1. Next-gen Mobile GPUs and Rendering Techniques
Game Connection, October 29-31, 2014
Niklas Smedberg
Senior Engine Programmer, Epic Games

2. Game Connection, October 29-31, 2014
Introduction
• Niklas Smedberg, a.k.a. “Smedis”
– 17 years in the game industry
– Graphics programmer since the C64 demo scene

3. Game Connection, October 29-31, 2014
Content
• Next-gen Hardware
– Tile-based GPU vs direct-rendering GPU
• Next-gen Rendering Techniques
– Unreal Engine 4
– Previous goal: Bringing AAA Console graphics to mobile (DONE!)
– New goal: Bringing AAA PC graphics to mobile (DONE!??)

4. Next Generation Mobile Hardware
Game Connection, October 29-31, 2014
• Big leap in features and performance
• Full-featured (e.g. OpenGL ES 3.1+AEP, DirectX 10/11)
• Peak performance now comparable to consoles (Xbox 360/PS3)
– About 300+ GFLOPS and 26 GB/s
• New goal: Bring AAA PC graphics to mobile

5. Performance Trends (FP16 GFLOPS)
Game Connection, October 29-31, 2014
6.4 12.8
25.5
154
300+
350
300
250
200
150
100
50
0
2010 2011 2012 2013 2014
2010 SGX 535
2011 SGX 543MP2
2012 SGX 543MP3
2013 G6430
2014 Adreno, K1, GX6650

6. Game Connection, October 29-31, 2014
iOS 8 Metal
• New rendering API for iOS
• Better match for the hardware
– Like a “game console API”
– Much more efficient on the CPU
– Exposes hardware features
• 20x faster on our rendering thread
– OpenGL ES API: 30% of renderthread
– Metal API: 1.6% of renderthread
• All power and perf responsibility is now in the hands of the developer!

7. Tech Demo: Zen Garden
Game Connection, October 29-31, 2014

8. Game Connection, October 29-31, 2014
Tile-based Mobile GPU
• Mobile GPUs are usually tile-based (next-gen too)
– Tile-based: ImgTec, Qualcomm*, ARM
– Direct: NVIDIA, Intel, Vivante
* Qualcomm Adreno can render either tile-based or direct to frame buffer
– Extension: GL_QCOM_binning_control

9. Game Connection, October 29-31, 2014
Tile-Based Mobile GPU
Summary:
• Split the screen into tiles
– E.g. 32x32 pixels (ImgTec) or 300x300 (Qualcomm)
• The whole tile fits within GPU, on chip
• Process all drawcalls for one tile
– Write out final tile results to RAM
• Repeat for each tile to fill the image in RAM

10. ImgTec Tile-based Rendering Process
Game Vertex Processing Tile Data (RAM)
Game Connection, October 29-31, 2014
Pixel Processing (Top-most
only)
Frame Buffer (RAM)
Cmd Buffer (RAM)
Hidden Surface
Removal
Tile
Memory
Per Tile:

11. Game Connection, October 29-31, 2014
ImgTec Series 6 G6430
• One GPU core
• Four shader units (USC)
– 16-way scalar
• FP16: Two SOP per clock
– (a*b + c*d)
• FP32: Two MADD per clock
– (a*b + c)
• 154 GFLOPS @ 400 MHz
– 16-bit floating point

12. Game Connection, October 29-31, 2014
FP16 Is Faster Than FP32
• ImgTec Series 6: 50% faster
– FP16 pipeline: Two SOP per clock
– FP32 pipeline: Two MADD per clock
• ImgTec Series 6XT: 100% faster
– FP16 pipeline: Four MADD per clock
– FP32 pipeline: Two MADD per clock
• Qualcomm Snapdragon: 100% faster

13. Game Connection, October 29-31, 2014
ImgTec Rendering Tips
• Hidden Surface Removal
– For opaque only
– Don’t keep alpha-test enabled all the time
– Don’t keep “discard” keyword in shader source, even if it’s not used
• Group opaque drawcalls together
• Sort on state, not distance

14. Game Connection, October 29-31, 2014
Framebuffer Resolve/Restore
• Expensive to switch Frame Buffer Object on Tile-based GPUs
– Saves the current FBO to RAM
– Reloads the new FBO from RAM
• Best performance:
– A single rendertarget for the entire frame
– No post-processing passes
• Does not apply to NVIDIA Tegra GPUs!
– This made it simpler for us to make our “Rivalry” tech demo for K1

15. Game Connection, October 29-31, 2014
Framebuffer Resolve/Restore
• Clear ALL FBO attachments after new frame/rendertarget
– Clear after eglSwapBuffers / glBindFramebuffer
– Avoids reloading FBO from RAM
– NOTE: Do NOT clear unnecessary on non-tile-based GPUs (e.g. NVIDIA)
• Discard unused attachments before new frame/rendertarget
– Discard before eglSwapBuffers / glBindFramebuffer
– Avoids saving unused FBO attachments to RAM
– glDiscardFramebufferEXT / glInvalidateFramebuffer

16. Game Connection, October 29-31, 2014
iOS Performance Profiling
• Screenshot from Xcode, which shows:
– How we clear FBO at the beginning of every render pass
– Other important performance info

17. Game Connection, October 29-31, 2014
Programmable Blending
• GL_EXT_shader_framebuffer_fetch (gl_LastFragData)
• Reads current pixel background “for free”
• Potential uses:
– Custom color blending
– Blend by background depth value (depth in alpha)
• E.g. Soft intersection against world geometry for particles
– Tone-mapping within tile-memory
– Deferred shading without resolving G-buffer
• Stay on GPU and avoid expensive round-trip to RAM
• See also: GL_EXT_shader_pixel_local_storage

18. Soul: Programmable Blending
Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143

19. Core Optimization: Opaque Draw Ordering
Game Connection, October 29-31, 2014
• All platforms,
1. Group draws by material (shader) to reduce state changes
• Then for all platforms except ImgTec,
2. Skybox last: 5 ms/frame savings (vs drawing skybox first)
3. Sort groups nearest first : extra 3 ms/frame savings
4. Sort inside groups nearest first : extra 7 ms/frame savings
• (Timings from a UE4 map on a Qualcomm-based device)

20. Game Connection, October 29-31, 2014
Optimization: Resolution
• Resolution does not match GPU performance!
• Use custom resolution to match perf/pixel
• Examples of same GPU:
– iPhone 5S = 0.7 Mpix (1136x640)
– iPad Air = 3.1 Mpix (2048x1536), more than 4 times slower!
• Other examples:
– Prev-Gen Console = 0.9 Mpix (1280x720)
– Current-Gen Console = 2.1 Mpix (1920x1080)

21. Single Content, Multiple Platforms
Game Connection, October 29-31, 2014
• Core motivating factor in designing UE4
– Authoring consistency between PC and Mobile
• Authoring environment for both platforms
– Physically-based shading model
– High dynamic range linear color space
– High quality post processing

22. Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143
Comparison: PC

23. Comparison: Mobile
Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143

24. Game Connection, October 29-31, 2014
Consistency: Material Editor
• One material for many platforms
– Artist authored feature levels to scale shader
perf from PC to mobile
• Using cross compiler tool to retarget
HLSL into GLSL

25. Directional Light + SDF Shadows
Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143

26. Consistency: HDR Directional Lightmaps
Game Connection, October 29-31, 2014
• Two compressed + One uncompressed textures:
1. HDR color with log luma encoding
2. World space 1st order spherical harmonic luma directionality
3. SDF shadow texture
• Optimized for Mobile and PVRTC compression:
– PVRTC (ImgTec) lacks separately compressed encoding for alpha
– PC color: RGB/Luma, LogLuma in Alpha
– Mobile color: RGB/Luma * LogLuma, no Alpha (LogLuma derived with ALU)
– Mobile: A single dynamic directional light as the “sun”

27. Image-Based Lighting
Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143

28. Game Connection, October 29-31, 2014
Image-Based Lighting
• Selects a mip-level in an IBL cubemap based on per-pixel roughness
– Same as PC, filtering same as PC
• PC: FP16
• Mobile: Decode(RGBM)^2
• PC: Blend multiple cubemaps per surface and parallax correction
• Mobile: One infinite-distance cubemap per object

29. 1/2 DOF
Downsample
1/2 DOF Filter
Tonemapping
Game Connection, October 29-31, 2014
Mobile Post Processing Pipeline
FP16 RGB=Color A=Depth
Anti-Aliasing
1/4 DOF Near Dilation
1/4 Lightshaft Filter, Pass 1
1/4 Final Filter Passes and Merge
{Light Shafts, Bloom, Vignette}
Bloom Filter Tree
1/4 Lightshaft Filter, Pass 2
1/4 Smart Reduction
Light Shaft (Sun) Mask
A=Depth to A=CoC+Sun
[conversion done on chip if possible]
1/8
1/16
1/32
1/8
1/16
1/32
1/64

30. Mobile Depth of Field
Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143

31. Packed Circle of Confusion and Sun Intensity
Game Connection, October 29-31, 2014
• Optimization done for Depth of Field and Light Shafts
– Represent sun intensity and circle of confusion (CoC) in one FP16 value
– Saves needing an extra render target
Depth (0 to 65504)
CoC (0 to 1) Sun Intensity (1 to 65504)
0=Max Near Bokeh
0.5=In Focus
1=Max Far Bokeh and No Sun
65504=Max Sun (still at Max Far Bokeh)

32. Vignette + Bloom + Light Shafts
Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143

33. Vignette + Bloom + Light Shafts: Optimized
Game Connection, October 29-31, 2014
• Composited at quarter resolution
– Using pre-multiplied alpha FP16
– Also performs the final filtering passes for bloom and light shafts
• Optimized to minimize rendertarget switches
• 3 effects applied to scene with one full-res TEX fetch
– Applied in the tonemap pass

34. Game Connection, October 29-31, 2014
Mobile Light Shafts
• Filtered at quarter resolution
• Monochromatic with artist controlled tint on final composite
– Bloom and light shaft down-sample pass shared
– RGB = color for bloom, A = light shaft intensity
• Light shaft filter runs in tonemapped space (8-bit/channel)
– Applied in linear (reverse tonemap before tint and composite)
• Filtering done by 3 passes of 8 taps

35. Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143
Mobile Bloom

36. Game Connection, October 29-31, 2014
Mobile Bloom
• Lower quality version to minimize resolves
– Limited effect radius and less passes
• Turns out to be faster and higher-quality
– Standard hierarchical algorithm with some optimizations
– Down-sample from 1:1/4 res first (shared with light shaft)
– Then down-sample in 1:1/2 resolution passes
– Single pass circle-based filter (instead of two-pass Gaussian)
• 15 taps on circle during down-sampling
• 7 taps for both circles during up-sample+merge pass

37. Film Post Tonemapping
Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143

38. Film Post Tonemapping: Mobile Shader
Game Connection, October 29-31, 2014
Film Post
RGBA8 LDR sRGB Output
Quantization Grain
(optional)
Shadow Tint
(optional)
Color Matrix
{Saturation, Channel Mixer}
(optional)
Tint, Tonemap Curve Linear to sRGB
RGBA16F HDR Linear Color
Blend in DOF
(optional) 1/2 DOF
Film Grain Jitter
(optional)
Blend in {Bloom, Vignette, Light Shafts}
(optional)
Film Grain
(optional)
1/4 Pre-multiplied Alpha

39. Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143
Anti-Aliasing

40. Game Connection, October 29-31, 2014
Anti-Aliasing on Mobile
• Using a spatial & temporal anti-aliasing filter
– 2x temporal super-sampling (higher quality surface shading)
– Blending two jittered frames after tonemapping (32 bpp,
perceptual color space)
– Some special logic to remove ghosting/judder (not using
motion re-projection)
• Not currently using MSAA
– Needed super-sampled shading for HDR physically based shading model
Pixel

41. All Techniques Combined
Game DeGvealmopee Cr Cononnefecrteionnc,e O, Mctoabrcehr 295-3219, 20143

42. Game Connection, October 29-31, 2014
Android Extension Pack
• Released with Android “L”
• OpenGL ES 3.1 plus a specific set of extensions
– Compute shaders
– Tessellation
– ASTC
– Detailed spec on www.khronos.org: GL_ANDROID_extension_pack_es31a
• Full UE4 desktop rendering pipeline on Android!
– Deferred rendering with G-buffer
– Physically-based shading
– Image-based lighting
– Solid 30 FPS on NVIDIA K1 mobile GPU

43. Tech Demo: Rivalry
Game Connection, October 29-31, 2014

44. Game Connection, October 29-31, 2014
Unreal Engine 4
Full source code available!
unrealengine.com
Includes all C++, shaders, tools, content
$19/mo
