Patterns of Parallel
  Programming
Prepared by Yan Drugalya
 ydrugalya@gmail.com
      @ydrugalya
Agenda
•   Why parallel?
•   Terms and measures
•   Building Blocks
•   Patterns overview
    – Pipeline and data flow
    – Producer-Consumer
    – Map-Reduce
    – Other
Why Moore's law is not working
               anymore
•   Power consumption
•   Wire delays
•   DRAM access latency
•   Diminishing returns of more instruction-level
    parallelism
Power consumption
                                                                                      Sun’s Surface
                        10,000


                         1,000                                          Rocket Nozzle
Power Density (W/cm2)




                          100                               Nuclear Reactor



                           10                            Pentium® processors

                                                                               Hot Plate
                            1
                                   8080




                             ‘70             ‘80   ’90               ’00                        ‘10
Wire delays
Diminishing returns
• 80’s
  – 10 CPI  1 CPI
• 90
  – 1 CPI  0.5CPI
• 00’s: multicore
No matter how fast processors get, software
consistently finds new ways to eat up the extra
speed.
                                 Herb Sutter
Survival




 To scale performance, put many processing cores on the
  microprocessor chip
 New Moore’s law edition is about doubling of cores.
Terms & Measures
•   Work = T1
•   Span = T∞
•   Work Law: Tp>=T1/P
•   Span Law: Tp>=T∞
•   Speedup: Tp/T1
    – Linear: θ(P)
    – Perfect: P
• Parallelism: T1/T∞
• Tp<=(T1-T∞)/P + T∞
Definitions
• Concurrent
  - Several things happenings at the same time
• Multithreaded
  – Multiple execution contexts
• Parallel
  – Multiple simultaneous computations
• Asynchronous
  – Not having to wait
Dangers
•   Race Conditions
•   Starvations
•   Deadlocks
•   Livelock
•   Optimizing compilers
•   …
Data parallelism




Parallel.ForEach(letters, ch => Capitalize(ch));
Task parallelism




Parallel.Invoke(() => Average(), () => Minimum() …);
Fork-Join
 • Additional work may be started only when specific subsets of
   the original elements have completed processing
 • All elements should be given the chance to run even if one
   invocation fails (Ping)


                               Parallel.Invoke(
                                   () => ComputeMean(),
            Fork                   () => ComputeMedian(),
                                   () => ComputeMode());

Compute   Compute   Compute    static void MyParallelInvoke(params Action[] actions)
 Median    Mean      Mode      {
                                    var tasks = new Task[actions.Length];
                                    for (int i = 0; i < actions.Length; i++)
                                            tasks[i] = Task.Factory.StartNew(actions[i]);
            Join                    Task.WaitAll(tasks);
                               }
Pipeline pattern
             Task<int> T1 = Task.Factory.StartNew(() =>
Task 1           { return result1(); });




             Task<double> T2 = T1.ContinueWith((antecedent) =>
Task 2           { return result2(antecedent.Result); });




             Task<double> T3 = T2.ContinueWith((antecedent) =>
Task 3           { return result3(antecedent.Result); });
Producer/Consumer
    Disk/Net
                   Read 1   Read 2    Read 3
BlockingCollection<T>       Process   Process   Process
Patterns of parallel programming
Other patterns
• Speculative Execution
• APM (IAsyncResult, Begin/end pairs)
• EAP(Operation/Callback pairs)
References
• Patterns for Parallel Programming: Understanding and Applying
  Parallel Patterns with the .NET Framework 4
• Pluralsight:
   – Introduction to Async and Parallel Programming in .NET 4
   – Async and Parallel Programming: Application Design
• The Free Lunch Is Over: A Fundamental Turn Toward
  Concurrency in Software
• Chapter 27 Multithreaded Algorithms from Introduction to
  algorithms 3rd edition
