BIOMECHANICS OF TM JOINT
D R . C A M Y B H A G AT ( P T )
M U S C U L O S K E L E TA L C O N D I T I O N S W I T H S P O R T S
INTRODUCTION
• TM joint is unique within the body both structurally
and functionally.
• Structurally, the mandible is a horseshoe-shaped
that articulates with the temporal bone at each end;
thus, the mandible has two different but connected
articulations
• Each TM joint also has a disk that separates the
articulation into discrete upper and lower joints that
each function slightly differently.
INTRODUCTION
INTRODUCTION
• Each TM joint is formed by the condyle (or head) of
the mandible inferiorly and the articular eminence
the temporal bone superiorly with an interposed
articular disk
INTRODUCTION
• The lower joint formed by the mandibular condyle and
the inferior surface of the disk is a simple hinge joint.
• The upper joint formed by the articular eminence and
the superior surface of the disk is a plane or gliding
joint.
INTRODUCTION
• TM joint is classified as a synovial joint, although no
hyaline cartilage covers the articular surfaces.
• The disk increases stability while minimizing loss of
mobility. The articular disk is necessary to reduce
friction and avoid biomechanical stress on the joint
• Mandibular motion plays a role in phonation, facial
expression, mastication, and swallowing.
STRUCTURE
Articular Surfaces
• Above: Mandibular fossa and articular tubercle
• Below: Head of Mandible
Articular Disc
• Biconcave
• Anterior and Posterior portion of disc is Vascular and
innervated
• Middle Portion is Avascular and Not innervated
ARTICULAR DISC
CAPSULE AND LIGAMENTS
• Short capsular fibers running from temporal bone to
disc and disc to neck of condyle.
• Capsule is highly vascularized and innervated, which
provide information about position and movements.
• Ligaments: Temporomandibular ligament,
Stylomandibular Ligament and sphenomandibular
ligament
Tm joint
UPPER AND LOWER
TEMPOROMANDIBULAR JOINTS
• The TM disk divides the TM joint into two separate
joint spaces, each with its own synovial lining.
• Synovial fluid supplies the nutritional demands of the
fibrocartilage covering the joint surfaces and the
avascular middle portion of the disk.
• The lower joint of the TM articulation functions
effectively as a hinge joint. Allows free rotation and
little Translatory movement
UPPER AND LOWER
TEMPOROMANDIBULAR JOINTS
• The upper joint of the TM articulation functions as a
plane joint, with the loose attachment of the disk to
the temporal bone allowing Translatory movement
between the disk and articular eminence.
FUNCTIONS
• The TM joint is one of the most frequently used joints
in the body.
• It is involved in talking, chewing, and swallowing.
• Most TM joint movements are empty-mouth
movements (e.g., talking); that is, they occur with no
resistance from food or contact between the upper
and lower teeth.
• Speech requires fine control of the jaw, and the ability
to chew requires great strength.
MANDIBULAR MOTIONS
• The motions of the TM joint are mouth opening
(mandibular depression), mouth closing
(mandibular elevation), jutting the chin forward
(mandibular protrusion),sliding the teeth backward
(mandibular retrusion),and sliding the teeth to either
side (lateral deviation of the mandible).
MANDIBULAR ELEVATION
AND DEPRESSION
• mouth opening can be found in two sequential
phases: rotation and glide.
• In the rotation phase of mouth opening, there is pure
anterior rotation (spin) of the condyle on the disk in
the lower joint . This has also been described as
posterior rotation of the disk on the condyle.
• Second phase involves translation of the disk-condyle
unit anteriorly and inferiorly along the articular
eminence.
• This motion occurs in the upper joint between the disk
MANDIBULAR ELEVATION
AND DEPRESSION
• Normal mouth opening is considered to be 40 to 50
mm.
• Of that motion, between 11 mm and 25 mm is gained
from rotation of the condyle in the disk, whereas the
remainder is from translation of the disk and condyle
along the articular eminence.
• fit of three PIP joints is considered normal
MANDIBULAR ELEVATION
AND DEPRESSION
• Mandibular elevation (mouth closing) is the reverse of
depression.
• It consists of translation of the disk-condyle unit
posteriorly and superiorly and of posterior rotation of
the condyle on the disk.
CONTROL OF THE DISK DURING MANDIBULAR
ELEVATION AND DEPRESSION
• The articular disk is controlled both actively and
passively during mouth opening and closing.
• The passive control is exerted by the
capsuloligamentous attachments of the disk to the
condyle.
• Active control of the disk may be exerted through the
disk’s attachment anteriorly to the superior portion of
the lateral pterygoid muscle
CONTROL OF THE DISK DURING
MANDIBULAR
ELEVATION AND DEPRESSION
• During mouth closing, the elastic character of the
superior retrodiskal lamina applies a posterior
distractive force on the disk.
• The activity of the superior lateral pterygoid allows the
disk-condyle complex to translate upward and
posteriorly during mouth closing and then maintains
the disk in a forward position until the condyle has
completed its posterior rotation on the disk or until
the disk has rotated anteriorly on the condyle.
MANDIBULAR PROTRUSION
AND RETRUSION
• This motion occurs when all points of the mandible
move forward the same amount.
• The condyle and disk together translate anteriorly and
inferiorly along the articular eminence.
• No rotation occurs in the TM joint during protrusion.
• The motion is all translation and occurs in the upper
joint alone.
MANDIBULAR PROTRUSION
AND RETRUSION
• Retrusion occurs when all points of the mandible
move posteriorly the same amount.
• Tension in the temporomandibular ligament limits this
motion,
Tm joint
MANDIBULAR LATERAL
DEVIATION
• In lateral deviation of the mandible (chin) to one side,
one condyle spins around a vertical axis and the other
condyle translates forward.
• For example, deviation to the right would involve the
right condyle spinning and the left condyle translating
or gliding forward
MUSCULAR CONTROL OF THE
TEMPOROMANDIBULAR JOINT
MUSCULAR CONTROL OF THE
TEMPOROMANDIBULAR JOINT
• The primary muscle responsible for mandibular depression is the
digastric muscle
• The posterior portion of the digastric muscle arises from the
mastoid notch, and the anterior portion arises from the inferior
mandible.
• The tendon that joins the anterior and posterior portions is
connected by a fibrous loop to the hyoid bone in the neck.
MANDIBULAR DEPRESSOR
• The lateral pterygoid muscles are considered to be mandibular
depressors.
• Gravity is also a mandibular depressor.
MANDIBULAR ELEVATOR
• The temporalis muscle attaches to the inside of the coronoid
process .
• The masseter muscle is attached to the outer surface of the
angle and ramus of the mandible.
• The medial pterygoid muscle is attached to the inner surface of
the angle and ramus of the mandible
• the superior portion of the lateral pterygoid is also active
during mouth closing assumed to be eccentric control of the disk
SUMMARY: MANDIBULAR
ELEVATION AND DEPRESSION
• Mouth opening (mandibular depression) is initiated by
concentric action of the digastric muscles bilaterally,
and by the inferior portion of the lateral pterygoid
muscles.
• Mouth closing (mandibular elevation) is produced by
the collective concentric action of the masseter,
temporalis, and medial pterygoid muscles, with
eccentric control of the TM disks by the superior
lateral pterygoid muscles
PROTRUSION, RETRUSION
AND LATERAL DEVIATION
• Mandibular protrusion is produced by bilateral action
of the masseter, medial pterygoid and lateral
pterygoid muscles.
• Retrusion is produced through the bilateral action of
the posterior fibers of the temporalis muscles with
assistance from the anterior portion of the digastric
muscle.
PROTRUSION, RETRUSION
AND LATERAL DEVIATION
• Lateral deviation of the mandible is caused by
unilateral action of a selected set of these muscles.
• The medial and lateral pterygoid muscles each
deviate the mandible to the opposite side. The
temporalis muscle can deviate the mandible to the
same side.
RELATIONSHIP WITH THE
CERVICAL SPINE
• The cervical spine and the TM joint are intimately
connected.
• muscles that attach to the mandible also have
attachments to the head (cranium), to the hyoid bone,
and to the clavicle, atlanto-occipital joint and Cervical.
• Head and neck position, too, may affect the tension in
cervical muscles that, in turn, may affect the position
or function of the mandible.
RELATIONSHIP WITH THE
CERVICAL SPINE
• Proper posture minimizes the force produced by the cervical
extensors and other cervical muscles necessary to support the
weight of the head.
• Poor cervical posture over time may lead to adaptive shortening
or lengthening in muscles around the head and cervical spine,
affecting range of motion, muscular force production
capacity, and joint morphology in the involved region.
TM/CERVICAL
JOINT INTERRELATIONSHIPS
• A forward head posture frequently involves extension of the
occiput and the upper cervical spine, leading to compensatory
flattening of the lower cervical spine and upper thoracic spine to
achieve a level head position.
• With the occiput extended on the atlas (C1), the suboccipital
tissues adapt and shorten.
• The suboccipital tissues include the anterior atlantoaxial and
atlanto-occipital ligaments (cephalad continuations of the
ligamentum flavum), the posterior belly of the digastric muscles,
the stylohyoid muscles, and the upper fibers of the upper
trapezius, semispinalis capitis, and splenius capitis muscles.
TM/CERVICAL
JOINT INTERRELATIONSHIPS
• The forces necessary to maintain the head against
gravity with a poor cervical posture and forward head
result in muscle imbalance and altered movement
patterns.
• Increased tension from shortening of the
tissues may lead to headaches that originate in the
suboccipital area, limitation in active range of motion
of the upper cervical spine, and TM joint dysfunction.
• Furthermore, pain in the TM region may be referred
from the cervical region.
TM/RESPIRATORY/
CERVICAL DYSFUNCTION
• a child with allergies who has difficulty breathing
through the nose will often hyperextend the upper
cervical spine to more fully open the upper respiratory
tract.
• Such a cervical posture places the upper and lower
teeth in contact with each other and may affect the
resting position of the TM joint.
• muscles surrounding the TM joint complex expend
greater energy to maintain this posture and have
more difficulty resting and repair.
TM/RESPIRATORY/
CERVICAL DYSFUNCTION
• Resistance to inspiration may also lead to use of
accessory muscles of respiration (scalene and
sternocleidomastoid muscles) to assist with breathing.
• Use of these accessory muscles may lead to a forward
head posture.
• Such a posture contributes over time to a cycle of
increasing musculoskeletal dysfunction, including
repeated episodes of TM inflammation that can result
in fibrosis of the TM joint capsule.
DENTITION
• Occlusion, or contact of the teeth, is intimately
involved in the function of the TM joint.
• When the central incisors are in firm approximation,
the position is called maximal intercuspation or the
occlusal position.
• This is not, however, the normal resting position of the
mandible. Rather, 1.5 to 5.0 mm of “freeway” space
between the upper and lower incisors is normally
maintained
• By maintaining this space, the intra-articular pressure
within the TM joint is decreased, the stress on the
articular structures is reduced, and the tissues of the
area are able to rest and repair.
AGE-RELATED CHANGES IN THE
TEMPOROMANDIBULAR JOINT
• tissues are likely to become less supple, less elastic,
and less able to withstand maximal forces with aging,
leading to biomechanical changes in musculoskeletal
tissues as one progresses through the life span.
DYSFUNCTIONS
• dysfunctions are caused by direct trauma such as
motor vehicle accidents or falls.
• Others are the result of years of poor postural or oral
habits such as forward head posture or bruxism
(grinding of the teeth).
• most common forms of TM joint complex dysfunction:
inflammatory conditions, capsular fibrosis, osseous
mobility conditions, articular disk displacement, and
degenerative conditions.
INFLAMMATORY
CONDITIONS
• Inflammatory conditions of the TM joint include
capsulitis and synovitis.
• Individuals with inflammatory conditions may
experience diminished mandibular depression as a
result of pain and inflammation within the joint
complex.
• Inflammation can lead to adhesions that restrict the
movement of the disk and limit the function of the TM
joint
OSSEOUS MOBILITY
CONDITIONS
• Osseous mobility disorders of the TM joint complex
include joint hypermobility and dislocation.
• The hypermobility is a result of laxity of the joint
capsules, tendons, and ligaments.
• Joint noises occur at the end of mandibular
depression and at the beginning of mandibular
closing.
• Hypermobility of one TM joint results in deflection of
the mandible toward the contralateral side with mouth
opening.
ARTICULAR DISK
DISPLACEMENT
• The articular disk of the TM joint may sublux,
contributing to dysfunction in this joint.
• Articular disk displacement conditions include disk
displacement with reduction and disk displacement
without reduction.
• Individuals exhibiting disk displacement with
reduction experience “joint noise” at two intervals:
during mandibular opening and mandibular closing.
• This joint noise is known as a reciprocal click and is a
key sign in diagnosing disk displacement with
ARTICULAR DISK
DISPLACEMENT
• Individuals with disk displacement without reduction
typically describe an inability to fully depress the
mandible, as well as difficulty performing functional
movements involving the jaw such as chewing, talking,
or yawning.
• The abnormalities of the lateral pterygoid muscle
noted included hypertrophy, contracture, and
atrophy of the superior and inferior bellies of the
lateral pterygoid muscles of the involved TM joint.
• Hypertrophy of this muscle indicates overactivity,
which thus possibly leads to the excessive anterior
DEGENERATIVE CONDITIONS
• Primarily two conditions affect the TM joint:
osteoarthritis and rheumatoid arthritis
• degenerative changes in the TM joint, including joint
space narrowing, erosions, osteophyte formation,
sclerosis, and remodelling.
• Loss of posterior teeth may also contribute to
degenerative changes because simple occlusion of the
remaining teeth alters the forces that occur between
the TM joint forces
Tm joint

More Related Content

What's hot

Structural adaptations to weight bearing of Hip
Structural adaptations to weight bearing of HipStructural adaptations to weight bearing of Hip
Structural adaptations to weight bearing of Hip
Ajith lolita

Scapulohumeral rhythm and exercises
Scapulohumeral rhythm and exercisesScapulohumeral rhythm and exercises
Scapulohumeral rhythm and exercises
Dr. Rucha Acharya (PT)

Extensor mechanism of finger
Extensor mechanism of fingerExtensor mechanism of finger
Extensor mechanism of finger
Likhit Sai

Kinetics and kimematics of the hip
Kinetics and kimematics of the hipKinetics and kimematics of the hip
Kinetics and kimematics of the hip
Kumarpal Singh

Biomechanics of Posture
Biomechanics of PostureBiomechanics of Posture
Biomechanics of Posture
Yaswanthi Tippani

Biomechanics of foot
Biomechanics  of footBiomechanics  of foot
Biomechanics of foot
Kumarpal Singh

Joint structures and function
Joint structures and functionJoint structures and function
Joint structures and function
Radhika Chintamani

Kinesiology of the Shoulder
Kinesiology of the ShoulderKinesiology of the Shoulder
Kinesiology of the Shoulder
Sado Anatomist

1. biomechanics of the knee joint basics
1. biomechanics of the knee joint  basics1. biomechanics of the knee joint  basics
1. biomechanics of the knee joint basics
Saurab Sharma

Biomechanics of ankle_joint
Biomechanics of ankle_jointBiomechanics of ankle_joint
Biomechanics of ankle_joint
Nityal Kumar

SOFT TISSUE MANIPULATION.pptx
SOFT TISSUE MANIPULATION.pptxSOFT TISSUE MANIPULATION.pptx
SOFT TISSUE MANIPULATION.pptx
sakshiupadhyay88

Tissue biomechanics
Tissue biomechanicsTissue biomechanics
Tissue biomechanics
Kumarpal Singh

Biomechanics of the knee joint
Biomechanics of the knee joint Biomechanics of the knee joint
3. biomechanics of Patellofemoral joint
3. biomechanics of Patellofemoral joint3. biomechanics of Patellofemoral joint
3. biomechanics of Patellofemoral joint
Saurab Sharma

Vertebral column
Vertebral columnVertebral column
Vertebral column
Dr Chandan Verma

Biomechanich of the spine ppt (2)
Biomechanich of the spine ppt (2)Biomechanich of the spine ppt (2)
Biomechanich of the spine ppt (2)
Dr.Debanjan Mondal(PT)

Biomech lumbar spine
Biomech lumbar spineBiomech lumbar spine
Biomech lumbar spine
Muhammadasif909

Postural deviations
Postural deviationsPostural deviations
Postural deviations
Jayasri Prasanna

Wrist joint complex
Wrist joint complexWrist joint complex
Wrist joint complex
Dr Chandan Verma

The Knee Complex
The Knee ComplexThe Knee Complex
The Knee Complex
Philip Keriaka


What's hot (20)

Structural adaptations to weight bearing of Hip
Structural adaptations to weight bearing of HipStructural adaptations to weight bearing of Hip
Structural adaptations to weight bearing of Hip

Scapulohumeral rhythm and exercises
Scapulohumeral rhythm and exercisesScapulohumeral rhythm and exercises
Scapulohumeral rhythm and exercises

Extensor mechanism of finger
Extensor mechanism of fingerExtensor mechanism of finger
Extensor mechanism of finger

Kinetics and kimematics of the hip
Kinetics and kimematics of the hipKinetics and kimematics of the hip
Kinetics and kimematics of the hip

Biomechanics of Posture
Biomechanics of PostureBiomechanics of Posture
Biomechanics of Posture

Biomechanics of foot
Biomechanics  of footBiomechanics  of foot
Biomechanics of foot

Joint structures and function
Joint structures and functionJoint structures and function
Joint structures and function

Kinesiology of the Shoulder
Kinesiology of the ShoulderKinesiology of the Shoulder
Kinesiology of the Shoulder

1. biomechanics of the knee joint basics
1. biomechanics of the knee joint  basics1. biomechanics of the knee joint  basics
1. biomechanics of the knee joint basics

Biomechanics of ankle_joint
Biomechanics of ankle_jointBiomechanics of ankle_joint
Biomechanics of ankle_joint

SOFT TISSUE MANIPULATION.pptx
SOFT TISSUE MANIPULATION.pptxSOFT TISSUE MANIPULATION.pptx
SOFT TISSUE MANIPULATION.pptx

Tissue biomechanics
Tissue biomechanicsTissue biomechanics
Tissue biomechanics

Biomechanics of the knee joint
Biomechanics of the knee joint Biomechanics of the knee joint
Biomechanics of the knee joint

3. biomechanics of Patellofemoral joint
3. biomechanics of Patellofemoral joint3. biomechanics of Patellofemoral joint
3. biomechanics of Patellofemoral joint

Vertebral column
Vertebral columnVertebral column
Vertebral column

Biomechanich of the spine ppt (2)
Biomechanich of the spine ppt (2)Biomechanich of the spine ppt (2)
Biomechanich of the spine ppt (2)

Biomech lumbar spine
Biomech lumbar spineBiomech lumbar spine
Biomech lumbar spine

Postural deviations
Postural deviationsPostural deviations
Postural deviations

Wrist joint complex
Wrist joint complexWrist joint complex
Wrist joint complex

The Knee Complex
The Knee ComplexThe Knee Complex
The Knee Complex


Similar to Tm joint

Temporomadibular joint and prosthodontic implications
Temporomadibular joint and prosthodontic implications Temporomadibular joint and prosthodontic implications
Temporomadibular joint and prosthodontic implications
AniketShinde102

biomechanicsoftmj-210811054244.pdf
biomechanicsoftmj-210811054244.pdfbiomechanicsoftmj-210811054244.pdf
biomechanicsoftmj-210811054244.pdf
ShiriShir

TMJ PPT By Dr.Nasser
TMJ PPT  By Dr.NasserTMJ PPT  By Dr.Nasser
TMJ PPT By Dr.Nasser
Gamal Nasser

TEMPOROMANDIBULAR JOINT 2021.ppt
TEMPOROMANDIBULAR JOINT 2021.pptTEMPOROMANDIBULAR JOINT 2021.ppt
TEMPOROMANDIBULAR JOINT 2021.ppt
PANKAJGANGIL

Parotid & Temporal Regions.pptx
Parotid & Temporal Regions.pptxParotid & Temporal Regions.pptx
Parotid & Temporal Regions.pptx
AbdalrahmanyousefSal

Examination of tmj &muscles of mastication (2)
Examination of tmj &muscles of mastication (2)Examination of tmj &muscles of mastication (2)
Examination of tmj &muscles of mastication (2)
rachitajainr

Anatomy of temporomandibular joint(tmj)
Anatomy of temporomandibular joint(tmj)Anatomy of temporomandibular joint(tmj)
Anatomy of temporomandibular joint(tmj)
oorvi

TMJ - Copy.pptx ANATOMY EXAMINITION DISORDER
TMJ - Copy.pptx ANATOMY EXAMINITION DISORDERTMJ - Copy.pptx ANATOMY EXAMINITION DISORDER
TMJ - Copy.pptx ANATOMY EXAMINITION DISORDER
Nitika588942

Presentation temporomandibular joint anatomy
Presentation temporomandibular joint anatomyPresentation temporomandibular joint anatomy
Presentation temporomandibular joint anatomy
Leena Gangil

TMJ, Muscles of Mastication and their Applied Anatomy .pptx
TMJ, Muscles of Mastication and their Applied Anatomy .pptxTMJ, Muscles of Mastication and their Applied Anatomy .pptx
TMJ, Muscles of Mastication and their Applied Anatomy .pptx
Dr. Mukesh Kumar Dey

Elbow complex (Biomechanics)
Elbow complex (Biomechanics)Elbow complex (Biomechanics)
Elbow complex (Biomechanics)
Ajith lolita

Biomechanics of thorax
Biomechanics of thoraxBiomechanics of thorax
Biomechanics of thorax
DR.RAMANDEEP KAUR SAINI

Shoulder bio-mechanics
Shoulder bio-mechanicsShoulder bio-mechanics
Shoulder bio-mechanics
Maryam Alasfour

tmj ana,phy,dys.pptx
tmj ana,phy,dys.pptxtmj ana,phy,dys.pptx
tmj ana,phy,dys.pptx
DINESHVENKATESAN8

Temporomandibular joint [Autosaved].pptx
Temporomandibular joint [Autosaved].pptxTemporomandibular joint [Autosaved].pptx
Temporomandibular joint [Autosaved].pptx
Abhidha Tripathi

Cervical spine
Cervical spineCervical spine
Cervical spine
Aubreyvale Sagun

TEMPOROMANDIBULAR JOINT & IT'S BIOMECHANICS.pptx
TEMPOROMANDIBULAR JOINT & IT'S BIOMECHANICS.pptxTEMPOROMANDIBULAR JOINT & IT'S BIOMECHANICS.pptx
TEMPOROMANDIBULAR JOINT & IT'S BIOMECHANICS.pptx
SatvikaPrasad

Shoulder by sunil
Shoulder by sunilShoulder by sunil
Shoulder by sunil
sunil JMI

Tmj -muscles & movements/prosthodontic courses
Tmj -muscles & movements/prosthodontic coursesTmj -muscles & movements/prosthodontic courses
Tmj -muscles & movements/prosthodontic courses
Indian dental academy

Tmj muscles &movements / fellowships in orthodontics
Tmj muscles &movements / fellowships in orthodonticsTmj muscles &movements / fellowships in orthodontics
Tmj muscles &movements / fellowships in orthodontics
Indian dental academy


Similar to Tm joint (20)

Temporomadibular joint and prosthodontic implications
Temporomadibular joint and prosthodontic implications Temporomadibular joint and prosthodontic implications
Temporomadibular joint and prosthodontic implications

biomechanicsoftmj-210811054244.pdf
biomechanicsoftmj-210811054244.pdfbiomechanicsoftmj-210811054244.pdf
biomechanicsoftmj-210811054244.pdf

TMJ PPT By Dr.Nasser
TMJ PPT  By Dr.NasserTMJ PPT  By Dr.Nasser
TMJ PPT By Dr.Nasser

TEMPOROMANDIBULAR JOINT 2021.ppt
TEMPOROMANDIBULAR JOINT 2021.pptTEMPOROMANDIBULAR JOINT 2021.ppt
TEMPOROMANDIBULAR JOINT 2021.ppt

Parotid & Temporal Regions.pptx
Parotid & Temporal Regions.pptxParotid & Temporal Regions.pptx
Parotid & Temporal Regions.pptx

Examination of tmj &muscles of mastication (2)
Examination of tmj &muscles of mastication (2)Examination of tmj &muscles of mastication (2)
Examination of tmj &muscles of mastication (2)

Anatomy of temporomandibular joint(tmj)
Anatomy of temporomandibular joint(tmj)Anatomy of temporomandibular joint(tmj)
Anatomy of temporomandibular joint(tmj)

TMJ - Copy.pptx ANATOMY EXAMINITION DISORDER
TMJ - Copy.pptx ANATOMY EXAMINITION DISORDERTMJ - Copy.pptx ANATOMY EXAMINITION DISORDER
TMJ - Copy.pptx ANATOMY EXAMINITION DISORDER

Presentation temporomandibular joint anatomy
Presentation temporomandibular joint anatomyPresentation temporomandibular joint anatomy
Presentation temporomandibular joint anatomy

TMJ, Muscles of Mastication and their Applied Anatomy .pptx
TMJ, Muscles of Mastication and their Applied Anatomy .pptxTMJ, Muscles of Mastication and their Applied Anatomy .pptx
TMJ, Muscles of Mastication and their Applied Anatomy .pptx

Elbow complex (Biomechanics)
Elbow complex (Biomechanics)Elbow complex (Biomechanics)
Elbow complex (Biomechanics)

Biomechanics of thorax
Biomechanics of thoraxBiomechanics of thorax
Biomechanics of thorax

Shoulder bio-mechanics
Shoulder bio-mechanicsShoulder bio-mechanics
Shoulder bio-mechanics

tmj ana,phy,dys.pptx
tmj ana,phy,dys.pptxtmj ana,phy,dys.pptx
tmj ana,phy,dys.pptx

Temporomandibular joint [Autosaved].pptx
Temporomandibular joint [Autosaved].pptxTemporomandibular joint [Autosaved].pptx
Temporomandibular joint [Autosaved].pptx

Cervical spine
Cervical spineCervical spine
Cervical spine

TEMPOROMANDIBULAR JOINT & IT'S BIOMECHANICS.pptx
TEMPOROMANDIBULAR JOINT & IT'S BIOMECHANICS.pptxTEMPOROMANDIBULAR JOINT & IT'S BIOMECHANICS.pptx
TEMPOROMANDIBULAR JOINT & IT'S BIOMECHANICS.pptx

Shoulder by sunil
Shoulder by sunilShoulder by sunil
Shoulder by sunil

Tmj -muscles & movements/prosthodontic courses
Tmj -muscles & movements/prosthodontic coursesTmj -muscles & movements/prosthodontic courses
Tmj -muscles & movements/prosthodontic courses

Tmj muscles &movements / fellowships in orthodontics
Tmj muscles &movements / fellowships in orthodonticsTmj muscles &movements / fellowships in orthodontics
Tmj muscles &movements / fellowships in orthodontics


More from Dr. Camy Bhura

LIMB LENGTH DISCEPANCY.pptx
LIMB LENGTH DISCEPANCY.pptxLIMB LENGTH DISCEPANCY.pptx
LIMB LENGTH DISCEPANCY.pptx
Dr. Camy Bhura

Ortho Evaluation.ppt
Ortho Evaluation.pptOrtho Evaluation.ppt
Ortho Evaluation.ppt
Dr. Camy Bhura

Biofeedback in rehabilitation
Biofeedback in rehabilitationBiofeedback in rehabilitation
Biofeedback in rehabilitation
Dr. Camy Bhura

Physiotherapy management (pa)
Physiotherapy management (pa)Physiotherapy management (pa)
Physiotherapy management (pa)
Dr. Camy Bhura

Physiotherapy management
Physiotherapy managementPhysiotherapy management
Physiotherapy management
Dr. Camy Bhura

Group therapy
Group therapyGroup therapy
Group therapy
Dr. Camy Bhura

Wheel and axle
Wheel and axleWheel and axle
Wheel and axle
Dr. Camy Bhura


More from Dr. Camy Bhura (7)

LIMB LENGTH DISCEPANCY.pptx
LIMB LENGTH DISCEPANCY.pptxLIMB LENGTH DISCEPANCY.pptx
LIMB LENGTH DISCEPANCY.pptx

Ortho Evaluation.ppt
Ortho Evaluation.pptOrtho Evaluation.ppt
Ortho Evaluation.ppt

Biofeedback in rehabilitation
Biofeedback in rehabilitationBiofeedback in rehabilitation
Biofeedback in rehabilitation

Physiotherapy management (pa)
Physiotherapy management (pa)Physiotherapy management (pa)
Physiotherapy management (pa)

Physiotherapy management
Physiotherapy managementPhysiotherapy management
Physiotherapy management

Group therapy
Group therapyGroup therapy
Group therapy

Wheel and axle
Wheel and axleWheel and axle
Wheel and axle


Recently uploaded

C# Interview Questions PDF By ScholarHat.pdf
C# Interview Questions PDF By ScholarHat.pdfC# Interview Questions PDF By ScholarHat.pdf
C# Interview Questions PDF By ScholarHat.pdf
Scholarhat

CTD Punjab Police Past Papers MCQs PPSC PDF
CTD Punjab Police Past Papers MCQs PPSC PDFCTD Punjab Police Past Papers MCQs PPSC PDF
CTD Punjab Police Past Papers MCQs PPSC PDF
hammadmughal76316

Mail Server Configuration Using App passwords in Odoo 17
Mail Server Configuration Using App passwords in Odoo 17Mail Server Configuration Using App passwords in Odoo 17
Mail Server Configuration Using App passwords in Odoo 17
Celine George

The Cruelty of Animal Testing in the Industry.pdf
The Cruelty of Animal Testing in the Industry.pdfThe Cruelty of Animal Testing in the Industry.pdf
The Cruelty of Animal Testing in the Industry.pdf
luzmilaglez334

BÀI TẬP BỔ TRỢ 4 KỸ NĂNG TIẾNG ANH LỚP 12 - GLOBAL SUCCESS - FORM MỚI 2025 - ...
BÀI TẬP BỔ TRỢ 4 KỸ NĂNG TIẾNG ANH LỚP 12 - GLOBAL SUCCESS - FORM MỚI 2025 - ...BÀI TẬP BỔ TRỢ 4 KỸ NĂNG TIẾNG ANH LỚP 12 - GLOBAL SUCCESS - FORM MỚI 2025 - ...
BÀI TẬP BỔ TRỢ 4 KỸ NĂNG TIẾNG ANH LỚP 12 - GLOBAL SUCCESS - FORM MỚI 2025 - ...
Nguyen Thanh Tu Collection

Introduction to Banking System in India.ppt
Introduction to Banking System in India.pptIntroduction to Banking System in India.ppt
Introduction to Banking System in India.ppt
Dr. S. Bulomine Regi

AZ-900 Microsoft Azure Fundamentals Summary.pdf
AZ-900 Microsoft Azure Fundamentals Summary.pdfAZ-900 Microsoft Azure Fundamentals Summary.pdf
AZ-900 Microsoft Azure Fundamentals Summary.pdf
OlivierLumeau1

NAEYC Code of Ethical Conduct Resource Book
NAEYC Code of Ethical Conduct Resource BookNAEYC Code of Ethical Conduct Resource Book
NAEYC Code of Ethical Conduct Resource Book
lakitawilson

formative Evaluation By Dr.Kshirsagar R.V
formative Evaluation By Dr.Kshirsagar R.Vformative Evaluation By Dr.Kshirsagar R.V
formative Evaluation By Dr.Kshirsagar R.V
DrRavindrakshirsagar1

matatag curriculum education for Kindergarten
matatag curriculum education for Kindergartenmatatag curriculum education for Kindergarten
matatag curriculum education for Kindergarten
SarahAlie1

Odoo 17 Social Marketing - Lead Generation On Facebook
Odoo 17 Social Marketing - Lead Generation On FacebookOdoo 17 Social Marketing - Lead Generation On Facebook
Odoo 17 Social Marketing - Lead Generation On Facebook
Celine George

(T.L.E.) Agriculture: Essentials of Gardening
(T.L.E.) Agriculture: Essentials of Gardening(T.L.E.) Agriculture: Essentials of Gardening
(T.L.E.) Agriculture: Essentials of Gardening
MJDuyan

SEQUNCES Lecture_Notes_Unit4_chapter11_sequence
SEQUNCES  Lecture_Notes_Unit4_chapter11_sequenceSEQUNCES  Lecture_Notes_Unit4_chapter11_sequence
SEQUNCES Lecture_Notes_Unit4_chapter11_sequence
Murugan Solaiyappan

Imagination in Computer Science Research
Imagination in Computer Science ResearchImagination in Computer Science Research
Imagination in Computer Science Research
Abhik Roychoudhury

Kesadaran_Berbangsa_dan_Bernegara_Nasion.pptx
Kesadaran_Berbangsa_dan_Bernegara_Nasion.pptxKesadaran_Berbangsa_dan_Bernegara_Nasion.pptx
Kesadaran_Berbangsa_dan_Bernegara_Nasion.pptx
artenzmartenkai

Bài tập bộ trợ anh 7 I learn smart world kì 1 năm học 2022 2023 unit 1.doc
Bài tập bộ trợ anh 7 I learn smart world kì 1 năm học 2022 2023 unit 1.docBài tập bộ trợ anh 7 I learn smart world kì 1 năm học 2022 2023 unit 1.doc
Bài tập bộ trợ anh 7 I learn smart world kì 1 năm học 2022 2023 unit 1.doc
PhngThLmHnh

How to Create & Publish a Blog in Odoo 17 Website
How to Create & Publish a Blog in Odoo 17 WebsiteHow to Create & Publish a Blog in Odoo 17 Website
How to Create & Publish a Blog in Odoo 17 Website
Celine George

"DANH SÁCH THÍ SINH XÉT TUYỂN SỚM ĐỦ ĐIỀU KIỆN TRÚNG TUYỂN ĐẠI HỌC CHÍNH QUY ...
"DANH SÁCH THÍ SINH XÉT TUYỂN SỚM ĐỦ ĐIỀU KIỆN TRÚNG TUYỂN ĐẠI HỌC CHÍNH QUY ..."DANH SÁCH THÍ SINH XÉT TUYỂN SỚM ĐỦ ĐIỀU KIỆN TRÚNG TUYỂN ĐẠI HỌC CHÍNH QUY ...
"DANH SÁCH THÍ SINH XÉT TUYỂN SỚM ĐỦ ĐIỀU KIỆN TRÚNG TUYỂN ĐẠI HỌC CHÍNH QUY ...
thanhluan21

How to Empty a One2Many Field in Odoo 17
How to Empty a One2Many Field in Odoo 17How to Empty a One2Many Field in Odoo 17
How to Empty a One2Many Field in Odoo 17
Celine George

Allopathic M1 Srudent Orientation Powerpoint
Allopathic M1 Srudent Orientation PowerpointAllopathic M1 Srudent Orientation Powerpoint
Allopathic M1 Srudent Orientation Powerpoint
Julie Sarpy


Recently uploaded (20)

C# Interview Questions PDF By ScholarHat.pdf
C# Interview Questions PDF By ScholarHat.pdfC# Interview Questions PDF By ScholarHat.pdf
C# Interview Questions PDF By ScholarHat.pdf

CTD Punjab Police Past Papers MCQs PPSC PDF
CTD Punjab Police Past Papers MCQs PPSC PDFCTD Punjab Police Past Papers MCQs PPSC PDF
CTD Punjab Police Past Papers MCQs PPSC PDF

Mail Server Configuration Using App passwords in Odoo 17
Mail Server Configuration Using App passwords in Odoo 17Mail Server Configuration Using App passwords in Odoo 17
Mail Server Configuration Using App passwords in Odoo 17

The Cruelty of Animal Testing in the Industry.pdf
The Cruelty of Animal Testing in the Industry.pdfThe Cruelty of Animal Testing in the Industry.pdf
The Cruelty of Animal Testing in the Industry.pdf

BÀI TẬP BỔ TRỢ 4 KỸ NĂNG TIẾNG ANH LỚP 12 - GLOBAL SUCCESS - FORM MỚI 2025 - ...
BÀI TẬP BỔ TRỢ 4 KỸ NĂNG TIẾNG ANH LỚP 12 - GLOBAL SUCCESS - FORM MỚI 2025 - ...BÀI TẬP BỔ TRỢ 4 KỸ NĂNG TIẾNG ANH LỚP 12 - GLOBAL SUCCESS - FORM MỚI 2025 - ...
BÀI TẬP BỔ TRỢ 4 KỸ NĂNG TIẾNG ANH LỚP 12 - GLOBAL SUCCESS - FORM MỚI 2025 - ...

Introduction to Banking System in India.ppt
Introduction to Banking System in India.pptIntroduction to Banking System in India.ppt
Introduction to Banking System in India.ppt

AZ-900 Microsoft Azure Fundamentals Summary.pdf
AZ-900 Microsoft Azure Fundamentals Summary.pdfAZ-900 Microsoft Azure Fundamentals Summary.pdf
AZ-900 Microsoft Azure Fundamentals Summary.pdf

NAEYC Code of Ethical Conduct Resource Book
NAEYC Code of Ethical Conduct Resource BookNAEYC Code of Ethical Conduct Resource Book
NAEYC Code of Ethical Conduct Resource Book

formative Evaluation By Dr.Kshirsagar R.V
formative Evaluation By Dr.Kshirsagar R.Vformative Evaluation By Dr.Kshirsagar R.V
formative Evaluation By Dr.Kshirsagar R.V

matatag curriculum education for Kindergarten
matatag curriculum education for Kindergartenmatatag curriculum education for Kindergarten
matatag curriculum education for Kindergarten

Odoo 17 Social Marketing - Lead Generation On Facebook
Odoo 17 Social Marketing - Lead Generation On FacebookOdoo 17 Social Marketing - Lead Generation On Facebook
Odoo 17 Social Marketing - Lead Generation On Facebook

(T.L.E.) Agriculture: Essentials of Gardening
(T.L.E.) Agriculture: Essentials of Gardening(T.L.E.) Agriculture: Essentials of Gardening
(T.L.E.) Agriculture: Essentials of Gardening

SEQUNCES Lecture_Notes_Unit4_chapter11_sequence
SEQUNCES  Lecture_Notes_Unit4_chapter11_sequenceSEQUNCES  Lecture_Notes_Unit4_chapter11_sequence
SEQUNCES Lecture_Notes_Unit4_chapter11_sequence

Imagination in Computer Science Research
Imagination in Computer Science ResearchImagination in Computer Science Research
Imagination in Computer Science Research

Kesadaran_Berbangsa_dan_Bernegara_Nasion.pptx
Kesadaran_Berbangsa_dan_Bernegara_Nasion.pptxKesadaran_Berbangsa_dan_Bernegara_Nasion.pptx
Kesadaran_Berbangsa_dan_Bernegara_Nasion.pptx

Bài tập bộ trợ anh 7 I learn smart world kì 1 năm học 2022 2023 unit 1.doc
Bài tập bộ trợ anh 7 I learn smart world kì 1 năm học 2022 2023 unit 1.docBài tập bộ trợ anh 7 I learn smart world kì 1 năm học 2022 2023 unit 1.doc
Bài tập bộ trợ anh 7 I learn smart world kì 1 năm học 2022 2023 unit 1.doc

How to Create & Publish a Blog in Odoo 17 Website
How to Create & Publish a Blog in Odoo 17 WebsiteHow to Create & Publish a Blog in Odoo 17 Website
How to Create & Publish a Blog in Odoo 17 Website

"DANH SÁCH THÍ SINH XÉT TUYỂN SỚM ĐỦ ĐIỀU KIỆN TRÚNG TUYỂN ĐẠI HỌC CHÍNH QUY ...
"DANH SÁCH THÍ SINH XÉT TUYỂN SỚM ĐỦ ĐIỀU KIỆN TRÚNG TUYỂN ĐẠI HỌC CHÍNH QUY ..."DANH SÁCH THÍ SINH XÉT TUYỂN SỚM ĐỦ ĐIỀU KIỆN TRÚNG TUYỂN ĐẠI HỌC CHÍNH QUY ...
"DANH SÁCH THÍ SINH XÉT TUYỂN SỚM ĐỦ ĐIỀU KIỆN TRÚNG TUYỂN ĐẠI HỌC CHÍNH QUY ...

How to Empty a One2Many Field in Odoo 17
How to Empty a One2Many Field in Odoo 17How to Empty a One2Many Field in Odoo 17
How to Empty a One2Many Field in Odoo 17

Allopathic M1 Srudent Orientation Powerpoint
Allopathic M1 Srudent Orientation PowerpointAllopathic M1 Srudent Orientation Powerpoint
Allopathic M1 Srudent Orientation Powerpoint


Tm joint

  • 1. BIOMECHANICS OF TM JOINT D R . C A M Y B H A G AT ( P T ) M U S C U L O S K E L E TA L C O N D I T I O N S W I T H S P O R T S
  • 2. INTRODUCTION • TM joint is unique within the body both structurally and functionally. • Structurally, the mandible is a horseshoe-shaped that articulates with the temporal bone at each end; thus, the mandible has two different but connected articulations • Each TM joint also has a disk that separates the articulation into discrete upper and lower joints that each function slightly differently.
  • 4. INTRODUCTION • Each TM joint is formed by the condyle (or head) of the mandible inferiorly and the articular eminence the temporal bone superiorly with an interposed articular disk
  • 5. INTRODUCTION • The lower joint formed by the mandibular condyle and the inferior surface of the disk is a simple hinge joint. • The upper joint formed by the articular eminence and the superior surface of the disk is a plane or gliding joint.
  • 6. INTRODUCTION • TM joint is classified as a synovial joint, although no hyaline cartilage covers the articular surfaces. • The disk increases stability while minimizing loss of mobility. The articular disk is necessary to reduce friction and avoid biomechanical stress on the joint • Mandibular motion plays a role in phonation, facial expression, mastication, and swallowing.
  • 7. STRUCTURE Articular Surfaces • Above: Mandibular fossa and articular tubercle • Below: Head of Mandible Articular Disc • Biconcave • Anterior and Posterior portion of disc is Vascular and innervated • Middle Portion is Avascular and Not innervated
  • 9. CAPSULE AND LIGAMENTS • Short capsular fibers running from temporal bone to disc and disc to neck of condyle. • Capsule is highly vascularized and innervated, which provide information about position and movements. • Ligaments: Temporomandibular ligament, Stylomandibular Ligament and sphenomandibular ligament
  • 11. UPPER AND LOWER TEMPOROMANDIBULAR JOINTS • The TM disk divides the TM joint into two separate joint spaces, each with its own synovial lining. • Synovial fluid supplies the nutritional demands of the fibrocartilage covering the joint surfaces and the avascular middle portion of the disk. • The lower joint of the TM articulation functions effectively as a hinge joint. Allows free rotation and little Translatory movement
  • 12. UPPER AND LOWER TEMPOROMANDIBULAR JOINTS • The upper joint of the TM articulation functions as a plane joint, with the loose attachment of the disk to the temporal bone allowing Translatory movement between the disk and articular eminence.
  • 13. FUNCTIONS • The TM joint is one of the most frequently used joints in the body. • It is involved in talking, chewing, and swallowing. • Most TM joint movements are empty-mouth movements (e.g., talking); that is, they occur with no resistance from food or contact between the upper and lower teeth. • Speech requires fine control of the jaw, and the ability to chew requires great strength.
  • 14. MANDIBULAR MOTIONS • The motions of the TM joint are mouth opening (mandibular depression), mouth closing (mandibular elevation), jutting the chin forward (mandibular protrusion),sliding the teeth backward (mandibular retrusion),and sliding the teeth to either side (lateral deviation of the mandible).
  • 15. MANDIBULAR ELEVATION AND DEPRESSION • mouth opening can be found in two sequential phases: rotation and glide. • In the rotation phase of mouth opening, there is pure anterior rotation (spin) of the condyle on the disk in the lower joint . This has also been described as posterior rotation of the disk on the condyle. • Second phase involves translation of the disk-condyle unit anteriorly and inferiorly along the articular eminence. • This motion occurs in the upper joint between the disk
  • 16. MANDIBULAR ELEVATION AND DEPRESSION • Normal mouth opening is considered to be 40 to 50 mm. • Of that motion, between 11 mm and 25 mm is gained from rotation of the condyle in the disk, whereas the remainder is from translation of the disk and condyle along the articular eminence. • fit of three PIP joints is considered normal
  • 17. MANDIBULAR ELEVATION AND DEPRESSION • Mandibular elevation (mouth closing) is the reverse of depression. • It consists of translation of the disk-condyle unit posteriorly and superiorly and of posterior rotation of the condyle on the disk.
  • 18. CONTROL OF THE DISK DURING MANDIBULAR ELEVATION AND DEPRESSION • The articular disk is controlled both actively and passively during mouth opening and closing. • The passive control is exerted by the capsuloligamentous attachments of the disk to the condyle. • Active control of the disk may be exerted through the disk’s attachment anteriorly to the superior portion of the lateral pterygoid muscle
  • 19. CONTROL OF THE DISK DURING MANDIBULAR ELEVATION AND DEPRESSION • During mouth closing, the elastic character of the superior retrodiskal lamina applies a posterior distractive force on the disk. • The activity of the superior lateral pterygoid allows the disk-condyle complex to translate upward and posteriorly during mouth closing and then maintains the disk in a forward position until the condyle has completed its posterior rotation on the disk or until the disk has rotated anteriorly on the condyle.
  • 20. MANDIBULAR PROTRUSION AND RETRUSION • This motion occurs when all points of the mandible move forward the same amount. • The condyle and disk together translate anteriorly and inferiorly along the articular eminence. • No rotation occurs in the TM joint during protrusion. • The motion is all translation and occurs in the upper joint alone.
  • 21. MANDIBULAR PROTRUSION AND RETRUSION • Retrusion occurs when all points of the mandible move posteriorly the same amount. • Tension in the temporomandibular ligament limits this motion,
  • 23. MANDIBULAR LATERAL DEVIATION • In lateral deviation of the mandible (chin) to one side, one condyle spins around a vertical axis and the other condyle translates forward. • For example, deviation to the right would involve the right condyle spinning and the left condyle translating or gliding forward
  • 24. MUSCULAR CONTROL OF THE TEMPOROMANDIBULAR JOINT
  • 25. MUSCULAR CONTROL OF THE TEMPOROMANDIBULAR JOINT • The primary muscle responsible for mandibular depression is the digastric muscle • The posterior portion of the digastric muscle arises from the mastoid notch, and the anterior portion arises from the inferior mandible. • The tendon that joins the anterior and posterior portions is connected by a fibrous loop to the hyoid bone in the neck.
  • 26. MANDIBULAR DEPRESSOR • The lateral pterygoid muscles are considered to be mandibular depressors. • Gravity is also a mandibular depressor.
  • 27. MANDIBULAR ELEVATOR • The temporalis muscle attaches to the inside of the coronoid process . • The masseter muscle is attached to the outer surface of the angle and ramus of the mandible. • The medial pterygoid muscle is attached to the inner surface of the angle and ramus of the mandible • the superior portion of the lateral pterygoid is also active during mouth closing assumed to be eccentric control of the disk
  • 28. SUMMARY: MANDIBULAR ELEVATION AND DEPRESSION • Mouth opening (mandibular depression) is initiated by concentric action of the digastric muscles bilaterally, and by the inferior portion of the lateral pterygoid muscles. • Mouth closing (mandibular elevation) is produced by the collective concentric action of the masseter, temporalis, and medial pterygoid muscles, with eccentric control of the TM disks by the superior lateral pterygoid muscles
  • 29. PROTRUSION, RETRUSION AND LATERAL DEVIATION • Mandibular protrusion is produced by bilateral action of the masseter, medial pterygoid and lateral pterygoid muscles. • Retrusion is produced through the bilateral action of the posterior fibers of the temporalis muscles with assistance from the anterior portion of the digastric muscle.
  • 30. PROTRUSION, RETRUSION AND LATERAL DEVIATION • Lateral deviation of the mandible is caused by unilateral action of a selected set of these muscles. • The medial and lateral pterygoid muscles each deviate the mandible to the opposite side. The temporalis muscle can deviate the mandible to the same side.
  • 31. RELATIONSHIP WITH THE CERVICAL SPINE • The cervical spine and the TM joint are intimately connected. • muscles that attach to the mandible also have attachments to the head (cranium), to the hyoid bone, and to the clavicle, atlanto-occipital joint and Cervical. • Head and neck position, too, may affect the tension in cervical muscles that, in turn, may affect the position or function of the mandible.
  • 32. RELATIONSHIP WITH THE CERVICAL SPINE • Proper posture minimizes the force produced by the cervical extensors and other cervical muscles necessary to support the weight of the head. • Poor cervical posture over time may lead to adaptive shortening or lengthening in muscles around the head and cervical spine, affecting range of motion, muscular force production capacity, and joint morphology in the involved region.
  • 33. TM/CERVICAL JOINT INTERRELATIONSHIPS • A forward head posture frequently involves extension of the occiput and the upper cervical spine, leading to compensatory flattening of the lower cervical spine and upper thoracic spine to achieve a level head position. • With the occiput extended on the atlas (C1), the suboccipital tissues adapt and shorten. • The suboccipital tissues include the anterior atlantoaxial and atlanto-occipital ligaments (cephalad continuations of the ligamentum flavum), the posterior belly of the digastric muscles, the stylohyoid muscles, and the upper fibers of the upper trapezius, semispinalis capitis, and splenius capitis muscles.
  • 34. TM/CERVICAL JOINT INTERRELATIONSHIPS • The forces necessary to maintain the head against gravity with a poor cervical posture and forward head result in muscle imbalance and altered movement patterns. • Increased tension from shortening of the tissues may lead to headaches that originate in the suboccipital area, limitation in active range of motion of the upper cervical spine, and TM joint dysfunction. • Furthermore, pain in the TM region may be referred from the cervical region.
  • 35. TM/RESPIRATORY/ CERVICAL DYSFUNCTION • a child with allergies who has difficulty breathing through the nose will often hyperextend the upper cervical spine to more fully open the upper respiratory tract. • Such a cervical posture places the upper and lower teeth in contact with each other and may affect the resting position of the TM joint. • muscles surrounding the TM joint complex expend greater energy to maintain this posture and have more difficulty resting and repair.
  • 36. TM/RESPIRATORY/ CERVICAL DYSFUNCTION • Resistance to inspiration may also lead to use of accessory muscles of respiration (scalene and sternocleidomastoid muscles) to assist with breathing. • Use of these accessory muscles may lead to a forward head posture. • Such a posture contributes over time to a cycle of increasing musculoskeletal dysfunction, including repeated episodes of TM inflammation that can result in fibrosis of the TM joint capsule.
  • 37. DENTITION • Occlusion, or contact of the teeth, is intimately involved in the function of the TM joint. • When the central incisors are in firm approximation, the position is called maximal intercuspation or the occlusal position. • This is not, however, the normal resting position of the mandible. Rather, 1.5 to 5.0 mm of “freeway” space between the upper and lower incisors is normally maintained • By maintaining this space, the intra-articular pressure within the TM joint is decreased, the stress on the articular structures is reduced, and the tissues of the area are able to rest and repair.
  • 38. AGE-RELATED CHANGES IN THE TEMPOROMANDIBULAR JOINT • tissues are likely to become less supple, less elastic, and less able to withstand maximal forces with aging, leading to biomechanical changes in musculoskeletal tissues as one progresses through the life span.
  • 39. DYSFUNCTIONS • dysfunctions are caused by direct trauma such as motor vehicle accidents or falls. • Others are the result of years of poor postural or oral habits such as forward head posture or bruxism (grinding of the teeth). • most common forms of TM joint complex dysfunction: inflammatory conditions, capsular fibrosis, osseous mobility conditions, articular disk displacement, and degenerative conditions.
  • 40. INFLAMMATORY CONDITIONS • Inflammatory conditions of the TM joint include capsulitis and synovitis. • Individuals with inflammatory conditions may experience diminished mandibular depression as a result of pain and inflammation within the joint complex. • Inflammation can lead to adhesions that restrict the movement of the disk and limit the function of the TM joint
  • 41. OSSEOUS MOBILITY CONDITIONS • Osseous mobility disorders of the TM joint complex include joint hypermobility and dislocation. • The hypermobility is a result of laxity of the joint capsules, tendons, and ligaments. • Joint noises occur at the end of mandibular depression and at the beginning of mandibular closing. • Hypermobility of one TM joint results in deflection of the mandible toward the contralateral side with mouth opening.
  • 42. ARTICULAR DISK DISPLACEMENT • The articular disk of the TM joint may sublux, contributing to dysfunction in this joint. • Articular disk displacement conditions include disk displacement with reduction and disk displacement without reduction. • Individuals exhibiting disk displacement with reduction experience “joint noise” at two intervals: during mandibular opening and mandibular closing. • This joint noise is known as a reciprocal click and is a key sign in diagnosing disk displacement with
  • 43. ARTICULAR DISK DISPLACEMENT • Individuals with disk displacement without reduction typically describe an inability to fully depress the mandible, as well as difficulty performing functional movements involving the jaw such as chewing, talking, or yawning. • The abnormalities of the lateral pterygoid muscle noted included hypertrophy, contracture, and atrophy of the superior and inferior bellies of the lateral pterygoid muscles of the involved TM joint. • Hypertrophy of this muscle indicates overactivity, which thus possibly leads to the excessive anterior
  • 44. DEGENERATIVE CONDITIONS • Primarily two conditions affect the TM joint: osteoarthritis and rheumatoid arthritis • degenerative changes in the TM joint, including joint space narrowing, erosions, osteophyte formation, sclerosis, and remodelling. • Loss of posterior teeth may also contribute to degenerative changes because simple occlusion of the remaining teeth alters the forces that occur between the TM joint forces
