Stop overpaying for outdoor lighting. Here is your 2-minute Wall Pack Buying Guide. đź’ˇ

Not all wall packs are created equal. Choosing the wrong one can lead to light pollution, wasted energy, or frequent maintenance. If you’re upgrading your facility, here’s what you need to know: ✅ The "Mini" Style: Perfect for entryways and low-mounting heights where aesthetics and a compact footprint matter. ✅ Full-Cutoff: The go-to for "Dark Sky" compliance. It directs light strictly downwards, eliminating glare and sky glow. ✅ Half-Cutoff: A balanced approach—providing forward-throw light for wider coverage while still controlling glare. The "Must-Haves" for 2026: Protection: Look for IP65 ratings to ensure your investment survives the elements. Automation: Integrated Photocells for effortless dusk-to-dawn operation. Safety: Emergency Backup options are critical for egress paths during power outages. Compliance: Only buy DLC and ETL/cETL/CE certified products to ensure safety and qualify for utility rebates. We back all our fixtures with a 5-year warranty. Ready to spec the right light for your next project? DM me for our full catalog or a custom quote! 📩 #LEDLighting #EnergyEfficiency #FacilityManagement #LightingDesign #Sustainability

Salesâ—¦
sales Catalog 2026 OUTDOOR LED WALL PACKS Lightide Manufactory sales@lightideled.com www.lightideled.com
Introduction Is your building shrouded in the dim glow of outdated fixtures? Ditch those energy-guzzling monsters and step into the future with our revolutionary LED Wall Packs. These aren't your average lights – they're the ultimate illumination warriors, ready to conquer darkness, slash your energy bills, and keep your property safe
Set up in 2009, Lightide has focused on the lighting industry for over 20 years. In addition, we have designed and produced several varieties of commercial & emergency LED light fixtures. Till now, we have provided service to more than 200 companies from 19 countries. About us www.lightideled.com | sales@lightideled.com
Enhance Security and Aesthetics Selecting the most suitable LED wall pack light necessitates a comprehensive evaluation of several critical factors. This decision-making process should be approached with meticulous attention to detail to ensure the chosen fixture aligns seamlessly with your specific requirements. Ultra Safe: Certified tough (UL924 listed), it provides reliable light for 90 minutes during a blackout, guiding everyone out safely. 01 Saves You Cash: It's DLC-qualified, meaning you get sweet rebates that make this a super affordable upgrade. 02 Super Efficient: It uses way less energy than older lights, saving you money on your bills and helping the planet. Win-win! 03 Built to Last: This weatherproof champ can handle anything Mother Nature throws its way, so you can relax and enjoy the reliable light. 04 www.lightideled.com | sales@lightideled.com
Com. Series Rated Voltage CCT Option Duration Cover LT WP01 40W Blank=100-277vac 30K =3000K DM=1-10VDC STD.=90MIN. Blank=Glass 60W H =200-480vac 40K=4000K PC=Photocell 2H=120MIN. P=Plastic 90W M=120-347vac 50K=5000K MS=Motion 3H=180MIN. 120W E=200-240vac 57K= 5700K EM=Emergency 60WCP =36W-48W- 60W Selectable T= 30K-40K-50K Selectable 120WCP =72W-100W -120W Selectable Remote Control Motion Sensor Model# Wattage Light Output Input Voltage Equivalent Dimension Standard LT-WP01-40W 40 Watt 6,600 Lumens 120-277vac 75-100 Watt MH/HPS 14.4"X9.25"X7.5" DLC, ETL, cETL, CE, RoHS LT-WP01-60W 60 Watt 9,600 Lumens 120-277vac 125-150 Watt MH/HPS 14.4"X9.25"X7.5" DLC, ETL, cETL, CE, RoHS LT-WP01-90W 90 Watt 12,400 Lumens 120-277vac 250 Watt MH/HPS 14.4"X9.25"X7.5" DLC, ETL, cETL, CE, RoHS LT-WP01-120W 120 Watt 16,400 Lumens 120-277vac 400 Watt MH/HPS 14.4"X9.25"X7.5" DLC, ETL, cETL, CE, RoHS premium Chip 140 LPW Emergency Backup www.lightideled.com | sales@lightideled.com SEMI CUT-OFF LT-WP01 Series ORDERING GUIDE 01 02 Emergency Backup Option 1. UL924 & CEC Title 20 Compliant 2. DoE High Efficiency 3. Internal battery 4. Charge cycle: >500 times 5. Work Temp. -22°F~+122°F ( -30°C~50°C). 6. 2in1 Test switch + Indicator lamp Wide Input Voltage – 100-277 or 120~347vac Excellent Efficacy – 140 lumens per watt Std.1-10vdc Dimming Work Temperature: -40ºF ~+140°F High-duty die-casting aluminum case Shatter-proof PC or Tempered glass diffuser IP65 Waterproof Dark Sky Compliant Shield SPECIFICATION DIMENSION
Com. Series Rated Voltage CCT Option Duration Cover LT WP03 40W Blank=100-277vac 30K =3000K DM=1-10VDC STD.=90MIN. Blank=Glass 60W H =200-480vac 40K=4000K PC=Photocell 2H=120MIN. P=Plastic 90W M=120-347vac 50K=5000K MS=Motion 3H=180MIN. 120W E=200-240vac 57K= 5700K EM=Emergency T= 30K-40K-50K Selectable Model# Wattage Light Output Input Voltage Equivalent Dimension Standard LT-WP03-40W 40 Watt 6,600 Lumens 120-277vac 75-100 Watt MH/HPS 13-3/4″X9-1/4″X4-1/3″ ETL, cETL, CE, RoHS LT-WP03-60W 60 Watt 9,600 Lumens 120-277vac 125-150 Watt MH/HPS 13-3/4″X9-1/4″X4-1/3″ ETL, cETL, CE, RoHS LT-WP03-90W 90 Watt 12,400 Lumens 120-277vac 250 Watt MH/HPS 13-3/4″X9-1/4″X4-1/3″ ETL, cETL, CE, RoHS LT-WP03-120W 120 Watt 16,400 Lumens 120-277vac 400 Watt MH/HPS 13-3/4″X9-1/4″X4-1/3″ ETL, cETL, CE, RoHS premium Chip 140 LPW Remote Control Motion Sensor Emergency Backup www.lightideled.com | sales@lightideled.com SEMI CUT-OFF LT-WP03 Series ORDERING GUIDE 01 02 Emergency Backup Option 1. UL924 & CEC Title 20 Compliant 2. DoE High Efficiency 3. Internal battery 4. Charge cycle: >500 times 5. Work Temp. -22°F~+122°F ( -30°C~50°C). 6. 2in1 Test switch + Indicator lamp Wide Input Voltage – 100-277 or 120~347vac Excellent Efficacy – 140 lumens per watt Std.1-10vdc Dimming Work Temperature: -40ºF ~+140°F High-duty die-casting aluminum case Shatter-proof PC or Tempered glass diffuser IP65 Waterproof SPECIFICATION DIMENSION
Remote Control Motion Sensor Com. Series Rated Voltage CCT Option Duration Finish LT WPCA 35W Blank=100-277vac 30K =3000K DM=1-10VDC STD.=90MIN. Blank=Bronze 60W H =200-480vac 40K=4000K PC=Photocell 2H=120MIN. WH=White 80W M=120-347vac 50K=5000K MS=Motion Sensor 3H=180MIN. E=200-240vac 57K= 5700K EM=Emergency Battery 65K= 6500K Model# Wattage Light Output Input Voltage Equivalent Dimension Standard LT-WPCA-35W 35 Watt 4,900 Lumens 120-277vac 75-100 Watt MH/HPS 320X182X182 MM ETL, cETL, CE, RoHS LT-WPCA-60W 60 Watt 6,600 Lumens 120-277vac 125-150 Watt MH/HPS 320X182X182 MM ETL, cETL, CE, RoHS LT-WPCA-80W 80 Watt 11,400 Lumens 120-277vac 250 Watt MH/HPS 320X182X182 MM ETL, cETL, CE, RoHS Emergency Backup Option 1. UL924 & CEC Title 20 Compliant 2. DoE High Efficiency 3. Internal /external battery 4. Charge cycle: >500 times 5. Work Temp. -22°F~+122°F ( -30°C~50°C). 6. 2in1 Test switch + Indicator lamp 01 02 Wide Input Voltage – 100-277 or 120~347vac Excellent Efficacy – 140 lumens per watt Std.1-10vdc Dimming Work Temperature: -40ºF ~+130°F High-duty die-casting aluminum case Shatter-proof PC Motion Sensor/Photocell available Type III IP65 Outdoor Rated FULL CUT-OFF LT-WPCA Series (Trapezoid) ORDERING GUIDE SPECIFICATION Emergency Backup Premium Chip 140 LPW (Type III) Photocell www.lightideled.com | sales@lightideled.com DIMENSION
Remote Control Motion Sensor Com. Series Rated Voltage CCT Option Duration Finish LT WPCS 50W Blank=100-277vac 30K =3000K DM=1-10VDC STD.=90MIN. Blank=Bronze 80W H =200-480vac 40K=4000K PC=Photocell 2H=120MIN. WH=White 100W M=120-347vac 50K=5000K MS=Motion Sensor 3H=180MIN. E=200-240vac 57K= 5700K EM=Emergency Battery Model# Wattage Light Output Input Voltage Equivalent Dimension Standard LT-WPCS-50W 50 Watt 6,500 Lumens 120-277vac 75-100 Watt MH/HPS 14.24“x6.6″x9.27″ ETL, cETL, CE, RoHS LT-WPCS-80W 80 Watt 10,600 Lumens 120-277vac 125-150 Watt MH/HPS 14.24“x6.6″x9.27″ ETL, cETL, CE, RoHS LT-WPCS-100W 100 Watt 13,400 Lumens 120-277vac 250 Watt MH/HPS 14.24“x6.6″x9.27″ ETL, cETL, CE, RoHS Emergency Backup Option 1. UL924 & CEC Title 20 Compliant 2. DoE High Efficiency 3. Internal /external battery 4. Charge cycle: >500 times 5. Work Temp. -22°F~+122°F ( -30°C~50°C). 6. 2in1 Test switch + Indicator lamp 01 02 Wide Input Voltage – 100-277 or 120~347vac Excellent Efficacy – 140 lumens per watt Std.1-10vdc Dimming Work Temperature: -40ºF ~+130°F High-duty die-casting aluminum case Shatter-proof PC Motion Sensor/Photocell available Type III IP65 Outdoor Rated FULL CUT-OFF LT-WPCS Series (Trapezoid) ORDERING GUIDE SPECIFICATION Emergency Backup Premium Chip 140 LPW (Type III) Photocell www.lightideled.com | sales@lightideled.com DIMENSION
Com. Series Rated Profile CCT Finish LT WP02 15W 30K =3000K Blank=Bronze 20W S 40K=4000K WH= White 25W T 50K=5000K 30W 57K= 5700K 40W Blank= 30K-40K-50K Selectable LT-WP02-S Series (20W, 30W, 40W) LT-WP02 series (15W, 25W, 30W) Style Option 1. Standard WP02 Series 15W, 25W, 30W 2. S series 30W 3. T series 20W, 30W, 40W Model# Wattage Light Output Style Option Equivalent Dimension CCT LT-WP02-15W 15 Watt 1,650 Lumens Std. 35-50 Watt MH/HPS 213X142X82 MM 2700K-6500K LT-WP02-20WS 20 Watt 3,000 Lumens S 35-50 Watt MH/HPS 224X144X85 MM 2700K-6500K LT-WP02-25W 25 Watt 2,625 Lumens Std. 50 Watt MH/HPS 213X142X82 MM 2700K-6500K LT-WP02-30W 30 Watt 3,600 Lumens Std. 75-100 Watt MH/HPS 213X142X82 MM 2700K-6500K LT-WP02-30WS 30 Watt 3,900 Lumens S 75-100 Watt MH/HPS 224X144X85 MM 2700K-6500K LT-WP02-30WT 30 Watt 3,600 Lumens T 75-100 Watt MH/HPS 223X150X65 MM 30K-40K-50K Selectable LT-WP02-40S 40 Watt 4,800 Lumens S 100 Watt MH/HPS 224X144X85 MM 30K-40K-50K Selectable 01 02 Wide Input Voltage – 100-277 VAC Excellent Efficacy – 110-130 lumens per watt Std. Non-Dimming High-duty die-casting aluminum case Shatter-proof PC Standard photocell control 120 degree IP65 Outdoor Rated MINI STYLE LT-WP02 Series (HALF CUTOFF) SPECIFICATION ORDERING GUIDE www.lightideled.com | sales@lightideled.com LT-WP02-T series (30W)
Com. Series Code Rated Voltage CCT Option Duration Finish LT WRA 145 12W Blank=100-277vac 30K =3000K DM=1-10VDC STD.=90MIN. Blank=Black WRB 220 15W E=200-240vac 40K=4000K PC=Photocell 2H=120MIN. WH=White WRC 275 20W 50K=5000K MS=Motion Sensor 3H=180MIN. WRD 360 30W 57K= 5700K EM=Internal Battery WRE Model# Wattage Light Output Input Voltage Equivalent Dimension Standard LT-WRX145-12W 12 Watt 1,400 Lumens 120-277vac 150 Watt Halogen D145X65 MM ETL, cETL, CE, RoHS LT-WRX220-15W 15 Watt 1,800 Lumens 120-277vac 150 Watt Halogen D220X65 MM ETL, cETL, CE, RoHS LT-WRX275-20W 20 Watt 2,400 Lumens 120-277vac 250 Watt Halogen D275X65 MM ETL, cETL, CE, RoHS LT-WRX360-30W 30 Watt 3,600 Lumens 120-277vac 400 Watt Halogen D350X65 MM ETL, cETL, CE, RoHS WRA SERIES (No Grid) WRB SERIES (Half Cutoff) WRD SERIE (# Grid) WRC SERIES (Y Grid) WRE SERIE (+ Grid) 01 Wide Input Voltage – 100-277 or 120~347vac Excellent Efficacy – 120 lumens per watt Flush Mount Work Temperature: -40ºF ~+130°F High-duty die-casting aluminum case Shatter-proof PC Photocell available 120 degree IP65 Outdoor Rated BULKHEAD LT-WRX Series SPECIFICATION Emergency Backup Option 1. UL924 & CEC Title 20 Compliant 2. DoE High Efficiency 3. Internal/exterior battery 4. Charge cycle: >500 times 5. Work Temp. -22°F~+122°F ( -30°C~50°C). 6. 2in1 Test switch + Indicator lamp 02 ORDERING GUIDE X means A,B,C,D,E,F www.lightideled.com | sales@lightideled.com
Com. Series Code Wattage CCT Option EM (Duration) Base Finish LT WLA 200 12W 30K =3000K MS=Microwave Motion Sensor STD.=90 MIN. Blank=Black WLB 230 15W 40K=4000K EM= Emergency Battery Back 2H=120 MIN. WH= White WLD 18W 50K=5000K PS= PIR Motion Sensor 3H=180 MIN. WLE 20W 57K= 5700K 10W WLD SERIES (# Grid) WLA SERIES (No Grid) ORDERING GUIDE WLE SERIES (+ Grid) WLB SERIES (Half Cutoff) Model# Wattage Light Output Input Voltage Equivalent Dimension Standard LT-WLX200-12W 12 Watt 1,400 Lumens 120-277vac 150 Watt Halogen 200X100X65 MM ETL, cETL, CE, RoHS LT-WLX200-15W 15 Watt 1,800 Lumens 120-277vac 150 Watt Halogen 200X100X65 MM ETL, cETL, CE, RoHS LT-WLX230-18W 18 Watt 2,160 Lumens 120-277vac 250 Watt Halogen 230X100X65 MM ETL, cETL, CE, RoHS LT-WLX230-20W 20 Watt 2,400 Lumens 120-277vac 250 Watt Halogen 230X100X65 MM ETL, cETL, CE, RoHS 01 Wide Input Voltage – 100-277 or 120~347vac Excellent Efficacy – 120 lumens per watt Flush Mount Work Temperature: -40ºF ~+130°F High-duty die-casting aluminum case Shatter-proof PC Photocell available 120 degree IP65 Outdoor Rated BULKHEAD LT-WLX Series SPECIFICATION X means A,B,D,E, Emergency Backup Option 1. UL924 & CEC Title 20 Compliant 2. DoE High Efficiency 3. Internal/exterior battery 4. Charge cycle: >500 times 5. Work Temp. -22°F~+122°F ( -30°C~50°C). 6. 2in1 Test switch + Indicator lamp 02 www.lightideled.com | sales@lightideled.com
Com. Series Rated Voltage CCT Option LT AF02 35W Blank=120-277vac 30K =3000K DM=1-10VDC 70W HV=200-480vac 40K=4000K PC1=Big Photocell 50K=5000K PC2=Small Photocell 57K= 5700K ORDERING GUIDE PHOTOCELL Dusk-Dawn Model# Wattage Light Output Input Voltage Equivalent Dimension Standard LT-AF02-35W 30 Watt 3,850 Lumens 120-277vac 75-125 Watt Halogen 268x175x100 MM ETL, cETL, CE, RoHS LT-AF02-75W 72 Watt 7,920 Lumens 120-277vac 150-250 Watt Halogen 350x240x125 MM ETL, cETL, CE, RoHS 01 Wide Input Voltage – 100-277 or 120~347vac Excellent Efficacy – Up to 130 lumens per watt Flush Mount Work Temperature: -40ºF ~+130°F High-duty die-casting aluminum case Shatter-proof PC Photocell available 120 degree IP65 Outdoor Rated BARN LIGHT LT-af02 Series SPECIFICATION www.lightideled.com | sales@lightideled.com
Com. Series Code Rated Voltage CCT Option Mount Base Beam Angle LT SBAL C 100=100W Blank=100-277vac 30K =3000K DM=1-10VDC SF=Slip fitter Blank=T3 150=150W HV=200-480vac 40K=4000K PC=Photocell EA=Adjustable Arm T2=Type II 200=200W 50K=5000K MS=Motion T5=Type V 250=250W 57K= 5700K 300=300W Model# Wattage Light Output Input Voltage Equivalent Dimension Standard LT-SBALC-100W 100 Watt 14,050 Lumens 100-277vac 250 Watt MH/HPS 532X315X183 MM DLC, ETL, cETL, CE, RoHS LT-SBALC-150W 150 Watt 21,920 Lumens 100-277vac 400 Watt MH/HPS 532X315X183 MM DLC, ETL, cETL, CE, RoHS LT-SBALC-200W 200 Watt 28,260 Lumens 100-277vac 600 Watt MH/HPS 532X315X183 MM DLC, ETL, cETL, CE, RoHS LT-SBALC-250W 250 Watt 33,600 Lumens 100-277vac 600 Watt MH/HPS 820X315X164 MM DLC, ETL, cETL, CE, RoHS LT-SBALC-300W 300 Watt 44,920 Lumens 100-277vac 1000 Watt MH/HPS 820X315X164 MM DLC, ETL, cETL, CE, RoHS Mount Adapter Optiins ORDERING GUIDE Wide Input Voltage – 100-277 or 120~347vac Excellent Efficacy – 140 lumens per watt Wall Mount Adapter Work Temperature: -40ºF ~+130°F High-duty die-casting aluminum case Shatter-proof PC Two style of Photocell (small, big) available Type II, III, V Beam angle IP66 Outdoor Rated PARKING LOT LIGHT LT-SBAL (C) Series SPECIFICATION Photocell Sensor Light Distribution: Type II, III, V www.lightideled.com | sales@lightideled.com 01 02 Installation Options Wall Mount Slip Fitter (1.9"-2.3" tenon) Yoke surface mount Trunnion surface mount
Semi Cutoff Full Cutoff Mini Style Bulkhead Parking Lot Light shield wire guard Mount Adapter Emergency Battery Choose Style Choose Wattage Choose Accessories Choose Options LED WALL PACKS CHOOSING GUIDE 40W 100W EQUIV. Up to 4,800 lm 60W 150W EQUIV. Up to 7,200 lm 90W 250W EQUIV. Up to 10,800 lm 120W 250W EQUIV. Up to 14,400 lm CCT 3000K 4000K 5000K 5700K Voltage 100-277vac 347vac 480 vac Control 1-10vdc dim Motion Photocell Emergency Cover Glass Plastic www.lightideled.com | sales@lightideled.com
1 2 3 4 5 Choosing Light Distribution Made Easy: A Guide to Light Spread/Distribution 1. Size Matters: Think about how big your space is. Bigger areas need lights that spread light out wide, while smaller spaces do better with more focused beams. This will help you get the right amount of light everywhere. 2. What are you using the lights for? Do you just want some general light, or do you need something bright for working on tasks? Different light spreads work better for different things. Wide beams are good for even light everywhere, while narrow beams are great for spotlighting specific areas. Check out the light spread options and the light fixtures themselves to see what works best for you. 3. How High Up Will They Be? Where you put the lights affects how the light spreads. Higher lights need wider beams to reach everything, while lower lights work better with narrower beams so they don’t create glare. 4. Don't Forget the Weather! For outdoor lights, consider how rain, wind, and other weather might affect the light. 5. Light Distribution Patterns Choices! There are many different LED light distribution types, like Type I, II, III, IV, and V. Each one spreads light in a different way, so there’s a perfect fit for your needs. Do some research to see which type works best for you. www.lightideled.com | sales@lightideled.com
THANKYOU! THANKYOU! THANKYOU! THANKYOU! PRESENTED BY: LIGHTIDE MANUFACTORY www.lightideled.com sales@lightideled.com
