Fluentd ♥ MongoDB
Log Everything As JSON
Kazuki Ohta, CTO at Treasure Data, Inc.
Tuesday, July 17, 2012

Self-Introduction
• Kazuki Ohta
> twitter: @kzk_mover
> github: kzk
• Treasure Data, Inc.
> Chief Technology Officer; Founder
> Original Fluentd Author @frsyuki is another co-founder.
• Open-Source Enthusiast
> KDE, uim, Hadoop, memcached, Mozilla, Mongo, etc.
> Fluentd rpm/deb package manager
2
Tuesday, July 17, 2012

Logging? Why?
Tuesday, July 17, 2012

Figure 1: Common Logging Purposes
Analytics
Error Notification
Recommendation
4
Tuesday, July 17, 2012

Figure 2: Types of Logs
App Log
Access Log
(Apache, Rails, etc.)
System Log
(syslog etc.)
Others
5
Tuesday, July 17, 2012

From “Scaling Lessons learned at Dropbox”
6
Tuesday, July 17, 2012

Fragile for format change,
No type information,
No field name, etc.
From “Scaling Lessons learned at Dropbox”
6
Tuesday, July 17, 2012

About Fluentd
Tuesday, July 17, 2012

It's like syslogd, but uses JSON for log
messages
8
Tuesday, July 17, 2012

Logs in JSON? Why?
1. Machine-Readable
> machine is goint to be a main consumer of logs
2. Schema-Free
> you want to add/remove fields from logs at anytime
Write Logs for Machines, use JSON
http://journal.paul.querna.org/articles/2011/12/26/log-for-machines-in-json/
9
Tuesday, July 17, 2012

Logs As TEXT
Logs As JSON
+ Field Name
+ No Custom Parser
+ Type Information
+ Schema Free
10
Tuesday, July 17, 2012

Logs As TEXT
“2011-04-01 host1 myapp: cmessage size=12MB user=me”
Logs As JSON
2011-04-01 myapp.message {
“on_host”: ”host1”,
”combined”: true,
“size”: 12000000, + Field Name
“user”: “me” + No Custom Parser
+ Type Information
} + Schema Free
10
Tuesday, July 17, 2012

http://fluentd.org/
11
Tuesday, July 17, 2012

• Website
> http://fluentd.org/
• Community
> http://github.com/fluent
> 16 committers across
many organizations
> web, game, enterprise
• Mailing list
> Google groups
12
Tuesday, July 17, 2012

Fluentd Architecture
Tuesday, July 17, 2012

Fluentd: Log Format
Application
Fluentd
Storage
14
Tuesday, July 17, 2012

Fluentd: Log Format
Application
2012-02-04 01:33:51
myapp.buylog {
Fluentd
“user”: ”me”,
“path”: “/buyItem”,
“price”: 150,
“referer”: “/landing”
Storage }
14
Tuesday, July 17, 2012

Fluentd: Log Format
time
Application tag
2012-02-04 01:33:51
myapp.buylog {
Fluentd
“user”: ”me”,
“path”: “/buyItem”,
“price”: 150,
“referer”: “/landing”
Storage }
record
14
Tuesday, July 17, 2012

Fluentd: Plugins
Application
filter / buffer /
Fluentd
routing
Storage
15
Tuesday, July 17, 2012

Fluentd: Plugins
Application
filter / buffer /
Fluentd
routing
SaaS Storage Fluentd
Plug-in Plug-in Plug-in
15
Tuesday, July 17, 2012

Fluentd: Plugins
Application
filter / buffer /
Fluentd
routing
SaaS Storage Fluentd
Plug-in Plug-in Plug-in
16
Tuesday, July 17, 2012

Fluentd: Plugins
syslogd Scribe Application File Plug-in
tail
Plug-in Plug-in
filter / buffer /
Fluentd
routing
SaaS Storage Fluentd
Plug-in Plug-in Plug-in
16
Tuesday, July 17, 2012

• Client libraries
> Ruby
> Perl Application Buffering
> PHP
HTTP / TCP / UDS
> Python
> Java Fluentd
> ...
17
Tuesday, July 17, 2012

• Client libraries
> Ruby
> Perl Application Buffering
> PHP
HTTP / TCP / UDS
> Python
> Java Fluentd
> ...
Fluent.open(“myapp”)
Fluent.event(“login”, {“user”=>38})
#=> 2012-02-04 04:56:01 myapp.login {“user”:38}
17
Tuesday, July 17, 2012

Typical Log Collection by `rsync`
Burst of traffic
rsync consumes
all bandwidth
18
Tuesday, July 17, 2012

Typical Log Collection by `rsync`
App server App server App server
Application Application Application
File File File ... File File File ... File File File ...
File
Burst of traffic High latency
rsync consumes must wait for a day
all bandwidth Log server Hard to analyze
complex text parsers
18
Tuesday, July 17, 2012

Log Collection using Fluentd
Fluentd Fluentd Fluentd
Realtime!
Fluentd Fluentd
19
Tuesday, July 17, 2012

Log Collection using Fluentd
Fluentd Fluentd Fluentd
Realtime!
Fluentd Fluentd
Amazon Ready to
Hadoop Mongo
S3 /
/ Hive DB
EMR Analyze!
19
Tuesday, July 17, 2012

Fluentd Case Study
Ruby on Rails Ruby on Rails Ruby on Rails
Fluentd Fluentd Fluentd
✓ 127 RoR servers
✓ 100,000 msgs/sec Fluentd Fluentd routing
✓ 120Mbps at peak
✓ 1TB/day
Hadoop Mongo User behavior
PV logs / Hive DB logs
20
Tuesday, July 17, 2012

# read logs from a file # forward other logs to servers
<source> # (load-balancing + fail-over)
type tail <match **>
path /var/log/httpd.log type forward
format apache <server>
tag apache.access host 192.168.0.11
</source> weight 20
</server>
# save access logs to MongoDB <server>
<match apache.access> host 192.168.0.12
type mongo weight 60
host 127.0.0.1 </server>
</match> </match>
Tuesday, July 17, 2012

Comparison
Tuesday, July 17, 2012

Scribe: log collector by
Facebook
Frontend servers
Aggregator nodes
scribe
scribe
scribe
Hadoop
HDFS
scribe
scribe
scribe
23
Tuesday, July 17, 2012

Scribe’s Pros & Cons
• Pros.
• Fast (written in C++)
• Cons.
• VERY HARD to install
• nightmare of boost, thrift, libhdfs, etc.
• Unstructured Logs
• parsing must be required before the analysis
• Hard to extend
• recompiling C++ programs are required
• No longer maintained
24
Tuesday, July 17, 2012

Fluentd vs Scribe
• Easy to install
• “gem install fluentd”
• Stable RPM and Deb packages
• http://packages.treasure-data.com/
• Easy to write plugins
• you can use Ruby
• Easy plugin distribution
• “gem search -rd fluent-plugin”
25
Tuesday, July 17, 2012

Flume: distributed log collector by Cloudera
Phisical
Flume Master
Topology
Flume Flume Flume
Logical Hadoop
Topology HDFS
26
Tuesday, July 17, 2012

Flume’s Pros & Cons
• Pros.
• Central master server manages all nodes
• Cons.
• Difficult to understand
• logical topologies, phisical servers and a
configuration of the logical/phisical mapping
• Difficult to configure
• replicated master servers, log servers and agents
• Big footprint
• 50,000 lines of Java
27
Tuesday, July 17, 2012

Fluentd vs Flume
• Easy to understand
• “syslogd that understands JSON”
• Easy to setup
• “sudo fluentd --setup && fluentd”
• Very small footprint
• small engine (3,000) lines + plugins
• small, but battle-tested!
• Easy to configure
28
Tuesday, July 17, 2012

Fluentd Scribe Flume
Installation gem/rpm/deb make jar/rpm/deb
3000 lines of 8000 lines of 50,000 lines of
Footprint Ruby C++ Java
Plugin Ruby N/A Java
Plugin distribution RubyGems.org N/A N/A
Master Server No No Yes
License Apache License Apache License Apache License
29
Tuesday, July 17, 2012

Fluentd Plugin for
Tuesday, July 17, 2012

fluent-plugin-mongo
• Included within rpm/deb by default!
• http://github.com/fluent/fluent-plugin-mongo
• #1 plugin among 50+ Fluentd plugins
• Logs As JSON. WHY NOT Put Them Into Mongo??
• http://fluentd.org/plugin/
• Supports most of the MongoDB features
• Authentication
• ReplicaSet
• Capped Collection
31
Tuesday, July 17, 2012

• MongoDB Output Plugin
Application • Maintain JSON Structure
• Reliable Buffering
• Batch Insertion
Fluentd Buffering • Handle Broken Records
• Ruby Driver #82
Authentication
MongoDB MongoDB MongoDB MongoDB
MongoDB MongoDB
Single Instance MongoDB MongoDB
(Capped or Not) MongoDB MongoDB
Sharding
ReplicaSet
32
Tuesday, July 17, 2012

• MongoDB Output Plugin
Application • Maintain JSON Structure
• Reliable Buffering
• Batch Insertion
Fluentd Buffering • Handle Broken Records
• Ruby Driver #82
Authentication
MongoDB MongoDB MongoDB MongoDB
MongoDB MongoDB
Single Instance MongoDB MongoDB
(Capped or Not) MongoDB MongoDB
Sharding
ReplicaSet
32
Tuesday, July 17, 2012

ReplicaSet
(Capped Collection)
Single Instance
(Capped Collection) MongoDB
MongoDB MongoDB MongoDB
Authentication
Fluentd Buffering
• MongoDB Input Plugin
• Tailing Capped Collections
33
Tuesday, July 17, 2012

ReplicaSet
(Capped Collection)
Single Instance
(Capped Collection) MongoDB
MongoDB MongoDB MongoDB
Authentication
Fluentd Buffering
• MongoDB Input Plugin
• Tailing Capped Collections
33
Tuesday, July 17, 2012

Realtime Analytics with Fluentd + MongoDB
App App App
Fluentd Fluentd Fluentd
routing Fluentd Fluentd
Nagios, Zabbix, etc.
Mongo query
Charting
Alert DB
34
Tuesday, July 17, 2012

Realtime or Batch? No, BOTH!
App App App
Fluentd Fluentd Fluentd
routing Fluentd Fluentd
Hadoop Amazon Mongo query
Charting
/ Hive S3 DB
batch archive realtime 35
Tuesday, July 17, 2012

Intro of our company’s service: Treasure Data
App App App
Fluentd Fluentd Fluentd
routing Fluentd Fluentd
Treasure Mongo Hadoop-based
Data DB Cloud Data Warehouse
batch realtime 36
Tuesday, July 17, 2012

Exercise: Apache Logs into MongoDB
Tuesday, July 17, 2012

Log File
38
Tuesday, July 17, 2012

39
Tuesday, July 17, 2012

40
Tuesday, July 17, 2012

Conclusion
• Log Everything as JSON
• Machine Readability
• Schema Freeness
• MongoDB fits into Fluentd’s backend perfectly
• Both using JSON representation
41
