Rethinking Data-Intensive
Science Using Scalable
Analytics Systems
Frank Austin Nothaft
UC Berkeley AMP/ASPIRE Lab, @fnothaft
With Matt Massie, Timothy Danford, Zhao Zhang, Uri Laserson, Carl Yeksigian, Jey Kottalam, Arun Ahuja,
Jeff Hammerbacher, Michael Linderman, Michael J. Franklin, Anthony D. Joseph, David A. Patterson
Scientific revolutions are
driven by data acquisition
revolutions
Genome Sequencing
Source: NIH National Genome Research Institute
2014: ~230,000 genomes sequenced
15-250GB/genome = ~30TB/day
= ~10PB/year
Human Genome!
Project: ~10GB
1000 Genomes: 15TB
TCGA: 3PB
Sequencing advances line up well
with scalable analytics software
Source: NIH National Genome Research Institute
Google
MapReduce
Hadoop MR
Spark
Parquet
Mapping scientific systems to
commodity analytics systems
• Contemporary scientific systems are custom-built
• Leads to functionality from commodity systems being rebuilt
• We have an opportunity to rethink the abstractions that
scientific systems use:
• Migrate from a flat architecture to a stacked
architecture
• Expose higher level programming primitives
• Use commodity tools wherever possible
Common Traits of Legacy Data
Intensive Scientific Systems
1. Computation is workflow/pipeline oriented
2. Processing system has monolithic/flat architecture
3. Data is stored in flat files
Genomics Pipelines
Source: The Broad Institute of MIT/Harvard
Flat File Formats
• Scientific data is typically stored in application
specific file formats:
• Genomic reads: SAM/BAM, CRAM
• Genomic variants: VCF/BCF, MAF
• Genomic features: BED, NarrowPeak, GTF
• Centralized metadata makes it difficult to parallelize
applications
Flat Architectures
• APIs present very barebones abstractions:
• GATK: Sorted iterator over the genome
• Why are flat architectures bad?
1. Trivial: low level abstractions are not productive
2. Trivial: flat architectures create technical lock-in
3. Subtle: low level abstractions can introduce bugs
The perils of flattening…
• The trivial:
• You can improve performance by pushing data
access order into your data layout
• But now, you can’t easily compose pipeline stages
that have different access orders
• The obscure:
• If you access data via a sorted iterator, will you
incorrectly implement your algorithm?
A green field approach
First, define a schema
record AlignmentRecord {
union { null, Contig } contig = null;
union { null, long } start = null;
union { null, long } end = null;
union { null, int } mapq = null;
union { null, string } readName = null;
union { null, string } sequence = null;
union { null, string } mateReference = null;
union { null, long } mateAlignmentStart = null;
union { null, string } cigar = null;
union { null, string } qual = null;
union { null, string } recordGroupName = null;
union { int, null } basesTrimmedFromStart = 0;
union { int, null } basesTrimmedFromEnd = 0;
union { boolean, null } readPaired = false;
union { boolean, null } properPair = false;
union { boolean, null } readMapped = false;
union { boolean, null } mateMapped = false;
union { boolean, null } firstOfPair = false;
union { boolean, null } secondOfPair = false;
union { boolean, null } failedVendorQualityChecks = false;
union { boolean, null } duplicateRead = false;
union { boolean, null } readNegativeStrand = false;
union { boolean, null } mateNegativeStrand = false;
union { boolean, null } primaryAlignment = false;
union { boolean, null } secondaryAlignment = false;
union { boolean, null } supplementaryAlignment = false;
union { null, string } mismatchingPositions = null;
union { null, string } origQual = null;
union { null, string } attributes = null;
union { null, string } recordGroupSequencingCenter = null;
union { null, string } recordGroupDescription = null;
union { null, long } recordGroupRunDateEpoch = null;
union { null, string } recordGroupFlowOrder = null;
union { null, string } recordGroupKeySequence = null;
union { null, string } recordGroupLibrary = null;
union { null, int } recordGroupPredictedMedianInsertSize = null;
union { null, string } recordGroupPlatform = null;
union { null, string } recordGroupPlatformUnit = null;
union { null, string } recordGroupSample = null;
union { null, Contig } mateContig = null;
}
Application
Transformations
Physical Storage
Attached Storage
Data Distribution
Parallel FS
Materialized Data
Columnar Storage
Evidence Access
MapReduce/DBMS
Presentation
Enriched Models
Schema
Data Models
Application
Transformations
Physical Storage
Attached Storage
Data Distribution
Parallel FS
Materialized Data
Columnar Storage
Evidence Access
MapReduce/DBMS
Presentation
Enriched Models
Schema
Data Models
A schema provides a
narrow waistrecord AlignmentRecord {
union { null, Contig } contig = null;
union { null, long } start = null;
union { null, long } end = null;
union { null, int } mapq = null;
union { null, string } readName = null;
union { null, string } sequence = null;
union { null, string } mateReference = null;
union { null, long } mateAlignmentStart = null;
union { null, string } cigar = null;
union { null, string } qual = null;
union { null, string } recordGroupName = null;
union { int, null } basesTrimmedFromStart = 0;
union { int, null } basesTrimmedFromEnd = 0;
union { boolean, null } readPaired = false;
union { boolean, null } properPair = false;
union { boolean, null } readMapped = false;
union { boolean, null } mateMapped = false;
union { boolean, null } firstOfPair = false;
union { boolean, null } secondOfPair = false;
union { boolean, null } failedVendorQualityChecks = false;
union { boolean, null } duplicateRead = false;
union { boolean, null } readNegativeStrand = false;
union { boolean, null } mateNegativeStrand = false;
union { boolean, null } primaryAlignment = false;
union { boolean, null } secondaryAlignment = false;
union { boolean, null } supplementaryAlignment = false;
union { null, string } mismatchingPositions = null;
union { null, string } origQual = null;
union { null, string } attributes = null;
union { null, string } recordGroupSequencingCenter = null;
union { null, string } recordGroupDescription = null;
union { null, long } recordGroupRunDateEpoch = null;
union { null, string } recordGroupFlowOrder = null;
union { null, string } recordGroupKeySequence = null;
union { null, string } recordGroupLibrary = null;
union { null, int } recordGroupPredictedMedianInsertSize = null;
union { null, string } recordGroupPlatform = null;
union { null, string } recordGroupPlatformUnit = null;
union { null, string } recordGroupSample = null;
union { null, Contig } mateContig = null;
}
Application
Transformations
Physical Storage
Attached Storage
Data Distribution
Parallel FS
Materialized Data
Columnar Storage
Evidence Access
MapReduce/DBMS
Presentation
Enriched Models
Schema
Data Models
Accelerate common
access patterns
• In genomics, we commonly
have to find observations that
overlap in a coordinate plane
• This coordinate plane is
genomics specific, and is
known a priori
• We can use our knowledge of
the coordinate plane to
implement a fast overlap join
Application
Transformations
Physical Storage
Attached Storage
Data Distribution
Parallel FS
Materialized Data
Columnar Storage
Evidence Access
MapReduce/DBMS
Presentation
Enriched Models
Schema
Data Models
Application
Transformations
Physical Storage
Attached Storage
Data Distribution
Parallel FS
Materialized Data
Columnar Storage
Evidence Access
MapReduce/DBMS
Presentation
Enriched Models
Schema
Data Models
Pick appropriate storage
• When accessing scientific
datasets, we frequently slice and
dice the dataset:
• Algorithms may touch
subsets of columns
• We don’t always touch the
whole dataset
• This is a good match for
columnar storage
Application
Transformations
Physical Storage
Attached Storage
Data Distribution
Parallel FS
Materialized Data
Columnar Storage
Evidence Access
MapReduce/DBMS
Presentation
Enriched Models
Schema
Data Models
Application
Transformations
Physical Storage
Attached Storage
Data Distribution
Parallel FS
Materialized Data
Columnar Storage
Evidence Access
MapReduce/DBMS
Presentation
Enriched Models
Schema
Data Models
Is introducing a new data
model really a good idea?
Source: XKCD, http://xkcd.com/927/
A subtle point:!
Proper stack design can simplify
backwards compatibility
To support legacy data formats, you define a way to
serialize/deserialize the schema into/from the
legacy flat file format!
Data Distribution
Materialized Data
Legacy File Format
Schema
Data Models
Data Distribution
Materialized Data
Columnar Storage
Schema
Data Models
A subtle point:!
Proper stack design can simplify
backwards compatibility
This is a view!
Data Distribution
Materialized Data
Legacy File Format
Schema
Data Models
Data Distribution
Materialized Data
Columnar Storage
Schema
Data Models
A well designed stack
simplifies application design
Application
Transformations
Physical Storage
Attached Storage
Data Distribution
Parallel FS
Materialized Data
Columnar Storage
Evidence Access
MapReduce/DBMS
Presentation
Enriched Models
Schema
Data Models
Variant calling & analysis,
RNA-seq analysis, etc.
Disk, SDD, block
store, memory cache
HDFS, Tachyon, HPC file
systems, S3
Load data from Parquet and
legacy formats
Spark, Spark-SQL,
Hadoop
Enriched Read/Variant
Avro Schema for reads,
variants, and genotypes
Users define analyses
via transformations
Enriched models provide convenient
methods on common models
The evidence access layer
efficiently executes transformations
Schemas define the logical
structure of basic genomic objects
Common interfaces map logical
schema to bytes on disk
Parallel file system layer
coordinates distribution of data
Decoupling storage enables
performance/cost tradeoff
How does this perform
on real scientific data?
ADAM performs genomic
preprocessing
Source: The Broad Institute of MIT/Harvard
ADAM’s Performance
• Achieve linear scalability out
to 128 nodes for most tasks
• Up to 3x improvement over
current tools on a single node
Analysis run using Amazon EC2, single node was i2.8xlarge, cluster was r3.2xlarge
Scripts available at https://www.github.com/bigdatagenomics/bdg-services.git
Astronomy Pipelines
Source: The LSST Project
Astronomy Image
Co-addition Performance
• Scales out to 16 nodes
• ~3x improvement over extant
tool on a single node
Analysis run using Amazon EC2, cluster was c3.8xlarge (HPC optimized)
Conclusions
• There is a huge increase in the amount of scientific
data being processed
• Although scientific processing pipelines tend to be
custom solutions, we can replace these pipelines
with general, DBMS backed solutions
• When we move to a general solution, we can gain
performance without losing correctness
Acknowledgements
• ADAM (https://www.github.com/bigdatagenomics/adam):!
• UC Berkeley: Matt Massie, Timothy Danford, André Schumacher, Jey
Kottalam, Karen Feng, Eric Tu, Niranjan Kumar, Ananth Pallaseni, Anthony
Joseph, Dave Patterson!
• Mt. Sinai: Arun Ahuja, Neal Sidhwaney, Ryan Williams, Michael Linderman,
Jeff Hammerbacher!
• GenomeBridge: Carl Yeksigian!
• Cloudera: Uri Laserson!
• Microsoft Research: Ravi Pandya!
• UC Santa Cruz: Benedict Paten, David Haussler!
• KIRA (https://www.github.com/BIDS/Kira):!
• UC Berkeley: Zhao Zhang, Mike Franklin, Evan Sparks, Kyle Barbary,
Oliver Zahn, Saul Perlmutter!
• PoC code at https://github.com/zhaozhang/SparkMontage

More Related Content

What's hot

Twinkle: A SPARQL Query Tool
Twinkle: A SPARQL Query ToolTwinkle: A SPARQL Query Tool
Twinkle: A SPARQL Query Tool
Leigh Dodds

Introduction to data analysis using R
Introduction to data analysis using RIntroduction to data analysis using R
Introduction to data analysis using R
Victoria López

Data Wrangling and Visualization Using Python
Data Wrangling and Visualization Using PythonData Wrangling and Visualization Using Python
Data Wrangling and Visualization Using Python
MOHITKUMAR1379

SPARQL Cheat Sheet
SPARQL Cheat SheetSPARQL Cheat Sheet
SPARQL Cheat Sheet
LeeFeigenbaum

Democratizing Big Semantic Data management
Democratizing Big Semantic Data managementDemocratizing Big Semantic Data management
Democratizing Big Semantic Data management
WU (Vienna University of Economics and Business)

Scalable Data Analysis in R -- Lee Edlefsen
Scalable Data Analysis in R -- Lee EdlefsenScalable Data Analysis in R -- Lee Edlefsen
Scalable Data Analysis in R -- Lee Edlefsen
Revolution Analytics

Bridging Batch and Real-time Systems for Anomaly Detection
Bridging Batch and Real-time Systems for Anomaly DetectionBridging Batch and Real-time Systems for Anomaly Detection
Bridging Batch and Real-time Systems for Anomaly Detection
DataWorks Summit

12. Heaps - Data Structures using C++ by Varsha Patil
12. Heaps - Data Structures using C++ by Varsha Patil12. Heaps - Data Structures using C++ by Varsha Patil
12. Heaps - Data Structures using C++ by Varsha Patil
widespreadpromotion

ParlBench: a SPARQL-benchmark for electronic publishing applications.
ParlBench: a SPARQL-benchmark for electronic publishing applications.ParlBench: a SPARQL-benchmark for electronic publishing applications.
ParlBench: a SPARQL-benchmark for electronic publishing applications.
Tatiana Tarasova

Data structures cs301 power point slides lecture 01
Data structures   cs301 power point slides lecture 01Data structures   cs301 power point slides lecture 01
Data structures cs301 power point slides lecture 01
shaziabibi5

Analysis of different similarity measures: Simrank
Analysis of different similarity measures: SimrankAnalysis of different similarity measures: Simrank
Analysis of different similarity measures: Simrank
Abhishek Mungoli

ffbase, statistical functions for large datasets
ffbase, statistical functions for large datasetsffbase, statistical functions for large datasets
ffbase, statistical functions for large datasets
Edwin de Jonge

Presentation on data preparation with pandas
Presentation on data preparation with pandasPresentation on data preparation with pandas
Presentation on data preparation with pandas
AkshitaKanther

A Workshop on R
A Workshop on RA Workshop on R
A Workshop on R
Ajay Ohri

Practical dimensions
Practical dimensionsPractical dimensions
Practical dimensions
tholem

pandas: a Foundational Python Library for Data Analysis and Statistics
pandas: a Foundational Python Library for Data Analysis and Statisticspandas: a Foundational Python Library for Data Analysis and Statistics
pandas: a Foundational Python Library for Data Analysis and Statistics
Wes McKinney

2010 03 Lodoxf Openflydata
2010 03 Lodoxf Openflydata2010 03 Lodoxf Openflydata
2010 03 Lodoxf Openflydata
Jun Zhao

Data Structure
Data StructureData Structure
Data Structure
Karthikeyan A K

Database , 8 Query Optimization
Database , 8 Query OptimizationDatabase , 8 Query Optimization
Database , 8 Query Optimization
Ali Usman

Querying Linked Data with SPARQL
Querying Linked Data with SPARQLQuerying Linked Data with SPARQL
Querying Linked Data with SPARQL
Olaf Hartig


What's hot (20)

Twinkle: A SPARQL Query Tool
Twinkle: A SPARQL Query ToolTwinkle: A SPARQL Query Tool
Twinkle: A SPARQL Query Tool

Introduction to data analysis using R
Introduction to data analysis using RIntroduction to data analysis using R
Introduction to data analysis using R

Data Wrangling and Visualization Using Python
Data Wrangling and Visualization Using PythonData Wrangling and Visualization Using Python
Data Wrangling and Visualization Using Python

SPARQL Cheat Sheet
SPARQL Cheat SheetSPARQL Cheat Sheet
SPARQL Cheat Sheet

Democratizing Big Semantic Data management
Democratizing Big Semantic Data managementDemocratizing Big Semantic Data management
Democratizing Big Semantic Data management

Scalable Data Analysis in R -- Lee Edlefsen
Scalable Data Analysis in R -- Lee EdlefsenScalable Data Analysis in R -- Lee Edlefsen
Scalable Data Analysis in R -- Lee Edlefsen

Bridging Batch and Real-time Systems for Anomaly Detection
Bridging Batch and Real-time Systems for Anomaly DetectionBridging Batch and Real-time Systems for Anomaly Detection
Bridging Batch and Real-time Systems for Anomaly Detection

12. Heaps - Data Structures using C++ by Varsha Patil
12. Heaps - Data Structures using C++ by Varsha Patil12. Heaps - Data Structures using C++ by Varsha Patil
12. Heaps - Data Structures using C++ by Varsha Patil

ParlBench: a SPARQL-benchmark for electronic publishing applications.
ParlBench: a SPARQL-benchmark for electronic publishing applications.ParlBench: a SPARQL-benchmark for electronic publishing applications.
ParlBench: a SPARQL-benchmark for electronic publishing applications.

Data structures cs301 power point slides lecture 01
Data structures   cs301 power point slides lecture 01Data structures   cs301 power point slides lecture 01
Data structures cs301 power point slides lecture 01

Analysis of different similarity measures: Simrank
Analysis of different similarity measures: SimrankAnalysis of different similarity measures: Simrank
Analysis of different similarity measures: Simrank

ffbase, statistical functions for large datasets
ffbase, statistical functions for large datasetsffbase, statistical functions for large datasets
ffbase, statistical functions for large datasets

Presentation on data preparation with pandas
Presentation on data preparation with pandasPresentation on data preparation with pandas
Presentation on data preparation with pandas

A Workshop on R
A Workshop on RA Workshop on R
A Workshop on R

Practical dimensions
Practical dimensionsPractical dimensions
Practical dimensions

pandas: a Foundational Python Library for Data Analysis and Statistics
pandas: a Foundational Python Library for Data Analysis and Statisticspandas: a Foundational Python Library for Data Analysis and Statistics
pandas: a Foundational Python Library for Data Analysis and Statistics

2010 03 Lodoxf Openflydata
2010 03 Lodoxf Openflydata2010 03 Lodoxf Openflydata
2010 03 Lodoxf Openflydata

Data Structure
Data StructureData Structure
Data Structure

Database , 8 Query Optimization
Database , 8 Query OptimizationDatabase , 8 Query Optimization
Database , 8 Query Optimization

Querying Linked Data with SPARQL
Querying Linked Data with SPARQLQuerying Linked Data with SPARQL
Querying Linked Data with SPARQL


Similar to Rethinking Data-Intensive Science Using Scalable Analytics Systems

Scalable Genome Analysis with ADAM
Scalable Genome Analysis with ADAMScalable Genome Analysis with ADAM
Scalable Genome Analysis with ADAM
fnothaft

Processing Terabyte-Scale Genomics Datasets with ADAM: Spark Summit East talk...
Processing Terabyte-Scale Genomics Datasets with ADAM: Spark Summit East talk...Processing Terabyte-Scale Genomics Datasets with ADAM: Spark Summit East talk...
Processing Terabyte-Scale Genomics Datasets with ADAM: Spark Summit East talk...
Spark Summit

Fast Variant Calling with ADAM and avocado
Fast Variant Calling with ADAM and avocadoFast Variant Calling with ADAM and avocado
Fast Variant Calling with ADAM and avocado
fnothaft

Scaling up genomic analysis with ADAM
Scaling up genomic analysis with ADAMScaling up genomic analysis with ADAM
Scaling up genomic analysis with ADAM
fnothaft

Silicon valleycodecamp2013
Silicon valleycodecamp2013Silicon valleycodecamp2013
Silicon valleycodecamp2013
Sanjeev Mishra

Sharing massive data analysis: from provenance to linked experiment reports
Sharing massive data analysis: from provenance to linked experiment reportsSharing massive data analysis: from provenance to linked experiment reports
Sharing massive data analysis: from provenance to linked experiment reports
Gaignard Alban

What's next in Julia
What's next in JuliaWhat's next in Julia
What's next in Julia
Jiahao Chen

Barga Data Science lecture 5
Barga Data Science lecture 5Barga Data Science lecture 5
Barga Data Science lecture 5
Roger Barga

Workflow Provenance: From Modelling to Reporting
Workflow Provenance: From Modelling to ReportingWorkflow Provenance: From Modelling to Reporting
Workflow Provenance: From Modelling to Reporting
Rayhan Ferdous

Bringing OpenClinica Data into SAS
Bringing OpenClinica Data into SASBringing OpenClinica Data into SAS
Bringing OpenClinica Data into SAS
Rick Watts

Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
NoSQLmatters

Predicting query performance and explaining results to assist Linked Data con...
Predicting query performance and explaining results to assist Linked Data con...Predicting query performance and explaining results to assist Linked Data con...
Predicting query performance and explaining results to assist Linked Data con...
Rakebul Hasan

Dagstuhl 2013 - Montali - On the Relationship between OBDA and Relational Map...
Dagstuhl 2013 - Montali - On the Relationship between OBDA and Relational Map...Dagstuhl 2013 - Montali - On the Relationship between OBDA and Relational Map...
Dagstuhl 2013 - Montali - On the Relationship between OBDA and Relational Map...
Faculty of Computer Science - Free University of Bozen-Bolzano

User biglm
User biglmUser biglm
User biglm
johnatan pladott

Computer notes - data structures
Computer notes - data structuresComputer notes - data structures
Computer notes - data structures
ecomputernotes

Accessing hemibrain data using Neuprintr
Accessing hemibrain data using Neuprintr Accessing hemibrain data using Neuprintr
Accessing hemibrain data using Neuprintr
Alexander Bates

computer notes - Data Structures - 1
computer notes - Data Structures - 1computer notes - Data Structures - 1
computer notes - Data Structures - 1
ecomputernotes

Data structure and algorithm.
Data structure and algorithm. Data structure and algorithm.
Data structure and algorithm.
Abdul salam

Interactive Analysis of Large-Scale Sequencing Genomics Data Sets using a Rea...
Interactive Analysis of Large-Scale Sequencing Genomics Data Sets using a Rea...Interactive Analysis of Large-Scale Sequencing Genomics Data Sets using a Rea...
Interactive Analysis of Large-Scale Sequencing Genomics Data Sets using a Rea...
Dominic Suciu

ORM JPA
ORM JPAORM JPA

Similar to Rethinking Data-Intensive Science Using Scalable Analytics Systems (20)

Scalable Genome Analysis with ADAM
Scalable Genome Analysis with ADAMScalable Genome Analysis with ADAM
Scalable Genome Analysis with ADAM

Processing Terabyte-Scale Genomics Datasets with ADAM: Spark Summit East talk...
Processing Terabyte-Scale Genomics Datasets with ADAM: Spark Summit East talk...Processing Terabyte-Scale Genomics Datasets with ADAM: Spark Summit East talk...
Processing Terabyte-Scale Genomics Datasets with ADAM: Spark Summit East talk...

Fast Variant Calling with ADAM and avocado
Fast Variant Calling with ADAM and avocadoFast Variant Calling with ADAM and avocado
Fast Variant Calling with ADAM and avocado

Scaling up genomic analysis with ADAM
Scaling up genomic analysis with ADAMScaling up genomic analysis with ADAM
Scaling up genomic analysis with ADAM

Silicon valleycodecamp2013
Silicon valleycodecamp2013Silicon valleycodecamp2013
Silicon valleycodecamp2013

Sharing massive data analysis: from provenance to linked experiment reports
Sharing massive data analysis: from provenance to linked experiment reportsSharing massive data analysis: from provenance to linked experiment reports
Sharing massive data analysis: from provenance to linked experiment reports

What's next in Julia
What's next in JuliaWhat's next in Julia
What's next in Julia

Barga Data Science lecture 5
Barga Data Science lecture 5Barga Data Science lecture 5
Barga Data Science lecture 5

Workflow Provenance: From Modelling to Reporting
Workflow Provenance: From Modelling to ReportingWorkflow Provenance: From Modelling to Reporting
Workflow Provenance: From Modelling to Reporting

Bringing OpenClinica Data into SAS
Bringing OpenClinica Data into SASBringing OpenClinica Data into SAS
Bringing OpenClinica Data into SAS

Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...
Uwe Friedrichsen – Extreme availability and self-healing data with CRDTs - No...

Predicting query performance and explaining results to assist Linked Data con...
Predicting query performance and explaining results to assist Linked Data con...Predicting query performance and explaining results to assist Linked Data con...
Predicting query performance and explaining results to assist Linked Data con...

Dagstuhl 2013 - Montali - On the Relationship between OBDA and Relational Map...
Dagstuhl 2013 - Montali - On the Relationship between OBDA and Relational Map...Dagstuhl 2013 - Montali - On the Relationship between OBDA and Relational Map...
Dagstuhl 2013 - Montali - On the Relationship between OBDA and Relational Map...

User biglm
User biglmUser biglm
User biglm

Computer notes - data structures
Computer notes - data structuresComputer notes - data structures
Computer notes - data structures

Accessing hemibrain data using Neuprintr
Accessing hemibrain data using Neuprintr Accessing hemibrain data using Neuprintr
Accessing hemibrain data using Neuprintr

computer notes - Data Structures - 1
computer notes - Data Structures - 1computer notes - Data Structures - 1
computer notes - Data Structures - 1

Data structure and algorithm.
Data structure and algorithm. Data structure and algorithm.
Data structure and algorithm.

Interactive Analysis of Large-Scale Sequencing Genomics Data Sets using a Rea...
Interactive Analysis of Large-Scale Sequencing Genomics Data Sets using a Rea...Interactive Analysis of Large-Scale Sequencing Genomics Data Sets using a Rea...
Interactive Analysis of Large-Scale Sequencing Genomics Data Sets using a Rea...

ORM JPA
ORM JPAORM JPA
ORM JPA


More from fnothaft

Scalable Genome Analysis With ADAM
Scalable Genome Analysis With ADAMScalable Genome Analysis With ADAM
Scalable Genome Analysis With ADAM
fnothaft

Scaling Genomic Analyses
Scaling Genomic AnalysesScaling Genomic Analyses
Scaling Genomic Analyses
fnothaft

Scaling up genomic analysis with ADAM
Scaling up genomic analysis with ADAMScaling up genomic analysis with ADAM
Scaling up genomic analysis with ADAM
fnothaft

Reproducible Emulation of Analog Behavioral Models
Reproducible Emulation of Analog Behavioral ModelsReproducible Emulation of Analog Behavioral Models
Reproducible Emulation of Analog Behavioral Models
fnothaft

CS176: Genome Assembly
CS176: Genome AssemblyCS176: Genome Assembly
CS176: Genome Assembly
fnothaft

Execution Environments
Execution EnvironmentsExecution Environments
Execution Environments
fnothaft

PacMin @ AMPLab All-Hands
PacMin @ AMPLab All-HandsPacMin @ AMPLab All-Hands
PacMin @ AMPLab All-Hands
fnothaft

Adam bosc-071114
Adam bosc-071114Adam bosc-071114
Adam bosc-071114
fnothaft

ADAM—Spark Summit, 2014
ADAM—Spark Summit, 2014ADAM—Spark Summit, 2014
ADAM—Spark Summit, 2014
fnothaft


More from fnothaft (9)

Scalable Genome Analysis With ADAM
Scalable Genome Analysis With ADAMScalable Genome Analysis With ADAM
Scalable Genome Analysis With ADAM

Scaling Genomic Analyses
Scaling Genomic AnalysesScaling Genomic Analyses
Scaling Genomic Analyses

Scaling up genomic analysis with ADAM
Scaling up genomic analysis with ADAMScaling up genomic analysis with ADAM
Scaling up genomic analysis with ADAM

Reproducible Emulation of Analog Behavioral Models
Reproducible Emulation of Analog Behavioral ModelsReproducible Emulation of Analog Behavioral Models
Reproducible Emulation of Analog Behavioral Models

CS176: Genome Assembly
CS176: Genome AssemblyCS176: Genome Assembly
CS176: Genome Assembly

Execution Environments
Execution EnvironmentsExecution Environments
Execution Environments

PacMin @ AMPLab All-Hands
PacMin @ AMPLab All-HandsPacMin @ AMPLab All-Hands
PacMin @ AMPLab All-Hands

Adam bosc-071114
Adam bosc-071114Adam bosc-071114
Adam bosc-071114

ADAM—Spark Summit, 2014
ADAM—Spark Summit, 2014ADAM—Spark Summit, 2014
ADAM—Spark Summit, 2014


Recently uploaded

SCALING OF MOS CIRCUITS m .pptx
SCALING OF MOS CIRCUITS m                 .pptxSCALING OF MOS CIRCUITS m                 .pptx
SCALING OF MOS CIRCUITS m .pptx
harshapolam10

Null Bangalore | Pentesters Approach to AWS IAM
Null Bangalore | Pentesters Approach to AWS IAMNull Bangalore | Pentesters Approach to AWS IAM
Null Bangalore | Pentesters Approach to AWS IAM
Divyanshu

Zener Diode and its V-I Characteristics and Applications
Zener Diode and its V-I Characteristics and ApplicationsZener Diode and its V-I Characteristics and Applications
Zener Diode and its V-I Characteristics and Applications
Shiny Christobel

原版制作(Humboldt毕业证书)柏林大学毕业证学位证一模一样
原版制作(Humboldt毕业证书)柏林大学毕业证学位证一模一样原版制作(Humboldt毕业证书)柏林大学毕业证学位证一模一样
原版制作(Humboldt毕业证书)柏林大学毕业证学位证一模一样
ydzowc

一比一原版(USF毕业证)旧金山大学毕业证如何办理
一比一原版(USF毕业证)旧金山大学毕业证如何办理一比一原版(USF毕业证)旧金山大学毕业证如何办理
一比一原版(USF毕业证)旧金山大学毕业证如何办理
uqyfuc

DEEP LEARNING FOR SMART GRID INTRUSION DETECTION: A HYBRID CNN-LSTM-BASED MODEL
DEEP LEARNING FOR SMART GRID INTRUSION DETECTION: A HYBRID CNN-LSTM-BASED MODELDEEP LEARNING FOR SMART GRID INTRUSION DETECTION: A HYBRID CNN-LSTM-BASED MODEL
DEEP LEARNING FOR SMART GRID INTRUSION DETECTION: A HYBRID CNN-LSTM-BASED MODEL
ijaia

Digital Twins Computer Networking Paper Presentation.pptx
Digital Twins Computer Networking Paper Presentation.pptxDigital Twins Computer Networking Paper Presentation.pptx
Digital Twins Computer Networking Paper Presentation.pptx
aryanpankaj78

一比一原版(uoft毕业证书)加拿大多伦多大学毕业证如何办理
一比一原版(uoft毕业证书)加拿大多伦多大学毕业证如何办理一比一原版(uoft毕业证书)加拿大多伦多大学毕业证如何办理
一比一原版(uoft毕业证书)加拿大多伦多大学毕业证如何办理
sydezfe

NATURAL DEEP EUTECTIC SOLVENTS AS ANTI-FREEZING AGENT
NATURAL DEEP EUTECTIC SOLVENTS AS ANTI-FREEZING AGENTNATURAL DEEP EUTECTIC SOLVENTS AS ANTI-FREEZING AGENT
NATURAL DEEP EUTECTIC SOLVENTS AS ANTI-FREEZING AGENT
Addu25809

Accident detection system project report.pdf
Accident detection system project report.pdfAccident detection system project report.pdf
Accident detection system project report.pdf
Kamal Acharya

An Introduction to the Compiler Designss
An Introduction to the Compiler DesignssAn Introduction to the Compiler Designss
An Introduction to the Compiler Designss
ElakkiaU

SENTIMENT ANALYSIS ON PPT AND Project template_.pptx
SENTIMENT ANALYSIS ON PPT AND Project template_.pptxSENTIMENT ANALYSIS ON PPT AND Project template_.pptx
SENTIMENT ANALYSIS ON PPT AND Project template_.pptx
b0754201

一比一原版(CalArts毕业证)加利福尼亚艺术学院毕业证如何办理
一比一原版(CalArts毕业证)加利福尼亚艺术学院毕业证如何办理一比一原版(CalArts毕业证)加利福尼亚艺术学院毕业证如何办理
一比一原版(CalArts毕业证)加利福尼亚艺术学院毕业证如何办理
ecqow

Pressure Relief valve used in flow line to release the over pressure at our d...
Pressure Relief valve used in flow line to release the over pressure at our d...Pressure Relief valve used in flow line to release the over pressure at our d...
Pressure Relief valve used in flow line to release the over pressure at our d...
cannyengineerings

UNIT 4 LINEAR INTEGRATED CIRCUITS-DIGITAL ICS
UNIT 4 LINEAR INTEGRATED CIRCUITS-DIGITAL ICSUNIT 4 LINEAR INTEGRATED CIRCUITS-DIGITAL ICS
UNIT 4 LINEAR INTEGRATED CIRCUITS-DIGITAL ICS
vmspraneeth

Open Channel Flow: fluid flow with a free surface
Open Channel Flow: fluid flow with a free surfaceOpen Channel Flow: fluid flow with a free surface
Open Channel Flow: fluid flow with a free surface
Indrajeet sahu

Call For Paper -3rd International Conference on Artificial Intelligence Advan...
Call For Paper -3rd International Conference on Artificial Intelligence Advan...Call For Paper -3rd International Conference on Artificial Intelligence Advan...
Call For Paper -3rd International Conference on Artificial Intelligence Advan...
ijseajournal

Transformers design and coooling methods
Transformers design and coooling methodsTransformers design and coooling methods
Transformers design and coooling methods
Roger Rozario

一比一原版(uofo毕业证书)美国俄勒冈大学毕业证如何办理
一比一原版(uofo毕业证书)美国俄勒冈大学毕业证如何办理一比一原版(uofo毕业证书)美国俄勒冈大学毕业证如何办理
一比一原版(uofo毕业证书)美国俄勒冈大学毕业证如何办理
upoux

Generative AI Use cases applications solutions and implementation.pdf
Generative AI Use cases applications solutions and implementation.pdfGenerative AI Use cases applications solutions and implementation.pdf
Generative AI Use cases applications solutions and implementation.pdf
mahaffeycheryld


Recently uploaded (20)

SCALING OF MOS CIRCUITS m .pptx
SCALING OF MOS CIRCUITS m                 .pptxSCALING OF MOS CIRCUITS m                 .pptx
SCALING OF MOS CIRCUITS m .pptx

Null Bangalore | Pentesters Approach to AWS IAM
Null Bangalore | Pentesters Approach to AWS IAMNull Bangalore | Pentesters Approach to AWS IAM
Null Bangalore | Pentesters Approach to AWS IAM

Zener Diode and its V-I Characteristics and Applications
Zener Diode and its V-I Characteristics and ApplicationsZener Diode and its V-I Characteristics and Applications
Zener Diode and its V-I Characteristics and Applications

原版制作(Humboldt毕业证书)柏林大学毕业证学位证一模一样
原版制作(Humboldt毕业证书)柏林大学毕业证学位证一模一样原版制作(Humboldt毕业证书)柏林大学毕业证学位证一模一样
原版制作(Humboldt毕业证书)柏林大学毕业证学位证一模一样

一比一原版(USF毕业证)旧金山大学毕业证如何办理
一比一原版(USF毕业证)旧金山大学毕业证如何办理一比一原版(USF毕业证)旧金山大学毕业证如何办理
一比一原版(USF毕业证)旧金山大学毕业证如何办理

DEEP LEARNING FOR SMART GRID INTRUSION DETECTION: A HYBRID CNN-LSTM-BASED MODEL
DEEP LEARNING FOR SMART GRID INTRUSION DETECTION: A HYBRID CNN-LSTM-BASED MODELDEEP LEARNING FOR SMART GRID INTRUSION DETECTION: A HYBRID CNN-LSTM-BASED MODEL
DEEP LEARNING FOR SMART GRID INTRUSION DETECTION: A HYBRID CNN-LSTM-BASED MODEL

Digital Twins Computer Networking Paper Presentation.pptx
Digital Twins Computer Networking Paper Presentation.pptxDigital Twins Computer Networking Paper Presentation.pptx
Digital Twins Computer Networking Paper Presentation.pptx

一比一原版(uoft毕业证书)加拿大多伦多大学毕业证如何办理
一比一原版(uoft毕业证书)加拿大多伦多大学毕业证如何办理一比一原版(uoft毕业证书)加拿大多伦多大学毕业证如何办理
一比一原版(uoft毕业证书)加拿大多伦多大学毕业证如何办理

NATURAL DEEP EUTECTIC SOLVENTS AS ANTI-FREEZING AGENT
NATURAL DEEP EUTECTIC SOLVENTS AS ANTI-FREEZING AGENTNATURAL DEEP EUTECTIC SOLVENTS AS ANTI-FREEZING AGENT
NATURAL DEEP EUTECTIC SOLVENTS AS ANTI-FREEZING AGENT

Accident detection system project report.pdf
Accident detection system project report.pdfAccident detection system project report.pdf
Accident detection system project report.pdf

An Introduction to the Compiler Designss
An Introduction to the Compiler DesignssAn Introduction to the Compiler Designss
An Introduction to the Compiler Designss

SENTIMENT ANALYSIS ON PPT AND Project template_.pptx
SENTIMENT ANALYSIS ON PPT AND Project template_.pptxSENTIMENT ANALYSIS ON PPT AND Project template_.pptx
SENTIMENT ANALYSIS ON PPT AND Project template_.pptx

一比一原版(CalArts毕业证)加利福尼亚艺术学院毕业证如何办理
一比一原版(CalArts毕业证)加利福尼亚艺术学院毕业证如何办理一比一原版(CalArts毕业证)加利福尼亚艺术学院毕业证如何办理
一比一原版(CalArts毕业证)加利福尼亚艺术学院毕业证如何办理

Pressure Relief valve used in flow line to release the over pressure at our d...
Pressure Relief valve used in flow line to release the over pressure at our d...Pressure Relief valve used in flow line to release the over pressure at our d...
Pressure Relief valve used in flow line to release the over pressure at our d...

UNIT 4 LINEAR INTEGRATED CIRCUITS-DIGITAL ICS
UNIT 4 LINEAR INTEGRATED CIRCUITS-DIGITAL ICSUNIT 4 LINEAR INTEGRATED CIRCUITS-DIGITAL ICS
UNIT 4 LINEAR INTEGRATED CIRCUITS-DIGITAL ICS

Open Channel Flow: fluid flow with a free surface
Open Channel Flow: fluid flow with a free surfaceOpen Channel Flow: fluid flow with a free surface
Open Channel Flow: fluid flow with a free surface

Call For Paper -3rd International Conference on Artificial Intelligence Advan...
Call For Paper -3rd International Conference on Artificial Intelligence Advan...Call For Paper -3rd International Conference on Artificial Intelligence Advan...
Call For Paper -3rd International Conference on Artificial Intelligence Advan...

Transformers design and coooling methods
Transformers design and coooling methodsTransformers design and coooling methods
Transformers design and coooling methods

一比一原版(uofo毕业证书)美国俄勒冈大学毕业证如何办理
一比一原版(uofo毕业证书)美国俄勒冈大学毕业证如何办理一比一原版(uofo毕业证书)美国俄勒冈大学毕业证如何办理
一比一原版(uofo毕业证书)美国俄勒冈大学毕业证如何办理

Generative AI Use cases applications solutions and implementation.pdf
Generative AI Use cases applications solutions and implementation.pdfGenerative AI Use cases applications solutions and implementation.pdf
Generative AI Use cases applications solutions and implementation.pdf


Rethinking Data-Intensive Science Using Scalable Analytics Systems

  • 1. Rethinking Data-Intensive Science Using Scalable Analytics Systems Frank Austin Nothaft UC Berkeley AMP/ASPIRE Lab, @fnothaft With Matt Massie, Timothy Danford, Zhao Zhang, Uri Laserson, Carl Yeksigian, Jey Kottalam, Arun Ahuja, Jeff Hammerbacher, Michael Linderman, Michael J. Franklin, Anthony D. Joseph, David A. Patterson
  • 2. Scientific revolutions are driven by data acquisition revolutions
  • 3. Genome Sequencing Source: NIH National Genome Research Institute 2014: ~230,000 genomes sequenced 15-250GB/genome = ~30TB/day = ~10PB/year Human Genome! Project: ~10GB 1000 Genomes: 15TB TCGA: 3PB
  • 4. Sequencing advances line up well with scalable analytics software Source: NIH National Genome Research Institute Google MapReduce Hadoop MR Spark Parquet
  • 5. Mapping scientific systems to commodity analytics systems • Contemporary scientific systems are custom-built • Leads to functionality from commodity systems being rebuilt • We have an opportunity to rethink the abstractions that scientific systems use: • Migrate from a flat architecture to a stacked architecture • Expose higher level programming primitives • Use commodity tools wherever possible
  • 6. Common Traits of Legacy Data Intensive Scientific Systems 1. Computation is workflow/pipeline oriented 2. Processing system has monolithic/flat architecture 3. Data is stored in flat files
  • 7. Genomics Pipelines Source: The Broad Institute of MIT/Harvard
  • 8. Flat File Formats • Scientific data is typically stored in application specific file formats: • Genomic reads: SAM/BAM, CRAM • Genomic variants: VCF/BCF, MAF • Genomic features: BED, NarrowPeak, GTF • Centralized metadata makes it difficult to parallelize applications
  • 9. Flat Architectures • APIs present very barebones abstractions: • GATK: Sorted iterator over the genome • Why are flat architectures bad? 1. Trivial: low level abstractions are not productive 2. Trivial: flat architectures create technical lock-in 3. Subtle: low level abstractions can introduce bugs
  • 10. The perils of flattening… • The trivial: • You can improve performance by pushing data access order into your data layout • But now, you can’t easily compose pipeline stages that have different access orders • The obscure: • If you access data via a sorted iterator, will you incorrectly implement your algorithm?
  • 11. A green field approach
  • 12. First, define a schema record AlignmentRecord { union { null, Contig } contig = null; union { null, long } start = null; union { null, long } end = null; union { null, int } mapq = null; union { null, string } readName = null; union { null, string } sequence = null; union { null, string } mateReference = null; union { null, long } mateAlignmentStart = null; union { null, string } cigar = null; union { null, string } qual = null; union { null, string } recordGroupName = null; union { int, null } basesTrimmedFromStart = 0; union { int, null } basesTrimmedFromEnd = 0; union { boolean, null } readPaired = false; union { boolean, null } properPair = false; union { boolean, null } readMapped = false; union { boolean, null } mateMapped = false; union { boolean, null } firstOfPair = false; union { boolean, null } secondOfPair = false; union { boolean, null } failedVendorQualityChecks = false; union { boolean, null } duplicateRead = false; union { boolean, null } readNegativeStrand = false; union { boolean, null } mateNegativeStrand = false; union { boolean, null } primaryAlignment = false; union { boolean, null } secondaryAlignment = false; union { boolean, null } supplementaryAlignment = false; union { null, string } mismatchingPositions = null; union { null, string } origQual = null; union { null, string } attributes = null; union { null, string } recordGroupSequencingCenter = null; union { null, string } recordGroupDescription = null; union { null, long } recordGroupRunDateEpoch = null; union { null, string } recordGroupFlowOrder = null; union { null, string } recordGroupKeySequence = null; union { null, string } recordGroupLibrary = null; union { null, int } recordGroupPredictedMedianInsertSize = null; union { null, string } recordGroupPlatform = null; union { null, string } recordGroupPlatformUnit = null; union { null, string } recordGroupSample = null; union { null, Contig } mateContig = null; } Application Transformations Physical Storage Attached Storage Data Distribution Parallel FS Materialized Data Columnar Storage Evidence Access MapReduce/DBMS Presentation Enriched Models Schema Data Models
  • 13. Application Transformations Physical Storage Attached Storage Data Distribution Parallel FS Materialized Data Columnar Storage Evidence Access MapReduce/DBMS Presentation Enriched Models Schema Data Models A schema provides a narrow waistrecord AlignmentRecord { union { null, Contig } contig = null; union { null, long } start = null; union { null, long } end = null; union { null, int } mapq = null; union { null, string } readName = null; union { null, string } sequence = null; union { null, string } mateReference = null; union { null, long } mateAlignmentStart = null; union { null, string } cigar = null; union { null, string } qual = null; union { null, string } recordGroupName = null; union { int, null } basesTrimmedFromStart = 0; union { int, null } basesTrimmedFromEnd = 0; union { boolean, null } readPaired = false; union { boolean, null } properPair = false; union { boolean, null } readMapped = false; union { boolean, null } mateMapped = false; union { boolean, null } firstOfPair = false; union { boolean, null } secondOfPair = false; union { boolean, null } failedVendorQualityChecks = false; union { boolean, null } duplicateRead = false; union { boolean, null } readNegativeStrand = false; union { boolean, null } mateNegativeStrand = false; union { boolean, null } primaryAlignment = false; union { boolean, null } secondaryAlignment = false; union { boolean, null } supplementaryAlignment = false; union { null, string } mismatchingPositions = null; union { null, string } origQual = null; union { null, string } attributes = null; union { null, string } recordGroupSequencingCenter = null; union { null, string } recordGroupDescription = null; union { null, long } recordGroupRunDateEpoch = null; union { null, string } recordGroupFlowOrder = null; union { null, string } recordGroupKeySequence = null; union { null, string } recordGroupLibrary = null; union { null, int } recordGroupPredictedMedianInsertSize = null; union { null, string } recordGroupPlatform = null; union { null, string } recordGroupPlatformUnit = null; union { null, string } recordGroupSample = null; union { null, Contig } mateContig = null; } Application Transformations Physical Storage Attached Storage Data Distribution Parallel FS Materialized Data Columnar Storage Evidence Access MapReduce/DBMS Presentation Enriched Models Schema Data Models
  • 14. Accelerate common access patterns • In genomics, we commonly have to find observations that overlap in a coordinate plane • This coordinate plane is genomics specific, and is known a priori • We can use our knowledge of the coordinate plane to implement a fast overlap join Application Transformations Physical Storage Attached Storage Data Distribution Parallel FS Materialized Data Columnar Storage Evidence Access MapReduce/DBMS Presentation Enriched Models Schema Data Models Application Transformations Physical Storage Attached Storage Data Distribution Parallel FS Materialized Data Columnar Storage Evidence Access MapReduce/DBMS Presentation Enriched Models Schema Data Models
  • 15. Pick appropriate storage • When accessing scientific datasets, we frequently slice and dice the dataset: • Algorithms may touch subsets of columns • We don’t always touch the whole dataset • This is a good match for columnar storage Application Transformations Physical Storage Attached Storage Data Distribution Parallel FS Materialized Data Columnar Storage Evidence Access MapReduce/DBMS Presentation Enriched Models Schema Data Models Application Transformations Physical Storage Attached Storage Data Distribution Parallel FS Materialized Data Columnar Storage Evidence Access MapReduce/DBMS Presentation Enriched Models Schema Data Models
  • 16. Is introducing a new data model really a good idea? Source: XKCD, http://xkcd.com/927/
  • 17. A subtle point:! Proper stack design can simplify backwards compatibility To support legacy data formats, you define a way to serialize/deserialize the schema into/from the legacy flat file format! Data Distribution Materialized Data Legacy File Format Schema Data Models Data Distribution Materialized Data Columnar Storage Schema Data Models
  • 18. A subtle point:! Proper stack design can simplify backwards compatibility This is a view! Data Distribution Materialized Data Legacy File Format Schema Data Models Data Distribution Materialized Data Columnar Storage Schema Data Models
  • 19. A well designed stack simplifies application design Application Transformations Physical Storage Attached Storage Data Distribution Parallel FS Materialized Data Columnar Storage Evidence Access MapReduce/DBMS Presentation Enriched Models Schema Data Models Variant calling & analysis, RNA-seq analysis, etc. Disk, SDD, block store, memory cache HDFS, Tachyon, HPC file systems, S3 Load data from Parquet and legacy formats Spark, Spark-SQL, Hadoop Enriched Read/Variant Avro Schema for reads, variants, and genotypes Users define analyses via transformations Enriched models provide convenient methods on common models The evidence access layer efficiently executes transformations Schemas define the logical structure of basic genomic objects Common interfaces map logical schema to bytes on disk Parallel file system layer coordinates distribution of data Decoupling storage enables performance/cost tradeoff
  • 20. How does this perform on real scientific data?
  • 21. ADAM performs genomic preprocessing Source: The Broad Institute of MIT/Harvard
  • 22. ADAM’s Performance • Achieve linear scalability out to 128 nodes for most tasks • Up to 3x improvement over current tools on a single node Analysis run using Amazon EC2, single node was i2.8xlarge, cluster was r3.2xlarge Scripts available at https://www.github.com/bigdatagenomics/bdg-services.git
  • 24. Astronomy Image Co-addition Performance • Scales out to 16 nodes • ~3x improvement over extant tool on a single node Analysis run using Amazon EC2, cluster was c3.8xlarge (HPC optimized)
  • 25. Conclusions • There is a huge increase in the amount of scientific data being processed • Although scientific processing pipelines tend to be custom solutions, we can replace these pipelines with general, DBMS backed solutions • When we move to a general solution, we can gain performance without losing correctness
  • 26. Acknowledgements • ADAM (https://www.github.com/bigdatagenomics/adam):! • UC Berkeley: Matt Massie, Timothy Danford, André Schumacher, Jey Kottalam, Karen Feng, Eric Tu, Niranjan Kumar, Ananth Pallaseni, Anthony Joseph, Dave Patterson! • Mt. Sinai: Arun Ahuja, Neal Sidhwaney, Ryan Williams, Michael Linderman, Jeff Hammerbacher! • GenomeBridge: Carl Yeksigian! • Cloudera: Uri Laserson! • Microsoft Research: Ravi Pandya! • UC Santa Cruz: Benedict Paten, David Haussler! • KIRA (https://www.github.com/BIDS/Kira):! • UC Berkeley: Zhao Zhang, Mike Franklin, Evan Sparks, Kyle Barbary, Oliver Zahn, Saul Perlmutter! • PoC code at https://github.com/zhaozhang/SparkMontage
