Style Guides Are The New Photoshop (Fronteers 2012)

Stephen Hay
Stephen HaySenior UX Design Lead at Catawiki
STYLE GUIDES ARE THE NEW PHOTOSHOP
                   STEPHEN HAY @ FRONTEERS 2012
DESIGNING IN THE BROWSER


   Demonstrating our designs to clients as
   XHTML/CSS pages rather than as static
   Photoshop or Fireworks has streamlined our
   workflow and helped us to set and manage a
   client’s expectations better than ever before.


               Andy Clarke, “Time to stop showing clients static design visuals” (2008)
WALLS COME TUMBLING DOWN (2009)

   Coming up with new and better workflows
   Designing in the browser
   Learning to live with constraints
   Designing systems, rather than sites
PHOTOSHOP IS IMPRACTICAL FOR
 RESPONSIVE DESIGN MOCKUPS
PROBLEMS WITH “PHOTOSHOP” COMPS

   Design changes are time-consuming
   Too much manual work
   The image editor is a dependency
   Responsive design implies multiple and
   flexible layouts
REALITY
   (Screenshots by Adobe Edge Inspect)
WEB TECH IS VERY PRACTICAL FOR
 RESPONSIVE DESIGN MOCKUPS
WEB-BASED COMPS: THE GOOD
   Doesn’t need to take much longer than Photoshop
   Automate trivial tasks
   Realistic presentation / real-life rendering
   State changes are easily visualized
   Free and open: everyone has a browser & editor
   No negative surprises for the client
   Possible prep for development
   They can be responsive
WE NEED TWO THINGS TO REPLACE
    PHOTOSHOP FOR COMPS
1. Static Web-based Comps
2. Style Guides
STYLE GUIDES
STYLE GUIDES: THE GOOD


   No measuring
   State and breakpoint changes can be included
   Useful for future designers, devs & others
   Design consistency and maintainability
STYLE GUIDES IN THE WILD
 Apple Identity Guidelines
STYLE GUIDES IN THE WILD
 BBC GEL
ANNA DEBENHAM’S COLLECTION
                     STYLE GUIDES, PATTERN LIBRARIES & TOOLS TO CREATE THEM

http://gim.ie/fZyK
MY WEB STYLE GUIDE WISHLIST
Free-form writable
Taking screenshots should be automated
Update code snippets automatically
   when mockup code changes
Update screenshots automatically
   when something changes
Elements/modules should not have to be
   physically split into separate files
Syntax highlighting for code
AM I TOO DEMANDING?


   Free-form writable
   Automated screenshot-taking
   Update code snippets automatically
   Update screenshots automatically
   No separate files for code snippets
   Syntax highlighting
I COULD NOT FIND A SINGLE TOOL
          TO DO THIS
Sporf
  http://en.wikipedia.org/wiki/Sporf
Free-form writing
       DEXY + PANDOC (OR MARKDOWN) FILTER
                                            http://www.dexy.it/
Taking screenshots
                 PHANTOM.JS + CASPER.JS




                                  http://casperjs.org/



http://phantomjs.org/
Code & screenshot updating
       JINJA TEMPLATES + DEXY’S IDIOPIDAE FILTER
Syntax highlighting
       DEXY’S PYGMENTS FILTER
THE
  COMMAND
      LINE
http://www.flickr.com/photos/evdaimon/337754011/
Style Guides Are The New Photoshop (Fronteers 2012)
Style Guides Are The New Photoshop (Fronteers 2012)
Style Guides Are The New Photoshop (Fronteers 2012)
hi.
http://xkcd.com/149/
How this works

  Web-based mockup             Style guide content in Markdown     Style guide




                     screenshots taken, code snippets extracted
    HTML   CSS                                                    SCREEN   CODE
STEPS
1 Create a web-based mockup


   Use HTML, CSS & when necessary, JavaScript
   Your goal is to represent the design in the browser
   Your goal is not to create production code
   Your CSS should be modular (it will end up in your
   style guide!)
SMACSS

         MAKE CSS MORE MODULAR WITH…
         A LUMBERJACK.
2 Install Dexy & any dependencies




  If you’re a designer and can’t do it alone, ask a
  developer’s help.
  Before you ask for help, try going to the sites and
  following the instructions as best you can.
2 Install PhantomJS & CasperJS




  If you’re a designer and can’t do it alone, ask a
  developer’s help.
  Before you ask for help, try going to the sites and
  following the instructions as best you can.
3 Write your guide and use Jinja templates




     Use simple Markdown links to screenshots. Note the filenames you use.
4 Script your screenshots with CasperJS




 Keep things easy by adding a new casper.then() for each screenshot. Code brevity is not the goal.
5 Mark the CSS you want to export




          An export ends when another starts, or with @end.
6 Run Dexy




             Wow, that command line stuff is hard.
DONE
Changes in design? Run dexy again.




 Well, okay. In some cases you might want to do dexy cleanup followed by dexy setup and then dexy.
Demo
This is not without a learning curve.
            But what is?
Choose what works for you.
Hopefully something here will inspire you to find your own way. Experiment!
These are new times.
The problems we have with responsive workflow should encourage us to examine
                   and evaluate our processes and tools.
Have fun.
Make great stuff.
KEEP LEARNING.

Thanks!
@stephenhay


                    Special thanks to Ana Nelson
