Vhdl 2017: new and noteworthy

This presentation discusses new features in VHDL 2017, including records with direction that allow defining interfaces more clearly. It also covers small language improvements like sequential blocks and ternary expressions. New library features are proposed like generic data structures and reflection APIs to enable automatic data conversion. The changes aim to make VHDL more concise, safer and better support abstraction through improved library development.

Engineering◦
Download as PDF, PPTX
redefine.digital.design: Helping you deal with complexity in VHDL and Verilog. VHDL 2017. Lieven Lemiengre FPGA Kongress 2017-07-13
● Chief R&D @ Sigasi ● Software guy ● Front-end compiler ○ VHDL ○ SystemVerilog ● VHDL Working Group About me
● Open IEEE group ○ bi-weekly meetings ● Prominent members ○ Jim Lewis (chair) ○ Rob Gaddi & Patrick Lehmann (vice-chair) ● http://www.eda-twiki.org/cgi-bin/view.cgi/P1076/WebHome ○ Meeting minutes ○ All proposals ○ Join the WG reflector VHDL Working Group
● VHDL: long legacy, strong future ● Unique advantages ○ Find bugs early ■ Strong typing ■ Easy to analyse ○ Library focussed ■ “Growable” language ○ Portable designs ■ Deterministic simulation ■ Unambiguous, simple semantics VHDL: Why?
VHDL 2017: Approach Need to evolve ○ Users: more concise, easy to use, safer ○ Library developers: better abstractions, less restrictions 2014: VHDL 20xx proposals survey 1. Interfaces: Records with directions 2. Language ergonomics 3. Library features 4. Bugfixes
Evaluating proposals a. Backwards compatibility b. Feature complexity vs benefit c. Interaction with other features d. Implementation considerations ■ Performance ■ Compiler complexity VHDL 2017: Approach
In this presentation ● Interfaces: Records with direction ● 5 Small features ● Library features VHDL 2017
● Interfaces are everywhere ○ AXI, SPI, I2C, … ● Current approaches ○ Repeat interface definition everywhere ■ Hard to maintain ■ Very verbose ○ inout record ■ Unsafe ○ Gaisler coding style:, record for each direction ■ Split record for every direction ■ Maintain different records with naming conventions VHDL 2017: Records with direction
Definition package p is type if_record is record data_in : std_logic_vector; valid : std_logic; data_out : std_logic_vector; end record if_record; end package p; VHDL 2017: Records with direction
Definition package p is type if_record is record data_in : std_logic_vector; valid : std_logic; data_out : std_logic_vector; end record if_record; view if_view of if_record is data_in : in; valid, data_out : out; end view if_view; end package p; VHDL 2017: Records with direction
Long form use work.p.all; entity e is port( clk : in std_logic; rst : in std_logic; if : view if_view of if_record ); end entity e; VHDL 2017: Records with direction
Short form use work.p.all; entity e is port( clk : in std_logic; rst : in std_logic; if : view if_view ); end entity e; VHDL 2017: Records with direction
Converse use work.p.all; entity e is port( clk : in std_logic; rst : in std_logic; if : view if_view’converse ); end entity e; VHDL 2017: Records with direction
Converse use work.p.all; entity e is port( clk : in std_logic; rst : in std_logic; if : view if_view’converse ); end entity e; VHDL 2017: Records with direction out -> in in -> out inout -> inout buffer -> in
Constrained subtype entity e is generic(g : natural); port( clk : in std_logic; rst : in std_logic; if : view if_view of if_record ( data_in(0 to g), data_out(0 to g) ) ); end entity e; VHDL 2017: Records with direction
Arrays type if_record_vector is array (natural range <>) of if_record; entity e is port( clk : in std_logic; rst : in std_logic; if : view (if_view) of if_record_vector(1 to 10) ); end entity e; VHDL 2017: Records with direction
package p2 is type nested_if_record is record nested_field : if_record; valid : std_logic; end record nested_record; view nested_if_view of nested_if_record is nested_field : view if_view; valid : out; end view nested_if_view; end package p2; VHDL 2017: Records with direction Composition package p is type if_record is record data_in : std_logic_vector; valid : std_logic; data_out : std_logic_vector; end record if_record; view if_view of if_record is data_in : in; valid, data_out : out; end view if_view; end package p;
Subprograms procedure p(signal b : view if_view; i : integer); function f(signal b : view if_view; i : integer) return integer; VHDL 2017: Records with direction
VHDL 2017: Records with direction Instantiation architecture a of top is signal clk, rst : std_logic; signal if_inst : if_record; begin lbl : entity work.e port map( clk => clk; rst => rst; if => if_inst; ); end architecture
● VHDL 2017: Interface ○ Record + Mode view (+ Subtype) ● Highlights ○ Simple ○ Composable ○ Arrays of interfaces ○ Converse of a interface ○ As parameter on subprogram VHDL 2017: Records with direction
1. Sequential Blocks p : process is variable outer : integer := 0; begin b : block variable inner : integer := 0; begin inner := inner + 1; report inner’image; -- always 1 outer := outer + 1; report outer’image; -- 1 2 3 4 5 ... end block b; end process p; VHDL 2017: Small improvements
1. Sequential Blocks p : process is begin if condition then variable v : integer := 10; constant c : integer := 4; begin v := c * 3; end if; end process p; VHDL 2017: Small improvements
1. Sequential Blocks p : process is begin for i in vect’range then constant element : integer := vect(i); begin some_operation(element); end for; end process p; VHDL 2017: Small improvements
2. Ternary expressions ● constant DELAY : time := 3 ns when FAST else 5 ns; attribute RAM_STYLE of RegFile : signal is "distributed" when SMALL else "block"; ● y <= a xor b after (3 ns when FAST else 5 ns); ● return when condition; return a when condition else b; VHDL 2017: Small improvements
3. Function knows return size ● Before VHDL 2008 some_vector <= resize(another_vector, some_vector’length); ● VHDL 2017 ✔ some_vector <= resize(another_vector); ✘ some_vector <= v & resize(another_vector); VHDL 2017: Small improvements
3. Function knows return size ● function to_unsigned(i : integer) return r : unsigned is begin return to_unsigned(i, r’length); end function; ● unsigned_s <= to_unsigned(integer_value); VHDL 2017: Small improvements
4. Improved attributes ● Directly use attributes on an object ○ report o’subtype’image(o); -- VHDL 2008 report o’image -- VHDL 2017 ○ type state_t is (a, b, c); variable pos : natural; pos := state_t’pos(a); -- VHDL 2008 pos := a’pos; -- VHDL 2017 VHDL 2017: Small improvements
5. New APIs ● Improved file api ○ Open a file in READ_WRITE_MODE ○ Determine if a file is still open ■ file_state(f) ○ Determine & modify file size ■ file_size(f) and file_truncate(f, size) ○ Quickly move around ■ file_position(f), file_seek(f, offset), file_rewind(f) VHDL 2017: Small improvements
5. New APIs ● New directory api ○ Explore directory tree ○ Create files in directories ○ Create and delete directories VHDL 2017: Small improvements
5. New APIs ● New date/time api ○ std.env package ○ Local or UTC time ○ to_string(localtime); = "2017-07-13T09:20:13" VHDL 2017: Small improvements type time_record is record microsecond : integer range 0 to 999_999 second : integer range 0 to 61; minute : integer range 0 to 59; hour : integer range 0 to 23; day : integer range 1 to 31; month : integer range 0 to 11; year : integer range 1 to 4095; weekday : dayofweek; dayofyear : integer range 0 to 365; end record time_record;
1. Proposals ● Improved generics ● Anonymous types ● Garbage collection ● Removed restrictions for protected types ● Generics on protected types ● Reflection API VHDL 2017: Library features
2. Use case: Generic data structures type int_list is new generic_list generic map(vect => integer_vector); variable lst : int_list; lst.addAll((1, 2, 3)); -- lst = (1, 2, 3) lst.add(10); -- lst = (1, 2, 3, 10) lst.index_of(3); -- = 2 lst.remove_all(2); -- lst = (1, 3, 10) VHDL 2017: Library features
2. Use case: Generic data structures type int_to_string is new generic_map generic map(key => integer, value => string); variable lookup_table : int_to_string; lookup_table.put(1, “this”); lookup_table.put(8, “that”); lookup_table.get(8); -- = “that” lookup_table.exists(3); -- = false VHDL 2017: Library features
2. Use case: Generic data structures ● List ● Associative arrays ● Set ● Stack or Heap ● Graph ● ... VHDL 2017: Library features
3. Use case: Data conversions using reflection ● to_string(value’reflect) ● to_json(value’reflect) ● to_std_logic_vector(value’reflect) VHDL 2017: Library features
3. Use case: Data conversions using reflection + anonymous types ● to_string(value) ● to_json(value) ● to_std_logic_vector(value) VHDL 2017: Library features
● Enhanced records to describe complicated interfaces ● Streamlined everyday use ● Enable new libraries Conclusion: VHDL 2017
Questions ?
