Maven Basics
Vijay Ramaswamy
Test Architect & Consultant
What you will learn…
 Introduction to Maven
 The POM.xml file
 The standard directory layout
 Maven archetypes
 The dependency mechanism:
 Overview
 Repositories
 The build lifecycle:
 Overview
 Goals and Plugins
 Maven Vs. Ant
2
Pre-requisites
 You will need to be familiar with Java basics and Eclipse
 Familiarity with a build automation tool such as Ant would be useful
3
Reference material
 https://maven.apache.org/guides/
4
Let’s go!
5
Introduction to Maven (~5 mins)
 A tool designed to build and manage any Java based project
 Core capabilities:
 Build automation:
 Automate processes such as compilation, packaging, running tests, etc.
 Dependency management
 Extensible through plugins
 Favors Convention over Configuration
 Widely accepted as a huge step forward from previous generation build
automation tools such as Ant
6
Introduction to Maven (~5 mins)
 Installing Maven:
 Eclipse comes pre-installed with Maven integration out of the box
 If you want to run Maven from the command line, you will need to install it
separately outside of Eclipse:
 Download link: https://maven.apache.org/download.cgi
 Running Maven:
 From the command line: Use the “mvn” command
 From Eclipse: Use the “Run As->Maven build” menu option
 From Jenkins: Using the Maven plugin for Jenkins
 Trivia: The word “Maven” means “accumulator of knowledge” in Yiddish
7
The POM.xml file (~10 mins)
 POM = Project Object Model
 Basic unit of work in Maven
 XML file containing complete configuration details
about the project
 Key elements within a POM.xml file:
 groupId: Unique ID of the company/organization
(E.g.: com.mycompany)
 artifactId: Unique name of the build artifact to be
generated (usually a JAR or WAR file)
 version: Version number for the build artifact to be
generated
 packaging: The package type to be used while
generating the build artifact (JAR/WAR/WAR, etc.)
 All these elements can be specified easily using
the “Overview” tab for your POM file within
Eclipse
 POM files can inherit from each other, so common
configuration details can be collapsed into one
place
8
The POM.xml file (contd.)
 Super POM:
 Maven’s default POM
 All project specific POM’s inherit from the Super POM by default:
 The Super POM provides default configurations that are suitable for most projects
 This helps to keep the project specific POM’s really compact
 Eclipse has an “Effective POM” tab, which combines the Super POM and the project
specific POM into one view for easy reference
 You can also create your own parent POM’s if required
9
The standard directory layout (~5 mins)
 One of the key goals of Maven is to
standardize the structure of Java
projects
 The standard directory layout is a
common layout recommended by
Maven to enable Java developers to
move between Maven projects with
little to no context switching
 Basic structure:
 Root level files:
 POM.xml
 README files, LICENSE files, etc.
 Metadata files such as .gitignore,
.classpath, .project, etc.
 Basic structure (contd.):
 Root level directories:
 “src” -> Directory to store source code
and related artifacts
 “target” -> Directory to store all output
from a build
 Sub-directories:
 “src/main” -> Directory to store
development source code and related
artifacts
 “src/test” -> Directory to store unit
testing source code and related artifacts
 “src/main/java” & “src/test/java” ->
Directories to store Java source code
 “src/main/resources” &
“src/main/resources” -> Directories to
store resources such as configuration
files which are accessed by the source
code
10
Maven archetypes (~5 mins)
 A toolkit for Maven project templating:
 Choose from a list of available templates while creating a new Maven
project
 Helps users get up and running in the shortest time possible:
 Automatically sets up the project as per the defined directory layout
 Automatically generates the POM.xml file
 Automatically sets up default dependencies for the project
 Maven comes with several in-built archetypes for common project
types such as web applications, J2EE applications, etc.
 Eclipse provides a list of available archetypes at the time of creating a
new Maven project
 Try using the “quickstart” archetype as an example
 It is also possible to create our own custom archetypes:
 This is useful for standardizing best practices across an organization
11
The dependency mechanism: Overview (~5 mins)
 One of the key features of
Maven
 Project dependencies are
managed using the POM.xml
file:
 Eclipse provides the
“Dependencies” tab to enable
you to add dependencies to
your POM.xml file easily
 Each dependency should be
assigned a “scope” -> Most
common ones are “compile”
and “test”
12
The dependency mechanism: Overview (contd.)
 Maven builds a complete tree
of dependencies for your
project, and configures
downstream dependencies for
each of your primary
dependencies:
 Eclipse provides the
“Dependency Hierarchy” tab
to help manage the
dependency tree for your
POM.xml file
 Note that the sequence of
dependencies matters while
building the dependency tree
13
The dependency mechanism: Repositories (~10 mins)
 Maven stores all your dependencies in a centralized repository on the
local machine, known as the m2 repository:
 By default, this is available @ “%userprofile%.m2”
 When you add a dependency to your project, Maven automatically
downloads the dependency and stores it in your local m2 repository:
 This explains why it takes a long time when you import or build a project
for the first time – that is Maven downloading everything behind the
scenes
 By default, Maven downloads all dependencies from “Maven Central”,
which is a common repository used by Maven users around the world:
 This is specified within the Super POM
 This can be overridden if required within the project specific POM
 In the same vein, it is also possible to upload/publish any artifacts that
you create into a remote repository such as Maven Central, so that other
developers can leverage your work as a dependency
14
The build lifecycle: Overview (~5 mins)
 Maven is based around the central concept of a build lifecycle:
 A build lifecycle defines the process for building and distributing a particular artifact
 Maven has 3 default lifecycles built-in:
 clean -> Clean up the project
 default -> Deploy the project
 site -> Create the project’s site documentation
 Each lifecycle consists of multiple build “phases”, which represent various stages
within the lifecycle:
 Build phases are executed sequentially in a defined order
 “clean” lifecycle phases:
 pre-clean
 clean (remove all files generated by previous build)
 post-clean
15
The build lifecycle: Overview (contd.)
 “default” lifecycle phases:
 validate (check for errors)
 compile (compile source code)
 test (run unit tests)
 package (generate JAR/WAR)
 verify (run integration tests)
 install (copy JAR/WAR to local repo)
 deploy (upload JAR/WAR to remote repo)
 Use the “mvn <lifecycle-phase>” command to execute a build lifecycle up to
the specified phase:
 mvn install -> execute the default lifecycle until the “install” phase
 mvn clean install -> execute the clean lifecycle followed by the default lifecycle
16
The build lifecycle: Goals and Plugins (~10 mins)
 Each build phase within a lifecycle is made up of one or more “goals”:
 If a build phase has zero goals, it is not executed
 Goals are fine grained tasks that are executed by so-called “plugins”:
 Maven is - at its heart - a plugin execution framework; all work is done by plugins
 Maven has a huge eco-system of plugins which handle various different aspects of the
build process through specific goals
 A plugin can have multiple goals if required
 Maven manages plugins the same way it manages dependencies:
 Plugins are configured within the POM.xml file
 Plugins are downloaded from a specified remote repository and stored in your local m2
repository
 Gotcha: Sometimes, a build phase, plugin and goal may all have the exact same
name!
17
The build lifecycle: Goals and Plugins (contd.)
 Commonly used plugins and goals:
18
Plugin Goal Goal Description Build lifecycle phase
compiler compile Compile dev source code Compile
testCompile Compile test source code compile
surefire test Run unit tests test
jar jar Package dev source code into JAR file package
testJar Package test source code into JAR file package
failsafe integration-test Run integration tests verify
verify Verify integration test results verify
javadoc javadoc Generate Javadoc for dev code Not bound to a phase
test-javadoc Generate Javadoc for test code Not bound to a phase
install install Install the project’s main artifact (JAR/WAR, etc.), its POM, and any
attached artifacts (such as Javadoc) into the local m2 repository
install
deploy deploy Install the project’s main artifact (JAR/WAR, etc.), its POM, and any
attached artifacts (such as Javadoc) into the specified remote repository
deploy
The build lifecycle: Goals and Plugins (contd.)
 Use the “mvn <plugin>:<goal>” command to execute a specific
plugin goal:
 E.g.: mvn compiler:compile, mvn jar:jar, etc.
 A more recommended way to execute a plugin goal is to “bind” it
to any of the pre-defined build lifecycle phases, and then execute
the lifecycle until the desired phase using the “mvn <lifecycle-
phase>” command
 Note that Maven automatically binds most of the basic goals to
various phases of the build lifecycle:
 These default bindings are configured within the Super POM file
 Refer to the table on the previous slide to see some of the default
bindings
 It is also possible to manually bind plugin goals to phases within
your project specific POM file
19
The build lifecycle: Summary
20
Build lifecycle Phase Goal
Plugin
Has many Has many
Executed
by
Maven Vs. Ant (~5 mins)
 Similarities:
 Command line execution
 Eclipse integration
 XML based configuration
 Maven benefits over Ant:
 Maven POM.xml files are usually more compact than Ant build.xml files (because of
the Super POM)
 Better dependency management (network based)
 Standardized directory layout
 Archetypes for templating
21
Maven Vs. Ant (contd.)
 Rough equivalents between Maven and Ant:
 Maven build phase ~ Ant target
 The main difference is that build phases are pre-defined in Maven, whereas Ant targets
need to be manually defined
 Maven goal ~ Ant task
 Maven plugin ~ Ant plugin
 Migration path from Ant to Maven:
 Adopt the standard directory layout
 Identify your dependencies and map them out into your new POM.xml file
 Identify any plugins required and map them out into your new POM.xml file
 If required, use the Ant plugin for Maven to continue using key targets from your
existing Ant build files
22
Other topics of interest
 Maven modules
 Managed dependencies
 Optional dependencies and dependency exclusions
 Build profiles
23
Recap
In this module, you learnt:
 Introduction to Maven
 The POM.xml file
 The standard directory layout
 Maven archetypes
 The dependency mechanism:
 Overview
 Repositories
 The build lifecycle:
 Overview
 Goals and Plugins
 Maven Vs. Ant
24
THANK YOU!
Vijay Ramaswamy
Test Architect & Consultant
25

More Related Content

What's hot

Maven Basics - Explained
Maven Basics - ExplainedMaven Basics - Explained
Maven Basics - Explained
Smita Prasad

Maven ppt
Maven pptMaven ppt
Maven ppt
natashasweety7

Build Automation using Maven
Build Automation using Maven Build Automation using Maven
Build Automation using Maven
Ankit Gubrani

An Introduction to Maven
An Introduction to MavenAn Introduction to Maven
An Introduction to Maven
Vadym Lotar

Apache Maven
Apache MavenApache Maven
Apache Maven
Rahul Tanwani

Introduction to maven
Introduction to mavenIntroduction to maven
Introduction to maven
Manos Georgopoulos

Maven
Maven Maven
Maven
Khan625

Java Builds with Maven and Ant
Java Builds with Maven and AntJava Builds with Maven and Ant
Java Builds with Maven and Ant
David Noble

Apache Maven In 10 Slides
Apache Maven In 10 SlidesApache Maven In 10 Slides
Apache Maven In 10 Slides
Robert Burrell Donkin

Maven tutorial
Maven tutorialMaven tutorial
Maven tutorial
James Cellini

Using Maven 2
Using Maven 2Using Maven 2
Using Maven 2
andyhot

Maven 2 features
Maven 2 featuresMaven 2 features
Maven 2 features
Angel Ruiz

Introduction to Maven
Introduction to MavenIntroduction to Maven
Introduction to Maven
Mindfire Solutions

Hands On with Maven
Hands On with MavenHands On with Maven
Hands On with Maven
Sid Anand

Maven 3 Overview
Maven 3  OverviewMaven 3  Overview
Maven 3 Overview
Mike Ensor

Introduction to Apache Maven
Introduction to Apache MavenIntroduction to Apache Maven
Introduction to Apache Maven
Rajind Ruparathna

Maven 2 Introduction
Maven 2 IntroductionMaven 2 Introduction
Maven 2 Introduction
Valentin Jacquemin

Maven plugins, properties en profiles: Advanced concepts in Maven
Maven plugins, properties en profiles: Advanced concepts in MavenMaven plugins, properties en profiles: Advanced concepts in Maven
Maven plugins, properties en profiles: Advanced concepts in Maven
Geert Pante

Apache maven 2 overview
Apache maven 2 overviewApache maven 2 overview
Apache maven 2 overview
Return on Intelligence

Maven for Dummies
Maven for DummiesMaven for Dummies
Maven for Dummies
Tomer Gabel


What's hot (20)

Maven Basics - Explained
Maven Basics - ExplainedMaven Basics - Explained
Maven Basics - Explained

Maven ppt
Maven pptMaven ppt
Maven ppt

Build Automation using Maven
Build Automation using Maven Build Automation using Maven
Build Automation using Maven

An Introduction to Maven
An Introduction to MavenAn Introduction to Maven
An Introduction to Maven

Apache Maven
Apache MavenApache Maven
Apache Maven

Introduction to maven
Introduction to mavenIntroduction to maven
Introduction to maven

Maven
Maven Maven
Maven

Java Builds with Maven and Ant
Java Builds with Maven and AntJava Builds with Maven and Ant
Java Builds with Maven and Ant

Apache Maven In 10 Slides
Apache Maven In 10 SlidesApache Maven In 10 Slides
Apache Maven In 10 Slides

Maven tutorial
Maven tutorialMaven tutorial
Maven tutorial

Using Maven 2
Using Maven 2Using Maven 2
Using Maven 2

Maven 2 features
Maven 2 featuresMaven 2 features
Maven 2 features

Introduction to Maven
Introduction to MavenIntroduction to Maven
Introduction to Maven

Hands On with Maven
Hands On with MavenHands On with Maven
Hands On with Maven

Maven 3 Overview
Maven 3  OverviewMaven 3  Overview
Maven 3 Overview

Introduction to Apache Maven
Introduction to Apache MavenIntroduction to Apache Maven
Introduction to Apache Maven

Maven 2 Introduction
Maven 2 IntroductionMaven 2 Introduction
Maven 2 Introduction

Maven plugins, properties en profiles: Advanced concepts in Maven
Maven plugins, properties en profiles: Advanced concepts in MavenMaven plugins, properties en profiles: Advanced concepts in Maven
Maven plugins, properties en profiles: Advanced concepts in Maven

Apache maven 2 overview
Apache maven 2 overviewApache maven 2 overview
Apache maven 2 overview

Maven for Dummies
Maven for DummiesMaven for Dummies
Maven for Dummies


Similar to Maven basics

Apache maven, a software project management tool
Apache maven, a software project management toolApache maven, a software project management tool
Apache maven, a software project management tool
Renato Primavera

Maven
MavenMaven
Mavennotes.pdf
Mavennotes.pdfMavennotes.pdf
Mavennotes.pdf
AnkurSingh656748

Jenkins advance topic
Jenkins advance topicJenkins advance topic
Jenkins advance topic
Gourav Varma

Introduction to maven, its configuration, lifecycle and relationship to JS world
Introduction to maven, its configuration, lifecycle and relationship to JS worldIntroduction to maven, its configuration, lifecycle and relationship to JS world
Introduction to maven, its configuration, lifecycle and relationship to JS world
Dmitry Bakaleinik

A-Z_Maven.pdf
A-Z_Maven.pdfA-Z_Maven.pdf
A-Z_Maven.pdf
Mithilesh Singh

Exploring Maven SVN GIT
Exploring Maven SVN GITExploring Maven SVN GIT
Exploring Maven SVN GIT
People Strategists

Maven Introduction
Maven IntroductionMaven Introduction
Maven Introduction
Sandeep Chawla

Maven
MavenMaven
Java, Eclipse, Maven & JSF tutorial
Java, Eclipse, Maven & JSF tutorialJava, Eclipse, Maven & JSF tutorial
Java, Eclipse, Maven & JSF tutorial
Raghavan Mohan

Maven in mulesoft
Maven in mulesoftMaven in mulesoft
Maven in mulesoft
venkata20k

Maven
MavenMaven
Maven
MavenMaven
Testing Java Web Apps With Selenium
Testing Java Web Apps With SeleniumTesting Java Web Apps With Selenium
Testing Java Web Apps With Selenium
Marakana Inc.

(Re)-Introduction to Maven
(Re)-Introduction to Maven(Re)-Introduction to Maven
(Re)-Introduction to Maven
Eric Wyles

Mavenppt
MavenpptMavenppt
Mavenppt
Surekha Achanta

Maven
MavenMaven
Wonderful World of Maven
Wonderful World of MavenWonderful World of Maven
Wonderful World of Maven
Justin J. Moses

Maven: Managing Software Projects for Repeatable Results
Maven: Managing Software Projects for Repeatable ResultsMaven: Managing Software Projects for Repeatable Results
Maven: Managing Software Projects for Repeatable Results
Steve Keener

Manen Ant SVN
Manen Ant SVNManen Ant SVN

Similar to Maven basics (20)

Apache maven, a software project management tool
Apache maven, a software project management toolApache maven, a software project management tool
Apache maven, a software project management tool

Maven
MavenMaven
Maven

Mavennotes.pdf
Mavennotes.pdfMavennotes.pdf
Mavennotes.pdf

Jenkins advance topic
Jenkins advance topicJenkins advance topic
Jenkins advance topic

Introduction to maven, its configuration, lifecycle and relationship to JS world
Introduction to maven, its configuration, lifecycle and relationship to JS worldIntroduction to maven, its configuration, lifecycle and relationship to JS world
Introduction to maven, its configuration, lifecycle and relationship to JS world

A-Z_Maven.pdf
A-Z_Maven.pdfA-Z_Maven.pdf
A-Z_Maven.pdf

Exploring Maven SVN GIT
Exploring Maven SVN GITExploring Maven SVN GIT
Exploring Maven SVN GIT

Maven Introduction
Maven IntroductionMaven Introduction
Maven Introduction

Maven
MavenMaven
Maven

Java, Eclipse, Maven & JSF tutorial
Java, Eclipse, Maven & JSF tutorialJava, Eclipse, Maven & JSF tutorial
Java, Eclipse, Maven & JSF tutorial

Maven in mulesoft
Maven in mulesoftMaven in mulesoft
Maven in mulesoft

Maven
MavenMaven
Maven

Maven
MavenMaven
Maven

Testing Java Web Apps With Selenium
Testing Java Web Apps With SeleniumTesting Java Web Apps With Selenium
Testing Java Web Apps With Selenium

(Re)-Introduction to Maven
(Re)-Introduction to Maven(Re)-Introduction to Maven
(Re)-Introduction to Maven

Mavenppt
MavenpptMavenppt
Mavenppt

Maven
MavenMaven
Maven

Wonderful World of Maven
Wonderful World of MavenWonderful World of Maven
Wonderful World of Maven

Maven: Managing Software Projects for Repeatable Results
Maven: Managing Software Projects for Repeatable ResultsMaven: Managing Software Projects for Repeatable Results
Maven: Managing Software Projects for Repeatable Results

Manen Ant SVN
Manen Ant SVNManen Ant SVN
Manen Ant SVN


Recently uploaded

Comparison Table of DiskWarrior Alternatives.pdf
Comparison Table of DiskWarrior Alternatives.pdfComparison Table of DiskWarrior Alternatives.pdf
Comparison Table of DiskWarrior Alternatives.pdf
Andrey Yasko

Implementations of Fused Deposition Modeling in real world
Implementations of Fused Deposition Modeling  in real worldImplementations of Fused Deposition Modeling  in real world
Implementations of Fused Deposition Modeling in real world
Emerging Tech

BEGINNER’S GUIDE TO AI AGENTS (1).pptx...
BEGINNER’S GUIDE TO AI AGENTS (1).pptx...BEGINNER’S GUIDE TO AI AGENTS (1).pptx...
BEGINNER’S GUIDE TO AI AGENTS (1).pptx...
WriteMe

TrustArc Webinar - 2024 Data Privacy Trends: A Mid-Year Check-In
TrustArc Webinar - 2024 Data Privacy Trends: A Mid-Year Check-InTrustArc Webinar - 2024 Data Privacy Trends: A Mid-Year Check-In
TrustArc Webinar - 2024 Data Privacy Trends: A Mid-Year Check-In
TrustArc

Scaling Connections in PostgreSQL Postgres Bangalore(PGBLR) Meetup-2 - Mydbops
Scaling Connections in PostgreSQL Postgres Bangalore(PGBLR) Meetup-2 - MydbopsScaling Connections in PostgreSQL Postgres Bangalore(PGBLR) Meetup-2 - Mydbops
Scaling Connections in PostgreSQL Postgres Bangalore(PGBLR) Meetup-2 - Mydbops
Mydbops

The Role of Technology in Payroll Statutory Compliance (1).pdf
The Role of Technology in Payroll Statutory Compliance (1).pdfThe Role of Technology in Payroll Statutory Compliance (1).pdf
The Role of Technology in Payroll Statutory Compliance (1).pdf
paysquare consultancy

Fluttercon 2024: Showing that you care about security - OpenSSF Scorecards fo...
Fluttercon 2024: Showing that you care about security - OpenSSF Scorecards fo...Fluttercon 2024: Showing that you care about security - OpenSSF Scorecards fo...
Fluttercon 2024: Showing that you care about security - OpenSSF Scorecards fo...
Chris Swan

BT & Neo4j: Knowledge Graphs for Critical Enterprise Systems.pptx.pdf
BT & Neo4j: Knowledge Graphs for Critical Enterprise Systems.pptx.pdfBT & Neo4j: Knowledge Graphs for Critical Enterprise Systems.pptx.pdf
BT & Neo4j: Knowledge Graphs for Critical Enterprise Systems.pptx.pdf
Neo4j

Best Practices for Effectively Running dbt in Airflow.pdf
Best Practices for Effectively Running dbt in Airflow.pdfBest Practices for Effectively Running dbt in Airflow.pdf
Best Practices for Effectively Running dbt in Airflow.pdf
Tatiana Al-Chueyr

(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
Priyanka Aash

Password Rotation in 2024 is still Relevant
Password Rotation in 2024 is still RelevantPassword Rotation in 2024 is still Relevant
Password Rotation in 2024 is still Relevant
Bert Blevins

Tirana Tech Meetup - Agentic RAG with Milvus, Llama3 and Ollama
Tirana Tech Meetup - Agentic RAG with Milvus, Llama3 and OllamaTirana Tech Meetup - Agentic RAG with Milvus, Llama3 and Ollama
Tirana Tech Meetup - Agentic RAG with Milvus, Llama3 and Ollama
Zilliz

Pigging Solutions Sustainability brochure.pdf
Pigging Solutions Sustainability brochure.pdfPigging Solutions Sustainability brochure.pdf
Pigging Solutions Sustainability brochure.pdf
Pigging Solutions

Gen-AI in Telcos: Strategies, Challenges & Impact
Gen-AI in Telcos: Strategies, Challenges & ImpactGen-AI in Telcos: Strategies, Challenges & Impact
Gen-AI in Telcos: Strategies, Challenges & Impact
aejazahamed4

Data Integration Basics: Merging & Joining Data
Data Integration Basics: Merging & Joining DataData Integration Basics: Merging & Joining Data
Data Integration Basics: Merging & Joining Data
Safe Software

Three New Criminal Laws in India 1 July 2024
Three New Criminal Laws in India 1 July 2024Three New Criminal Laws in India 1 July 2024
Three New Criminal Laws in India 1 July 2024
aakash malhotra

Choose our Linux Web Hosting for a seamless and successful online presence
Choose our Linux Web Hosting for a seamless and successful online presenceChoose our Linux Web Hosting for a seamless and successful online presence
Choose our Linux Web Hosting for a seamless and successful online presence
rajancomputerfbd

How RPA Help in the Transportation and Logistics Industry.pptx
How RPA Help in the Transportation and Logistics Industry.pptxHow RPA Help in the Transportation and Logistics Industry.pptx
How RPA Help in the Transportation and Logistics Industry.pptx
SynapseIndia

Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Muhammad Ali

ARTIFICIAL INTELLIGENCE (AI) IN MUSIC.pdf
ARTIFICIAL INTELLIGENCE (AI) IN MUSIC.pdfARTIFICIAL INTELLIGENCE (AI) IN MUSIC.pdf
ARTIFICIAL INTELLIGENCE (AI) IN MUSIC.pdf
Inglês no Mundo Digital


Recently uploaded (20)

Comparison Table of DiskWarrior Alternatives.pdf
Comparison Table of DiskWarrior Alternatives.pdfComparison Table of DiskWarrior Alternatives.pdf
Comparison Table of DiskWarrior Alternatives.pdf

Implementations of Fused Deposition Modeling in real world
Implementations of Fused Deposition Modeling  in real worldImplementations of Fused Deposition Modeling  in real world
Implementations of Fused Deposition Modeling in real world

BEGINNER’S GUIDE TO AI AGENTS (1).pptx...
BEGINNER’S GUIDE TO AI AGENTS (1).pptx...BEGINNER’S GUIDE TO AI AGENTS (1).pptx...
BEGINNER’S GUIDE TO AI AGENTS (1).pptx...

TrustArc Webinar - 2024 Data Privacy Trends: A Mid-Year Check-In
TrustArc Webinar - 2024 Data Privacy Trends: A Mid-Year Check-InTrustArc Webinar - 2024 Data Privacy Trends: A Mid-Year Check-In
TrustArc Webinar - 2024 Data Privacy Trends: A Mid-Year Check-In

Scaling Connections in PostgreSQL Postgres Bangalore(PGBLR) Meetup-2 - Mydbops
Scaling Connections in PostgreSQL Postgres Bangalore(PGBLR) Meetup-2 - MydbopsScaling Connections in PostgreSQL Postgres Bangalore(PGBLR) Meetup-2 - Mydbops
Scaling Connections in PostgreSQL Postgres Bangalore(PGBLR) Meetup-2 - Mydbops

The Role of Technology in Payroll Statutory Compliance (1).pdf
The Role of Technology in Payroll Statutory Compliance (1).pdfThe Role of Technology in Payroll Statutory Compliance (1).pdf
The Role of Technology in Payroll Statutory Compliance (1).pdf

Fluttercon 2024: Showing that you care about security - OpenSSF Scorecards fo...
Fluttercon 2024: Showing that you care about security - OpenSSF Scorecards fo...Fluttercon 2024: Showing that you care about security - OpenSSF Scorecards fo...
Fluttercon 2024: Showing that you care about security - OpenSSF Scorecards fo...

BT & Neo4j: Knowledge Graphs for Critical Enterprise Systems.pptx.pdf
BT & Neo4j: Knowledge Graphs for Critical Enterprise Systems.pptx.pdfBT & Neo4j: Knowledge Graphs for Critical Enterprise Systems.pptx.pdf
BT & Neo4j: Knowledge Graphs for Critical Enterprise Systems.pptx.pdf

Best Practices for Effectively Running dbt in Airflow.pdf
Best Practices for Effectively Running dbt in Airflow.pdfBest Practices for Effectively Running dbt in Airflow.pdf
Best Practices for Effectively Running dbt in Airflow.pdf

(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...
(CISOPlatform Summit & SACON 2024) Keynote _ Power Digital Identities With AI...

Password Rotation in 2024 is still Relevant
Password Rotation in 2024 is still RelevantPassword Rotation in 2024 is still Relevant
Password Rotation in 2024 is still Relevant

Tirana Tech Meetup - Agentic RAG with Milvus, Llama3 and Ollama
Tirana Tech Meetup - Agentic RAG with Milvus, Llama3 and OllamaTirana Tech Meetup - Agentic RAG with Milvus, Llama3 and Ollama
Tirana Tech Meetup - Agentic RAG with Milvus, Llama3 and Ollama

Pigging Solutions Sustainability brochure.pdf
Pigging Solutions Sustainability brochure.pdfPigging Solutions Sustainability brochure.pdf
Pigging Solutions Sustainability brochure.pdf

Gen-AI in Telcos: Strategies, Challenges & Impact
Gen-AI in Telcos: Strategies, Challenges & ImpactGen-AI in Telcos: Strategies, Challenges & Impact
Gen-AI in Telcos: Strategies, Challenges & Impact

Data Integration Basics: Merging & Joining Data
Data Integration Basics: Merging & Joining DataData Integration Basics: Merging & Joining Data
Data Integration Basics: Merging & Joining Data

Three New Criminal Laws in India 1 July 2024
Three New Criminal Laws in India 1 July 2024Three New Criminal Laws in India 1 July 2024
Three New Criminal Laws in India 1 July 2024

Choose our Linux Web Hosting for a seamless and successful online presence
Choose our Linux Web Hosting for a seamless and successful online presenceChoose our Linux Web Hosting for a seamless and successful online presence
Choose our Linux Web Hosting for a seamless and successful online presence

How RPA Help in the Transportation and Logistics Industry.pptx
How RPA Help in the Transportation and Logistics Industry.pptxHow RPA Help in the Transportation and Logistics Industry.pptx
How RPA Help in the Transportation and Logistics Industry.pptx

Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)
Litestack talk at Brighton 2024 (Unleashing the power of SQLite for Ruby apps)

ARTIFICIAL INTELLIGENCE (AI) IN MUSIC.pdf
ARTIFICIAL INTELLIGENCE (AI) IN MUSIC.pdfARTIFICIAL INTELLIGENCE (AI) IN MUSIC.pdf
ARTIFICIAL INTELLIGENCE (AI) IN MUSIC.pdf


Maven basics

  • 1. Maven Basics Vijay Ramaswamy Test Architect & Consultant
  • 2. What you will learn…  Introduction to Maven  The POM.xml file  The standard directory layout  Maven archetypes  The dependency mechanism:  Overview  Repositories  The build lifecycle:  Overview  Goals and Plugins  Maven Vs. Ant 2
  • 3. Pre-requisites  You will need to be familiar with Java basics and Eclipse  Familiarity with a build automation tool such as Ant would be useful 3
  • 6. Introduction to Maven (~5 mins)  A tool designed to build and manage any Java based project  Core capabilities:  Build automation:  Automate processes such as compilation, packaging, running tests, etc.  Dependency management  Extensible through plugins  Favors Convention over Configuration  Widely accepted as a huge step forward from previous generation build automation tools such as Ant 6
  • 7. Introduction to Maven (~5 mins)  Installing Maven:  Eclipse comes pre-installed with Maven integration out of the box  If you want to run Maven from the command line, you will need to install it separately outside of Eclipse:  Download link: https://maven.apache.org/download.cgi  Running Maven:  From the command line: Use the “mvn” command  From Eclipse: Use the “Run As->Maven build” menu option  From Jenkins: Using the Maven plugin for Jenkins  Trivia: The word “Maven” means “accumulator of knowledge” in Yiddish 7
  • 8. The POM.xml file (~10 mins)  POM = Project Object Model  Basic unit of work in Maven  XML file containing complete configuration details about the project  Key elements within a POM.xml file:  groupId: Unique ID of the company/organization (E.g.: com.mycompany)  artifactId: Unique name of the build artifact to be generated (usually a JAR or WAR file)  version: Version number for the build artifact to be generated  packaging: The package type to be used while generating the build artifact (JAR/WAR/WAR, etc.)  All these elements can be specified easily using the “Overview” tab for your POM file within Eclipse  POM files can inherit from each other, so common configuration details can be collapsed into one place 8
  • 9. The POM.xml file (contd.)  Super POM:  Maven’s default POM  All project specific POM’s inherit from the Super POM by default:  The Super POM provides default configurations that are suitable for most projects  This helps to keep the project specific POM’s really compact  Eclipse has an “Effective POM” tab, which combines the Super POM and the project specific POM into one view for easy reference  You can also create your own parent POM’s if required 9
  • 10. The standard directory layout (~5 mins)  One of the key goals of Maven is to standardize the structure of Java projects  The standard directory layout is a common layout recommended by Maven to enable Java developers to move between Maven projects with little to no context switching  Basic structure:  Root level files:  POM.xml  README files, LICENSE files, etc.  Metadata files such as .gitignore, .classpath, .project, etc.  Basic structure (contd.):  Root level directories:  “src” -> Directory to store source code and related artifacts  “target” -> Directory to store all output from a build  Sub-directories:  “src/main” -> Directory to store development source code and related artifacts  “src/test” -> Directory to store unit testing source code and related artifacts  “src/main/java” & “src/test/java” -> Directories to store Java source code  “src/main/resources” & “src/main/resources” -> Directories to store resources such as configuration files which are accessed by the source code 10
  • 11. Maven archetypes (~5 mins)  A toolkit for Maven project templating:  Choose from a list of available templates while creating a new Maven project  Helps users get up and running in the shortest time possible:  Automatically sets up the project as per the defined directory layout  Automatically generates the POM.xml file  Automatically sets up default dependencies for the project  Maven comes with several in-built archetypes for common project types such as web applications, J2EE applications, etc.  Eclipse provides a list of available archetypes at the time of creating a new Maven project  Try using the “quickstart” archetype as an example  It is also possible to create our own custom archetypes:  This is useful for standardizing best practices across an organization 11
  • 12. The dependency mechanism: Overview (~5 mins)  One of the key features of Maven  Project dependencies are managed using the POM.xml file:  Eclipse provides the “Dependencies” tab to enable you to add dependencies to your POM.xml file easily  Each dependency should be assigned a “scope” -> Most common ones are “compile” and “test” 12
  • 13. The dependency mechanism: Overview (contd.)  Maven builds a complete tree of dependencies for your project, and configures downstream dependencies for each of your primary dependencies:  Eclipse provides the “Dependency Hierarchy” tab to help manage the dependency tree for your POM.xml file  Note that the sequence of dependencies matters while building the dependency tree 13
  • 14. The dependency mechanism: Repositories (~10 mins)  Maven stores all your dependencies in a centralized repository on the local machine, known as the m2 repository:  By default, this is available @ “%userprofile%.m2”  When you add a dependency to your project, Maven automatically downloads the dependency and stores it in your local m2 repository:  This explains why it takes a long time when you import or build a project for the first time – that is Maven downloading everything behind the scenes  By default, Maven downloads all dependencies from “Maven Central”, which is a common repository used by Maven users around the world:  This is specified within the Super POM  This can be overridden if required within the project specific POM  In the same vein, it is also possible to upload/publish any artifacts that you create into a remote repository such as Maven Central, so that other developers can leverage your work as a dependency 14
  • 15. The build lifecycle: Overview (~5 mins)  Maven is based around the central concept of a build lifecycle:  A build lifecycle defines the process for building and distributing a particular artifact  Maven has 3 default lifecycles built-in:  clean -> Clean up the project  default -> Deploy the project  site -> Create the project’s site documentation  Each lifecycle consists of multiple build “phases”, which represent various stages within the lifecycle:  Build phases are executed sequentially in a defined order  “clean” lifecycle phases:  pre-clean  clean (remove all files generated by previous build)  post-clean 15
  • 16. The build lifecycle: Overview (contd.)  “default” lifecycle phases:  validate (check for errors)  compile (compile source code)  test (run unit tests)  package (generate JAR/WAR)  verify (run integration tests)  install (copy JAR/WAR to local repo)  deploy (upload JAR/WAR to remote repo)  Use the “mvn <lifecycle-phase>” command to execute a build lifecycle up to the specified phase:  mvn install -> execute the default lifecycle until the “install” phase  mvn clean install -> execute the clean lifecycle followed by the default lifecycle 16
  • 17. The build lifecycle: Goals and Plugins (~10 mins)  Each build phase within a lifecycle is made up of one or more “goals”:  If a build phase has zero goals, it is not executed  Goals are fine grained tasks that are executed by so-called “plugins”:  Maven is - at its heart - a plugin execution framework; all work is done by plugins  Maven has a huge eco-system of plugins which handle various different aspects of the build process through specific goals  A plugin can have multiple goals if required  Maven manages plugins the same way it manages dependencies:  Plugins are configured within the POM.xml file  Plugins are downloaded from a specified remote repository and stored in your local m2 repository  Gotcha: Sometimes, a build phase, plugin and goal may all have the exact same name! 17
  • 18. The build lifecycle: Goals and Plugins (contd.)  Commonly used plugins and goals: 18 Plugin Goal Goal Description Build lifecycle phase compiler compile Compile dev source code Compile testCompile Compile test source code compile surefire test Run unit tests test jar jar Package dev source code into JAR file package testJar Package test source code into JAR file package failsafe integration-test Run integration tests verify verify Verify integration test results verify javadoc javadoc Generate Javadoc for dev code Not bound to a phase test-javadoc Generate Javadoc for test code Not bound to a phase install install Install the project’s main artifact (JAR/WAR, etc.), its POM, and any attached artifacts (such as Javadoc) into the local m2 repository install deploy deploy Install the project’s main artifact (JAR/WAR, etc.), its POM, and any attached artifacts (such as Javadoc) into the specified remote repository deploy
  • 19. The build lifecycle: Goals and Plugins (contd.)  Use the “mvn <plugin>:<goal>” command to execute a specific plugin goal:  E.g.: mvn compiler:compile, mvn jar:jar, etc.  A more recommended way to execute a plugin goal is to “bind” it to any of the pre-defined build lifecycle phases, and then execute the lifecycle until the desired phase using the “mvn <lifecycle- phase>” command  Note that Maven automatically binds most of the basic goals to various phases of the build lifecycle:  These default bindings are configured within the Super POM file  Refer to the table on the previous slide to see some of the default bindings  It is also possible to manually bind plugin goals to phases within your project specific POM file 19
  • 20. The build lifecycle: Summary 20 Build lifecycle Phase Goal Plugin Has many Has many Executed by
  • 21. Maven Vs. Ant (~5 mins)  Similarities:  Command line execution  Eclipse integration  XML based configuration  Maven benefits over Ant:  Maven POM.xml files are usually more compact than Ant build.xml files (because of the Super POM)  Better dependency management (network based)  Standardized directory layout  Archetypes for templating 21
  • 22. Maven Vs. Ant (contd.)  Rough equivalents between Maven and Ant:  Maven build phase ~ Ant target  The main difference is that build phases are pre-defined in Maven, whereas Ant targets need to be manually defined  Maven goal ~ Ant task  Maven plugin ~ Ant plugin  Migration path from Ant to Maven:  Adopt the standard directory layout  Identify your dependencies and map them out into your new POM.xml file  Identify any plugins required and map them out into your new POM.xml file  If required, use the Ant plugin for Maven to continue using key targets from your existing Ant build files 22
  • 23. Other topics of interest  Maven modules  Managed dependencies  Optional dependencies and dependency exclusions  Build profiles 23
  • 24. Recap In this module, you learnt:  Introduction to Maven  The POM.xml file  The standard directory layout  Maven archetypes  The dependency mechanism:  Overview  Repositories  The build lifecycle:  Overview  Goals and Plugins  Maven Vs. Ant 24
  • 25. THANK YOU! Vijay Ramaswamy Test Architect & Consultant 25
