- 1. Infrastructure as CodeHelping You Conquer the Cloud Ana Biazetti, Distinguished Engineer, IBM Cloud for Financial Services Master Inventor Shikha Srivastava, Distinguished Engineer - IBM SaaS Master Inventor
- 2. Agenda • Landscape ofModernization and Hybrid Cloud • Challenges and Opportunities • Continuous Integration and Continuous Delivery • Infrastructure as Code • Scenarios and Examples • Summary and Call to Action
- 3. Rise of Cloudand Modernization Mainframe Client Server Web Cloud Pain Points with Monoliths • Large Applications are complex • Full application upgrade required for minor or major updates • Difficult to scale • Bug in one module brings down the entire application • Painful to adopt new technologies
- 4. Cloud has changedexpectations Availability 24X7 Hyperscale Agility Start small and grow to enterprise scale Uptime with defined SLAs Deliver in-time and deliver at regular interval
- 5. An approach tomodernization Rationalize and decommission 20% Hybrid IT Modernize and Migrate to Cloud …on any cloud platform Private Cloud on premises Dedicated/Hosted off-premises Public Cloud 20% Traditional on premises Re-Host (lift & shift) Re-Platform Re-Architect (Microservices / APIs) 10% 10% 15% Public SaaS Retain on Traditional + for selected apps: - Automate - Containerise Replace with “as a service” solution 10% 50% Refactor 15%
- 6. Hybrid Cloud –Best of the both worlds Public Cloud Fully Customizable Secure by Design Full control and robust management Elastic Pay-as-you go mode Low entry cost Maximize returns Match workload to best fit infrastructure Meet Capacity Highly scalable Innovate at the speed of your choice Private Cloud
- 7. What does ittake to modernize Collaboration and Communication Continuous Integration Continuous Delivery Observability Change and incident management Security and Compliance Test and Quality Scale Plan Build Test Secure Release Operate Modernization Ideas Modernization Ideas Iterate
- 8. Dev and SREcollaboration Modernization requires Dev and SRE to work together towards DevSecOps approach Developers Create SRE Manage Shift Left SRE ( DevSecOps) Communication Collaboration Integration
- 9. Write application Code Write infrastructure as code and templatize Reliabilityas code Create your DevSecOps pipeline leveraging CICD Iterate Design Shikha Dev and SRE collaboration Modernization requires robust CI/CD pipeline
- 10. Write application Code Write infrastructure as code and templatize Reliabilityas code Create your DevSecOps pipeline leveraging CI/CD Iterate Design Dev and SRE collaboration Modernization requires robust CI/CD pipeline
- 11. CD Continuous Delivery CI Continuous Integration CD Continuous Deployment Production Ops Team Dev Team Source Code •Clear definition of tasks (“Runbook”) • Faster Delivery • Improved processes • Automation and reduction of errors Pipelines and CI/CD: Connecting Dev with Sec/Ops
- 12. / Type DevOps GitOps GitOps Structure Each part of the pipelineis 1 YAML Each part of the pipeline is 1 YAML Only 1 Jenkins file Pipelines Manager X X -- Language Go Go Java with Plugins Tekton Tekton Server/VM K8s-native Part of K8 project (Cloud Native) Cloud Native No (Server/V M) Execution Multiple PODs Paralelis m Multiple PODs Only 1 POD, Sequential Execution V3.0 Pipeline Technologies
- 13. Everything as Code Automate Everything DevOps andSecurity have merged Speed with Control for Modernized Workloads on Hybrid Cloud Shift-Left Governance 1 3
- 14. Infrastructure as Code(IaC) helping with Modernization to Hybrid Cloud Codify infrastructure in a way that makes provisioning automated, faster, and repeatable. Infrastructure as Code Technology: ○ Terraform ○ Ansible ○ Chef ○ Puppet Benefits: ● Improve speed ● Improve reliability ● Prevent configuration drift ● Support experimentation, testing, and optimization
- 15. Terraform ● Terraform isan open source “Infrastructure as Code” tool, created by HashiCorp. ● A declarative coding tool, describes the desired “end-state” infrastructure ● simple syntax ● provision infrastructure across multiple cloud and on-premises data centers https://www.terraform.io/
- 16. Terraform Concepts: Templates,Modules and Providers
- 17.
- 18. Scenario: Financial ServiceCore Banking Application
- 19. Summary – Modernizationis a journey Identify what to modernize Nail down the hybrid design and dependencies Reliable repeatable automation – “Everything- as-Code” Drive standardizati on and reuse Iterate Mitigate security risks as early as possible – “Shift-left”
- 20. References CI/CD Pipelines ● ContinuousIntegration ● Continuous Delivery ● Tekton ● Tekton versus Jenkins ● Speed and resiliency: two sides of the same coin ● DevSecOps Intro ● Pipelines enabling Audit and Compliance ● CI template ● CD template ● IBM Cloud for Financial Services pattern infrastructure as Code • Terraform • Infrastructure as Code • IBM Cloud Terraform Provider • IBM Cloud Terraform Modules • Terraform versus other infrastructure as code options
- 21.
Editor's Notes
- #9 Manage Infrastructure Manage configurations Observability Manage Alerts Manage Changes in production Manage security incidents Manage networking ----------------- Take requirements Design feature and function Write code Write tests ( may be) Test and automate test (may be) Refactor Push to production -----------------
- #10 Take requirements Design feature and function Write code Write tests ( may be) Test and automate test (may be) Refactor Push to production -----------------
- #12 Challenges organizations face today: Lack of deep security expertise in app dev teams Manual effort for audit and compliance readiness Ever changing security landscape Custom DevOps investments across teams Dev, Ops and Security teams working in silos Continuous integration is a software development process where developers integrate the new code they've written more frequently throughout the development cycle, adding it to the code base at least once a day. Automated testing is done against each iteration of the build to identify integration issues earlier, when they are easier to fix , which also helps avoid problems at the final merge for the release. Overall, continuous integration helps streamline the build process, resulting in higher-quality software and more predictable delivery schedules. Continuous delivery is the automated movement of code through the development lifecycle (sometimes called the delivery lifecycle); continuous deployment is the automated movement of that code into production, once it passes the required automated tests.
- #13 Others, like Travis, GitLab CI. etc How to get started: Instrument legacy CI/CD orchestration with reusable assets for evidence collection Orchestrate legacy tools using DevSecOps reference implementation Fully leverage DevSecOps reference implementation, eliminating legacy tools https://developer.ibm.com/videos/tekton-versus-Jenkins
- #14 DevOps premise: Velocity and quality can coexist! DevOps practices have become mainstream Supported by vibrant ecosystem of open source and commercial tools Automate everything Manual/human processes and handoffs remain a bottleneck, in addition to introducing error and inconsistency We’ve seen progress in quality – More consumable static analysis, lighter-weight test automation frameworks like Junit, cloud-based test labs, architectures that limited blast-radius, canary testing etc. reduce or eliminate traditional test cycles We’ve seen progress in deployments – Microservice architectures, containers, and technique like canary testing and progressive rollout speed up and de-risk deployments. No blackout windows, release weekend events, etc. PLUG OUR TEKTON WORK HERE--- Everything as code Consistent management, governance, auditability, branching/exploration model, sharing/contribution model, etc. break-down silos of specialized tools/expertise and enable the “full-stack developer”. While maintaining Separation of concerns E.g. Terraform, Ansible, Schematics, Tekton, … What are we seeing now? PLUG GITSECURE HERE---- “DevSecOps” – Emphasis on Security and Compliance Standardizing automation, e.g. through common pipeline tasks, of release-readiness checks, e.g. vulnerability scanning, test automation, code coverage, code review, etc. Maintaining audit-readiness by capturing results/outputs of above checks Shift-left – Risk is reduced and velocity increased the sooner feedback reaches the developer How many of the release readiness checks can be done on every pull request before it’s merged? E.g. scanning for source, package, OS vulnerabilities “GitOps” – extend Kubernetes-style declarative/state-based approach to describing production systems E.g. Razee, ArgoCD, … Consolidation/standardization through open source communities E.g. Continuous Delivery Foundation, under LF, has mission to drive tools AND approaches/practices E.g. Tekton
- #15 IaC uses code to define, deploy and update a given infrastructure. This means that networks, routes, load balancer, compute instances, storage buckets, etc are managed in code IaC allows developers to codify infrastructure in a way that makes provisioning automated, faster, and repeatable. It’s a key component of Agile and DevOps practices such as version control, continuous integration, and continuous deployment. Infrastructure as code can help with the following: Improve speed: Automation is faster than manually navigating an interface when you need to deploy and/or connect resources. Improve reliability: If your infrastructure is large, it becomes easy to misconfigure a resource or provision services in the wrong order. With IaC, the resources are always provisioned and configured exactly as declared. Prevent configuration drift: Configuration drift occurs when the configuration that provisioned your environment no longer matches the actual environment. (See ‘Immutable infrastructure’ below.) Support experimentation, testing, and optimization: Because Infrastructure as Code makes provisioning new infrastructure so much faster and easier, you can make and test experimental changes without investing lots of time and resources; and if you like the results, you can quickly scale up the new infrastructure for production. IaC tools include: - Provisioning tools - configuration management tools (eg, Chef , Puppet)– focus on installation an management of SW on existent servers) Also declarative versus procedural: Terraform and Puppet: declararive Ansible and Chef: procedural Terraform is purely a declarative tool (see above), Ansible combines both declarative and procedural configuration. In procedural configuration, you specify the steps, or the precise manner, in which you want to provision infrastructure to the desired state. Procedural configuration is more work but it provides more control. While Terraform is cloud agnostic, CloudFormation is a managed service offered by AWS that comes with a common language for modeling and provisioning third-party app resources. It is done for your cloud platform with a single point of reference for infrastructure mapping & development.
- #16 A declarative coding tool, Terraform enables developers to describe the desired “end-state” cloud or on-premises infrastructure for running an application. It then generates a plan for reaching that end-state and executes the plan to provision the infrastructure. Because Terraform uses a simple syntax, can provision infrastructure across multiple cloud and on-premises data centers, and can safely and efficiently re-provision infrastructure in response to configuration changes, it is currently one of the most popular infrastructure automation tools available, specially for hybrid cloud or multicloud environments The deployment of a solution consists of three stages: the init-stage, the plan-stage and the apply-stage. In the init-stage, the modules that the solution are dependent on will be downloaded to the hidden directory .terraform . In the plan-stage, Terraform will determine what differences there are between the configuration file(s) and the environment where the solution is deployed to. Plan will also return what objects will be added, changed or deleted. The deployment itself is done in a seperate step, which is called terraform apply. The deployment can be removed using terraform destroy.
- #17 A terraform template is a collection of files that, together, define the state of your infrastructure to be achieved. They include different configuration files such as variables, resources, and modules. Terraform modules are small, reusable Terraform configurations for multiple infrastructure resources that are used together. Terraform modules are useful because they allow complex resources to be automated with re-usable, configurable constructs. Writing even a very simple Terraform file results in a module. A module can call other modules—called child modules—which can make assembling configuration faster and more concise. Terraform providers are plugins that implement resource types. Providers contain all the code needed to authenticate and connect to a service—typically from a public cloud provider—on behalf of the user. You can find providers for the cloud platforms and services you use, add them to your configuration, and then use their resources to provision infrastructure. Providers are available for nearly every major cloud provider,
- #18 https://cloud.ibm.com/docs/solution-tutorials?topic=solution-tutorials-plan-create-update-deployments
- #20 Reliable repeatable automation – “Everything-as-Code” Application-as-Code Infrastructure-as-Code Reliability-as-Code Continuous integration, delivery and deployment as-Code Mitigate security risks as early as possible – “Shift-left” Automate scanning/testing throughout development (i.e., every change) Gate progression of changes with automated policies Maintain history with evidence for audit readiness integrated with Security and Compliance Center Drive standardization and reuse Toolchain templates embody DevSecOps practices Reference architectures include toolchain automation Integrating mix of tools from third parties, open source, in-house
