OBTURATION MATERIALS
AND EQUIPMENT

DR. N. UDAYA BHASKER
Requirements for an Ideal Root Canal-Filling Material
According to Grossman, an ideal root canal-filling material should:


Easy manipulation with ample working time



Have dimensional stability



Be able to seal the canal laterally and apically



Not irritate periapical tissues



Be impervious to moisture and nonporous



Be unaffected by tissue fluids and insoluble in tissue fluids: not corrode or
oxidize
 Bacteriostatic
 Radiopaque
 Not discolor the tooth structure
 Be sterile or easily and quickly sterilizable
 Be easily removed from the canal, if necessary.
Materials used for Obturation

Sealers

Core obturating materials
Solid materials

Semisolids [Pastes]

i.

ZnOE based

ii. Resin based
Gutta Percha

iii. Glass ionomer based
iv. Ca(OH)2 based

Gutta percha [Regular/ β phase]

Thermoplasticised [α phase]
Resin-based core
i.

Injectable

ii. Carrier based

Silverpoints
 Gutta-percha polymer is a trans-1,4-polyisoprene, obtained from the coagulation of
latex produced by trees of the Sapotaceae family
 It exists in two crystalline forms (alpha and beta) with differing properties. Another
unstable form (γ) exists, which is amorphous in nature.
 In beta phase the material is a solid mass that is compactable, when heated the
material changes to alpha phase that is pliable and tacky and can be made to flow
under pressure

Beta form

56-64oC

Alpha form
Composition of commercial gutta-percha

Materials

Percentage

Function

Gutta-percha

18-22%

Matrix

Zinc oxide

59-76%

Filler

Waxes or resins

1-4%

Plasticity

Metal sulfates
(barium or strontium)

1-18%

Radiopacity
Advantages

The advantages of gutta-percha as a filling material are
1. It is compactible and adapts excellently to the irregularities and contour of the
canal by the lateral and vertical condensation method.

2. It can be softened and made plastic by heat or by organic solvents (eucalyptol,
chloroform, xylol, turpentine).
3. It is inert.
4. It has dimensional stability; when unaltered by organic solvents, it will not shrink.
5. It is tissue tolerant (nonallergenic).
6. It will not discolor the tooth structure.
7. It is radiopaque.
8. It can be easily removed from the canal when necessary.
9. Recent studies have demonstrated that, in vitro, gutta-percha has activity
against several different bacterial species (Staphylococcus aureus, Streptococcus
mutans, S. pyogenes). They have also hypothesized that the active antibacterial
element of gutta-percha cones is probably zinc oxide.

9. It is also readily sterilizable, since immersion in 5.25% sodium hypochlorite for
as little as 60 seconds suffices to eliminate even the most resistant spores
Disadvantages

The disadvantages of gutta-percha as a filling material are as follows:

1. It lacks rigidity. The smallest, standardized gutta-percha cones are relatively more
difficult to use unless canals are enlarged above size no. 25.

2. It lacks adhesive quality. Gutta-percha docs not adhere to the canal walls;
consequently, sealer is required. The necessary use of a cementing agent introduces
the risk of using tissue-irritating sealers.
3.

Gutta percha does not bond to any sealers

4.

It can be easily displaced by pressure

5. Gutta percha is almost wholly dependent on a coronal seal to prevent the apical
migration of bacteria if it's challenged by coronal leakage.
Obturation
CURRENT FORMS OF GUTTA-PERCHA AVAILABLE

 Solid core Gutta-percha points
- Standardized
-

Non standardized

 Thermo mechanical compactible
Gutta-percha

 Thermo plasticized Gutta-percha
- Solid core system
-

Injectable form

 Medicated Gutta-percha
Gutta percha is supplied as:
 Sticks


used to check the vitality of teeth



used as a temporary filling

 Points/ Cones


used for obturation



tracing of sinuses
Syringe material :
 Obtura II
Obtura II is a heated-gun system, whereby guttapercha sticks are placed within a chamber in the
gun, and a plunger is used to express the heated,
flowing gutta percha through replaceable injection
tips. The flow of the gutta percha is controlled
through the temperature of the unit - the higher
the temperature, the easier the flow. By design,

the system is considered a "high heat" system
Obturation
 Ultrafil

Ultrafil uses a pre-dosed cannula system. Cannulas containing various types of
gutta percha are placed in a heating unit. When needed they are loaded into a
gun (similar to a periodontal ligament injection unit), which expresses gutta

percha from the cannula. The system is characterized as a "low-heat" unit, since
the temperature needed to plasticize the gutta percha is much lower than the
Obtura II system
Obturation
Coating on metal or plastic cores :
 Thermafil


It consists of a plastic core coated with alpha phase gutta-percha and a
heating device that controls the temperature.

The carrier is set to the

predetermined length using the millimeter calibration markings on the carrier
shaft. After heating it, the clinician has approximately 10 seconds to retrieve and

insert it into the canal, without rotating or twisting it. The gutta-percha is allowed
2 to 4 minutes to cool before resecting the carrier.


An advantage to this technique is the movement of gutta-percha into lateral and

accessory canals; however, extrusion of material beyond the apical extent of the
preparation is a disadvantage.
Obturation
 SimpliFill
SimpliFill uses a flexible, stainless-steel shaft to hold a 5 mm long cone of gutta
percha called the Apical GP Plug. Once the 5 mm Apical GP Plug is firmly
condensed in the apical third of the canal with sealer, the SimpliFill handle is
turned counter clockwise, allowing the carrier to be removed. Leaving only the
Apical GP Plug (no carrier) allows for easy retreatment, should it become
necessary
Obturation
Thermomechanical Compaction of Gutta-percha:
A totally new concept of heat softening and compacting gutta-percha
was introduced by McSpadden in 1979. Initially called the
McSpadden Compactor, the device resembled a reverse Hedstroem
file, or a reverse screw design. It fit into a latch-type handpiece and
was spun in the canal at speeds between 8,000 and 20,000 rpm. At
these speeds, the heat generated by friction softened the gutta-percha
and the design of the blades forced the material apically.
Obturation
Microseal Condenser : is used in conjunction with heat-softened, alpha
phase-like gutta-percha as well as regular gutta-percha points.
To obturate a canal, the clinician is advised to place the primary gutta-percha
point, followed by the appropriate size Condenser, which has been coated with
the heat-softened gutta-percha. The Condenser is spun in the canal with a
controlled speed handpiece at 1,000 to 4,000 rpm to form a firmer core. This
“flings” the gutta-percha laterally and vertically
J.S. Quick-Fill
 Titanium carriers coated with alpha-phase gutta-percha comes in four sizes
and operates in regular slow-speed handpiece.
 Friction plasticizes gutta-percha.
 Titanium core may be severed and left or removed while still spinning
Gutta Percha Sealers:
GP sealers are prepared by dissolving gutta-percha in solvents like chloroform,
eucalyptol, xylol etc., as well as in rosin and balsam –
 Chloropercha,
 Eucapercha
 Xylopercha
 Kloropercha : contains balsam, rosin, and zinc oxide in addition to gutta-percha and
chloroform
Medicated Gutta Percha:
The iodoform, tetracycline and iodoform/tetracycline combination are bound
within the gutta percha points. They act as a reservoir of antimicrobial that is capable
of diffusing onto the surface of the gutta percha thereby inhibiting the colonization of
bacteria on the gutta percha points and within the root canal system. Tetracycline is
capable of coalescing within the dentinal tubules to inhibit long term microbial
growth. These medicated gutta percha points are site specific, surface acting
antimicrobial gutta percha points.
 Calcium hydroxide containing Gutta percha:
Gutta percha with high content of Calcium hydroxide (40-60%)

 Chlorohexidine Diacetate containing gutta percha :
GP matrix embedded with 5% chlorohexidine diacetate

Used primarily as Intracanal Medicaments.
Silver points :
Introduced by Jasper In 1941,
silver cones were the most widely used solid-core
metallic filling material, although points of gold,
iridioplatinum, and tantalum are also available
Advantages:

 Can be used in narrow and curved canals
 Silver has more rigidity than gutta-percha and hence
can be pushed into tightly fitting canals and around

curves where it is difficult to force gutta-percha.
Disadvantages:
•

Silver points/cones have a circular cross section unlike the canals which may
be oval hence a poor lateral seal

•

Show high levels of corrosion especially due to the dissolution of the sealers.

•

Retreivability is difficult
Paste-type filling materials
Include zinc oxide-eugenol cements with various additives, epoxy resins (AH-26),
acrylic, polyethylene, and polyvinyl resins (Diaket), calcium hydroxide
Disadvantage:

Microleakage
IDEAL REQUIREMENTS OF A ROOT CANAL SEALER
1. It should be tacky when mixed to provide good adhesion between it and the
canal wall when set.
2. It should make a hermetic [sic] seal.
3. It should be radiopaque so that it can be visualized in the radiograph.
4. The particles of powder should be very fine so that they can mix easily with the
liquid.
5. It should not shrink upon setting.
6. It should not stain tooth structure.
7. It should be bacteriostatic or at least not encourage bacterial growth.
8. It should set slowly.
9. It should be insoluble in tissue fluids.
10. It should be tissue tolerant, that is, non-irritating to periradicular tissue.
11. It should be soluble in a common solvent if it is necessary to remove the root
canal filling.
12. It should not provoke an immune response in periradicular tissue.
13. It should be neither mutagenic nor carcinogenic.
The root canal sealer acts as


a binding agent to cement the well-fitted primary cone into a canal [ much as
zinc phosphate cement binds a well-fitted inlay into a cavity preparation]



a filler for the discrepancies between the cone and the canal walls, and



a lubricant to facilitate the seating of the primary cone into the canal.
Endodontic sealers can be broadly classified into :
•

Zinc oxide Eugenol based

•

Resin based

•

Calcium hydroxide based

•

Glass ionomer based
Zinc Oxide-Eugenol-Based
Rickert's sealer

Powder
zinc oxide

41.2 parts

precipitated silver

30 parts

white resin

16 parts

Thymol iodide

12.8 parts

Liquid
oil of clove

78 parts

Canada balsam

22 parts

It is germicidal, has excellent lubricating and adhesive qualities, and sets in about half
an hour.
Because of its silver content, Rickert's sealer may cause discoloration of tooth
structure
Grossman's Formulation [Roth’s Sealer]:

In 1958 Grossman recommended a nonstaining ZOE cement as a substitute for
Rickert’s formula

Powder

Zinc oxide, reagent

42 parts

Staybelite resin

27 parts

Bismuth subcarbonate

15 parts

Barium sulfate

15 parts

Sodium borate, anhydrous

1 part

Liquid
Eugenol
Considered standard by which other cements are measured because it reasonably meets
most of Grossman’s requirements for cement
 All ZOE cements have an extended working time but set faster in the tooth
than on the slab because of increased body temperature and humidity
 Zinc oxide eugenol has the disadvantage, however, of being decomposed by
water through a continuous loss of the eugenol. This makes ZOE a weak,
unstable material and precludes its use in bulk, such as for retrofillings placed
apically through a surgical approach
Other Zinc oxide Eugenol based sealers :

Kerr Pulp sealer:

The Rickerts sealer was reintroduced in 1951 as kerr pulp sealer. It has the same
composition as Rickert’s

Disadvantage : staining of the tooth

Available as

•

Regular set

•

Pulp Canal Sealer EWT [Extended working time ]
Tubliseal:
Base
zinc oxide

57.4%

Oleoresins

21.25%

Bismuth trioxide

7.5%

Thymol iodide

3.75%

Oils and waxes

10%

Catalyst
Eugenol
Polymerised resin
Annidalin
 This sealer is packaged in two collapsible tubes containing a base and an
accelerator, which when mixed together in equal amounts form a creamy mix
 Advantages: Non-staining, quick and easy to mix, good radiopacity
 Disadvantages: reduced working time in the presence of moisture, expands
on setting
Zinc oxide Non-eugenol based sealer [NOGENOL]
Developed to overcome the irritating quality of Eugenol

Base
Zinc oxide
Barium sulphate
Accelerator

Hydrogenated rosin
Methyl abietate
Lauric acid
Chlorothymol
Salicylic acid
Formaldehyde containing sealers:
 These sealers constantly release antimicrobial formalin.
 Highly cytotoxic
N2 :

introduced by Sargenti in 1954 . Also called Sargenti’s Paste
Powder :
Zinc oxide,
Bismuth subcarbonate

Barium sulphate
Hydrocortisone
Prednisolone
Paraformaldehyde
Titanium dioxide
Phenyl mercuric borate
Lead tetraoxide

Liquid:
Eugenol
Geraniol
•

Advantages:

Good antibacterial effect
•

Disadvantages:

Irreversible damage to the nerve tissue
Causes coagulation necrosis of the tissues
Other Formaldehyde containing sealers are:

1. RC2B [ American counterpart of N2 sealer]

2. Endomethasone

3. SPAD

4. Riebler’s paste
Resin based sealers:

Diaket:
 Introduced by Schmidt

 A resin-reinforced chelate formed between zinc oxide and diketone, is known
for its high resistance to absorption.
 Advantages: good adhesion, sets quickly in the root canal, low solubility and
good volume stability, superior tensile strength
 Disadvantages: highly toxic, non resorbable and forms fibrous encapsulation if
extruded
AH-26:
Introduced by Schroeder 1957
It is an epoxy resin based sealer

Powder

Percentage

Silver powder

10%

Bismuth oxide

60%

Hexamethylene tetramine

25%

Titanium oxide

5%

Liquid
Bisphenol diglycidyl ether

100%
 As AH-26 sets, traces of formaldehyde are temporarily released, which
initially makes it antibacterial.
 AH-26 is not sensitive to moisture and will even set under water.
 It will not set, however, if hydrogen peroxide is present.
 It sets slowly, in 24 to 36 hours
 Has strong adhesive properties
 Disadvantages: slight contraction while setting,

delayed setting, staining
AH- Plus
Available as two paste system
•

Epoxide paste

•

Amine paste

Advantages over AH-26
•

less toxic

•

new amines added to maintain the natural color of the tooth

•

half the film thickness

•

better flow

•

shorter setting time of 8 hrs,

•

increased radiopacity
Epiphany Root canal Sealer
Is a dual cure , hydrophilic resin sealer
Used with Resilon core materials
Dispensed from a double barrelled, automix syringe
Originally it was used along with Epiphany Self-Etch Primer
Now available as Epiphany Self-Etch Sealer [eliminates the priming step]
The system consists of three parts:
1. Resilon – a thermoplastic synthetic polymer-based (polyester) root canal filling
material, as the major component;
2. Epiphany sealer – a resin-based composite that forms a bond to the dentin wall
and the core material under chemical reactions and halogen curing light; and

3. Primer - which prepares the canal wall to get in contact with Resilon and the
sealer
Calcium hydroxide based sealers:

The two most important reasons for using calcium hydroxide as a root-filling

material are
•

stimulation of the periapical tissues in order to maintain health or promotehealing and

•

for its antimicrobial effects
CRCS (Calciobiotic Root Canal Sealer)
 Is essentially a ZOE/eucalyptol sealer to which calcium hydroxide hasbeen added for
its called osteogenic effect.

 CRCS takes 3 days to set fully in either dry or humid environments.
 It also shows very little water sorption.
 This means it is quite stable, which improves its sealant qualities, but brings into
question its ability to actually stimulate cementum and/or bone formation. If the
calcium hydroxide is not released from the cement, it cannot exert an osteogenic
effect, and thus its intended role is negated
Seal apex:
It is a zinc oxide based calcium hydroxide sealer containing polymeric resin
Available as two paste system

Base

Catalyst

Calcium hydroxide

Barium sulphate

Zinc oxide

Titanium dioxide

Butyl benzene

Isobutyl salicylate

Sulphonamide

Aerosil

Zinc stearate
Advantages:

•

Biocompatible

•

Extruded material resorbs in 4 months

•

Good therapeutic effect

Disadvantages:
•

Long setting time

•

Absorbs water while setting and expands

•

Poor cohesive strength
Apexit:
Available as a two paste system
Better seal than that provided by sealapex
Biocompatible
Glass ionomer based sealers:

Ketac-Endo:
Advantages:
Biocompatible
Chemical bonding with the root dentine, hence strengthens the root
Less solubility
Dimensionally stable
Less technique sensitive

Disadvantage:
Extruded sealer is highly resistant to resorption [ delayed resorption]

Retrievability is difficult
Heat sources during obturation with gutta percha:

Touch N Heat

Endotec II

System B
Elements Obturation Unit
The SybronEndo Elements Obturation Unit (EOU) is a thermoplastic gutta
percha/RealSeal injector with backfill, down-pack, cautery and hot-pulp testing
capability

More Related Content

What's hot

Obturation materials ppt
Obturation materials pptObturation materials ppt
Obturation materials ppt
Dr.Leela naga Pavani

root canal sealers
root canal sealersroot canal sealers
root canal sealers
Sai D

Endodontic biofilm
Endodontic biofilmEndodontic biofilm
Endodontic biofilm
Praveena Veena

Rationale of endodontics
Rationale of endodonticsRationale of endodontics
Rationale of endodontics
alka shukla

ELECTRONIC APEX LOCATOR (EAL)
 ELECTRONIC APEX LOCATOR  (EAL) ELECTRONIC APEX LOCATOR  (EAL)
ELECTRONIC APEX LOCATOR (EAL)
Deepak Neupane

Obturation of root canal system
Obturation of root canal systemObturation of root canal system
Obturation of root canal system
Nivedha Tina

Obturation technique
Obturation technique Obturation technique
Obturation technique
Deepashri Tekam

TECHNIQUES OF OBTURATION
TECHNIQUES OF OBTURATIONTECHNIQUES OF OBTURATION
TECHNIQUES OF OBTURATION
Shazeena Qaiser

Biodentine™
Biodentine™Biodentine™
1. Intracanal medicaments
1. Intracanal medicaments 1. Intracanal medicaments
1. Intracanal medicaments
Ishani Sharma

Instrument seperation and its management
Instrument seperation and its managementInstrument seperation and its management
Instrument seperation and its management
Nivedha Tina

Single visit endodontics
Single visit endodonticsSingle visit endodontics
Single visit endodontics
Rajana Raghunath

Irrigation in endodontics
Irrigation in endodonticsIrrigation in endodontics
Irrigation in endodontics
Ashish Choudhary

Mta presentation
Mta presentationMta presentation
Mta presentation
Sk Aziz Ikbal

Recent advances in obturation techniques/ dental implant courses
Recent advances in obturation techniques/ dental implant coursesRecent advances in obturation techniques/ dental implant courses
Recent advances in obturation techniques/ dental implant courses
Indian dental academy

GLASS IONOMER CEMENT AND ITS RECENT ADVANCES- by Dr. JAGADEESH KODITYALA
GLASS IONOMER CEMENT AND ITS RECENT ADVANCES- by Dr. JAGADEESH KODITYALAGLASS IONOMER CEMENT AND ITS RECENT ADVANCES- by Dr. JAGADEESH KODITYALA
GLASS IONOMER CEMENT AND ITS RECENT ADVANCES- by Dr. JAGADEESH KODITYALA
Jagadeesh Kodityala

Caries infiltration
Caries infiltrationCaries infiltration
Caries infiltration
Ahmed Assaf

Rotary instruments in Endodontics -part1
Rotary instruments in Endodontics -part1Rotary instruments in Endodontics -part1
Rotary instruments in Endodontics -part1
Neha Bedwal

Indirect composite restorations
Indirect composite restorations Indirect composite restorations
Indirect composite restorations
Dr ATHUL CHANDRA.M

Composite preparation
Composite preparationComposite preparation
Composite preparation
Sami Alanazi


What's hot (20)

Obturation materials ppt
Obturation materials pptObturation materials ppt
Obturation materials ppt

root canal sealers
root canal sealersroot canal sealers
root canal sealers

Endodontic biofilm
Endodontic biofilmEndodontic biofilm
Endodontic biofilm

Rationale of endodontics
Rationale of endodonticsRationale of endodontics
Rationale of endodontics

ELECTRONIC APEX LOCATOR (EAL)
 ELECTRONIC APEX LOCATOR  (EAL) ELECTRONIC APEX LOCATOR  (EAL)
ELECTRONIC APEX LOCATOR (EAL)

Obturation of root canal system
Obturation of root canal systemObturation of root canal system
Obturation of root canal system

Obturation technique
Obturation technique Obturation technique
Obturation technique

TECHNIQUES OF OBTURATION
TECHNIQUES OF OBTURATIONTECHNIQUES OF OBTURATION
TECHNIQUES OF OBTURATION

Biodentine™
Biodentine™Biodentine™
Biodentine™

1. Intracanal medicaments
1. Intracanal medicaments 1. Intracanal medicaments
1. Intracanal medicaments

Instrument seperation and its management
Instrument seperation and its managementInstrument seperation and its management
Instrument seperation and its management

Single visit endodontics
Single visit endodonticsSingle visit endodontics
Single visit endodontics

Irrigation in endodontics
Irrigation in endodonticsIrrigation in endodontics
Irrigation in endodontics

Mta presentation
Mta presentationMta presentation
Mta presentation

Recent advances in obturation techniques/ dental implant courses
Recent advances in obturation techniques/ dental implant coursesRecent advances in obturation techniques/ dental implant courses
Recent advances in obturation techniques/ dental implant courses

GLASS IONOMER CEMENT AND ITS RECENT ADVANCES- by Dr. JAGADEESH KODITYALA
GLASS IONOMER CEMENT AND ITS RECENT ADVANCES- by Dr. JAGADEESH KODITYALAGLASS IONOMER CEMENT AND ITS RECENT ADVANCES- by Dr. JAGADEESH KODITYALA
GLASS IONOMER CEMENT AND ITS RECENT ADVANCES- by Dr. JAGADEESH KODITYALA

Caries infiltration
Caries infiltrationCaries infiltration
Caries infiltration

Rotary instruments in Endodontics -part1
Rotary instruments in Endodontics -part1Rotary instruments in Endodontics -part1
Rotary instruments in Endodontics -part1

Indirect composite restorations
Indirect composite restorations Indirect composite restorations
Indirect composite restorations

Composite preparation
Composite preparationComposite preparation
Composite preparation


Similar to Obturation

Obturation_1670937557.pptx
Obturation_1670937557.pptxObturation_1670937557.pptx
Obturation_1670937557.pptx
43NehaUpreti

Sealer and obturating materials
Sealer and obturating materialsSealer and obturating materials
Sealer and obturating materials
DrNandLal3

Obturation
ObturationObturation
Obturation
Deepashri Tekam

Obturation (Materials , Techniques and Properties)
Obturation (Materials , Techniques and Properties)Obturation (Materials , Techniques and Properties)
Obturation (Materials , Techniques and Properties)
Hamza Tahir

5 root canal filling materials
5 root canal filling materials5 root canal filling materials
5 root canal filling materials
Waleed K. O. Jaber

5 Root canal filling materials.ppt
5 Root canal filling materials.ppt5 Root canal filling materials.ppt
5 Root canal filling materials.ppt
doukinabiha

Obturating Material
Obturating Material Obturating Material
Obturating Material
RozinaKhatun2

Root canal filling instruments and materials
Root canal filling instruments and materialsRoot canal filling instruments and materials
Root canal filling instruments and materials
Linda Jenhani

Advances in obturation system in endodontics /certified fixed orthodontic co...
Advances in obturation system in endodontics  /certified fixed orthodontic co...Advances in obturation system in endodontics  /certified fixed orthodontic co...
Advances in obturation system in endodontics /certified fixed orthodontic co...
Indian dental academy

Obturation of Root Canal - An Endodontic Overview
Obturation of Root Canal - An Endodontic OverviewObturation of Root Canal - An Endodontic Overview
Obturation of Root Canal - An Endodontic Overview
Iraqi Dental Academy

OBTURATING MATERIALS.pptx
OBTURATING MATERIALS.pptxOBTURATING MATERIALS.pptx
OBTURATING MATERIALS.pptx
DrRutikaNaik

Endodontic materials BDS III lecture 2024- Dr Kisumbi (1).pdf
Endodontic materials BDS III lecture 2024- Dr Kisumbi (1).pdfEndodontic materials BDS III lecture 2024- Dr Kisumbi (1).pdf
Endodontic materials BDS III lecture 2024- Dr Kisumbi (1).pdf
KAMAUFRANCISGATHUTHI

3rd year Obturation Lecture
3rd year Obturation Lecture3rd year Obturation Lecture
3rd year Obturation Lecture
Al-Azhar University, Cairo, Egypt

Double seal in endodontics and conservative dentistry
Double seal in endodontics and conservative dentistryDouble seal in endodontics and conservative dentistry
Double seal in endodontics and conservative dentistry
drepsitaghosh

Casting procedure and casting defects
Casting procedure and casting defectsCasting procedure and casting defects
Casting procedure and casting defects
ChaithraPrabhu3

CASTING DEFECT.pptx
CASTING DEFECT.pptxCASTING DEFECT.pptx
CASTING DEFECT.pptx
Baishali Ghosh

Gutta percha
Gutta perchaGutta percha
Gutta percha
Anoop Nair

1. Root canal irrigants.pdfttggggggggggggg
1. Root canal irrigants.pdfttggggggggggggg1. Root canal irrigants.pdfttggggggggggggg
1. Root canal irrigants.pdfttggggggggggggg
HawzhinFakher

Casting in dentistry
Casting in dentistryCasting in dentistry
Casting in dentistry
Vasundhara naik

Obturation of root canal system
Obturation of root canal systemObturation of root canal system
Obturation of root canal system
Saeed Bajafar


Similar to Obturation (20)

Obturation_1670937557.pptx
Obturation_1670937557.pptxObturation_1670937557.pptx
Obturation_1670937557.pptx

Sealer and obturating materials
Sealer and obturating materialsSealer and obturating materials
Sealer and obturating materials

Obturation
ObturationObturation
Obturation

Obturation (Materials , Techniques and Properties)
Obturation (Materials , Techniques and Properties)Obturation (Materials , Techniques and Properties)
Obturation (Materials , Techniques and Properties)

5 root canal filling materials
5 root canal filling materials5 root canal filling materials
5 root canal filling materials

5 Root canal filling materials.ppt
5 Root canal filling materials.ppt5 Root canal filling materials.ppt
5 Root canal filling materials.ppt

Obturating Material
Obturating Material Obturating Material
Obturating Material

Root canal filling instruments and materials
Root canal filling instruments and materialsRoot canal filling instruments and materials
Root canal filling instruments and materials

Advances in obturation system in endodontics /certified fixed orthodontic co...
Advances in obturation system in endodontics  /certified fixed orthodontic co...Advances in obturation system in endodontics  /certified fixed orthodontic co...
Advances in obturation system in endodontics /certified fixed orthodontic co...

Obturation of Root Canal - An Endodontic Overview
Obturation of Root Canal - An Endodontic OverviewObturation of Root Canal - An Endodontic Overview
Obturation of Root Canal - An Endodontic Overview

OBTURATING MATERIALS.pptx
OBTURATING MATERIALS.pptxOBTURATING MATERIALS.pptx
OBTURATING MATERIALS.pptx

Endodontic materials BDS III lecture 2024- Dr Kisumbi (1).pdf
Endodontic materials BDS III lecture 2024- Dr Kisumbi (1).pdfEndodontic materials BDS III lecture 2024- Dr Kisumbi (1).pdf
Endodontic materials BDS III lecture 2024- Dr Kisumbi (1).pdf

3rd year Obturation Lecture
3rd year Obturation Lecture3rd year Obturation Lecture
3rd year Obturation Lecture

Double seal in endodontics and conservative dentistry
Double seal in endodontics and conservative dentistryDouble seal in endodontics and conservative dentistry
Double seal in endodontics and conservative dentistry

Casting procedure and casting defects
Casting procedure and casting defectsCasting procedure and casting defects
Casting procedure and casting defects

CASTING DEFECT.pptx
CASTING DEFECT.pptxCASTING DEFECT.pptx
CASTING DEFECT.pptx

Gutta percha
Gutta perchaGutta percha
Gutta percha

1. Root canal irrigants.pdfttggggggggggggg
1. Root canal irrigants.pdfttggggggggggggg1. Root canal irrigants.pdfttggggggggggggg
1. Root canal irrigants.pdfttggggggggggggg

Casting in dentistry
Casting in dentistryCasting in dentistry
Casting in dentistry

Obturation of root canal system
Obturation of root canal systemObturation of root canal system
Obturation of root canal system


More from IAU Dent

Odontogenic Infection
Odontogenic InfectionOdontogenic Infection
Odontogenic Infection
IAU Dent

Odontogenic Tumors
Odontogenic TumorsOdontogenic Tumors
Odontogenic Tumors
IAU Dent

Maxillofacial injuries
Maxillofacial injuriesMaxillofacial injuries
Maxillofacial injuries
IAU Dent

Impacted teeth
Impacted teethImpacted teeth
Impacted teeth
IAU Dent

Odontogenic Cysts
Odontogenic CystsOdontogenic Cysts
Odontogenic Cysts
IAU Dent

Chronic gingivitis
Chronic gingivitisChronic gingivitis
Chronic gingivitis
IAU Dent

Plaque control
Plaque controlPlaque control
Plaque control
IAU Dent

8. hypotension & hypertension
8. hypotension & hypertension8. hypotension & hypertension
8. hypotension & hypertension
IAU Dent

8. Prescription Writing
8. Prescription Writing8. Prescription Writing
8. Prescription Writing
IAU Dent

7. Adrenocorticosteriods
7. Adrenocorticosteriods7. Adrenocorticosteriods
7. Adrenocorticosteriods
IAU Dent

7.a. histamine & antihistaminics
7.a. histamine & antihistaminics7.a. histamine & antihistaminics
7.a. histamine & antihistaminics
IAU Dent

8 anticancer drugs
8  anticancer drugs8  anticancer drugs
8 anticancer drugs
IAU Dent

7 antibiotic-dental
7 antibiotic-dental7 antibiotic-dental
7 antibiotic-dental
IAU Dent

7.b. sedative hypnotics
7.b. sedative hypnotics 7.b. sedative hypnotics
7.b. sedative hypnotics
IAU Dent

6. peptic ulcer drugs 323
6. peptic ulcer drugs 3236. peptic ulcer drugs 323
6. peptic ulcer drugs 323
IAU Dent

6. anti drenergic
6. anti drenergic 6. anti drenergic
6. anti drenergic
IAU Dent

6 beta lactum drugs dental
6  beta lactum drugs dental6  beta lactum drugs dental
6 beta lactum drugs dental
IAU Dent

4.anti colinergic
4.anti colinergic 4.anti colinergic
4.anti colinergic
IAU Dent

5 aminoglycosides,macrolides, anti tb dental
5 aminoglycosides,macrolides, anti tb dental5 aminoglycosides,macrolides, anti tb dental
5 aminoglycosides,macrolides, anti tb dental
IAU Dent

5. opioid analgesics
5. opioid analgesics5. opioid analgesics
5. opioid analgesics
IAU Dent


More from IAU Dent (20)

Odontogenic Infection
Odontogenic InfectionOdontogenic Infection
Odontogenic Infection

Odontogenic Tumors
Odontogenic TumorsOdontogenic Tumors
Odontogenic Tumors

Maxillofacial injuries
Maxillofacial injuriesMaxillofacial injuries
Maxillofacial injuries

Impacted teeth
Impacted teethImpacted teeth
Impacted teeth

Odontogenic Cysts
Odontogenic CystsOdontogenic Cysts
Odontogenic Cysts

Chronic gingivitis
Chronic gingivitisChronic gingivitis
Chronic gingivitis

Plaque control
Plaque controlPlaque control
Plaque control

8. hypotension & hypertension
8. hypotension & hypertension8. hypotension & hypertension
8. hypotension & hypertension

8. Prescription Writing
8. Prescription Writing8. Prescription Writing
8. Prescription Writing

7. Adrenocorticosteriods
7. Adrenocorticosteriods7. Adrenocorticosteriods
7. Adrenocorticosteriods

7.a. histamine & antihistaminics
7.a. histamine & antihistaminics7.a. histamine & antihistaminics
7.a. histamine & antihistaminics

8 anticancer drugs
8  anticancer drugs8  anticancer drugs
8 anticancer drugs

7 antibiotic-dental
7 antibiotic-dental7 antibiotic-dental
7 antibiotic-dental

7.b. sedative hypnotics
7.b. sedative hypnotics 7.b. sedative hypnotics
7.b. sedative hypnotics

6. peptic ulcer drugs 323
6. peptic ulcer drugs 3236. peptic ulcer drugs 323
6. peptic ulcer drugs 323

6. anti drenergic
6. anti drenergic 6. anti drenergic
6. anti drenergic

6 beta lactum drugs dental
6  beta lactum drugs dental6  beta lactum drugs dental
6 beta lactum drugs dental

4.anti colinergic
4.anti colinergic 4.anti colinergic
4.anti colinergic

5 aminoglycosides,macrolides, anti tb dental
5 aminoglycosides,macrolides, anti tb dental5 aminoglycosides,macrolides, anti tb dental
5 aminoglycosides,macrolides, anti tb dental

5. opioid analgesics
5. opioid analgesics5. opioid analgesics
5. opioid analgesics


Recently uploaded

1234567891011121314151617181920212223242
12345678910111213141516171819202122232421234567891011121314151617181920212223242
1234567891011121314151617181920212223242
fauzanal343

Travel Tech Pitch Deck | ByeByeCity,com - Short Breaks Discovery & Booking Pl...
Travel Tech Pitch Deck | ByeByeCity,com - Short Breaks Discovery & Booking Pl...Travel Tech Pitch Deck | ByeByeCity,com - Short Breaks Discovery & Booking Pl...
Travel Tech Pitch Deck | ByeByeCity,com - Short Breaks Discovery & Booking Pl...
Rajesh Math

Discover who your target audience is and reach them
Discover who your target audience is and reach themDiscover who your target audience is and reach them
Discover who your target audience is and reach them
Quibble

Girls Call Kharghar 9910780858 Provide Best And Top Girl Service And No1 in City
Girls Call Kharghar 9910780858 Provide Best And Top Girl Service And No1 in CityGirls Call Kharghar 9910780858 Provide Best And Top Girl Service And No1 in City
Girls Call Kharghar 9910780858 Provide Best And Top Girl Service And No1 in City
maigasapphire

Growth Buyouts - The Dawn of the GBO (Slow Ventures)
Growth Buyouts - The  Dawn of the GBO (Slow Ventures)Growth Buyouts - The  Dawn of the GBO (Slow Ventures)
Growth Buyouts - The Dawn of the GBO (Slow Ventures)
Razin Mustafiz

High Profile Girls Call Bhubaneswar 🎈🔥000XX00000 🔥💋🎈 Provide Best And Top Gir...
High Profile Girls Call Bhubaneswar 🎈🔥000XX00000 🔥💋🎈 Provide Best And Top Gir...High Profile Girls Call Bhubaneswar 🎈🔥000XX00000 🔥💋🎈 Provide Best And Top Gir...
High Profile Girls Call Bhubaneswar 🎈🔥000XX00000 🔥💋🎈 Provide Best And Top Gir...
dimplekumaridk322

PETAVIT SIP-05.pdfAAAAAAAAAAAAAAAAAAAAAAAAA
PETAVIT SIP-05.pdfAAAAAAAAAAAAAAAAAAAAAAAAAPETAVIT SIP-05.pdfAAAAAAAAAAAAAAAAAAAAAAAAA
PETAVIT SIP-05.pdfAAAAAAAAAAAAAAAAAAAAAAAAA
lawrenceads01

Pricing sophistication - auto insurance telematics
Pricing sophistication - auto insurance telematicsPricing sophistication - auto insurance telematics
Pricing sophistication - auto insurance telematics
Matteo Carbone

PETAVIT MICHAEL TAY.pdfAAAAAAAAAAAAAAAAAAAA
PETAVIT MICHAEL TAY.pdfAAAAAAAAAAAAAAAAAAAAPETAVIT MICHAEL TAY.pdfAAAAAAAAAAAAAAAAAAAA
PETAVIT MICHAEL TAY.pdfAAAAAAAAAAAAAAAAAAAA
lawrenceads01

Case study on Indian Ecommerce logistics
Case study on Indian Ecommerce logisticsCase study on Indian Ecommerce logistics
Case study on Indian Ecommerce logistics
UnheardShayari

A STUDY OF MUTUAL FUND OF BANK OF INDIA .pdf
A STUDY OF MUTUAL FUND  OF BANK OF INDIA .pdfA STUDY OF MUTUAL FUND  OF BANK OF INDIA .pdf
A STUDY OF MUTUAL FUND OF BANK OF INDIA .pdf
rsonics22

THE IMPORTANCE OF CODING IN DEVOPS EXPLANATION
THE IMPORTANCE OF CODING IN DEVOPS EXPLANATIONTHE IMPORTANCE OF CODING IN DEVOPS EXPLANATION
THE IMPORTANCE OF CODING IN DEVOPS EXPLANATION
hrajkumar444

PAWFESSIONAL ELVA MAX.pdfAAAAAAAAAAAAAAAAAAA
PAWFESSIONAL ELVA MAX.pdfAAAAAAAAAAAAAAAAAAAPAWFESSIONAL ELVA MAX.pdfAAAAAAAAAAAAAAAAAAA
PAWFESSIONAL ELVA MAX.pdfAAAAAAAAAAAAAAAAAAA
lawrenceads01

Satta matka guessing Kalyan result sattamatka
Satta matka guessing Kalyan result sattamatkaSatta matka guessing Kalyan result sattamatka
Satta matka guessing Kalyan result sattamatka
➑➌➋➑➒➎➑➑➊➍

Anton Grutzmache- Ominisient: The Data Revolution in Banking: From Scoring Cr...
Anton Grutzmache- Ominisient: The Data Revolution in Banking: From Scoring Cr...Anton Grutzmache- Ominisient: The Data Revolution in Banking: From Scoring Cr...
Anton Grutzmache- Ominisient: The Data Revolution in Banking: From Scoring Cr...
itnewsafrica

ConvertKit: Best Email Marketing Tool for 2024
ConvertKit: Best Email Marketing Tool for 2024ConvertKit: Best Email Marketing Tool for 2024
ConvertKit: Best Email Marketing Tool for 2024
Rakesh Jalan

Mandated reporting powerpoint to help with understanding your role
Mandated reporting powerpoint to help with understanding your roleMandated reporting powerpoint to help with understanding your role
Mandated reporting powerpoint to help with understanding your role
khidalgo2

foodgasm restaurant and Bar pune road.docx
foodgasm restaurant and Bar pune road.docxfoodgasm restaurant and Bar pune road.docx
foodgasm restaurant and Bar pune road.docx
PraghyaBhandari

Innovation Hub_ Spotlight on Toms River's Role as a Beacon for Entrepreneuria...
Innovation Hub_ Spotlight on Toms River's Role as a Beacon for Entrepreneuria...Innovation Hub_ Spotlight on Toms River's Role as a Beacon for Entrepreneuria...
Innovation Hub_ Spotlight on Toms River's Role as a Beacon for Entrepreneuria...
Philip M Caputo

Entrepreneurial mindset: An Introduction to Entrepreneurship
Entrepreneurial mindset: An Introduction to EntrepreneurshipEntrepreneurial mindset: An Introduction to Entrepreneurship
Entrepreneurial mindset: An Introduction to Entrepreneurship
Sanjay Joshi


Recently uploaded (20)

1234567891011121314151617181920212223242
12345678910111213141516171819202122232421234567891011121314151617181920212223242
1234567891011121314151617181920212223242

Travel Tech Pitch Deck | ByeByeCity,com - Short Breaks Discovery & Booking Pl...
Travel Tech Pitch Deck | ByeByeCity,com - Short Breaks Discovery & Booking Pl...Travel Tech Pitch Deck | ByeByeCity,com - Short Breaks Discovery & Booking Pl...
Travel Tech Pitch Deck | ByeByeCity,com - Short Breaks Discovery & Booking Pl...

Discover who your target audience is and reach them
Discover who your target audience is and reach themDiscover who your target audience is and reach them
Discover who your target audience is and reach them

Girls Call Kharghar 9910780858 Provide Best And Top Girl Service And No1 in City
Girls Call Kharghar 9910780858 Provide Best And Top Girl Service And No1 in CityGirls Call Kharghar 9910780858 Provide Best And Top Girl Service And No1 in City
Girls Call Kharghar 9910780858 Provide Best And Top Girl Service And No1 in City

Growth Buyouts - The Dawn of the GBO (Slow Ventures)
Growth Buyouts - The  Dawn of the GBO (Slow Ventures)Growth Buyouts - The  Dawn of the GBO (Slow Ventures)
Growth Buyouts - The Dawn of the GBO (Slow Ventures)

High Profile Girls Call Bhubaneswar 🎈🔥000XX00000 🔥💋🎈 Provide Best And Top Gir...
High Profile Girls Call Bhubaneswar 🎈🔥000XX00000 🔥💋🎈 Provide Best And Top Gir...High Profile Girls Call Bhubaneswar 🎈🔥000XX00000 🔥💋🎈 Provide Best And Top Gir...
High Profile Girls Call Bhubaneswar 🎈🔥000XX00000 🔥💋🎈 Provide Best And Top Gir...

PETAVIT SIP-05.pdfAAAAAAAAAAAAAAAAAAAAAAAAA
PETAVIT SIP-05.pdfAAAAAAAAAAAAAAAAAAAAAAAAAPETAVIT SIP-05.pdfAAAAAAAAAAAAAAAAAAAAAAAAA
PETAVIT SIP-05.pdfAAAAAAAAAAAAAAAAAAAAAAAAA

Pricing sophistication - auto insurance telematics
Pricing sophistication - auto insurance telematicsPricing sophistication - auto insurance telematics
Pricing sophistication - auto insurance telematics

PETAVIT MICHAEL TAY.pdfAAAAAAAAAAAAAAAAAAAA
PETAVIT MICHAEL TAY.pdfAAAAAAAAAAAAAAAAAAAAPETAVIT MICHAEL TAY.pdfAAAAAAAAAAAAAAAAAAAA
PETAVIT MICHAEL TAY.pdfAAAAAAAAAAAAAAAAAAAA

Case study on Indian Ecommerce logistics
Case study on Indian Ecommerce logisticsCase study on Indian Ecommerce logistics
Case study on Indian Ecommerce logistics

A STUDY OF MUTUAL FUND OF BANK OF INDIA .pdf
A STUDY OF MUTUAL FUND  OF BANK OF INDIA .pdfA STUDY OF MUTUAL FUND  OF BANK OF INDIA .pdf
A STUDY OF MUTUAL FUND OF BANK OF INDIA .pdf

THE IMPORTANCE OF CODING IN DEVOPS EXPLANATION
THE IMPORTANCE OF CODING IN DEVOPS EXPLANATIONTHE IMPORTANCE OF CODING IN DEVOPS EXPLANATION
THE IMPORTANCE OF CODING IN DEVOPS EXPLANATION

PAWFESSIONAL ELVA MAX.pdfAAAAAAAAAAAAAAAAAAA
PAWFESSIONAL ELVA MAX.pdfAAAAAAAAAAAAAAAAAAAPAWFESSIONAL ELVA MAX.pdfAAAAAAAAAAAAAAAAAAA
PAWFESSIONAL ELVA MAX.pdfAAAAAAAAAAAAAAAAAAA

Satta matka guessing Kalyan result sattamatka
Satta matka guessing Kalyan result sattamatkaSatta matka guessing Kalyan result sattamatka
Satta matka guessing Kalyan result sattamatka

Anton Grutzmache- Ominisient: The Data Revolution in Banking: From Scoring Cr...
Anton Grutzmache- Ominisient: The Data Revolution in Banking: From Scoring Cr...Anton Grutzmache- Ominisient: The Data Revolution in Banking: From Scoring Cr...
Anton Grutzmache- Ominisient: The Data Revolution in Banking: From Scoring Cr...

ConvertKit: Best Email Marketing Tool for 2024
ConvertKit: Best Email Marketing Tool for 2024ConvertKit: Best Email Marketing Tool for 2024
ConvertKit: Best Email Marketing Tool for 2024

Mandated reporting powerpoint to help with understanding your role
Mandated reporting powerpoint to help with understanding your roleMandated reporting powerpoint to help with understanding your role
Mandated reporting powerpoint to help with understanding your role

foodgasm restaurant and Bar pune road.docx
foodgasm restaurant and Bar pune road.docxfoodgasm restaurant and Bar pune road.docx
foodgasm restaurant and Bar pune road.docx

Innovation Hub_ Spotlight on Toms River's Role as a Beacon for Entrepreneuria...
Innovation Hub_ Spotlight on Toms River's Role as a Beacon for Entrepreneuria...Innovation Hub_ Spotlight on Toms River's Role as a Beacon for Entrepreneuria...
Innovation Hub_ Spotlight on Toms River's Role as a Beacon for Entrepreneuria...

Entrepreneurial mindset: An Introduction to Entrepreneurship
Entrepreneurial mindset: An Introduction to EntrepreneurshipEntrepreneurial mindset: An Introduction to Entrepreneurship
Entrepreneurial mindset: An Introduction to Entrepreneurship


Obturation

  • 2. Requirements for an Ideal Root Canal-Filling Material According to Grossman, an ideal root canal-filling material should:  Easy manipulation with ample working time  Have dimensional stability  Be able to seal the canal laterally and apically  Not irritate periapical tissues  Be impervious to moisture and nonporous  Be unaffected by tissue fluids and insoluble in tissue fluids: not corrode or oxidize
  • 3.  Bacteriostatic  Radiopaque  Not discolor the tooth structure  Be sterile or easily and quickly sterilizable  Be easily removed from the canal, if necessary.
  • 4. Materials used for Obturation Sealers Core obturating materials Solid materials Semisolids [Pastes] i. ZnOE based ii. Resin based Gutta Percha iii. Glass ionomer based iv. Ca(OH)2 based Gutta percha [Regular/ β phase] Thermoplasticised [α phase] Resin-based core i. Injectable ii. Carrier based Silverpoints
  • 5.  Gutta-percha polymer is a trans-1,4-polyisoprene, obtained from the coagulation of latex produced by trees of the Sapotaceae family  It exists in two crystalline forms (alpha and beta) with differing properties. Another unstable form (γ) exists, which is amorphous in nature.  In beta phase the material is a solid mass that is compactable, when heated the material changes to alpha phase that is pliable and tacky and can be made to flow under pressure Beta form 56-64oC Alpha form
  • 6. Composition of commercial gutta-percha Materials Percentage Function Gutta-percha 18-22% Matrix Zinc oxide 59-76% Filler Waxes or resins 1-4% Plasticity Metal sulfates (barium or strontium) 1-18% Radiopacity
  • 7. Advantages The advantages of gutta-percha as a filling material are 1. It is compactible and adapts excellently to the irregularities and contour of the canal by the lateral and vertical condensation method. 2. It can be softened and made plastic by heat or by organic solvents (eucalyptol, chloroform, xylol, turpentine). 3. It is inert. 4. It has dimensional stability; when unaltered by organic solvents, it will not shrink. 5. It is tissue tolerant (nonallergenic). 6. It will not discolor the tooth structure. 7. It is radiopaque. 8. It can be easily removed from the canal when necessary.
  • 8. 9. Recent studies have demonstrated that, in vitro, gutta-percha has activity against several different bacterial species (Staphylococcus aureus, Streptococcus mutans, S. pyogenes). They have also hypothesized that the active antibacterial element of gutta-percha cones is probably zinc oxide. 9. It is also readily sterilizable, since immersion in 5.25% sodium hypochlorite for as little as 60 seconds suffices to eliminate even the most resistant spores
  • 9. Disadvantages The disadvantages of gutta-percha as a filling material are as follows: 1. It lacks rigidity. The smallest, standardized gutta-percha cones are relatively more difficult to use unless canals are enlarged above size no. 25. 2. It lacks adhesive quality. Gutta-percha docs not adhere to the canal walls; consequently, sealer is required. The necessary use of a cementing agent introduces the risk of using tissue-irritating sealers.
  • 10. 3. Gutta percha does not bond to any sealers 4. It can be easily displaced by pressure 5. Gutta percha is almost wholly dependent on a coronal seal to prevent the apical migration of bacteria if it's challenged by coronal leakage.
  • 12. CURRENT FORMS OF GUTTA-PERCHA AVAILABLE  Solid core Gutta-percha points - Standardized - Non standardized  Thermo mechanical compactible Gutta-percha  Thermo plasticized Gutta-percha - Solid core system - Injectable form  Medicated Gutta-percha
  • 13. Gutta percha is supplied as:  Sticks  used to check the vitality of teeth  used as a temporary filling  Points/ Cones  used for obturation  tracing of sinuses
  • 14. Syringe material :  Obtura II Obtura II is a heated-gun system, whereby guttapercha sticks are placed within a chamber in the gun, and a plunger is used to express the heated, flowing gutta percha through replaceable injection tips. The flow of the gutta percha is controlled through the temperature of the unit - the higher the temperature, the easier the flow. By design, the system is considered a "high heat" system
  • 16.  Ultrafil Ultrafil uses a pre-dosed cannula system. Cannulas containing various types of gutta percha are placed in a heating unit. When needed they are loaded into a gun (similar to a periodontal ligament injection unit), which expresses gutta percha from the cannula. The system is characterized as a "low-heat" unit, since the temperature needed to plasticize the gutta percha is much lower than the Obtura II system
  • 18. Coating on metal or plastic cores :  Thermafil  It consists of a plastic core coated with alpha phase gutta-percha and a heating device that controls the temperature. The carrier is set to the predetermined length using the millimeter calibration markings on the carrier shaft. After heating it, the clinician has approximately 10 seconds to retrieve and insert it into the canal, without rotating or twisting it. The gutta-percha is allowed 2 to 4 minutes to cool before resecting the carrier.  An advantage to this technique is the movement of gutta-percha into lateral and accessory canals; however, extrusion of material beyond the apical extent of the preparation is a disadvantage.
  • 20.  SimpliFill SimpliFill uses a flexible, stainless-steel shaft to hold a 5 mm long cone of gutta percha called the Apical GP Plug. Once the 5 mm Apical GP Plug is firmly condensed in the apical third of the canal with sealer, the SimpliFill handle is turned counter clockwise, allowing the carrier to be removed. Leaving only the Apical GP Plug (no carrier) allows for easy retreatment, should it become necessary
  • 22. Thermomechanical Compaction of Gutta-percha: A totally new concept of heat softening and compacting gutta-percha was introduced by McSpadden in 1979. Initially called the McSpadden Compactor, the device resembled a reverse Hedstroem file, or a reverse screw design. It fit into a latch-type handpiece and was spun in the canal at speeds between 8,000 and 20,000 rpm. At these speeds, the heat generated by friction softened the gutta-percha and the design of the blades forced the material apically.
  • 24. Microseal Condenser : is used in conjunction with heat-softened, alpha phase-like gutta-percha as well as regular gutta-percha points. To obturate a canal, the clinician is advised to place the primary gutta-percha point, followed by the appropriate size Condenser, which has been coated with the heat-softened gutta-percha. The Condenser is spun in the canal with a controlled speed handpiece at 1,000 to 4,000 rpm to form a firmer core. This “flings” the gutta-percha laterally and vertically
  • 25. J.S. Quick-Fill  Titanium carriers coated with alpha-phase gutta-percha comes in four sizes and operates in regular slow-speed handpiece.  Friction plasticizes gutta-percha.  Titanium core may be severed and left or removed while still spinning
  • 26. Gutta Percha Sealers: GP sealers are prepared by dissolving gutta-percha in solvents like chloroform, eucalyptol, xylol etc., as well as in rosin and balsam –  Chloropercha,  Eucapercha  Xylopercha  Kloropercha : contains balsam, rosin, and zinc oxide in addition to gutta-percha and chloroform
  • 27. Medicated Gutta Percha: The iodoform, tetracycline and iodoform/tetracycline combination are bound within the gutta percha points. They act as a reservoir of antimicrobial that is capable of diffusing onto the surface of the gutta percha thereby inhibiting the colonization of bacteria on the gutta percha points and within the root canal system. Tetracycline is capable of coalescing within the dentinal tubules to inhibit long term microbial growth. These medicated gutta percha points are site specific, surface acting antimicrobial gutta percha points.
  • 28.  Calcium hydroxide containing Gutta percha: Gutta percha with high content of Calcium hydroxide (40-60%)  Chlorohexidine Diacetate containing gutta percha : GP matrix embedded with 5% chlorohexidine diacetate Used primarily as Intracanal Medicaments.
  • 29. Silver points : Introduced by Jasper In 1941, silver cones were the most widely used solid-core metallic filling material, although points of gold, iridioplatinum, and tantalum are also available Advantages:  Can be used in narrow and curved canals  Silver has more rigidity than gutta-percha and hence can be pushed into tightly fitting canals and around curves where it is difficult to force gutta-percha.
  • 30. Disadvantages: • Silver points/cones have a circular cross section unlike the canals which may be oval hence a poor lateral seal • Show high levels of corrosion especially due to the dissolution of the sealers. • Retreivability is difficult
  • 31. Paste-type filling materials Include zinc oxide-eugenol cements with various additives, epoxy resins (AH-26), acrylic, polyethylene, and polyvinyl resins (Diaket), calcium hydroxide Disadvantage: Microleakage
  • 32. IDEAL REQUIREMENTS OF A ROOT CANAL SEALER 1. It should be tacky when mixed to provide good adhesion between it and the canal wall when set. 2. It should make a hermetic [sic] seal. 3. It should be radiopaque so that it can be visualized in the radiograph. 4. The particles of powder should be very fine so that they can mix easily with the liquid. 5. It should not shrink upon setting. 6. It should not stain tooth structure.
  • 33. 7. It should be bacteriostatic or at least not encourage bacterial growth. 8. It should set slowly. 9. It should be insoluble in tissue fluids. 10. It should be tissue tolerant, that is, non-irritating to periradicular tissue. 11. It should be soluble in a common solvent if it is necessary to remove the root canal filling. 12. It should not provoke an immune response in periradicular tissue. 13. It should be neither mutagenic nor carcinogenic.
  • 34. The root canal sealer acts as  a binding agent to cement the well-fitted primary cone into a canal [ much as zinc phosphate cement binds a well-fitted inlay into a cavity preparation]  a filler for the discrepancies between the cone and the canal walls, and  a lubricant to facilitate the seating of the primary cone into the canal.
  • 35. Endodontic sealers can be broadly classified into : • Zinc oxide Eugenol based • Resin based • Calcium hydroxide based • Glass ionomer based
  • 36. Zinc Oxide-Eugenol-Based Rickert's sealer Powder zinc oxide 41.2 parts precipitated silver 30 parts white resin 16 parts Thymol iodide 12.8 parts Liquid oil of clove 78 parts Canada balsam 22 parts It is germicidal, has excellent lubricating and adhesive qualities, and sets in about half an hour. Because of its silver content, Rickert's sealer may cause discoloration of tooth structure
  • 37. Grossman's Formulation [Roth’s Sealer]: In 1958 Grossman recommended a nonstaining ZOE cement as a substitute for Rickert’s formula Powder Zinc oxide, reagent 42 parts Staybelite resin 27 parts Bismuth subcarbonate 15 parts Barium sulfate 15 parts Sodium borate, anhydrous 1 part Liquid Eugenol Considered standard by which other cements are measured because it reasonably meets most of Grossman’s requirements for cement
  • 38.  All ZOE cements have an extended working time but set faster in the tooth than on the slab because of increased body temperature and humidity  Zinc oxide eugenol has the disadvantage, however, of being decomposed by water through a continuous loss of the eugenol. This makes ZOE a weak, unstable material and precludes its use in bulk, such as for retrofillings placed apically through a surgical approach
  • 39. Other Zinc oxide Eugenol based sealers : Kerr Pulp sealer: The Rickerts sealer was reintroduced in 1951 as kerr pulp sealer. It has the same composition as Rickert’s Disadvantage : staining of the tooth Available as • Regular set • Pulp Canal Sealer EWT [Extended working time ]
  • 40. Tubliseal: Base zinc oxide 57.4% Oleoresins 21.25% Bismuth trioxide 7.5% Thymol iodide 3.75% Oils and waxes 10% Catalyst Eugenol Polymerised resin Annidalin
  • 41.  This sealer is packaged in two collapsible tubes containing a base and an accelerator, which when mixed together in equal amounts form a creamy mix  Advantages: Non-staining, quick and easy to mix, good radiopacity  Disadvantages: reduced working time in the presence of moisture, expands on setting
  • 42. Zinc oxide Non-eugenol based sealer [NOGENOL] Developed to overcome the irritating quality of Eugenol Base Zinc oxide Barium sulphate Accelerator Hydrogenated rosin Methyl abietate Lauric acid Chlorothymol Salicylic acid
  • 43. Formaldehyde containing sealers:  These sealers constantly release antimicrobial formalin.  Highly cytotoxic N2 : introduced by Sargenti in 1954 . Also called Sargenti’s Paste Powder : Zinc oxide, Bismuth subcarbonate Barium sulphate Hydrocortisone Prednisolone Paraformaldehyde Titanium dioxide Phenyl mercuric borate Lead tetraoxide Liquid: Eugenol Geraniol
  • 44. • Advantages: Good antibacterial effect • Disadvantages: Irreversible damage to the nerve tissue Causes coagulation necrosis of the tissues
  • 45. Other Formaldehyde containing sealers are: 1. RC2B [ American counterpart of N2 sealer] 2. Endomethasone 3. SPAD 4. Riebler’s paste
  • 46. Resin based sealers: Diaket:  Introduced by Schmidt  A resin-reinforced chelate formed between zinc oxide and diketone, is known for its high resistance to absorption.  Advantages: good adhesion, sets quickly in the root canal, low solubility and good volume stability, superior tensile strength  Disadvantages: highly toxic, non resorbable and forms fibrous encapsulation if extruded
  • 47. AH-26: Introduced by Schroeder 1957 It is an epoxy resin based sealer Powder Percentage Silver powder 10% Bismuth oxide 60% Hexamethylene tetramine 25% Titanium oxide 5% Liquid Bisphenol diglycidyl ether 100%
  • 48.  As AH-26 sets, traces of formaldehyde are temporarily released, which initially makes it antibacterial.  AH-26 is not sensitive to moisture and will even set under water.  It will not set, however, if hydrogen peroxide is present.  It sets slowly, in 24 to 36 hours  Has strong adhesive properties  Disadvantages: slight contraction while setting, delayed setting, staining
  • 49. AH- Plus Available as two paste system • Epoxide paste • Amine paste Advantages over AH-26 • less toxic • new amines added to maintain the natural color of the tooth • half the film thickness • better flow • shorter setting time of 8 hrs, • increased radiopacity
  • 50. Epiphany Root canal Sealer Is a dual cure , hydrophilic resin sealer Used with Resilon core materials Dispensed from a double barrelled, automix syringe Originally it was used along with Epiphany Self-Etch Primer Now available as Epiphany Self-Etch Sealer [eliminates the priming step]
  • 51. The system consists of three parts: 1. Resilon – a thermoplastic synthetic polymer-based (polyester) root canal filling material, as the major component; 2. Epiphany sealer – a resin-based composite that forms a bond to the dentin wall and the core material under chemical reactions and halogen curing light; and 3. Primer - which prepares the canal wall to get in contact with Resilon and the sealer
  • 52. Calcium hydroxide based sealers: The two most important reasons for using calcium hydroxide as a root-filling material are • stimulation of the periapical tissues in order to maintain health or promotehealing and • for its antimicrobial effects
  • 53. CRCS (Calciobiotic Root Canal Sealer)  Is essentially a ZOE/eucalyptol sealer to which calcium hydroxide hasbeen added for its called osteogenic effect.  CRCS takes 3 days to set fully in either dry or humid environments.  It also shows very little water sorption.  This means it is quite stable, which improves its sealant qualities, but brings into question its ability to actually stimulate cementum and/or bone formation. If the calcium hydroxide is not released from the cement, it cannot exert an osteogenic effect, and thus its intended role is negated
  • 54. Seal apex: It is a zinc oxide based calcium hydroxide sealer containing polymeric resin Available as two paste system Base Catalyst Calcium hydroxide Barium sulphate Zinc oxide Titanium dioxide Butyl benzene Isobutyl salicylate Sulphonamide Aerosil Zinc stearate
  • 55. Advantages: • Biocompatible • Extruded material resorbs in 4 months • Good therapeutic effect Disadvantages: • Long setting time • Absorbs water while setting and expands • Poor cohesive strength
  • 56. Apexit: Available as a two paste system Better seal than that provided by sealapex Biocompatible
  • 57. Glass ionomer based sealers: Ketac-Endo: Advantages: Biocompatible Chemical bonding with the root dentine, hence strengthens the root Less solubility Dimensionally stable Less technique sensitive Disadvantage: Extruded sealer is highly resistant to resorption [ delayed resorption] Retrievability is difficult
  • 58. Heat sources during obturation with gutta percha: Touch N Heat Endotec II System B
  • 59. Elements Obturation Unit The SybronEndo Elements Obturation Unit (EOU) is a thermoplastic gutta percha/RealSeal injector with backfill, down-pack, cautery and hot-pulp testing capability
