Raspberry Pi
Technology
HISTROY
 The purpose of creating these affordable, programmable computers
was to
promote basic computer science to be taught in schools.
● Created by the Raspberry Pi Foundation (UK) in 2009.
● Sold over two million units within two years of having licensed
 It's supported by the University of Cambridge Computer Laboratory
and tech firm Broadcom
INTRODUCTION
Credit-card sized computer.
Initiated by Eben Upton.
Based on Broadcom chips.
Supported by UCCL and Broadcom.
Affordable
Runs LINUX. Microsoft is developing Windows 10 for newer
boards.
Consumes less than 5W of Power
Supports Full HD Video Output (1080p), Multiple USB Ports ,
etc
Why you should use one
o Low cost and low power
● Simple to use
● Educational device for youths
● Versatile for many different projects/applications
● Compact Size
MOTIVATION
 Computer science skills are important. Computers are the tool of
the 21st century
 Computer Science is concerned with much more than simply being
able to use a computer.
 For Developing CS skills. Easy access to computers
 One should understand how they work and how to program them,
easily and affectively.
FEATURES
 Provide a fun environment for experimenting with programming and
electronics.
 Inexpensive, simple, open and easy to maintain , Ultra low-cost
(Model A $25, Model B $35).
 Complete easy-to-program computer.
TECNOLOGY
 The Raspberry Pi has a Broadcom BCM2835 system on a chip ,
which includes an ARM1176JZF-S 700 MHz processor .
 It does not include a built-in hard disk , but uses an SD card for
booting and long-term storage.
 Dual Video Core IV GPU, Video Core IV GPU
 First model had 256MB RAM, newest has 1GB,2GB.
HARDWARE
4 Models: A, A+, B, B+.
● ARM1176JZF-S Processor
o Typical clock size is 700 MHz, preforming at approximately 40
MFLOPS, Can be overclocked to 1GHz without any issues.
● Includes Video Core IV graphics processor with1 billion pixels per
second.
● 512 MB of RAM is built into the board, not replaceable or
upgradeable
● Includes multiple built on I/O ports
o 100 MB/s Ethernet port
o HDMI port and RCA port
o Audio Jack
RISC Architecture
 Low Transistor Count
● Low Power Consumption/Heat Production
● Used in most mobile devices
o Phones
o Laptops
o Small Digital Devices

Raspberry Pi has similar requirements to
mobile devices

Architecture allows for various Unix Os, Raspberry Pi can utilizes
nearly all
Linux.
Instruction Set
 3 Instruction Sets
32 Bit ARM
Single Instructions
Handles Data
Organizes Processor Segments

16 Bit Thumb
Specialize in branch range and address space
Used with ARM for rapid interrupts
Used for Digital Signal Processing

8 Bit Java
Jazelle Technology
Deals with complex Java bytecodes
Pipelining
 8 stage pipeline
Data path consists of three pipelines:
ALU, shift,
Load or store pipeline
 Fetch stages can hold up to four instructions. Branch prediction
performed on instructions ahead of execution of earlier instructions
 Issue and Decode stages can contain any instruction in parallel with
a
predicted branch
 Execute, Memory, and Write stages can contain a predicted branch,
an
ALU, or multiply instruction load/store multiple instruction, and a
coprocessor instruction in parallel execution.
OPERATING SYSTEM
 Raspbian
 Fedora
 Arch-Linux ARM
 Windows 10 On Raspberry Pi2 (up-coming)
Programming on a Pi
 By default, It supports Python as the educational language.
 Any language which will compile for ARM v6 can be used with
the Raspberry Pi
 Raspberry Pi supports multiple Linux distributions
Ubuntu
Openelec
OSMC
 The installed ARMv6 also handle many languages
Python
C
C++
Java
Ruby
Scratch
 More programming languages can be installed with proper
support tools
Applications
 While originally used to teach kids about programming, the
Raspberry Pi
has evolved to be used for a multitude of different applications
 Automated Light Control System
 Game System Emulator
 Surveillance System
 Universal Remote Control system
 Automated House system
 Music Streaming Speakers , and a-lot more…,
Raspberry pi technology
POWER
5v micro
USB connector
(Similar to the one on a lot of mobile phones!)
DSI
(display
interface)
SOC (System On a Chip)
Broadcom BCM2835 700Mhz
INTERNAL
LAN Controller
CSI
(camera interface)
3.5mm Audio
Standard headphone
socket
RCA Video
(works with most older
TVs)
HDMI Audio & Video
(works with modern TVs and DVI monitors)
A/V (Audio/Video)
SD Card Slot
(supports SD cards up to 32GB)
STORAGE
GPIO
(General
Purpose
Input &
Output)
10/100Mb
Ethernet
2 x USB 2.0
ports
CONNECTIVITY
Raspberry pi technology
Raspberry pi technology
Raspberry pi technology
Sources
 http://www.raspberrypi.org (RasperryPi’s main website)
 http://infocenter.arm.com/help/topic/com.arm.doc.ddi0301h/DDI0301
H
_arm1176jzfs_r0p7_trm.pdf (ARM1176JZF-S Technical Reference
Manual)
 http://makezine.com/magazine/how-to-choose-the-right-
platformraspberry-pi-or-beaglebone-black/
 https://en.wikipedia.org/wiki/Main_Page
