JSOP in 60 seconds

David Nuescheler
David NueschelerVP, Enterprise Technology at Adobe
Introducing:

JSOP
Pitch & Goal
- Browser enabled, HTTP-based protocol
  designed to exchange fine-grained
  information efficiently.

- Easy to consume by todays
  Web-”Gear” (browsers, flash & friends)

- Probably suitable for an RFC @ IETF
Basics
- Serialization to JSON (optionally YAML/XML)
- GET (batch/hierarchical)
- PUT (batch/hierarchical)
- PATCH (json diff content type)
- Support for binary as multipart
Retro-style
- PUT & PATCH -> multipart POST
- Allows for Simple HTML forms
Extensions
- Sort-Order
- Query
- Typing
- Locking
- Versioning
- Essentially: WebDAV + friends but simple
Sample GET
Request:
GET /myfolder.json HTTP/1.1

Response:
{
"createdBy" : "uncled",
"name" : "myfolder",
"id" : "50d9317a-3a95-401a-9638-333a0dbf04bb"
"type" : "folder"
}
Sample GET 2
Request:
GET /myfolder.4.json HTTP/1.1

Response:
{
"createdBy" : "uncled",
"name" : "myfolder",
"id" : "50d9317a-3a95-401a-9638-333a0dbf04bb"
"type" : "folder"

"child1" :
  {
  "grandchild11" :
    {
    "depth3" :
      {
      "depth4 : { ... }
      }
    }
  }
}
Sample PUT
PUT /myfolder HTTP/1.1

{
"createdBy" : "uncled",
"name" : "myfolder",
"id" : "50d9317a-3a95-401a-9638-333a0dbf04bb"
"type" : "folder"

"child1" :
  {
  "grandchild11" :
    {
    "depth3" :
      {
      "depth4 : { ... }
      }
    }
  }
}
Sample PATCH
PATCH /myfolder HTTP/1.1

+newdoc : { "type" : "document", "createdBy" : "me" }
-olddoc
>movingdoc : /otherfolder/mydocument
^lastModifiedBy : "me"
PATCH diff ops
"+":
create Node/Property/Resource

"^":
update Node/Property/Resource

"-":
delete Node/Property/Resource

">":
move Node/Property/Resource
PATCH diff
diff       ::=   members
members    ::=   pair | pairs
pair       ::=   key [ " : " value ]
pairs      ::=   pair line-end pair | pair line-end pairs
line-end   ::=   "rn" | "n" | "r"
key        ::=   opchar id
opchar     ::=   "+" | "^" | "-" | ">"
id         ::=   * identification url (path | id) *
value      ::=   value+ | value- | value^ | value>
value+     ::=   * a JSON object *
value-     ::=   ""
value^     ::=   * any JSON value except JSON object *
value>     ::=   id
POST wrap 1
POST /myfolder/my.gif HTTP/1.1
Content-Type: multipart/form-data;
boundary=---------21447684891610979728262467120
Content-Length: 123

---------21447684891610979728262467120
Content-Disposition: form-data; name="data"
Content-Type: image/gif

GIF89a...................!.......,............s...f.;
---------21447684891610979728262467120
Content-Disposition: form-data; name="jsop:diff"
Content-Type: text/plain

^lastModifiedBy : "me"
+exif { cameraMake : "Apple", cameraModel : "Apple" }
---------21447684891610979728262467120--
POST wrap 2
POST /myfolder/my.gif HTTP/1.1
Content-Type: multipart/form-data;
boundary=---------21447684891610979728262467120
Content-Length: 123

---------21447684891610979728262467120
Content-Disposition: form-data; name="exif/cameraMake"
Content-Type: text/plain

Another Vendor
---------21447684891610979728262467120--
POST wrap 3
POST /myfolder/ HTTP/1.1
Content-Type: multipart/form-data;
boundary=---------21447684891610979728262467120
Content-Length: 123

---------21447684891610979728262467120
Content-Disposition: form-data; name=""; filename="my.gif"
Content-Type: image/gif

GIF89a...................!.......,............s...f.;
---------21447684891610979728262467120
Content-Disposition: form-data; name=""; filename="yo.gif"
Content-Type: image/gif

GIF89a...................!.......,............s...f.;
---------21447684891610979728262467120 --
