id module controller action 1 2 newsletter send index 2 1 cms article edit 3 3 % % % id name email pw 1 Chris [email_address] ******* 2 Jake [email_address] ******* 3 Jeniffer [email_address] ******* id name 1 webmaster 2 marketeer 3 admin user_id role_id 1 2 2 3 3 1
  52. 52. Application_Acl class Application_Acl { public function isAllowed($user = null , $request = null , $privilege = null ) { if (is_null($user) === false && $user !== false && $user instanceof User) { $userId = $user-> id ; } else { $userId = 0; } $db = Zend_Db_Table:: getDefaultAdapter (); $stmt = $db->query( ' select module_name, controller_name, action_name from privilege join role on role.id = privilege.role_id join userRole on userRole.role_id = role.role_id where userRole.user_id = ? and ( module_name = &quot;%&quot; or ( module_name = ? and ( controller_name = &quot;%&quot; or ( controller_name = ? and ( action_name = &quot;%&quot; or action_name = ? ) ) ) ) ) ' , array ( $userId, $request->getModuleName(), $request->getControllerName(), $request->getActionName() ) ); $stmt->execute(); $row = $stmt->fetch(); // Returns a row or false if ($row !== false ) { return true ; } else { return false ; } } }
  53. 53. To cache or not to cache - Option 1 (no cache) <ul><li>1 query per ACL request
  54. 54. = 1 query per pageview / ajax request
  55. 55. 99.99% will be identical
  56. 56. -> &quot;Just rely on MySQL query cache !&quot;
  57. 57. FAIL !
  58. 58. Even for cached queries, MySQL connections use memory, I/O, CPU, ... </li></ul>
  59. 59. Caching - Option 2 (cache the main query) <ul><li>1 DB query per user for each unique ACL request
  60. 60. User with 20 privileges -> 20 possible requests
  61. 61. All subsequent pageviews : 1 cache request </li></ul>
  62. 62. What's in the cache ? Entry Data acl_user_3_%_%_% 1 acl_user_1_cms_article_edit 1 acl_user_1_admin_destroy_planet 0 <ul>Problem : what if we add a privilege to a role ? <ul>-> All cached entries for all users should be refreshed (ouch !) </ul></ul>
  63. 63. Caching - Option 3 - denormalize in cache
  64. 64. What's in the cache ? Entry Data acl_user_3 3, 1, 4 acl_user_1 3, 1, 2 acl_role_1 a:3:{i:0;s:45:&quot;a:2:{i:0;s:5:&quot;%_%_%&quot;;}&quot;;i:1;i:1308106740;i:2;s:6:&quot;604800&quot;;} User's roles Privileges listed in a role
  65. 65. Caching - Option 3 - denormalize in cache <ul><li>1 DB query per user at login (retrieve user's roles)
  66. 66. User with 20 privileges -> just 1 DB query
  67. 67. 1 cache query per pageview + 1 per role
  68. 68. Good : </li><ul><li>Less queries on DB
  69. 69. Less data in the cache (only roles, not full privileges of each user)
  70. 70. Add a privilege to a role -> update the role only </li></ul><li>Bad : </li><ul><li>More queries on cache </li></ul><li>Choice : depends on where your highest load is </li><ul><li>(but memory is cheap and Memcache is fast !) </li></ul></ul>
  71. 71. Caching - let's have a look
  72. 72. Managing the roles / privileges <ul><li>Zend_Acl : manual typ(o)ing
  73. 73. Goals : </li><ul><li>automation
  74. 74. easy management </li></ul><li>-> Reflection </li></ul>
  75. 75. Reflection ? <ul><li>Used to inspect objects during run-time
  76. 76. Available since PHP 5.0
  77. 77. Can be applied to : </li><ul><li>Classes
  78. 78. Objects
  79. 79. Methods
  80. 80. Functions
  81. 81. Properties
  82. 82. Extensions </li></ul></ul>
  83. 83. Reflection - example <?php class Test { static public function testMe ($reason) { echo 'I have a reason : ' . $reason; } } $reflector = new ReflectionClass( 'Test' ); echo 'Class name : ' . $reflector->getName() . &quot;n&quot; ; echo &quot;Methods : n&quot; ; var_dump($reflector->getMethods()); Outputs : Class name : Test Methods : array(1) { [0]=> &object(ReflectionMethod)#2 (2) { [&quot;name&quot;]=> string(6) &quot;testMe&quot; [&quot;class&quot;]=> string(4) &quot;Test&quot; } }
  84. 84. Backend interface with reflection
  85. 85. <ul>Questions ? </ul>
  86. 86. Contact <ul><li>Web http://techblog.wimgodden.be
  87. 87. Slides http://www.slideshare.net/wimg
  88. 88. Twitter @wimgtr
  89. 89. E-mail [email_address] </li></ul>
  90. 90. <ul>Thanks ! </ul>Feel free to rate my webinar at http://tinyurl.com/acltalk

×
