  1. One Laptop Per Child Sameer Verma, Ph.D.
  2. Grown-ups, Take a Number
  3. Outline Introduction Education Laptop FOSS
  4. Outline- revised for CCCC Introduction Education Laptop FOSS
  5. Disclaimer <ul><li>I do not work for OLPC! </li></ul><ul><li>Enthusiast/developer </li></ul><ul><ul><li>Interests: Translations, UI and networking </li></ul></ul><ul><li>OLPC: Excellent example of disruptive technology innovation </li></ul><ul><ul><li>hardware (aka why your laptop sucks) </li></ul></ul><ul><ul><li>software (power of FOSS at work) </li></ul></ul>
  6. Somebody is finally thinking of the children
  7. Laptop <ul><li>7.5 inch diagonal screen at 1200x900 (200 dpi) </li></ul><ul><li>800x600 in grayscale </li></ul><ul><ul><li>Sunlight readable! </li></ul></ul><ul><li>Wi-fi, USB(x3), mic, speakers, camera, SD </li></ul><ul><li>Screen rotates to tablet mode </li></ul><ul><li>Water resistant keyboard </li></ul><ul><ul><li>walk in the rain with it! </li></ul></ul>
  8. More laptop <ul><li>Laptop, turned on its head </li></ul><ul><ul><li>All electronics are in the upper section, except the keyboard. </li></ul></ul><ul><ul><li>Easy to replace either component </li></ul></ul><ul><ul><li>Carry handle also acts as base stabilizer </li></ul></ul><ul><ul><li>Wi-fi rabbit ears double up as latches </li></ul></ul><ul><ul><li>Any 12 volt power supply will do </li></ul></ul><ul><ul><ul><li>wall wart </li></ul></ul></ul><ul><ul><ul><li>car battery </li></ul></ul></ul><ul><ul><ul><li>crank power </li></ul></ul></ul>
  9. Green <ul><li>Looks green, works green </li></ul><ul><ul><li>Fully recyclable </li></ul></ul><ul><ul><ul><li>5 year life span </li></ul></ul></ul><ul><ul><li>Idle power consumption </li></ul></ul><ul><ul><ul><li>Desktop – 80 watts </li></ul></ul></ul><ul><ul><ul><li>Laptop – 20 watts </li></ul></ul></ul><ul><ul><ul><li>OLPC – 1 watt </li></ul></ul></ul>
  10. More green <ul><li>Power consumption at about 10% of typical laptop </li></ul><ul><li>The laptop lifetime is 5 years or 2.5 times longer than a typical laptop </li></ul><ul><li>Half the size and weight of a typical laptop </li></ul><ul><li>Goal: not a single XO laptop should end up in a landfill </li></ul>
  11. Power innovations <ul><li>Batteries that last 4x longer </li></ul><ul><ul><li>Lithium Iron Phosphate (LiFePO 4 ) </li></ul></ul><ul><ul><li>Currently at ~ 5hrs, final goal ~10 hours </li></ul></ul><ul><li>Display refresh possible with board powered off </li></ul><ul><ul><li>0.1 watt in grayscale mode </li></ul></ul><ul><li>Wireless mesh works even when board powers off </li></ul><ul><ul><li>Mesh does not require central hub-like infrastructure </li></ul></ul>
  12. Look Ma! No moving parts! <ul><li>No fans, no hard drive, nothing spins. </li></ul><ul><ul><li>1GB Flash + 256 MB RAM </li></ul></ul><ul><ul><li>USB storage </li></ul></ul><ul><ul><li>SD slot </li></ul></ul><ul><li>Only thing that moves is the screen when it swivels over to tablet mode. </li></ul><ul><li>AMD Geode processor runs cool. </li></ul>
  13. Linux in the box <ul><li>Custom Fedora based distro </li></ul><ul><li>GNOME-based </li></ul><ul><li>Ported applications must follow OLPC HCI guidelines </li></ul>
  14. Sugar, because its sweet!
  15.
  16.
  17. Sugar <ul><li>Activities, not applications </li></ul><ul><li>Interface – Sugar </li></ul><ul><ul><li>GNOME based </li></ul></ul><ul><li>Borders + center wheel </li></ul><ul><li>Wheel is also a metaphor for available resources </li></ul><ul><li>Run your own Sugar environment </li></ul><ul><ul><li>http://wiki.laptop.org/go/LiveCD </li></ul></ul>
  18. Applications <ul><li>Word processor </li></ul><ul><ul><li>Yes, but does it run Word? </li></ul></ul><ul><li>Paint </li></ul><ul><li>Instant Messaging </li></ul><ul><ul><li>XMPP based </li></ul></ul><ul><li>Browser </li></ul><ul><ul><li>Firefox/gecko </li></ul></ul><ul><li>Record </li></ul><ul><ul><li>stills and video </li></ul></ul>
  19. Bitfrost Approach <ul><li>Open design </li></ul><ul><ul><li>The laptop's security must not depend upon a secret design. </li></ul></ul><ul><li>No lockdown </li></ul><ul><ul><li>There must exist a way for the security systems to be disabled for maintenance. </li></ul></ul><ul><li>No reading required </li></ul><ul><ul><li>Security cannot depend upon the user's ability to read a message from the computer. </li></ul></ul><ul><li>Unobtrusive security </li></ul><ul><ul><li>Whenever possible, the security on the machines must be behind the scenes. </li></ul></ul>
  20. Bitfrost Goals <ul><li>No user passwords </li></ul><ul><ul><li>Users as young as 5 years old, cannot remember a password. </li></ul></ul><ul><li>No unencrypted authentication </li></ul><ul><ul><li>Authentication of laptops or users will not depend upon unencrypted data over the network. </li></ul></ul><ul><li>Out-of-the-box security </li></ul><ul><ul><li>The laptop should be both usable and secure out-of-the-box. </li></ul></ul><ul><li>Limited institutional PKI </li></ul><ul><ul><li>Keys will not be used to validate the identity of laptop users. </li></ul></ul>
  21. Education <ul><li>Its an education project, not a laptop project. </li></ul><ul><ul><li>Nicholas Negroponte, Founder - OLPC </li></ul></ul><ul><li>OLPC's Goal: </li></ul><ul><ul><li>To provide children around the world with new opportunities to explore, experiment and express themselves. </li></ul></ul><ul><li>Yes, but the laptop is way cool! </li></ul><ul><ul><li>Sameer Verma, FOSS Enthusiast </li></ul></ul>
  22. My compi <ul><ul><li>Mira Verma </li></ul></ul>
  23. Building Content <ul><li>Constructionism is a philosophy of education in which children learn by doing and making. </li></ul><ul><ul><li>Electronic books created and stored on the school server </li></ul></ul><ul><ul><li>Collaborative activities </li></ul></ul><ul><ul><ul><li>IM, Video, Music </li></ul></ul></ul><ul><ul><li>E-toys </li></ul></ul><ul><ul><ul><li>Build books with multimedia content </li></ul></ul></ul><ul><li>Think Lego® </li></ul>
  24. Learning outside the box <ul><li>With sufficient self-confidence, teachers can learn from children without risk of unraveling the fabric of education—quite the contrary, improving it. </li></ul><ul><li>Children must not only own the laptop, but take it home. In so doing the whole family will benefit. </li></ul><ul><li>The child is not the object of change but the agent of change. </li></ul>
  25. Free and Open Source <ul><li>FOSS was the only option that was flexible enough for this project </li></ul><ul><li>No vendor lock-in on formats </li></ul><ul><li>No royalties on redistribution </li></ul><ul><li>Perhaps the first example of a software project that has forced hardware manufacturers to modify their way of business. </li></ul>
  26. FOSS: What does it mean? <ul><li>OLPC manifesto </li></ul><ul><li>Four freedoms </li></ul><ul><li>Open Source Definitions </li></ul>
  27. Richard Stallman's Four Freedoms <ul><li>Freedom 0: The freedom to run the program, for any purpose. </li></ul><ul><li>Freedom 1: The freedom to study how the program works, and adapt it to your needs. </li></ul><ul><li>Freedom 2: The freedom to redistribute copies so you can help your neighbor. </li></ul><ul><li>Freedom 3: The freedom to improve the program, and release your improvements to the public, so that the whole community benefits. </li></ul>
  28. The Open Source Definition <ul><li>1. Free Redistribution </li></ul><ul><li>2. Source Code </li></ul><ul><li>3. Derived Works </li></ul><ul><li>4. Integrity of The Author's Source Code </li></ul><ul><li>5. No Discrimination Against Persons or Groups </li></ul><ul><li>6. No Discrimination Against Fields of Endeavor </li></ul><ul><li>7. Distribution of License </li></ul><ul><li>8. License Must Not Be Specific to a Product </li></ul><ul><li>9. License Must Not Restrict Other Software </li></ul><ul><li>10. License Must Be Technology-Neutral </li></ul>
  29. How can you help? <ul><li>Developers </li></ul><ul><ul><li>http://wiki.laptop.org/go/Developer </li></ul></ul><ul><li>Educators </li></ul><ul><ul><li>http://wiki.laptop.org/go/Educators </li></ul></ul><ul><li>Getting involved </li></ul><ul><ul><li>http://wiki.laptop.org/go/Getting_involved_in_OLPC </li></ul></ul>

×
