Planting Trees in Urban Areas

  1. 1. planting trees in urban areas
  2. 2. Slideshow Content <ul><li>Site assessment for urban tree planting </li></ul><ul><li>Basic planting design </li></ul><ul><li>Special considerations for urban tree planting </li></ul><ul><li>Site preparation </li></ul><ul><li>Planting and maintenance techniques </li></ul>
  3. 3. Site Assessment for Urban Tree Planting <ul><li>Collect detailed information about conditions at previously identified planting sites </li></ul><ul><li>Use information to: develop planting plan, determine what to plant, where to plant and what special methods are needed to reduce urban impacts on trees </li></ul>
  4. 4. Impacts of Urbanization on Trees <ul><li>Air pollution </li></ul><ul><li>Poor soils </li></ul><ul><li>Exposure to wind </li></ul><ul><li>Drought </li></ul><ul><li>Flooding/standing water </li></ul><ul><li>Increased temperature </li></ul><ul><li>Competition </li></ul><ul><li>Disease </li></ul><ul><li>Damage from humans </li></ul><ul><li>Damage from animals </li></ul><ul><li>Salt from roads </li></ul><ul><li>Inadequate soil volume </li></ul><ul><li>Improper maintenance </li></ul><ul><li>Conflicts with infrastructure </li></ul>
  5. 5. Urban Reforestation Site Assessment (URSA) <ul><li>Major Sections: </li></ul><ul><li>General site information </li></ul><ul><li>Climate </li></ul><ul><li>Topography </li></ul><ul><li>Vegetation </li></ul><ul><li>Soils </li></ul><ul><li>Hydrology </li></ul><ul><li>Potential planting conflicts </li></ul><ul><li>Planting and maintenance logistics </li></ul><ul><li>Site sketch </li></ul>
  6. 6. Basic Planting Design <ul><li>Plant species – diversity is important, select species that are appropriate for the site and tolerant of urban conditions </li></ul><ul><li>Plant materials – select from balled and burlapped, container grown, bare root </li></ul><ul><li>Plant spacing – based on desired density, should account for plant survival rates </li></ul><ul><li>Planting plan – should include species list, sketch, planting dimensions, instructions, supply list, site preparation, schedule and cost estimate </li></ul>
  7. 7. Urban Tree Selection Guide <ul><li>Specific to the mid-Atlantic and Northeastern U.S. </li></ul><ul><li>Used to select species that can tolerate the environmental conditions at the site and perform specific functions </li></ul><ul><li>Chart 1: Environmental Conditions - hardiness zone, soil moisture, sun exposure, soil composition, and tolerance of drought, inundation, pests/disease, soil compaction , salt, and pH </li></ul><ul><li>Chart 2: Tree Characteristics – growth rate, mature height, canopy spread, form/habit, root structure, fruits, flowers </li></ul>
  8. 8. Example Planting Plan Sketch Source: Omaha Public Power District
  9. 9. Special Considerations for Urban Tree Planting <ul><li>Calculate soil volume </li></ul><ul><li>Evaluate potential for stormwater treatment </li></ul><ul><li>Recommend setbacks between trees and infrastructure </li></ul><ul><li>Other methods to reduce infrastructure conflicts </li></ul><ul><li>Protect trees from human and animal impacts </li></ul>
  10. 10. Calculate Soil Volume <ul><li>Typical tree pit in an urban area is only 4 feet by 4 feet in area – about 50 ft 3 of soil </li></ul><ul><li>Tree roots are typically confined to the pit due to compacted soils </li></ul><ul><li>Use designs that provide as much soil as possible for trees </li></ul>
  11. 11. Calculate Soil Volume Source: Jim Urban
  12. 12. Evaluate Potential for Stormwater Treatment <ul><li>Many urban trees either receive too much stormwater runoff or do not receive enough water because surrounding pipes and pavement direct water away </li></ul><ul><li>Stormwater management and planting strategies should be used to manage runoff at planting sites that receive too much water and to direct runoff to other planting sites to provide treatment and reduce irrigation needs </li></ul>
  13. 13. Evaluating Potential for Stormwater Treatment <ul><li>Sites should be evaluated to determine if they are: </li></ul><ul><ul><li>Under-capacity : currently does not receive runoff; runoff bypasses the site in pipe/ditch or is infiltrated </li></ul></ul><ul><ul><li>At-capacity : receive sheetflow only </li></ul></ul><ul><ul><li>Over-capacity : receive excessive runoff </li></ul></ul>
  14. 15. Recommended Setbacks Between Trees and Infrastructure
  15. 16. Trees vs. Pavement <ul><li>Tree roots crack or lift pavement if inadequate setbacks are used </li></ul><ul><li>10 to 15 foot setbacks are recommended </li></ul>
  16. 17. Trees vs. Utilities <ul><li>Falling limbs can cause power outages, trees can grow into wires </li></ul><ul><li>Maintenance/repair of utilities can damage tree </li></ul><ul><li>Recommended setbacks from overhead wires: </li></ul><ul><ul><li>10 feet for small trees </li></ul></ul><ul><ul><li>15-20 feet for medium trees </li></ul></ul><ul><ul><li>20 to 40 feet for large trees </li></ul></ul><ul><ul><li>Trees planted under overhead wires must be 10 to 15 feet below the height of the wires at maturity </li></ul></ul><ul><li>Recommended setback from underground utilities is 10-15 feet </li></ul>
  17. 19. Trees vs. Sewer and Drainage Pipes <ul><li>Tree roots can clog or break sewer and drainage pipes –although most damage occurs with older sewer systems </li></ul><ul><li>Trees that cause damage to sewer pipes are often removed </li></ul><ul><li>Recommended setbacks: </li></ul><ul><ul><li>15-25 feet between trees and perforated pipes </li></ul></ul><ul><ul><li>10 feet between trees and sewer lines </li></ul></ul>
  18. 20. Trees vs. Buildings <ul><li>Tree roots may crack foundations if planted too close to buildings </li></ul><ul><li>Root growth may become one-sided and cause tree to topple from high winds. </li></ul><ul><li>Recommended setbacks: </li></ul><ul><ul><li>15 feet for small trees </li></ul></ul><ul><ul><li>20-25 feet for large trees </li></ul></ul>
  19. 21. Other Recommended Setbacks <ul><li>10 foot setback between trees and lighting </li></ul><ul><li>10 foot setbacks between trees/shrubs and the centerline of trails (for safety) </li></ul>
  20. 22. Other Methods to Reduce Infrastructure Conflicts <ul><li>Species selection </li></ul><ul><li>Alternative sidewalk design </li></ul><ul><li>Alternative sidewalk materials </li></ul><ul><li>Root guidance systems </li></ul><ul><li>Structural soils </li></ul><ul><li>Maintenance strategies </li></ul>
  21. 23. Species Selection <ul><li>“ The right tree in the right place” </li></ul><ul><li>Selecting species with specific characteristics can reduce infrastructure conflicts: </li></ul><ul><ul><li>Choose shallow-rooted species when planting near sewer or drainage pipes </li></ul></ul><ul><ul><li>When planting near overhead wires, choose species with columnar form </li></ul></ul><ul><ul><li>Species with a small trunk flare or root buttress characteristics are ideal for planting next to pavement </li></ul></ul>
  22. 24. Alternative Sidewalk Design
  23. 25. Alternative Sidewalk Materials <ul><li>Reinforced or thicker concrete slabs </li></ul><ul><li>Asphalt </li></ul><ul><li>Pervious concrete </li></ul><ul><li>Decomposed granite and compacted gravel </li></ul><ul><li>Permeable pavers </li></ul><ul><li>Recycled rubber </li></ul><ul><li>Mulch </li></ul>
  24. 26. Root Guidance Systems <ul><li>Direct root growth away from infrastructure by restricting root growth laterally or radially, or by directing roots to appropriate areas </li></ul><ul><li>Examples: root barriers, root paths, steel plates, root channels, continuous soil trench </li></ul>
  25. 27. Structural Soils Graphic by Matt Arnn
  26. 28. Maintenance Strategies <ul><li>Use directional pruning instead of topping when pruning trees near overhead wires </li></ul><ul><li>Use tunneling as an alternative to trenching when installing or repairing underground utilities near trees </li></ul><ul><li>Use alternatives to root pruning to minimize damage to trees </li></ul>
  27. 29. Protect Trees from Human and Animal Impacts <ul><li>Beaver </li></ul><ul><li>Deer </li></ul><ul><li>Human Impacts </li></ul><ul><ul><li>Lawnmowers </li></ul></ul><ul><ul><li>Damage from vehicles </li></ul></ul><ul><ul><li>Vandalism </li></ul></ul><ul><ul><li>Foot traffic </li></ul></ul>
  28. 30. Protect Trees from Deer
  29. 31. Site Preparation Methods <ul><li>Trash and debris cleanup </li></ul><ul><li>Invasive plant control </li></ul><ul><li>Soil amendments </li></ul>
  30. 32. Trash and Debris Cleanup <ul><li>May be done with volunteers </li></ul><ul><li>Evaluate the site to determine the type and volume of trash </li></ul><ul><li>Implement measures to prevent future dumping </li></ul>
  31. 33. Invasive Plant Control Methods <ul><li>Hand removal </li></ul><ul><li>Mowing </li></ul><ul><li>Heavy equipment removal </li></ul><ul><li>Solarization </li></ul><ul><li>Girdling </li></ul><ul><li>Burning </li></ul><ul><li>Chemical </li></ul><ul><li>Cultural </li></ul><ul><li>Biological </li></ul>
  32. 34. Soil Amendments <ul><li>Compost : improves water and nutrient-holding capacity, increases nutrients, reduces compaction </li></ul><ul><li>Gypsum : decreases soil salinity, increases calcium and sulfur without affecting pH, enhances structure of clay soils </li></ul><ul><li>Limestone: decreases soil acidity </li></ul><ul><li>Peat: increases organic matter, acidity, and water and nutrient-holding capacity without increasing nutrient content </li></ul><ul><li>Sulphur: increases soil acidity </li></ul>
  33. 35. Typical Characteristics of Urban Soils <ul><li>Severe compaction </li></ul><ul><li>Elevated pH </li></ul><ul><li>Low organic matter </li></ul><ul><li>Low nutrients </li></ul><ul><li>Poor drainage </li></ul><ul><li>Pollutants may be present </li></ul>Source: Cornell Urban Horticulture Institute Healthy soil Compacted urban soil
  34. 36. Planting and Maintenance Techniques <ul><li>Tree planting techniques </li></ul><ul><li>Encourage natural regeneration </li></ul><ul><li>Maintenance techniques </li></ul>
  35. 37. Tree Planting Techniques <ul><li>Planting hole must be 2 to 3 times wider than the root ball because roots spread out laterally rather than going deep </li></ul><ul><li>Do not plant tree too deep </li></ul><ul><li>Technique varies with plant materials and when planting on slopes </li></ul><ul><li>Use tree shelters and mulch to protect tree if necessary </li></ul><ul><li>Stake only on very windy sites or with top-heavy trees </li></ul>
  36. 38. Tree Planting Specification Copyright International Society of Arboriculture. Used with permission.
  37. 39. Mulching Trees
  38. 40. Natural Regeneration <ul><li>Natural regeneration is the simplest and cheapest way to reforest: simply stop mowing </li></ul><ul><li>In urban areas, poor soils and lots of invasive species and deer can make regeneration difficult </li></ul><ul><li>Good candidate sites have: desirable tree seed sources nearby, adequate seed dispersal methods, bare mineral soils with good seed/soil contact, few invasive plants, controlled deer populations, and no sod-forming grasses (e.g., fescue) </li></ul>
  39. 41. Encourage Natural Regeneration <ul><li>To encourage natural regeneration: </li></ul><ul><li>Amend soils problems </li></ul><ul><li>Control deer </li></ul><ul><li>Control invasive species </li></ul><ul><li>Disc soils if sod is present </li></ul><ul><li>Install perches to encourage seed dispersal by birds </li></ul><ul><li>Supplement with plantings if necessary </li></ul>
  40. 42. Tree Inspection and Maintenance <ul><li>Post planting and long-term inspection </li></ul><ul><li>Watering </li></ul><ul><li>Pruning </li></ul><ul><li>Weed control </li></ul><ul><li>Integrated Pest Management </li></ul>
