Christopher ShainSoftware Development LeadTresata
   Hadoop for Financial Services   First completely Hadoop-powered analytics    application   Widely recognized as “Big...
   Software Development Lead at Tresata   Background in Financial Services IT     End-User Applications     Data Wareh...
   What is HBase?     From: http://hbase.apache.org:      ▪ “HBase is the Hadoop database.”     I think this is a confu...
   ‘Database’, to many, means:     Transactions     Joins     Indexes   HBase has none of these     More on this later
   HBase is a data storage platform designed to    work hand-in-hand with Hadoop       Distributed       Failure-tolera...
   Need for a low-latency, distributed datastore    with unlimited horizontal scale   Hadoop (MapReduce) doesn’t provide...
   November 2006: Google BigTable whitepaper    published:    http://research.google.com/archive/bigtable.html February ...
   Web Indexing   Social Graph   Messaging (Email etc.)
   HBase is written almost entirely in Java     JVM clients are first-class citizens                                    ...
   All data is stored in Tables   Table rows have exactly one Key, and all rows in a    table are physically ordered by ...
   Defined by the Table   A Column Family is a group of related    columns with it’s own name   All columns must be in ...
      Not exactly the same as rows in a traditional        RDBMS         Key: a byte array (usually a UTF-8 String)     ...
   All cells are created with a timestamp   Column family defines how many versions of    a cell to keep   Updates alwa...
    HBase deletes are a form of write called a     “tombstone”    Indicates that “beyond this point any previously     w...
   Requirement: Store real-time stock tick data     Ticker   Timestamp      Sequence    Bid      Ask      IBM     09:15:0...
Historical Prices:          Keys                   Column             DataType                     Ticker               Va...
Row Key                             Family:Column                                                 Prices:Bid[Ticker].[Rev_...
   HBase scales horizontally   Needs to split data over many RegionServers   Regions are the unit of scale
   All HBase tables are broken into 1 or more    regions   Regions have a start row key and an end row    key   Each Re...
“Users” Table                                         Row Keys in Region                                         “Aaron” –...
Deceptively simple
ZooKeeper                                           Cluster                                                 Backup HBase  ...
   ZooKeeper     Keeps track of which server is the current HBase     Master   HBase Master     Keeps track of Region/...
   RegionServer     Stores table regions   Clients     Need to be smarter than RDBMS clients     First connect to Zoo...
-ROOT- Table                 info:regioninfo.META.[region]   info:server               Points to DataNode hosting         ...
   HBase Master is not necessarily a single point of    failure (SPOF)     Multiple masters can be running     Current ...
ZooKeeper Quorum                 ZooKeeper                   Node     ZooKeeper               ZooKeeper       Node        ...
   HBase tolerates RegionServer failure when    running on HDFS     Data is replicated by HDFS (dfs.replication setting)...
    Similar to log in many RDBMS    All operations by default written to log before considered     ‘committed’ (can be o...
RegionServer Region                  Store                         Store                     Store                        ...
   A RegionServer is not guaranteed to be on    the same physical node as it’s data   Compaction causes RegionServer to ...
   All data is in memory initially (memstore)   HBase is a write-only system     Modifications and deletes are just wri...
   All HBase edits are initially stored in memory    (memstore)   Flushes occur when memstore reaches a    certain size ...
   Triggered when a certain number of HFiles are created for    a given Region Store (+ some other conditions)     By de...
   Triggered every 24 hours (with random    offset) or manually     Large HBase installations usually leave this for    ...
   HBase does not have transactions   However:     Row-level modifications are atomic: All      modifications to a row ...
   DO: Design your schema for linear range scans on your    most common queries.     Scans are the most efficient way to...
   DO: Be mindful of the size of your row and column    keys     They are used in indexes and queries, can be quite     ...
   DO: Query single rows using exact-match on key    (Gets) or Scans for multiple rows     Scans allow efficient I/O vs....
   Deceptively simple                                    HBase Master                   JVM Clients      RegionServer    ...
ZooKeeper Quorum                 ZooKeeper                   Node     ZooKeeper               ZooKeeper       Node        ...
RegionServer Region                  Store                         Store                      Store                       ...
   Requirement: Store an arbitrary set of    preferences for all users   Requirement: Each user may choose to store    a...
   One possible RDBMS solution:     Key/Value table     All values as strings     Flexible, but wastes spaceKeys:     ...
   Store all preferences in the Preferences    column family   Preference name as column name,    preference value as (s...
