Self-healing data
An introduction to consistency models, Quorums and CRDTs

Uwe Friedrichsen, codecentric AG, 2014-2015
@ufried
Uwe Friedrichsen | uwe.friedrichsen@codecentric.de | http://slideshare.net/ufried | http://ufried.tumblr.com
Why NoSQL?



•  Scalability
•  Easier schema evolution
•  Availability on unreliable OTS hardware
•  It‘s more fun ...
Why NoSQL?



•  Scalability
•  Easier schema evolution
•  Availability on unreliable OTS hardware
•  It‘s more fun ...
Challenges



•  Giving up ACID transactions
•  (Temporal) anomalies and inconsistencies

short-term due to replication or long-term due to partitioning


It might happen. Thus, it will happen!
C
Consistency
A
Availability
P
Partition Tolerance
Strict Consistency

ACID / 2PC
Strong Consistency

Quorum R&W / Paxos
Eventual Consistency

CRDT / Gossip / Hinted Handoff
Strict Consistency (CA)

•  Great programming model

no anomalies or inconsistencies need to be considered
•  Does not scale well

best for single node databases

„We know ACID – It works!“
„We know 2PC – It sucks!“

Use for moderate data amounts
And what if I need more data?






•  Distributed datastore
•  Partition tolerance is a must
•  Need to give up strict consistency (CP or AP)
Strong Consistency (CP)

•  Majority based consistency model

can tolerate up to N nodes failing out of 2N+1 nodes
•  Good programming model

Single-copy consistency
•  Trades consistency for availability

in case of partitioning

Paxos (for sequential consistency)
Quorum-based reads & writes
Quorum-based reads & writes


•  N – number of nodes (replicas)
•  R – number of reads delivering the same result required
•  W – number of confirmed writes required

W > N / 2
R + W > N
Example 1

•  3 replica nodes

This is: N = 3
•  W > N / 2 à W > 3 / 2 à W > 1,5

Let‘s pick: W = 2 (can tolerate failure of 1 node)
•  R + W > N à R + 2 > 3 à R > 1

Let‘s pick: R = 2 (can tolerate failure of 1 node)
Client
Node 1
 Node 3
Node 2
W
 W
W
Client
Node 1
 Node 3
Node 2
Client
Node 1
 Node 3
Node 2
✔
 ✖
✔
W = 2
 ✔
Client
Node 1
 Node 3
Node 2
R
 R
R
Client
Node 1
 Node 3
Node 2
✔
 ✔
 ✔
Client
Node 1
 Node 3
Node 2
2x / 1x
 ✔
R = 2
 ✔
Client
Node 1
 Node 3
Node 2
R
 R
R
Client
Node 1
 Node 3
Node 2
✔
 ✔
✖
Client
Node 1
 Node 3
Node 2
1x / 1x
 ✖
R = 1
 ✖
Example 2

•  3 replica nodes

This is: N = 3
•  W > N / 2 à W > 3 / 2 à W > 1,5

Let‘s pick: W = 3 (strict consistency – does not tolerate any failure)
•  R + W > N à R + 3 > 3 à R > 0

Let‘s pick: R = 1 (single read from any node sufficient)
Example 3

•  5 replica nodes

This is: N = 5
•  W > N / 2 à W > 5 / 2 à W > 2,5

Let‘s pick: W = 3 (can tolerate failure of 2 nodes)
•  R + W > N à R + 3 > 5 à R > 2

Let‘s pick: R = 3 (can tolerate failure of 2 nodes)
Limitations of QB R&W

•  Requires fixed set of replica nodes

Dynamic adding and removal of nodes not possible
•  Client-centric consistency

Consistency only perceived on client, not on nodes
•  Requires additional measures on nodes

Nodes need to implement at least eventual consistency

Use if client-perceived strong consistency is

sufficient and simplicity trumps formal precision
And what if I need more availability?






•  Need to give up strong consistency (CP)
•  Relax required consistency properties even more
•  Leads to eventual consistency (AP)
Eventual Consistency (AP)

•  Gives up some consistency guarantees

no sequential consistency, anomalies become visible
•  Maximum availability possible

can tolerate up to N-1 nodes failing out of N nodes
•  Challenging programming model

anomalies usually need to be resolved explicitly

Gossip / Hinted Handoffs
CRDT
Conflict-free Replicated Data Types


•  Eventually consistent, self-stabilizing data structures
•  Designed for maximum availability
•  Tolerates up to N-1 out of N nodes failing

State-based CRDT: Convergent Replicated Data Type (CvRDT)
Operation-based CRDT: Commutative Replicated Data Type (CmRDT)
A bit of theory first ...
Convergent Replicated Data Type

State-based CRDT – CvRDT

•  All replicas (usually) connected
•  Exchange state between replicas, calculate new state on target replica
•  State transfer at least once over eventually-reliable channels
•  Set of possible states form a Semilattice
•  Partially ordered set of elements where all subsets have a Least Upper Bound (LUB)
•  All state changes advance upwards with respect to the partial order
Commutative Replicated Data Type

Operation-based CRDT - CmRDT

•  All replicas (usually) connected
•  Exchange update operations between replicas, apply on target replica
•  Reliable broadcast with ordering guarantee for non-concurrent
updates
•  Concurrent updates must be commutative
That‘s been enough theory ...
Counter
Op-based Counter

Data
Integer i
Init
i ≔ 0
Query
return i
Operations
increment(): i ≔ i + 1
decrement(): i ≔ i - 1
State-based G-Counter (grow only)
(Naïve approach)

Data
Integer i
Init
i ≔ 0
Query
return i
Update
increment(): i ≔ i + 1
Merge( j)
i ≔ max(i, j)
State-based G-Counter (grow only)
(Naïve approach)
R1
R3
R2
i = 1
U
i = 1
U
i = 0
i = 0
i = 0
I
I
I
M
i = 1
 i = 1
M
State-based G-Counter (grow only)
(Vector-based approach)

Data
Integer V[] / one element per replica set
Init
V ≔ [0, 0, ... , 0]
Query
return ∑i V[i]
Update
increment(): V[i] ≔ V[i] + 1 / i is replica set number
Merge(V‘)
∀i ∈ [0, n-1] : V[i] ≔ max(V[i], V‘[i])
State-based G-Counter (grow only)
(Vector-based approach)
R1
R3
R2
V = [1, 0, 0]
U
V = [0, 0, 0]
I
I
I
V = [0, 0, 0]
V = [0, 0, 0]
U
V = [0, 0, 1]
M
V = [1, 0, 0]
M
V = [1, 0, 1]
State-based PN-Counter (pos./neg.)


•  Simple vector approach as with G-Counter does not work
•  Violates monotonicity requirement of semilattice
•  Need to use two vectors
•  Vector P to track incements
•  Vector N to track decrements
•  Query result is ∑i P[i] – N[i]
State-based PN-Counter (pos./neg.)

Data
Integer P[], N[] / one element per replica set
Init
P ≔ [0, 0, ... , 0], N ≔ [0, 0, ... , 0]
Query
Return ∑i P[i] – N[i]
Update
increment(): P[i] ≔ P[i] + 1 / i is replica set number
decrement(): N[i] ≔ N[i] + 1 / i is replica set number
Merge(P‘, N‘)
∀i ∈ [0, n-1] : P[i] ≔ max(P[i], P‘[i])
∀i ∈ [0, n-1] : N[i] ≔ max(N[i], N‘[i])
Non-negative Counter

Problem: How to check a global invariant with local information only?

•  Approach 1: Only dec when local state is > 0
•  Concurrent decs could still lead to negative value

•  Approach 2: Externalize negative values as 0
•  inc(negative value) == noop(), violates counter semantics

•  Approach 3: Local invariant – only allow dec if P[i] - N[i] > 0
•  Works, but may be too strong limitation

•  Approach 4: Synchronize
•  Works, but violates assumptions and prerequisites of CRDTs
Sets
Op-based Set
(Naïve approach)

Data
Set S
Init
S ≔ {}
Query(e)
return e ∈ S
Operations
add(e) : S ≔ S ∪ {e}
remove(e): S ≔ S  {e}
Op-based Set
(Naïve approach)
R1
R3
R2
S = {e}
add(e)
S = {}
S = {}
S = {}
I
I
I
S = {e}
S = {}
rmv(e)
add(e)
add(e)
 add(e)
 rmv(e)
add(e)
S = {e}
S = {e}
 S = {e}
 S = {}
State-based G-Set (grow only)

Data
Set S
Init
S ≔ {}
Query(e)
return e ∈ S
Update
add(e): S ≔ S ∪ {e}
Merge(S‘)
S = S ∪ S‘
State-based 2P-Set (two-phase)

Data
Set A, R / A: added, R: removed
Init
A ≔ {}, R ≔ {}
Query(e)
return e ∈ A ∧ e ∉ R
Update
add(e): A ≔ A ∪ {e}
remove(e): (pre query(e)) R ≔ R ∪ {e}
Merge(A‘, R‘)
A ≔ A ∪ A‘, R ≔ R ∪ R‘
Op-based OR-Set (observed-remove)

Data
Set S / Set of pairs { (element e, unique tag u), ... }
Init
S ≔ {}
Query(e)
return ∃u : (e, u) ∈ S
Operations
add(e): S ≔ S ∪ { (e, u) } / u is generated unique tag
remove(e):
pre query(e)
R ≔ { (e, u) | ∃u : (e, u) ∈ S } /at source („prepare“)
S ≔ S  R /downstream („execute“)
Op-based OR-Set (observed-remove)
R1
R3
R2
S = {ea}
add(e)
S = {}
S = {}
S = {}
I
I
I
S = {eb}
S = {}
rmv(e)
add(e)
add(eb)
 add(ea)
 rmv(ea)
add(eb)
S = {eb}
S = {eb}
 S = {ea, eb}
 S = {eb}
More datatypes

•  Register
•  Dictionary (Map)
•  Tree
•  Graph
•  Array
•  List

plus more representations for each datatype
Garbage collection

•  Sets could grow infinitely in worst case
•  Garbage collection possible, but a bit tricky
•  Only remove updates that can be deleted safely
and were received by all replicas
•  Usually implemented using vector clocks
•  Can tolerate up to n-1 crashes
•  Live only while no replicas are crashed
•  Can induce surprising behavior sometimes
•  Sometimes stronger consensus is needed (Paxos, ...)
Limitations of CRDTs

•  Very weak consistency guarantees

Strives for „quiescent consistency“
•  Eventually consistent

Not suitable for high-volume ID generator or alike
•  Not easy to understand and model
•  Not all data structures representable

Use if availability is extremely important
Further reading

1.  Shapiro et al., Conflict-free Replicated
Data Types, Inria Research report, 2011
2.  Shapiro et al., A comprehensive study
of Convergent and Commutative
Replicated Data Types,

Inria Research report, 2011
3.  Basho Tag Archives: CRDT,

https://basho.com/tag/crdt/
4.  Leslie Lamport,

Time, clocks, and the ordering of
events in a distributed system,

Communications of the ACM (1978)
Wrap-up

•  CAP requires rethinking consistency
•  Strict Consistency

ACID / 2PC
•  Strong Consistency

Quorum-based R&W, Paxos
•  Eventual Consistency

CRDT, Gossip, Hinted Handoffs

Pick your consistency model based on your

consistency and availability requirements
The real world is not ACID
Thus, it is perfectly fine to go for a relaxed consistency model
@ufried
Uwe Friedrichsen | uwe.friedrichsen@codecentric.de | http://slideshare.net/ufried | http://ufried.tumblr.com
Self healing data

More Related Content

What's hot

Event Driven Architecture
Event Driven ArchitectureEvent Driven Architecture
Event Driven Architecture
Sistek Yazılım

Application Resilience Patterns
Application Resilience PatternsApplication Resilience Patterns
Application Resilience Patterns
Kiran Sama

NETCONF Call Home
NETCONF Call Home NETCONF Call Home
NETCONF Call Home
ADVA

SRv6 Mobile User Plane : Initial POC and Implementation
SRv6 Mobile User Plane : Initial POC and ImplementationSRv6 Mobile User Plane : Initial POC and Implementation
SRv6 Mobile User Plane : Initial POC and Implementation
Kentaro Ebisawa

HIGH SPEED NETWORKS
HIGH SPEED NETWORKSHIGH SPEED NETWORKS
HIGH SPEED NETWORKS
Kathirvel Ayyaswamy

Introduction to Microservices
Introduction to MicroservicesIntroduction to Microservices
Introduction to Microservices
Amazon Web Services

hpsr-2020-srv6-tutorial
hpsr-2020-srv6-tutorialhpsr-2020-srv6-tutorial
hpsr-2020-srv6-tutorial
Stefano Salsano

Intelligent automation appian sathya srinmivasan cwin18-utrecht
Intelligent automation appian sathya srinmivasan cwin18-utrechtIntelligent automation appian sathya srinmivasan cwin18-utrecht
Intelligent automation appian sathya srinmivasan cwin18-utrecht
Capgemini

The eBay Architecture: Striking a Balance between Site Stability, Feature Ve...
The eBay Architecture:  Striking a Balance between Site Stability, Feature Ve...The eBay Architecture:  Striking a Balance between Site Stability, Feature Ve...
The eBay Architecture: Striking a Balance between Site Stability, Feature Ve...
Randy Shoup

PhD Thesis Defense Presentation: Robust Low-rank and Sparse Decomposition for...
PhD Thesis Defense Presentation: Robust Low-rank and Sparse Decomposition for...PhD Thesis Defense Presentation: Robust Low-rank and Sparse Decomposition for...
PhD Thesis Defense Presentation: Robust Low-rank and Sparse Decomposition for...
ActiveEon

A pattern language for microservices - June 2021
A pattern language for microservices - June 2021 A pattern language for microservices - June 2021
A pattern language for microservices - June 2021
Chris Richardson

Quantum error correction
Quantum error correctionQuantum error correction
Quantum error correction
Phelim Bradley

Cisco: QoS
Cisco: QoSCisco: QoS
Agile, User Stories, Domain Driven Design
Agile, User Stories, Domain Driven DesignAgile, User Stories, Domain Driven Design
Agile, User Stories, Domain Driven Design
Araf Karsh Hamid

Вопросы балансировки трафика
Вопросы балансировки трафикаВопросы балансировки трафика
Вопросы балансировки трафика
SkillFactory

API Gateway or Service mesh - Complementary or excluding concepts
API Gateway or Service mesh - Complementary or excluding conceptsAPI Gateway or Service mesh - Complementary or excluding concepts
API Gateway or Service mesh - Complementary or excluding concepts
Sven Bernhardt

Introducing Spring Cloud Gateway and API Hub for VMware Tanzu
Introducing Spring Cloud Gateway and API Hub for VMware TanzuIntroducing Spring Cloud Gateway and API Hub for VMware Tanzu
Introducing Spring Cloud Gateway and API Hub for VMware Tanzu
VMware Tanzu

Nx tutorial basics
Nx tutorial basicsNx tutorial basics
Nx tutorial basics
Deepakshankar S

Microservices, Containers, Kubernetes, Kafka, Kanban
Microservices, Containers, Kubernetes, Kafka, KanbanMicroservices, Containers, Kubernetes, Kafka, Kanban
Microservices, Containers, Kubernetes, Kafka, Kanban
Araf Karsh Hamid

MPLS on Router OS V7 - Part 1
MPLS on Router OS V7 - Part 1MPLS on Router OS V7 - Part 1
MPLS on Router OS V7 - Part 1
GLC Networks


What's hot (20)

Event Driven Architecture
Event Driven ArchitectureEvent Driven Architecture
Event Driven Architecture

Application Resilience Patterns
Application Resilience PatternsApplication Resilience Patterns
Application Resilience Patterns

NETCONF Call Home
NETCONF Call Home NETCONF Call Home
NETCONF Call Home

SRv6 Mobile User Plane : Initial POC and Implementation
SRv6 Mobile User Plane : Initial POC and ImplementationSRv6 Mobile User Plane : Initial POC and Implementation
SRv6 Mobile User Plane : Initial POC and Implementation

HIGH SPEED NETWORKS
HIGH SPEED NETWORKSHIGH SPEED NETWORKS
HIGH SPEED NETWORKS

Introduction to Microservices
Introduction to MicroservicesIntroduction to Microservices
Introduction to Microservices

hpsr-2020-srv6-tutorial
hpsr-2020-srv6-tutorialhpsr-2020-srv6-tutorial
hpsr-2020-srv6-tutorial

Intelligent automation appian sathya srinmivasan cwin18-utrecht
Intelligent automation appian sathya srinmivasan cwin18-utrechtIntelligent automation appian sathya srinmivasan cwin18-utrecht
Intelligent automation appian sathya srinmivasan cwin18-utrecht

The eBay Architecture: Striking a Balance between Site Stability, Feature Ve...
The eBay Architecture:  Striking a Balance between Site Stability, Feature Ve...The eBay Architecture:  Striking a Balance between Site Stability, Feature Ve...
The eBay Architecture: Striking a Balance between Site Stability, Feature Ve...

PhD Thesis Defense Presentation: Robust Low-rank and Sparse Decomposition for...
PhD Thesis Defense Presentation: Robust Low-rank and Sparse Decomposition for...PhD Thesis Defense Presentation: Robust Low-rank and Sparse Decomposition for...
PhD Thesis Defense Presentation: Robust Low-rank and Sparse Decomposition for...

A pattern language for microservices - June 2021
A pattern language for microservices - June 2021 A pattern language for microservices - June 2021
A pattern language for microservices - June 2021

Quantum error correction
Quantum error correctionQuantum error correction
Quantum error correction

Cisco: QoS
Cisco: QoSCisco: QoS
Cisco: QoS

Agile, User Stories, Domain Driven Design
Agile, User Stories, Domain Driven DesignAgile, User Stories, Domain Driven Design
Agile, User Stories, Domain Driven Design

Вопросы балансировки трафика
Вопросы балансировки трафикаВопросы балансировки трафика
Вопросы балансировки трафика

API Gateway or Service mesh - Complementary or excluding concepts
API Gateway or Service mesh - Complementary or excluding conceptsAPI Gateway or Service mesh - Complementary or excluding concepts
API Gateway or Service mesh - Complementary or excluding concepts

Introducing Spring Cloud Gateway and API Hub for VMware Tanzu
Introducing Spring Cloud Gateway and API Hub for VMware TanzuIntroducing Spring Cloud Gateway and API Hub for VMware Tanzu
Introducing Spring Cloud Gateway and API Hub for VMware Tanzu

Nx tutorial basics
Nx tutorial basicsNx tutorial basics
Nx tutorial basics

Microservices, Containers, Kubernetes, Kafka, Kanban
Microservices, Containers, Kubernetes, Kafka, KanbanMicroservices, Containers, Kubernetes, Kafka, Kanban
Microservices, Containers, Kubernetes, Kafka, Kanban

MPLS on Router OS V7 - Part 1
MPLS on Router OS V7 - Part 1MPLS on Router OS V7 - Part 1
MPLS on Router OS V7 - Part 1


Viewers also liked

Resilience with Hystrix
Resilience with HystrixResilience with Hystrix
Resilience with Hystrix
Uwe Friedrichsen

Devops for Developers
Devops for DevelopersDevops for Developers
Devops for Developers
Uwe Friedrichsen

How to survive in a BASE world
How to survive in a BASE worldHow to survive in a BASE world
How to survive in a BASE world
Uwe Friedrichsen

Dr. Hectic and Mr. Hype - surviving the economic darwinism
Dr. Hectic and Mr. Hype - surviving the economic darwinismDr. Hectic and Mr. Hype - surviving the economic darwinism
Dr. Hectic and Mr. Hype - surviving the economic darwinism
Uwe Friedrichsen

Fault tolerance made easy
Fault tolerance made easyFault tolerance made easy
Fault tolerance made easy
Uwe Friedrichsen

Patterns of resilience
Patterns of resiliencePatterns of resilience
Patterns of resilience
Uwe Friedrichsen

The promises and perils of microservices
The promises and perils of microservicesThe promises and perils of microservices
The promises and perils of microservices
Uwe Friedrichsen

Resilience reloaded - more resilience patterns
Resilience reloaded - more resilience patternsResilience reloaded - more resilience patterns
Resilience reloaded - more resilience patterns
Uwe Friedrichsen

No stress with state
No stress with stateNo stress with state
No stress with state
Uwe Friedrichsen

Microservices - stress-free and without increased heart attack risk
Microservices - stress-free and without increased heart attack riskMicroservices - stress-free and without increased heart attack risk
Microservices - stress-free and without increased heart attack risk
Uwe Friedrichsen

Conway's law revisited - Architectures for an effective IT
Conway's law revisited - Architectures for an effective ITConway's law revisited - Architectures for an effective IT
Conway's law revisited - Architectures for an effective IT
Uwe Friedrichsen

Why resilience - A primer at varying flight altitudes
Why resilience - A primer at varying flight altitudesWhy resilience - A primer at varying flight altitudes
Why resilience - A primer at varying flight altitudes
Uwe Friedrichsen

Fantastic Elastic
Fantastic ElasticFantastic Elastic
Fantastic Elastic
Uwe Friedrichsen

How we sleep well at night using Hystrix at Finn.no
How we sleep well at night using Hystrix at Finn.noHow we sleep well at night using Hystrix at Finn.no
How we sleep well at night using Hystrix at Finn.no
Henning Spjelkavik

Towards complex adaptive architectures
Towards complex adaptive architecturesTowards complex adaptive architectures
Towards complex adaptive architectures
Uwe Friedrichsen

Production-ready Software
Production-ready SoftwareProduction-ready Software
Production-ready Software
Uwe Friedrichsen

Resilient Functional Service Design
Resilient Functional Service DesignResilient Functional Service Design
Resilient Functional Service Design
Uwe Friedrichsen

Watch your communication
Watch your communicationWatch your communication
Watch your communication
Uwe Friedrichsen

DevOps is not enough - Embedding DevOps in a broader context
DevOps is not enough - Embedding DevOps in a broader contextDevOps is not enough - Embedding DevOps in a broader context
DevOps is not enough - Embedding DevOps in a broader context
Uwe Friedrichsen

Modern times - architectures for a Next Generation of IT
Modern times - architectures for a Next Generation of ITModern times - architectures for a Next Generation of IT
Modern times - architectures for a Next Generation of IT
Uwe Friedrichsen


Viewers also liked (20)

Resilience with Hystrix
Resilience with HystrixResilience with Hystrix
Resilience with Hystrix

Devops for Developers
Devops for DevelopersDevops for Developers
Devops for Developers

How to survive in a BASE world
How to survive in a BASE worldHow to survive in a BASE world
How to survive in a BASE world

Dr. Hectic and Mr. Hype - surviving the economic darwinism
Dr. Hectic and Mr. Hype - surviving the economic darwinismDr. Hectic and Mr. Hype - surviving the economic darwinism
Dr. Hectic and Mr. Hype - surviving the economic darwinism

Fault tolerance made easy
Fault tolerance made easyFault tolerance made easy
Fault tolerance made easy

Patterns of resilience
Patterns of resiliencePatterns of resilience
Patterns of resilience

The promises and perils of microservices
The promises and perils of microservicesThe promises and perils of microservices
The promises and perils of microservices

Resilience reloaded - more resilience patterns
Resilience reloaded - more resilience patternsResilience reloaded - more resilience patterns
Resilience reloaded - more resilience patterns

No stress with state
No stress with stateNo stress with state
No stress with state

Microservices - stress-free and without increased heart attack risk
Microservices - stress-free and without increased heart attack riskMicroservices - stress-free and without increased heart attack risk
Microservices - stress-free and without increased heart attack risk

Conway's law revisited - Architectures for an effective IT
Conway's law revisited - Architectures for an effective ITConway's law revisited - Architectures for an effective IT
Conway's law revisited - Architectures for an effective IT

Why resilience - A primer at varying flight altitudes
Why resilience - A primer at varying flight altitudesWhy resilience - A primer at varying flight altitudes
Why resilience - A primer at varying flight altitudes

Fantastic Elastic
Fantastic ElasticFantastic Elastic
Fantastic Elastic

How we sleep well at night using Hystrix at Finn.no
How we sleep well at night using Hystrix at Finn.noHow we sleep well at night using Hystrix at Finn.no
How we sleep well at night using Hystrix at Finn.no

Towards complex adaptive architectures
Towards complex adaptive architecturesTowards complex adaptive architectures
Towards complex adaptive architectures

Production-ready Software
Production-ready SoftwareProduction-ready Software
Production-ready Software

Resilient Functional Service Design
Resilient Functional Service DesignResilient Functional Service Design
Resilient Functional Service Design

Watch your communication
Watch your communicationWatch your communication
Watch your communication

DevOps is not enough - Embedding DevOps in a broader context
DevOps is not enough - Embedding DevOps in a broader contextDevOps is not enough - Embedding DevOps in a broader context
DevOps is not enough - Embedding DevOps in a broader context

Modern times - architectures for a Next Generation of IT
Modern times - architectures for a Next Generation of ITModern times - architectures for a Next Generation of IT
Modern times - architectures for a Next Generation of IT


Similar to Self healing data

Uwe Friedrichsen - CRDT und mehr - über extreme Verfügbarkeit und selbstheile...
Uwe Friedrichsen - CRDT und mehr - über extreme Verfügbarkeit und selbstheile...Uwe Friedrichsen - CRDT und mehr - über extreme Verfügbarkeit und selbstheile...
Uwe Friedrichsen - CRDT und mehr - über extreme Verfügbarkeit und selbstheile...
AboutYouGmbH

Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
NoSQLmatters

Realtime Analytics
Realtime AnalyticsRealtime Analytics
Realtime Analytics
eXascale Infolab

Approximation Data Structures for Streaming Applications
Approximation Data Structures for Streaming ApplicationsApproximation Data Structures for Streaming Applications
Approximation Data Structures for Streaming Applications
Debasish Ghosh

Heuristic design of experiments w meta gradient search
Heuristic design of experiments w meta gradient searchHeuristic design of experiments w meta gradient search
Heuristic design of experiments w meta gradient search
Greg Makowski

Dynamo: Not Just For Datastores
Dynamo: Not Just For DatastoresDynamo: Not Just For Datastores
Dynamo: Not Just For Datastores
Susan Potter

The Power of Motif Counting Theory, Algorithms, and Applications for Large Gr...
The Power of Motif Counting Theory, Algorithms, and Applications for Large Gr...The Power of Motif Counting Theory, Algorithms, and Applications for Large Gr...
The Power of Motif Counting Theory, Algorithms, and Applications for Large Gr...
Nesreen K. Ahmed

Functional Operations - Susan Potter
Functional Operations - Susan PotterFunctional Operations - Susan Potter
Functional Operations - Susan Potter
distributed matters

Parallel Computing with R
Parallel Computing with RParallel Computing with R
Parallel Computing with R
Abhirup Mallik

Jan vitek distributedrandomforest_5-2-2013
Jan vitek distributedrandomforest_5-2-2013Jan vitek distributedrandomforest_5-2-2013
Jan vitek distributedrandomforest_5-2-2013
Sri Ambati

Predective analytcis v0.1 AS
Predective analytcis v0.1 ASPredective analytcis v0.1 AS
Predective analytcis v0.1 AS
Ankur Sansanwal

Keynote: Machine Learning for Design Automation at DAC 2018
Keynote:  Machine Learning for Design Automation at DAC 2018Keynote:  Machine Learning for Design Automation at DAC 2018
Keynote: Machine Learning for Design Automation at DAC 2018
Manish Pandey

VRP2013 - Comp Aspects VRP
VRP2013 - Comp Aspects VRPVRP2013 - Comp Aspects VRP
VRP2013 - Comp Aspects VRP
Victor Pillac

1015 track2 abbott
1015 track2 abbott1015 track2 abbott
1015 track2 abbott
Rising Media, Inc.

1030 track2 abbott
1030 track2 abbott1030 track2 abbott
1030 track2 abbott
Rising Media, Inc.

MLSD18. Unsupervised Learning
MLSD18. Unsupervised LearningMLSD18. Unsupervised Learning
MLSD18. Unsupervised Learning
BigML, Inc

Hardware Acceleration for Machine Learning
Hardware Acceleration for Machine LearningHardware Acceleration for Machine Learning
Hardware Acceleration for Machine Learning
CastLabKAIST

Parallelising Dynamic Programming
Parallelising Dynamic ProgrammingParallelising Dynamic Programming
Parallelising Dynamic Programming
Raphael Reitzig

مدخل إلى تعلم الآلة
مدخل إلى تعلم الآلةمدخل إلى تعلم الآلة
مدخل إلى تعلم الآلة
Fares Al-Qunaieer

Stack squeues lists
Stack squeues listsStack squeues lists
Stack squeues lists
James Wong


Similar to Self healing data (20)

Uwe Friedrichsen - CRDT und mehr - über extreme Verfügbarkeit und selbstheile...
Uwe Friedrichsen - CRDT und mehr - über extreme Verfügbarkeit und selbstheile...Uwe Friedrichsen - CRDT und mehr - über extreme Verfügbarkeit und selbstheile...
Uwe Friedrichsen - CRDT und mehr - über extreme Verfügbarkeit und selbstheile...

Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...

Realtime Analytics
Realtime AnalyticsRealtime Analytics
Realtime Analytics

Approximation Data Structures for Streaming Applications
Approximation Data Structures for Streaming ApplicationsApproximation Data Structures for Streaming Applications
Approximation Data Structures for Streaming Applications

Heuristic design of experiments w meta gradient search
Heuristic design of experiments w meta gradient searchHeuristic design of experiments w meta gradient search
Heuristic design of experiments w meta gradient search

Dynamo: Not Just For Datastores
Dynamo: Not Just For DatastoresDynamo: Not Just For Datastores
Dynamo: Not Just For Datastores

The Power of Motif Counting Theory, Algorithms, and Applications for Large Gr...
The Power of Motif Counting Theory, Algorithms, and Applications for Large Gr...The Power of Motif Counting Theory, Algorithms, and Applications for Large Gr...
The Power of Motif Counting Theory, Algorithms, and Applications for Large Gr...

Functional Operations - Susan Potter
Functional Operations - Susan PotterFunctional Operations - Susan Potter
Functional Operations - Susan Potter

Parallel Computing with R
Parallel Computing with RParallel Computing with R
Parallel Computing with R

Jan vitek distributedrandomforest_5-2-2013
Jan vitek distributedrandomforest_5-2-2013Jan vitek distributedrandomforest_5-2-2013
Jan vitek distributedrandomforest_5-2-2013

Predective analytcis v0.1 AS
Predective analytcis v0.1 ASPredective analytcis v0.1 AS
Predective analytcis v0.1 AS

Keynote: Machine Learning for Design Automation at DAC 2018
Keynote:  Machine Learning for Design Automation at DAC 2018Keynote:  Machine Learning for Design Automation at DAC 2018
Keynote: Machine Learning for Design Automation at DAC 2018

VRP2013 - Comp Aspects VRP
VRP2013 - Comp Aspects VRPVRP2013 - Comp Aspects VRP
VRP2013 - Comp Aspects VRP

1015 track2 abbott
1015 track2 abbott1015 track2 abbott
1015 track2 abbott

1030 track2 abbott
1030 track2 abbott1030 track2 abbott
1030 track2 abbott

MLSD18. Unsupervised Learning
MLSD18. Unsupervised LearningMLSD18. Unsupervised Learning
MLSD18. Unsupervised Learning

Hardware Acceleration for Machine Learning
Hardware Acceleration for Machine LearningHardware Acceleration for Machine Learning
Hardware Acceleration for Machine Learning

Parallelising Dynamic Programming
Parallelising Dynamic ProgrammingParallelising Dynamic Programming
Parallelising Dynamic Programming

مدخل إلى تعلم الآلة
مدخل إلى تعلم الآلةمدخل إلى تعلم الآلة
مدخل إلى تعلم الآلة

Stack squeues lists
Stack squeues listsStack squeues lists
Stack squeues lists


More from Uwe Friedrichsen

Timeless design in a cloud-native world
Timeless design in a cloud-native worldTimeless design in a cloud-native world
Timeless design in a cloud-native world
Uwe Friedrichsen

Deep learning - a primer
Deep learning - a primerDeep learning - a primer
Deep learning - a primer
Uwe Friedrichsen

Life after microservices
Life after microservicesLife after microservices
Life after microservices
Uwe Friedrichsen

The hitchhiker's guide for the confused developer
The hitchhiker's guide for the confused developerThe hitchhiker's guide for the confused developer
The hitchhiker's guide for the confused developer
Uwe Friedrichsen

Digitization solutions - A new breed of software
Digitization solutions - A new breed of softwareDigitization solutions - A new breed of software
Digitization solutions - A new breed of software
Uwe Friedrichsen

Real-world consistency explained
Real-world consistency explainedReal-world consistency explained
Real-world consistency explained
Uwe Friedrichsen

The 7 quests of resilient software design
The 7 quests of resilient software designThe 7 quests of resilient software design
The 7 quests of resilient software design
Uwe Friedrichsen

Excavating the knowledge of our ancestors
Excavating the knowledge of our ancestorsExcavating the knowledge of our ancestors
Excavating the knowledge of our ancestors
Uwe Friedrichsen

The truth about "You build it, you run it!"
The truth about "You build it, you run it!"The truth about "You build it, you run it!"
The truth about "You build it, you run it!"
Uwe Friedrichsen

Life, IT and everything
Life, IT and everythingLife, IT and everything
Life, IT and everything
Uwe Friedrichsen

The Next Generation (of) IT
The Next Generation (of) ITThe Next Generation (of) IT
The Next Generation (of) IT
Uwe Friedrichsen


More from Uwe Friedrichsen (11)

Timeless design in a cloud-native world
Timeless design in a cloud-native worldTimeless design in a cloud-native world
Timeless design in a cloud-native world

Deep learning - a primer
Deep learning - a primerDeep learning - a primer
Deep learning - a primer

Life after microservices
Life after microservicesLife after microservices
Life after microservices

The hitchhiker's guide for the confused developer
The hitchhiker's guide for the confused developerThe hitchhiker's guide for the confused developer
The hitchhiker's guide for the confused developer

Digitization solutions - A new breed of software
Digitization solutions - A new breed of softwareDigitization solutions - A new breed of software
Digitization solutions - A new breed of software

Real-world consistency explained
Real-world consistency explainedReal-world consistency explained
Real-world consistency explained

The 7 quests of resilient software design
The 7 quests of resilient software designThe 7 quests of resilient software design
The 7 quests of resilient software design

Excavating the knowledge of our ancestors
Excavating the knowledge of our ancestorsExcavating the knowledge of our ancestors
Excavating the knowledge of our ancestors

The truth about "You build it, you run it!"
The truth about "You build it, you run it!"The truth about "You build it, you run it!"
The truth about "You build it, you run it!"

Life, IT and everything
Life, IT and everythingLife, IT and everything
Life, IT and everything

The Next Generation (of) IT
The Next Generation (of) ITThe Next Generation (of) IT
The Next Generation (of) IT


Recently uploaded

July Patch Tuesday
July Patch TuesdayJuly Patch Tuesday
July Patch Tuesday
Ivanti

The Rise of AI in Cybersecurity How Machine Learning Will Shape Threat Detect...
The Rise of AI in Cybersecurity How Machine Learning Will Shape Threat Detect...The Rise of AI in Cybersecurity How Machine Learning Will Shape Threat Detect...
The Rise of AI in Cybersecurity How Machine Learning Will Shape Threat Detect...
digitalxplive

Google I/O Extended Harare Merged Slides
Google I/O Extended Harare Merged SlidesGoogle I/O Extended Harare Merged Slides
Google I/O Extended Harare Merged Slides
Google Developer Group - Harare

Opencast Summit 2024 — Opencast @ University of Münster
Opencast Summit 2024 — Opencast @ University of MünsterOpencast Summit 2024 — Opencast @ University of Münster
Opencast Summit 2024 — Opencast @ University of Münster
Matthias Neugebauer

(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
Priyanka Aash

Girls call Kolkata 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
Girls call Kolkata 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery Girls call Kolkata 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
Girls call Kolkata 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
sunilverma7884

"Mastering Graphic Design: Essential Tips and Tricks for Beginners and Profes...
"Mastering Graphic Design: Essential Tips and Tricks for Beginners and Profes..."Mastering Graphic Design: Essential Tips and Tricks for Beginners and Profes...
"Mastering Graphic Design: Essential Tips and Tricks for Beginners and Profes...
Anant Gupta

Three New Criminal Laws in India 1 July 2024
Three New Criminal Laws in India 1 July 2024Three New Criminal Laws in India 1 July 2024
Three New Criminal Laws in India 1 July 2024
aakash malhotra

CHAPTER-8 COMPONENTS OF COMPUTER SYSTEM CLASS 9 CBSE
CHAPTER-8 COMPONENTS OF COMPUTER SYSTEM CLASS 9 CBSECHAPTER-8 COMPONENTS OF COMPUTER SYSTEM CLASS 9 CBSE
CHAPTER-8 COMPONENTS OF COMPUTER SYSTEM CLASS 9 CBSE
kumarjarun2010

The Role of IoT in Australian Mobile App Development - PDF Guide
The Role of IoT in Australian Mobile App Development - PDF GuideThe Role of IoT in Australian Mobile App Development - PDF Guide
The Role of IoT in Australian Mobile App Development - PDF Guide
Shiv Technolabs

Recent Advancements in the NIST-JARVIS Infrastructure
Recent Advancements in the NIST-JARVIS InfrastructureRecent Advancements in the NIST-JARVIS Infrastructure
Recent Advancements in the NIST-JARVIS Infrastructure
KAMAL CHOUDHARY

How to Build a Profitable IoT Product.pptx
How to Build a Profitable IoT Product.pptxHow to Build a Profitable IoT Product.pptx
How to Build a Profitable IoT Product.pptx
Adam Dunkels

IPLOOK Remote-Sensing Satellite Solution
IPLOOK Remote-Sensing Satellite SolutionIPLOOK Remote-Sensing Satellite Solution
IPLOOK Remote-Sensing Satellite Solution
IPLOOK Networks

Calgary MuleSoft Meetup APM and IDP .pptx
Calgary MuleSoft Meetup APM and IDP .pptxCalgary MuleSoft Meetup APM and IDP .pptx
Calgary MuleSoft Meetup APM and IDP .pptx
ishalveerrandhawa1

Best Practices for Effectively Running dbt in Airflow.pdf
Best Practices for Effectively Running dbt in Airflow.pdfBest Practices for Effectively Running dbt in Airflow.pdf
Best Practices for Effectively Running dbt in Airflow.pdf
Tatiana Al-Chueyr

Girls Call Churchgate 9910780858 Provide Best And Top Girl Service And No1 in...
Girls Call Churchgate 9910780858 Provide Best And Top Girl Service And No1 in...Girls Call Churchgate 9910780858 Provide Best And Top Girl Service And No1 in...
Girls Call Churchgate 9910780858 Provide Best And Top Girl Service And No1 in...
maigasapphire

Evolution of iPaaS - simplify IT workloads to provide a unified view of data...
Evolution of iPaaS - simplify IT workloads to provide a unified view of  data...Evolution of iPaaS - simplify IT workloads to provide a unified view of  data...
Evolution of iPaaS - simplify IT workloads to provide a unified view of data...
Torry Harris

Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Muhammad Ali

EuroPython 2024 - Streamlining Testing in a Large Python Codebase
EuroPython 2024 - Streamlining Testing in a Large Python CodebaseEuroPython 2024 - Streamlining Testing in a Large Python Codebase
EuroPython 2024 - Streamlining Testing in a Large Python Codebase
Jimmy Lai

[Talk] Moving Beyond Spaghetti Infrastructure [AOTB] 2024-07-04.pdf
[Talk] Moving Beyond Spaghetti Infrastructure [AOTB] 2024-07-04.pdf[Talk] Moving Beyond Spaghetti Infrastructure [AOTB] 2024-07-04.pdf
[Talk] Moving Beyond Spaghetti Infrastructure [AOTB] 2024-07-04.pdf
Kief Morris


Recently uploaded (20)

July Patch Tuesday
July Patch TuesdayJuly Patch Tuesday
July Patch Tuesday

The Rise of AI in Cybersecurity How Machine Learning Will Shape Threat Detect...
The Rise of AI in Cybersecurity How Machine Learning Will Shape Threat Detect...The Rise of AI in Cybersecurity How Machine Learning Will Shape Threat Detect...
The Rise of AI in Cybersecurity How Machine Learning Will Shape Threat Detect...

Google I/O Extended Harare Merged Slides
Google I/O Extended Harare Merged SlidesGoogle I/O Extended Harare Merged Slides
Google I/O Extended Harare Merged Slides

Opencast Summit 2024 — Opencast @ University of Münster
Opencast Summit 2024 — Opencast @ University of MünsterOpencast Summit 2024 — Opencast @ University of Münster
Opencast Summit 2024 — Opencast @ University of Münster

(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...

Girls call Kolkata 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
Girls call Kolkata 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery Girls call Kolkata 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
Girls call Kolkata 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery

"Mastering Graphic Design: Essential Tips and Tricks for Beginners and Profes...
"Mastering Graphic Design: Essential Tips and Tricks for Beginners and Profes..."Mastering Graphic Design: Essential Tips and Tricks for Beginners and Profes...
"Mastering Graphic Design: Essential Tips and Tricks for Beginners and Profes...

Three New Criminal Laws in India 1 July 2024
Three New Criminal Laws in India 1 July 2024Three New Criminal Laws in India 1 July 2024
Three New Criminal Laws in India 1 July 2024

CHAPTER-8 COMPONENTS OF COMPUTER SYSTEM CLASS 9 CBSE
CHAPTER-8 COMPONENTS OF COMPUTER SYSTEM CLASS 9 CBSECHAPTER-8 COMPONENTS OF COMPUTER SYSTEM CLASS 9 CBSE
CHAPTER-8 COMPONENTS OF COMPUTER SYSTEM CLASS 9 CBSE

The Role of IoT in Australian Mobile App Development - PDF Guide
The Role of IoT in Australian Mobile App Development - PDF GuideThe Role of IoT in Australian Mobile App Development - PDF Guide
The Role of IoT in Australian Mobile App Development - PDF Guide

Recent Advancements in the NIST-JARVIS Infrastructure
Recent Advancements in the NIST-JARVIS InfrastructureRecent Advancements in the NIST-JARVIS Infrastructure
Recent Advancements in the NIST-JARVIS Infrastructure

How to Build a Profitable IoT Product.pptx
How to Build a Profitable IoT Product.pptxHow to Build a Profitable IoT Product.pptx
How to Build a Profitable IoT Product.pptx

IPLOOK Remote-Sensing Satellite Solution
IPLOOK Remote-Sensing Satellite SolutionIPLOOK Remote-Sensing Satellite Solution
IPLOOK Remote-Sensing Satellite Solution

Calgary MuleSoft Meetup APM and IDP .pptx
Calgary MuleSoft Meetup APM and IDP .pptxCalgary MuleSoft Meetup APM and IDP .pptx
Calgary MuleSoft Meetup APM and IDP .pptx

Best Practices for Effectively Running dbt in Airflow.pdf
Best Practices for Effectively Running dbt in Airflow.pdfBest Practices for Effectively Running dbt in Airflow.pdf
Best Practices for Effectively Running dbt in Airflow.pdf

Girls Call Churchgate 9910780858 Provide Best And Top Girl Service And No1 in...
Girls Call Churchgate 9910780858 Provide Best And Top Girl Service And No1 in...Girls Call Churchgate 9910780858 Provide Best And Top Girl Service And No1 in...
Girls Call Churchgate 9910780858 Provide Best And Top Girl Service And No1 in...

Evolution of iPaaS - simplify IT workloads to provide a unified view of data...
Evolution of iPaaS - simplify IT workloads to provide a unified view of  data...Evolution of iPaaS - simplify IT workloads to provide a unified view of  data...
Evolution of iPaaS - simplify IT workloads to provide a unified view of data...

Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)

EuroPython 2024 - Streamlining Testing in a Large Python Codebase
EuroPython 2024 - Streamlining Testing in a Large Python CodebaseEuroPython 2024 - Streamlining Testing in a Large Python Codebase
EuroPython 2024 - Streamlining Testing in a Large Python Codebase

[Talk] Moving Beyond Spaghetti Infrastructure [AOTB] 2024-07-04.pdf
[Talk] Moving Beyond Spaghetti Infrastructure [AOTB] 2024-07-04.pdf[Talk] Moving Beyond Spaghetti Infrastructure [AOTB] 2024-07-04.pdf
[Talk] Moving Beyond Spaghetti Infrastructure [AOTB] 2024-07-04.pdf


Self healing data

  • 1. Self-healing data An introduction to consistency models, Quorums and CRDTs Uwe Friedrichsen, codecentric AG, 2014-2015
  • 2. @ufried Uwe Friedrichsen | uwe.friedrichsen@codecentric.de | http://slideshare.net/ufried | http://ufried.tumblr.com
  • 3. Why NoSQL? •  Scalability •  Easier schema evolution •  Availability on unreliable OTS hardware •  It‘s more fun ...
  • 4. Why NoSQL? •  Scalability •  Easier schema evolution •  Availability on unreliable OTS hardware •  It‘s more fun ...
  • 5. Challenges •  Giving up ACID transactions •  (Temporal) anomalies and inconsistencies
 short-term due to replication or long-term due to partitioning It might happen. Thus, it will happen!
  • 6. C Consistency A Availability P Partition Tolerance Strict Consistency ACID / 2PC Strong Consistency Quorum R&W / Paxos Eventual Consistency CRDT / Gossip / Hinted Handoff
  • 7. Strict Consistency (CA) •  Great programming model
 no anomalies or inconsistencies need to be considered •  Does not scale well
 best for single node databases „We know ACID – It works!“ „We know 2PC – It sucks!“ Use for moderate data amounts
  • 8. And what if I need more data? •  Distributed datastore •  Partition tolerance is a must •  Need to give up strict consistency (CP or AP)
  • 9. Strong Consistency (CP) •  Majority based consistency model
 can tolerate up to N nodes failing out of 2N+1 nodes •  Good programming model
 Single-copy consistency •  Trades consistency for availability
 in case of partitioning Paxos (for sequential consistency) Quorum-based reads & writes
  • 10. Quorum-based reads & writes •  N – number of nodes (replicas) •  R – number of reads delivering the same result required •  W – number of confirmed writes required W > N / 2 R + W > N
  • 11. Example 1 •  3 replica nodes
 This is: N = 3 •  W > N / 2 à W > 3 / 2 à W > 1,5
 Let‘s pick: W = 2 (can tolerate failure of 1 node) •  R + W > N à R + 2 > 3 à R > 1
 Let‘s pick: R = 2 (can tolerate failure of 1 node)
  • 12. Client Node 1 Node 3 Node 2
  • 13. W W W Client Node 1 Node 3 Node 2
  • 14. Client Node 1 Node 3 Node 2 ✔ ✖ ✔ W = 2 ✔
  • 15. Client Node 1 Node 3 Node 2
  • 16. R R R Client Node 1 Node 3 Node 2 ✔ ✔ ✔
  • 17. Client Node 1 Node 3 Node 2 2x / 1x ✔ R = 2 ✔
  • 18. Client Node 1 Node 3 Node 2
  • 19. R R R Client Node 1 Node 3 Node 2 ✔ ✔ ✖
  • 20. Client Node 1 Node 3 Node 2 1x / 1x ✖ R = 1 ✖
  • 21. Example 2 •  3 replica nodes
 This is: N = 3 •  W > N / 2 à W > 3 / 2 à W > 1,5
 Let‘s pick: W = 3 (strict consistency – does not tolerate any failure) •  R + W > N à R + 3 > 3 à R > 0
 Let‘s pick: R = 1 (single read from any node sufficient)
  • 22. Example 3 •  5 replica nodes
 This is: N = 5 •  W > N / 2 à W > 5 / 2 à W > 2,5
 Let‘s pick: W = 3 (can tolerate failure of 2 nodes) •  R + W > N à R + 3 > 5 à R > 2
 Let‘s pick: R = 3 (can tolerate failure of 2 nodes)
  • 23. Limitations of QB R&W •  Requires fixed set of replica nodes
 Dynamic adding and removal of nodes not possible •  Client-centric consistency
 Consistency only perceived on client, not on nodes •  Requires additional measures on nodes
 Nodes need to implement at least eventual consistency Use if client-perceived strong consistency is
 sufficient and simplicity trumps formal precision
  • 24. And what if I need more availability? •  Need to give up strong consistency (CP) •  Relax required consistency properties even more •  Leads to eventual consistency (AP)
  • 25. Eventual Consistency (AP) •  Gives up some consistency guarantees
 no sequential consistency, anomalies become visible •  Maximum availability possible
 can tolerate up to N-1 nodes failing out of N nodes •  Challenging programming model
 anomalies usually need to be resolved explicitly Gossip / Hinted Handoffs CRDT
  • 26. Conflict-free Replicated Data Types •  Eventually consistent, self-stabilizing data structures •  Designed for maximum availability •  Tolerates up to N-1 out of N nodes failing State-based CRDT: Convergent Replicated Data Type (CvRDT) Operation-based CRDT: Commutative Replicated Data Type (CmRDT)
  • 27. A bit of theory first ...
  • 28. Convergent Replicated Data Type State-based CRDT – CvRDT •  All replicas (usually) connected •  Exchange state between replicas, calculate new state on target replica •  State transfer at least once over eventually-reliable channels •  Set of possible states form a Semilattice •  Partially ordered set of elements where all subsets have a Least Upper Bound (LUB) •  All state changes advance upwards with respect to the partial order
  • 29. Commutative Replicated Data Type Operation-based CRDT - CmRDT •  All replicas (usually) connected •  Exchange update operations between replicas, apply on target replica •  Reliable broadcast with ordering guarantee for non-concurrent updates •  Concurrent updates must be commutative
  • 30. That‘s been enough theory ...
  • 32. Op-based Counter Data Integer i Init i ≔ 0 Query return i Operations increment(): i ≔ i + 1 decrement(): i ≔ i - 1
  • 33. State-based G-Counter (grow only) (Naïve approach) Data Integer i Init i ≔ 0 Query return i Update increment(): i ≔ i + 1 Merge( j) i ≔ max(i, j)
  • 34. State-based G-Counter (grow only) (Naïve approach) R1 R3 R2 i = 1 U i = 1 U i = 0 i = 0 i = 0 I I I M i = 1 i = 1 M
  • 35. State-based G-Counter (grow only) (Vector-based approach) Data Integer V[] / one element per replica set Init V ≔ [0, 0, ... , 0] Query return ∑i V[i] Update increment(): V[i] ≔ V[i] + 1 / i is replica set number Merge(V‘) ∀i ∈ [0, n-1] : V[i] ≔ max(V[i], V‘[i])
  • 36. State-based G-Counter (grow only) (Vector-based approach) R1 R3 R2 V = [1, 0, 0] U V = [0, 0, 0] I I I V = [0, 0, 0] V = [0, 0, 0] U V = [0, 0, 1] M V = [1, 0, 0] M V = [1, 0, 1]
  • 37. State-based PN-Counter (pos./neg.) •  Simple vector approach as with G-Counter does not work •  Violates monotonicity requirement of semilattice •  Need to use two vectors •  Vector P to track incements •  Vector N to track decrements •  Query result is ∑i P[i] – N[i]
  • 38. State-based PN-Counter (pos./neg.) Data Integer P[], N[] / one element per replica set Init P ≔ [0, 0, ... , 0], N ≔ [0, 0, ... , 0] Query Return ∑i P[i] – N[i] Update increment(): P[i] ≔ P[i] + 1 / i is replica set number decrement(): N[i] ≔ N[i] + 1 / i is replica set number Merge(P‘, N‘) ∀i ∈ [0, n-1] : P[i] ≔ max(P[i], P‘[i]) ∀i ∈ [0, n-1] : N[i] ≔ max(N[i], N‘[i])
  • 39. Non-negative Counter Problem: How to check a global invariant with local information only? •  Approach 1: Only dec when local state is > 0 •  Concurrent decs could still lead to negative value •  Approach 2: Externalize negative values as 0 •  inc(negative value) == noop(), violates counter semantics •  Approach 3: Local invariant – only allow dec if P[i] - N[i] > 0 •  Works, but may be too strong limitation •  Approach 4: Synchronize •  Works, but violates assumptions and prerequisites of CRDTs
  • 40. Sets
  • 41. Op-based Set (Naïve approach) Data Set S Init S ≔ {} Query(e) return e ∈ S Operations add(e) : S ≔ S ∪ {e} remove(e): S ≔ S {e}
  • 42. Op-based Set (Naïve approach) R1 R3 R2 S = {e} add(e) S = {} S = {} S = {} I I I S = {e} S = {} rmv(e) add(e) add(e) add(e) rmv(e) add(e) S = {e} S = {e} S = {e} S = {}
  • 43. State-based G-Set (grow only) Data Set S Init S ≔ {} Query(e) return e ∈ S Update add(e): S ≔ S ∪ {e} Merge(S‘) S = S ∪ S‘
  • 44. State-based 2P-Set (two-phase) Data Set A, R / A: added, R: removed Init A ≔ {}, R ≔ {} Query(e) return e ∈ A ∧ e ∉ R Update add(e): A ≔ A ∪ {e} remove(e): (pre query(e)) R ≔ R ∪ {e} Merge(A‘, R‘) A ≔ A ∪ A‘, R ≔ R ∪ R‘
  • 45. Op-based OR-Set (observed-remove) Data Set S / Set of pairs { (element e, unique tag u), ... } Init S ≔ {} Query(e) return ∃u : (e, u) ∈ S Operations add(e): S ≔ S ∪ { (e, u) } / u is generated unique tag remove(e): pre query(e) R ≔ { (e, u) | ∃u : (e, u) ∈ S } /at source („prepare“) S ≔ S R /downstream („execute“)
  • 46. Op-based OR-Set (observed-remove) R1 R3 R2 S = {ea} add(e) S = {} S = {} S = {} I I I S = {eb} S = {} rmv(e) add(e) add(eb) add(ea) rmv(ea) add(eb) S = {eb} S = {eb} S = {ea, eb} S = {eb}
  • 47. More datatypes •  Register •  Dictionary (Map) •  Tree •  Graph •  Array •  List plus more representations for each datatype
  • 48. Garbage collection •  Sets could grow infinitely in worst case •  Garbage collection possible, but a bit tricky •  Only remove updates that can be deleted safely and were received by all replicas •  Usually implemented using vector clocks •  Can tolerate up to n-1 crashes •  Live only while no replicas are crashed •  Can induce surprising behavior sometimes •  Sometimes stronger consensus is needed (Paxos, ...)
  • 49. Limitations of CRDTs •  Very weak consistency guarantees
 Strives for „quiescent consistency“ •  Eventually consistent
 Not suitable for high-volume ID generator or alike •  Not easy to understand and model •  Not all data structures representable Use if availability is extremely important
  • 50. Further reading 1.  Shapiro et al., Conflict-free Replicated Data Types, Inria Research report, 2011 2.  Shapiro et al., A comprehensive study of Convergent and Commutative Replicated Data Types,
 Inria Research report, 2011 3.  Basho Tag Archives: CRDT,
 https://basho.com/tag/crdt/ 4.  Leslie Lamport,
 Time, clocks, and the ordering of events in a distributed system,
 Communications of the ACM (1978)
  • 51. Wrap-up •  CAP requires rethinking consistency •  Strict Consistency
 ACID / 2PC •  Strong Consistency
 Quorum-based R&W, Paxos •  Eventual Consistency
 CRDT, Gossip, Hinted Handoffs Pick your consistency model based on your
 consistency and availability requirements
  • 52. The real world is not ACID Thus, it is perfectly fine to go for a relaxed consistency model
  • 53. @ufried Uwe Friedrichsen | uwe.friedrichsen@codecentric.de | http://slideshare.net/ufried | http://ufried.tumblr.com
