Copyright © 2016 M/Gateway Developments Ltd
EWD 3 Training Course
Part 4
Installing & Configuring
QEWD
Rob Tweed
Director, M/Gateway Developments Ltd
Twitter: @rtweed
Copyright © 2016 M/Gateway Developments Ltd
QEWD
• Complete EWD 3 run-time back-end
environment for applications:
– Interactive browser-based applications
– Interactive React Native mobile applications
– HTTP Web Services
– REST services
• Built using EWD 3 modules
• Extensible
Copyright © 2016 M/Gateway Developments Ltd
Pre-packaged EWD 3 Platform
• Ideal if you want to build and run applications:
– Interactive browser-based desktop apps
– Mobile apps using React Native
– REST and Web Service back-ends
• with a Node.js back-end
• Particularly if you want to use Caché, Redis or
GT.M
• All the necessary EWD 3 modules have been
integrated for you
– Very simple installation & configuration
Copyright © 2016 M/Gateway Developments Ltd
Getting Started on Windows with Caché
• Pre-requisites
– Windows 7 or later
– Decent modern browser
• Chrome recommended
– Decent text editor
• eg Notepad++
– Caché installed and running
Copyright © 2016 M/Gateway Developments Ltd
Step 1
• Install Node.js
– Go to https://nodejs.org
– Download latest version of Node.js
• LTS version recommended
• Currently 6.9.x
– Invoke the downloaded msi installer file
– Check using Command Prompt windows
• node –v
– Should report v6.9.3
Copyright © 2016 M/Gateway Developments Ltd
Step 2
• Create a directory for all QEWD work:
– eg C:qewd
Copyright © 2016 M/Gateway Developments Ltd
Step 3
• Install QEWD and qewd-monitor:
cd qewd
npm install qewd qewd-monitor
Ignore any warnings
On completion you should find a new directory:
C:qewdnode_modules
Copyright © 2016 M/Gateway Developments Ltd
Step 4
• Get and install the latest cache.node for
Node.js 6.x:
– Move/copy from Downloads directory to:
• C:qewdnode_modules
– Rename to cache.node
https://s3-eu-west-1.amazonaws.com/cache.node/build-124/win64/cache610.node
Copyright © 2016 M/Gateway Developments Ltd
Step 5 (a)
• Set up and configure QEWD
– Copy:
• C:qewdnode_modulesqewdexampleewd-xpress.js
– To:
• C:qewdqewd.js
Copyright © 2016 M/Gateway Developments Ltd
Step 5 (b)
• Edit C:qewdqewd.js
– eg using Notepad++
– Specify your Caché mgr path within the config
object, eg: var config = {
managementPassword: 'keepThisSecret!',
serverName: 'New QEWD Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr'
}
}
};
Copyright © 2016 M/Gateway Developments Ltd
Step 5 (b)
• Edit C:qewdqewd.js
– eg using Notepad++
– Specify your Caché mgr path within the config
object, eg:
Note the double
back-slashes
Note the comma!
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'New QEWD Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr'
}
}
};
Copyright © 2016 M/Gateway Developments Ltd
Step 6
• Set up qewd-monitor
– Create new directories:
• C:qewdwww
• C:qewdwwwqewd-monitor
– Copy all the files in:
• c:qewdnode_modulesqewd-monitorwww
– To:
• c:qewdwwwqewd-monitor
Copyright © 2016 M/Gateway Developments Ltd
Step 7
• Start up QEWD:
– In a Command Prompt window:
cd qewd
node qewd
C:ewd3>node qewd
webServerRootPath = C:qewd/www/
Worker Bootstrap Module file written to node_modules/ewd-qoper8-worker.js
========================================================
ewd-qoper8 is up and running. Max worker pool size: 1
Copyright © 2016 M/Gateway Developments Ltd
Step 8
• In your browser, enter the URL:
– http://127.0.0.1:8080/qewd-monitor/index.html
– When prompted for the management password, enter:
• keepThisSecret!
• QEWD and qewd-monitor should now be fully working!
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup file
• C:qewdqewd.js
– Can be renamed if you wish
• Define a config object
• Invoke the QEWD start() function
– Passing in the config object as an argument
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup config object
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'New QEWD Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr’
}
}};
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'New EWD Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr’
}
}};
var qewd = require('qewd').master;
qewd.start(config);
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup config object
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'New QEWD Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr’
}
}};
The management password that
You enter when you start up
qewd-monitor application
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup config object
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'My EWD App Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr’
}
}};
Used in qewd-monitor
to display the name of this
instance of QEWD
Useful if you have more
than one instance running
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup config object
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'My EWD App Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr’
}
}};
Port on which Express
listens for incoming
requests
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup config object
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'My EWD App Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr’
}
}};
Maximum number
of worker processes
to be started by
QEWD to handle
demand
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup config object
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'New EWD Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr’
}
}};
What database
do you want to
connect to your
worker processes?
- cache
- gtm
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup config object
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'New EWD Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr’
}
}};
If Caché, where is
its mgr directory
located?
Copyright © 2016 M/Gateway Developments Ltd
QEWD startup config object
var config = {
managementPassword: 'keepThisSecret!',
serverName: 'New EWD Server',
port: 8080,
poolSize: 1,
database: {
type: 'cache',
params: {
path: 'c:InterSystemsCache2015-2mgr’
}
}}; Other Caché database params available:
- username (_SYSTEM)
- password (SYS)
- namespace (USER)
Only need to be specified if different
values from defaults required
Copyright © 2016 M/Gateway Developments Ltd
QEWD is ready
• You can now try developing your own
applications
• Can use any JavaScript framework
– Including your own manually created
JavaScript code
Copyright © 2016 M/Gateway Developments Ltd
Installing QEWD on Linux
• The QEWD repository includes an installer
folder
– Contains a set of pre-written installer scripts
– Designed for use with Ubuntu 16.04
• "virgin" system without:
– Node.js or a database (GT.M, Cache or Redis)
• Easily adapted for use with other Linux versions
• Can be used as a starting point for "non-virgin"
systems
Copyright © 2016 M/Gateway Developments Ltd
Using the Installers
• Pre-requisites / assumptions:
– Freshly-installed Ubuntu 16.04 system:
• Physical server
• Virtual Machine
• Cloud image (EC2, Digital Ocean, etc)
– SSH access
– Port 8080 externally accessible
Copyright © 2016 M/Gateway Developments Ltd
Linux Installers:
• QEWD + NVM + Node.js
• Choice of database:
– GT.M (Free, Open Source)
– GlobalsDB (Free, Proprietary, Deprecated)
– Cache (Proprietary/Commercial):
• Use installer file as a guide only
• You must have a valid Cache license
Copyright © 2016 M/Gateway Developments Ltd
Using the Installers
• See instructions at:
– https://github.com/robtweed/qewd/tree/master/installers
Copyright © 2016 M/Gateway Developments Ltd
Installing QEWD on RPi
• QEWD can also be installed and run on a
Raspberry Pi
– Using Redis (ewd-redis-globals)
• A pre-built installer can be found in the
/installers folder
• See instructions at:
– https://github.com/robtweed/qewd/tree/master/installers
Copyright © 2016 M/Gateway Developments Ltd
Docker versions of QEWD
• Pre-built containers in Docker.io:
– rtweed/qewd:
• QEWD for Intel x64 machines
– rtweed/rpi-qewd
• QEWD for Raspberry Pi
• See the separate slide deck on using the
Docker versions of QEWD for more
information

More Related Content

What's hot

introduction to Vue.js 3
introduction to Vue.js 3 introduction to Vue.js 3
introduction to Vue.js 3
ArezooKmn

VueJS Introduction
VueJS IntroductionVueJS Introduction
VueJS Introduction
David Ličen

Vue.js for beginners
Vue.js for beginnersVue.js for beginners
Vue.js for beginners
Julio Bitencourt

Building a redundant CloudStack management cluster - Vladimir Melnik
Building a redundant CloudStack management cluster - Vladimir MelnikBuilding a redundant CloudStack management cluster - Vladimir Melnik
Building a redundant CloudStack management cluster - Vladimir Melnik
ShapeBlue

Intro to vue.js
Intro to vue.jsIntro to vue.js
Intro to vue.js
TechMagic

Introduction to Maven
Introduction to MavenIntroduction to Maven
Introduction to Maven
Onkar Deshpande

Why Vue.js?
Why Vue.js?Why Vue.js?
Why Vue.js?
Jonathan Goode

Tomcat
TomcatTomcat
Introduction to Maven
Introduction to MavenIntroduction to Maven
Introduction to Maven
Mindfire Solutions

Contrail Deep-dive - Cloud Network Services at Scale
Contrail Deep-dive - Cloud Network Services at ScaleContrail Deep-dive - Cloud Network Services at Scale
Contrail Deep-dive - Cloud Network Services at Scale
MarketingArrowECS_CZ

Maven Basics - Explained
Maven Basics - ExplainedMaven Basics - Explained
Maven Basics - Explained
Smita Prasad

[OpenStack 하반기 스터디] Docker를 이용한 OpenStack 가상화
[OpenStack 하반기 스터디] Docker를 이용한 OpenStack 가상화[OpenStack 하반기 스터디] Docker를 이용한 OpenStack 가상화
[OpenStack 하반기 스터디] Docker를 이용한 OpenStack 가상화
OpenStack Korea Community

[오픈소스컨설팅] Open Stack Ceph, Neutron, HA, Multi-Region
[오픈소스컨설팅] Open Stack Ceph, Neutron, HA, Multi-Region[오픈소스컨설팅] Open Stack Ceph, Neutron, HA, Multi-Region
[오픈소스컨설팅] Open Stack Ceph, Neutron, HA, Multi-Region
Ji-Woong Choi

[OpenInfra Days Korea 2018] (Track 4) - Grafana를 이용한 OpenStack 클라우드 성능 모니터링
[OpenInfra Days Korea 2018] (Track 4) - Grafana를 이용한 OpenStack 클라우드 성능 모니터링[OpenInfra Days Korea 2018] (Track 4) - Grafana를 이용한 OpenStack 클라우드 성능 모니터링
[OpenInfra Days Korea 2018] (Track 4) - Grafana를 이용한 OpenStack 클라우드 성능 모니터링
OpenStack Korea Community

Apache maven 2 overview
Apache maven 2 overviewApache maven 2 overview
Apache maven 2 overview
Return on Intelligence

오픈스택 기반 클라우드 서비스 구축 방안 및 사례
오픈스택 기반 클라우드 서비스 구축 방안 및 사례오픈스택 기반 클라우드 서비스 구축 방안 및 사례
오픈스택 기반 클라우드 서비스 구축 방안 및 사례
SONG INSEOB

Introduction To OpenStack
Introduction To OpenStackIntroduction To OpenStack
Introduction To OpenStack
Haim Ateya

Docker Networking Deep Dive
Docker Networking Deep DiveDocker Networking Deep Dive
Docker Networking Deep Dive
Docker, Inc.

Troubleshooting & Debugging Production Microservices in Kubernetes as present...
Troubleshooting & Debugging Production Microservices in Kubernetes as present...Troubleshooting & Debugging Production Microservices in Kubernetes as present...
Troubleshooting & Debugging Production Microservices in Kubernetes as present...
Baruch Sadogursky

Pwning mobile apps without root or jailbreak
Pwning mobile apps without root or jailbreakPwning mobile apps without root or jailbreak
Pwning mobile apps without root or jailbreak
Abraham Aranguren


What's hot (20)

introduction to Vue.js 3
introduction to Vue.js 3 introduction to Vue.js 3
introduction to Vue.js 3

VueJS Introduction
VueJS IntroductionVueJS Introduction
VueJS Introduction

Vue.js for beginners
Vue.js for beginnersVue.js for beginners
Vue.js for beginners

Building a redundant CloudStack management cluster - Vladimir Melnik
Building a redundant CloudStack management cluster - Vladimir MelnikBuilding a redundant CloudStack management cluster - Vladimir Melnik
Building a redundant CloudStack management cluster - Vladimir Melnik

Intro to vue.js
Intro to vue.jsIntro to vue.js
Intro to vue.js

Introduction to Maven
Introduction to MavenIntroduction to Maven
Introduction to Maven

Why Vue.js?
Why Vue.js?Why Vue.js?
Why Vue.js?

Tomcat
TomcatTomcat
Tomcat

Introduction to Maven
Introduction to MavenIntroduction to Maven
Introduction to Maven

Contrail Deep-dive - Cloud Network Services at Scale
Contrail Deep-dive - Cloud Network Services at ScaleContrail Deep-dive - Cloud Network Services at Scale
Contrail Deep-dive - Cloud Network Services at Scale

Maven Basics - Explained
Maven Basics - ExplainedMaven Basics - Explained
Maven Basics - Explained

[OpenStack 하반기 스터디] Docker를 이용한 OpenStack 가상화
[OpenStack 하반기 스터디] Docker를 이용한 OpenStack 가상화[OpenStack 하반기 스터디] Docker를 이용한 OpenStack 가상화
[OpenStack 하반기 스터디] Docker를 이용한 OpenStack 가상화

[오픈소스컨설팅] Open Stack Ceph, Neutron, HA, Multi-Region
[오픈소스컨설팅] Open Stack Ceph, Neutron, HA, Multi-Region[오픈소스컨설팅] Open Stack Ceph, Neutron, HA, Multi-Region
[오픈소스컨설팅] Open Stack Ceph, Neutron, HA, Multi-Region

[OpenInfra Days Korea 2018] (Track 4) - Grafana를 이용한 OpenStack 클라우드 성능 모니터링
[OpenInfra Days Korea 2018] (Track 4) - Grafana를 이용한 OpenStack 클라우드 성능 모니터링[OpenInfra Days Korea 2018] (Track 4) - Grafana를 이용한 OpenStack 클라우드 성능 모니터링
[OpenInfra Days Korea 2018] (Track 4) - Grafana를 이용한 OpenStack 클라우드 성능 모니터링

Apache maven 2 overview
Apache maven 2 overviewApache maven 2 overview
Apache maven 2 overview

오픈스택 기반 클라우드 서비스 구축 방안 및 사례
오픈스택 기반 클라우드 서비스 구축 방안 및 사례오픈스택 기반 클라우드 서비스 구축 방안 및 사례
오픈스택 기반 클라우드 서비스 구축 방안 및 사례

Introduction To OpenStack
Introduction To OpenStackIntroduction To OpenStack
Introduction To OpenStack

Docker Networking Deep Dive
Docker Networking Deep DiveDocker Networking Deep Dive
Docker Networking Deep Dive

Troubleshooting & Debugging Production Microservices in Kubernetes as present...
Troubleshooting & Debugging Production Microservices in Kubernetes as present...Troubleshooting & Debugging Production Microservices in Kubernetes as present...
Troubleshooting & Debugging Production Microservices in Kubernetes as present...

Pwning mobile apps without root or jailbreak
Pwning mobile apps without root or jailbreakPwning mobile apps without root or jailbreak
Pwning mobile apps without root or jailbreak


Viewers also liked

EWD 3 Training Course Part 2: EWD 3 Overview
EWD 3 Training Course Part 2: EWD 3 OverviewEWD 3 Training Course Part 2: EWD 3 Overview
EWD 3 Training Course Part 2: EWD 3 Overview
Rob Tweed

EWD 3 Training Course Part 5a: First Steps in Building a QEWD Application
EWD 3 Training Course Part 5a: First Steps in Building a QEWD ApplicationEWD 3 Training Course Part 5a: First Steps in Building a QEWD Application
EWD 3 Training Course Part 5a: First Steps in Building a QEWD Application
Rob Tweed

EWD 3 Training Course Part 5b: First Steps in Building a QEWD Application
EWD 3 Training Course Part 5b: First Steps in Building a QEWD ApplicationEWD 3 Training Course Part 5b: First Steps in Building a QEWD Application
EWD 3 Training Course Part 5b: First Steps in Building a QEWD Application
Rob Tweed

EWD 3 Training Course Part 6: What Happens when a QEWD Application is Started
EWD 3 Training Course Part 6: What Happens when a QEWD Application is StartedEWD 3 Training Course Part 6: What Happens when a QEWD Application is Started
EWD 3 Training Course Part 6: What Happens when a QEWD Application is Started
Rob Tweed

EWD 3 Training Course Part 7: Applying the QEWD Messaging Pattern
EWD 3 Training Course Part 7: Applying the QEWD Messaging PatternEWD 3 Training Course Part 7: Applying the QEWD Messaging Pattern
EWD 3 Training Course Part 7: Applying the QEWD Messaging Pattern
Rob Tweed

EWD 3 Training Course Part 3: Summary of EWD 3 Modules
EWD 3 Training Course Part 3: Summary of EWD 3 ModulesEWD 3 Training Course Part 3: Summary of EWD 3 Modules
EWD 3 Training Course Part 3: Summary of EWD 3 Modules
Rob Tweed

EWD 3 Training Course Part 10: QEWD Sessions and User Authentication
EWD 3 Training Course Part 10: QEWD Sessions and User AuthenticationEWD 3 Training Course Part 10: QEWD Sessions and User Authentication
EWD 3 Training Course Part 10: QEWD Sessions and User Authentication
Rob Tweed

EWD 3 Training Course Part 13: Putting Everything so far into Practice using ...
EWD 3 Training Course Part 13: Putting Everything so far into Practice using ...EWD 3 Training Course Part 13: Putting Everything so far into Practice using ...
EWD 3 Training Course Part 13: Putting Everything so far into Practice using ...
Rob Tweed

EWD 3 Training Course Part 37: Building a React.js application with ewd-xpres...
EWD 3 Training Course Part 37: Building a React.js application with ewd-xpres...EWD 3 Training Course Part 37: Building a React.js application with ewd-xpres...
EWD 3 Training Course Part 37: Building a React.js application with ewd-xpres...
Rob Tweed

EWD 3 Training Course Part 19: The cache.node APIs
EWD 3 Training Course Part 19: The cache.node APIsEWD 3 Training Course Part 19: The cache.node APIs
EWD 3 Training Course Part 19: The cache.node APIs
Rob Tweed

EWD 3 Training Course Part 41: Building a React.js application with QEWD, Part 5
EWD 3 Training Course Part 41: Building a React.js application with QEWD, Part 5EWD 3 Training Course Part 41: Building a React.js application with QEWD, Part 5
EWD 3 Training Course Part 41: Building a React.js application with QEWD, Part 5
Rob Tweed

EWD 3 Training Course Part 11: Handling Errors in QEWD
EWD 3 Training Course Part 11: Handling Errors in QEWDEWD 3 Training Course Part 11: Handling Errors in QEWD
EWD 3 Training Course Part 11: Handling Errors in QEWD
Rob Tweed

EWD 3 Training Course Part 20: The DocumentNode Object
EWD 3 Training Course Part 20: The DocumentNode ObjectEWD 3 Training Course Part 20: The DocumentNode Object
EWD 3 Training Course Part 20: The DocumentNode Object
Rob Tweed

EWD 3 Training Course Part 36: Accessing REST and Web Services from a QEWD ap...
EWD 3 Training Course Part 36: Accessing REST and Web Services from a QEWD ap...EWD 3 Training Course Part 36: Accessing REST and Web Services from a QEWD ap...
EWD 3 Training Course Part 36: Accessing REST and Web Services from a QEWD ap...
Rob Tweed

EWD 3トレーニングコース#9 複雑なewd-xpressメッセージと応答
EWD 3トレーニングコース#9 複雑なewd-xpressメッセージと応答EWD 3トレーニングコース#9 複雑なewd-xpressメッセージと応答
EWD 3トレーニングコース#9 複雑なewd-xpressメッセージと応答
Kiyoshi Sawada

EWD 3トレーニング・コース #3 EWD 3 モジュールの概要
EWD 3トレーニング・コース #3 EWD 3 モジュールの概要EWD 3トレーニング・コース #3 EWD 3 モジュールの概要
EWD 3トレーニング・コース #3 EWD 3 モジュールの概要
Kiyoshi Sawada

EWD 3トレーニング・コース #4 ewd-xpressのインストールと構成
EWD 3トレーニング・コース #4 ewd-xpressのインストールと構成EWD 3トレーニング・コース #4 ewd-xpressのインストールと構成
EWD 3トレーニング・コース #4 ewd-xpressのインストールと構成
Kiyoshi Sawada

EWD 3トレーニング・コース #2 EWD 3 の概要
EWD 3トレーニング・コース #2 EWD 3 の概要EWD 3トレーニング・コース #2 EWD 3 の概要
EWD 3トレーニング・コース #2 EWD 3 の概要
Kiyoshi Sawada

EWD 3 トレーニング・コース #1 Node.jsとGT.Mの統合方法
EWD 3トレーニング・コース #1 Node.jsとGT.Mの統合方法EWD 3トレーニング・コース #1 Node.jsとGT.Mの統合方法
EWD 3 トレーニング・コース #1 Node.jsとGT.Mの統合方法
Kiyoshi Sawada

EWD 3 Training Course Part 12: QEWD Session Timeout Control
EWD 3 Training Course Part 12: QEWD Session Timeout ControlEWD 3 Training Course Part 12: QEWD Session Timeout Control
EWD 3 Training Course Part 12: QEWD Session Timeout Control
Rob Tweed


Viewers also liked (20)

EWD 3 Training Course Part 2: EWD 3 Overview
EWD 3 Training Course Part 2: EWD 3 OverviewEWD 3 Training Course Part 2: EWD 3 Overview
EWD 3 Training Course Part 2: EWD 3 Overview

EWD 3 Training Course Part 5a: First Steps in Building a QEWD Application
EWD 3 Training Course Part 5a: First Steps in Building a QEWD ApplicationEWD 3 Training Course Part 5a: First Steps in Building a QEWD Application
EWD 3 Training Course Part 5a: First Steps in Building a QEWD Application

EWD 3 Training Course Part 5b: First Steps in Building a QEWD Application
EWD 3 Training Course Part 5b: First Steps in Building a QEWD ApplicationEWD 3 Training Course Part 5b: First Steps in Building a QEWD Application
EWD 3 Training Course Part 5b: First Steps in Building a QEWD Application

EWD 3 Training Course Part 6: What Happens when a QEWD Application is Started
EWD 3 Training Course Part 6: What Happens when a QEWD Application is StartedEWD 3 Training Course Part 6: What Happens when a QEWD Application is Started
EWD 3 Training Course Part 6: What Happens when a QEWD Application is Started

EWD 3 Training Course Part 7: Applying the QEWD Messaging Pattern
EWD 3 Training Course Part 7: Applying the QEWD Messaging PatternEWD 3 Training Course Part 7: Applying the QEWD Messaging Pattern
EWD 3 Training Course Part 7: Applying the QEWD Messaging Pattern

EWD 3 Training Course Part 3: Summary of EWD 3 Modules
EWD 3 Training Course Part 3: Summary of EWD 3 ModulesEWD 3 Training Course Part 3: Summary of EWD 3 Modules
EWD 3 Training Course Part 3: Summary of EWD 3 Modules

EWD 3 Training Course Part 10: QEWD Sessions and User Authentication
EWD 3 Training Course Part 10: QEWD Sessions and User AuthenticationEWD 3 Training Course Part 10: QEWD Sessions and User Authentication
EWD 3 Training Course Part 10: QEWD Sessions and User Authentication

EWD 3 Training Course Part 13: Putting Everything so far into Practice using ...
EWD 3 Training Course Part 13: Putting Everything so far into Practice using ...EWD 3 Training Course Part 13: Putting Everything so far into Practice using ...
EWD 3 Training Course Part 13: Putting Everything so far into Practice using ...

EWD 3 Training Course Part 37: Building a React.js application with ewd-xpres...
EWD 3 Training Course Part 37: Building a React.js application with ewd-xpres...EWD 3 Training Course Part 37: Building a React.js application with ewd-xpres...
EWD 3 Training Course Part 37: Building a React.js application with ewd-xpres...

EWD 3 Training Course Part 19: The cache.node APIs
EWD 3 Training Course Part 19: The cache.node APIsEWD 3 Training Course Part 19: The cache.node APIs
EWD 3 Training Course Part 19: The cache.node APIs

EWD 3 Training Course Part 41: Building a React.js application with QEWD, Part 5
EWD 3 Training Course Part 41: Building a React.js application with QEWD, Part 5EWD 3 Training Course Part 41: Building a React.js application with QEWD, Part 5
EWD 3 Training Course Part 41: Building a React.js application with QEWD, Part 5

EWD 3 Training Course Part 11: Handling Errors in QEWD
EWD 3 Training Course Part 11: Handling Errors in QEWDEWD 3 Training Course Part 11: Handling Errors in QEWD
EWD 3 Training Course Part 11: Handling Errors in QEWD

EWD 3 Training Course Part 20: The DocumentNode Object
EWD 3 Training Course Part 20: The DocumentNode ObjectEWD 3 Training Course Part 20: The DocumentNode Object
EWD 3 Training Course Part 20: The DocumentNode Object

EWD 3 Training Course Part 36: Accessing REST and Web Services from a QEWD ap...
EWD 3 Training Course Part 36: Accessing REST and Web Services from a QEWD ap...EWD 3 Training Course Part 36: Accessing REST and Web Services from a QEWD ap...
EWD 3 Training Course Part 36: Accessing REST and Web Services from a QEWD ap...

EWD 3トレーニングコース#9 複雑なewd-xpressメッセージと応答
EWD 3トレーニングコース#9 複雑なewd-xpressメッセージと応答EWD 3トレーニングコース#9 複雑なewd-xpressメッセージと応答
EWD 3トレーニングコース#9 複雑なewd-xpressメッセージと応答

EWD 3トレーニング・コース #3 EWD 3 モジュールの概要
EWD 3トレーニング・コース #3 EWD 3 モジュールの概要EWD 3トレーニング・コース #3 EWD 3 モジュールの概要
EWD 3トレーニング・コース #3 EWD 3 モジュールの概要

EWD 3トレーニング・コース #4 ewd-xpressのインストールと構成
EWD 3トレーニング・コース #4 ewd-xpressのインストールと構成EWD 3トレーニング・コース #4 ewd-xpressのインストールと構成
EWD 3トレーニング・コース #4 ewd-xpressのインストールと構成

EWD 3トレーニング・コース #2 EWD 3 の概要
EWD 3トレーニング・コース #2 EWD 3 の概要EWD 3トレーニング・コース #2 EWD 3 の概要
EWD 3トレーニング・コース #2 EWD 3 の概要

EWD 3 トレーニング・コース #1 Node.jsとGT.Mの統合方法
EWD 3トレーニング・コース #1 Node.jsとGT.Mの統合方法EWD 3トレーニング・コース #1 Node.jsとGT.Mの統合方法
EWD 3 トレーニング・コース #1 Node.jsとGT.Mの統合方法

EWD 3 Training Course Part 12: QEWD Session Timeout Control
EWD 3 Training Course Part 12: QEWD Session Timeout ControlEWD 3 Training Course Part 12: QEWD Session Timeout Control
EWD 3 Training Course Part 12: QEWD Session Timeout Control


Similar to EWD 3 Training Course Part 4: Installing & Configuring QEWD

qewd-ripple: The Ripple OSI Middle Tier
qewd-ripple: The Ripple OSI Middle Tierqewd-ripple: The Ripple OSI Middle Tier
qewd-ripple: The Ripple OSI Middle Tier
Rob Tweed

EWD 3 Training Course Part 34: QEWD Resilient Mode
EWD 3 Training Course Part 34: QEWD Resilient ModeEWD 3 Training Course Part 34: QEWD Resilient Mode
EWD 3 Training Course Part 34: QEWD Resilient Mode
Rob Tweed

EWD 3 Training Course Part 30: Modularising QEWD Applications
EWD 3 Training Course Part 30: Modularising QEWD ApplicationsEWD 3 Training Course Part 30: Modularising QEWD Applications
EWD 3 Training Course Part 30: Modularising QEWD Applications
Rob Tweed

EWD 3 Training Course Part 31: Using QEWD for Web and REST Services
EWD 3 Training Course Part 31: Using QEWD for Web and REST ServicesEWD 3 Training Course Part 31: Using QEWD for Web and REST Services
EWD 3 Training Course Part 31: Using QEWD for Web and REST Services
Rob Tweed

Deploying windows containers with kubernetes
Deploying windows containers with kubernetesDeploying windows containers with kubernetes
Deploying windows containers with kubernetes
Ben Hall

ewd-qoper8-vistarpc: Exposing VistA's RPCs as REST Services
ewd-qoper8-vistarpc: Exposing VistA's RPCs as REST Servicesewd-qoper8-vistarpc: Exposing VistA's RPCs as REST Services
ewd-qoper8-vistarpc: Exposing VistA's RPCs as REST Services
Rob Tweed

Deploying Windows Containers on Windows Server 2016
Deploying Windows Containers on Windows Server 2016Deploying Windows Containers on Windows Server 2016
Deploying Windows Containers on Windows Server 2016
Ben Hall

EWD 3 Training Course Part 8: Anatomy of the QEWD Messaging Cycle
EWD 3 Training Course Part 8: Anatomy of the QEWD Messaging CycleEWD 3 Training Course Part 8: Anatomy of the QEWD Messaging Cycle
EWD 3 Training Course Part 8: Anatomy of the QEWD Messaging Cycle
Rob Tweed

18CSC311J WEB DESIGN AND DEVELOPMENT UNIT-4
18CSC311J WEB DESIGN AND DEVELOPMENT UNIT-418CSC311J WEB DESIGN AND DEVELOPMENT UNIT-4
18CSC311J WEB DESIGN AND DEVELOPMENT UNIT-4
sivakumarmcs

betterCode Workshop: Effizientes DevOps-Tooling mit Go
betterCode Workshop:  Effizientes DevOps-Tooling mit GobetterCode Workshop:  Effizientes DevOps-Tooling mit Go
betterCode Workshop: Effizientes DevOps-Tooling mit Go
QAware GmbH

Introduction of webpack 4
Introduction of webpack 4Introduction of webpack 4
Introduction of webpack 4
Vijay Shukla

[Devconf.cz][2017] Understanding OpenShift Security Context Constraints
[Devconf.cz][2017] Understanding OpenShift Security Context Constraints[Devconf.cz][2017] Understanding OpenShift Security Context Constraints
[Devconf.cz][2017] Understanding OpenShift Security Context Constraints
Alessandro Arrichiello

WebSphere and Docker
WebSphere and DockerWebSphere and Docker
WebSphere and Docker
David Currie

Introduction to node js - From "hello world" to deploying on azure
Introduction to node js - From "hello world" to deploying on azureIntroduction to node js - From "hello world" to deploying on azure
Introduction to node js - From "hello world" to deploying on azure
Colin Mackay

Linux advanced concepts - Part 2
Linux advanced concepts - Part 2Linux advanced concepts - Part 2
Linux advanced concepts - Part 2
NAILBITER

Nicolas Vazquez - Open vSwitch with DPDK on CloudStack
Nicolas Vazquez - Open vSwitch with DPDK on CloudStackNicolas Vazquez - Open vSwitch with DPDK on CloudStack
Nicolas Vazquez - Open vSwitch with DPDK on CloudStack
ShapeBlue

App development with quasar (pdf)
App development with quasar (pdf)App development with quasar (pdf)
App development with quasar (pdf)
wonyong hwang

EWD 3 Training Course Part 17: Introduction to Global Storage Databases
EWD 3 Training Course Part 17: Introduction to Global Storage DatabasesEWD 3 Training Course Part 17: Introduction to Global Storage Databases
EWD 3 Training Course Part 17: Introduction to Global Storage Databases
Rob Tweed

OpenStack Summit 2013 Hong Kong - OpenStack and Windows
OpenStack Summit 2013 Hong Kong - OpenStack and WindowsOpenStack Summit 2013 Hong Kong - OpenStack and Windows
OpenStack Summit 2013 Hong Kong - OpenStack and Windows
Alessandro Pilotti

Orchestration Tool Roundup - Arthur Berezin & Trammell Scruggs
Orchestration Tool Roundup - Arthur Berezin & Trammell ScruggsOrchestration Tool Roundup - Arthur Berezin & Trammell Scruggs
Orchestration Tool Roundup - Arthur Berezin & Trammell Scruggs
Cloud Native Day Tel Aviv


Similar to EWD 3 Training Course Part 4: Installing & Configuring QEWD (20)

qewd-ripple: The Ripple OSI Middle Tier
qewd-ripple: The Ripple OSI Middle Tierqewd-ripple: The Ripple OSI Middle Tier
qewd-ripple: The Ripple OSI Middle Tier

EWD 3 Training Course Part 34: QEWD Resilient Mode
EWD 3 Training Course Part 34: QEWD Resilient ModeEWD 3 Training Course Part 34: QEWD Resilient Mode
EWD 3 Training Course Part 34: QEWD Resilient Mode

EWD 3 Training Course Part 30: Modularising QEWD Applications
EWD 3 Training Course Part 30: Modularising QEWD ApplicationsEWD 3 Training Course Part 30: Modularising QEWD Applications
EWD 3 Training Course Part 30: Modularising QEWD Applications

EWD 3 Training Course Part 31: Using QEWD for Web and REST Services
EWD 3 Training Course Part 31: Using QEWD for Web and REST ServicesEWD 3 Training Course Part 31: Using QEWD for Web and REST Services
EWD 3 Training Course Part 31: Using QEWD for Web and REST Services

Deploying windows containers with kubernetes
Deploying windows containers with kubernetesDeploying windows containers with kubernetes
Deploying windows containers with kubernetes

ewd-qoper8-vistarpc: Exposing VistA's RPCs as REST Services
ewd-qoper8-vistarpc: Exposing VistA's RPCs as REST Servicesewd-qoper8-vistarpc: Exposing VistA's RPCs as REST Services
ewd-qoper8-vistarpc: Exposing VistA's RPCs as REST Services

Deploying Windows Containers on Windows Server 2016
Deploying Windows Containers on Windows Server 2016Deploying Windows Containers on Windows Server 2016
Deploying Windows Containers on Windows Server 2016

EWD 3 Training Course Part 8: Anatomy of the QEWD Messaging Cycle
EWD 3 Training Course Part 8: Anatomy of the QEWD Messaging CycleEWD 3 Training Course Part 8: Anatomy of the QEWD Messaging Cycle
EWD 3 Training Course Part 8: Anatomy of the QEWD Messaging Cycle

18CSC311J WEB DESIGN AND DEVELOPMENT UNIT-4
18CSC311J WEB DESIGN AND DEVELOPMENT UNIT-418CSC311J WEB DESIGN AND DEVELOPMENT UNIT-4
18CSC311J WEB DESIGN AND DEVELOPMENT UNIT-4

betterCode Workshop: Effizientes DevOps-Tooling mit Go
betterCode Workshop:  Effizientes DevOps-Tooling mit GobetterCode Workshop:  Effizientes DevOps-Tooling mit Go
betterCode Workshop: Effizientes DevOps-Tooling mit Go

Introduction of webpack 4
Introduction of webpack 4Introduction of webpack 4
Introduction of webpack 4

[Devconf.cz][2017] Understanding OpenShift Security Context Constraints
[Devconf.cz][2017] Understanding OpenShift Security Context Constraints[Devconf.cz][2017] Understanding OpenShift Security Context Constraints
[Devconf.cz][2017] Understanding OpenShift Security Context Constraints

WebSphere and Docker
WebSphere and DockerWebSphere and Docker
WebSphere and Docker

Introduction to node js - From "hello world" to deploying on azure
Introduction to node js - From "hello world" to deploying on azureIntroduction to node js - From "hello world" to deploying on azure
Introduction to node js - From "hello world" to deploying on azure

Linux advanced concepts - Part 2
Linux advanced concepts - Part 2Linux advanced concepts - Part 2
Linux advanced concepts - Part 2

Nicolas Vazquez - Open vSwitch with DPDK on CloudStack
Nicolas Vazquez - Open vSwitch with DPDK on CloudStackNicolas Vazquez - Open vSwitch with DPDK on CloudStack
Nicolas Vazquez - Open vSwitch with DPDK on CloudStack

App development with quasar (pdf)
App development with quasar (pdf)App development with quasar (pdf)
App development with quasar (pdf)

EWD 3 Training Course Part 17: Introduction to Global Storage Databases
EWD 3 Training Course Part 17: Introduction to Global Storage DatabasesEWD 3 Training Course Part 17: Introduction to Global Storage Databases
EWD 3 Training Course Part 17: Introduction to Global Storage Databases

OpenStack Summit 2013 Hong Kong - OpenStack and Windows
OpenStack Summit 2013 Hong Kong - OpenStack and WindowsOpenStack Summit 2013 Hong Kong - OpenStack and Windows
OpenStack Summit 2013 Hong Kong - OpenStack and Windows

Orchestration Tool Roundup - Arthur Berezin & Trammell Scruggs
Orchestration Tool Roundup - Arthur Berezin & Trammell ScruggsOrchestration Tool Roundup - Arthur Berezin & Trammell Scruggs
Orchestration Tool Roundup - Arthur Berezin & Trammell Scruggs


More from Rob Tweed

QEWD Update
QEWD UpdateQEWD Update
QEWD Update
Rob Tweed

Data Persistence as a Language Feature
Data Persistence as a Language FeatureData Persistence as a Language Feature
Data Persistence as a Language Feature
Rob Tweed

LNUG: Having Your Node.js Cake and Eating It Too
LNUG: Having Your Node.js Cake and Eating It TooLNUG: Having Your Node.js Cake and Eating It Too
LNUG: Having Your Node.js Cake and Eating It Too
Rob Tweed

EWD 3 Training Course Part 45: Using QEWD's Advanced MicroService Functionality
EWD 3 Training Course Part 45: Using QEWD's Advanced MicroService FunctionalityEWD 3 Training Course Part 45: Using QEWD's Advanced MicroService Functionality
EWD 3 Training Course Part 45: Using QEWD's Advanced MicroService Functionality
Rob Tweed

EWD 3 Training Course Part 43: Using JSON Web Tokens with QEWD REST Services
EWD 3 Training Course Part 43: Using JSON Web Tokens with QEWD REST ServicesEWD 3 Training Course Part 43: Using JSON Web Tokens with QEWD REST Services
EWD 3 Training Course Part 43: Using JSON Web Tokens with QEWD REST Services
Rob Tweed

QEWD.js, JSON Web Tokens & MicroServices
QEWD.js, JSON Web Tokens & MicroServicesQEWD.js, JSON Web Tokens & MicroServices
QEWD.js, JSON Web Tokens & MicroServices
Rob Tweed

QEWD.js: Have your Node.js Cake and Eat It Too
QEWD.js: Have your Node.js Cake and Eat It TooQEWD.js: Have your Node.js Cake and Eat It Too
QEWD.js: Have your Node.js Cake and Eat It Too
Rob Tweed

EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 4
EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 4EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 4
EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 4
Rob Tweed

EWD 3 Training Course Part 39: Building a React.js application with QEWD, Part 3
EWD 3 Training Course Part 39: Building a React.js application with QEWD, Part 3EWD 3 Training Course Part 39: Building a React.js application with QEWD, Part 3
EWD 3 Training Course Part 39: Building a React.js application with QEWD, Part 3
Rob Tweed

EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 2
EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 2EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 2
EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 2
Rob Tweed

EWD 3 Training Course Part 35: QEWD Session Locking
EWD 3 Training Course Part 35: QEWD Session LockingEWD 3 Training Course Part 35: QEWD Session Locking
EWD 3 Training Course Part 35: QEWD Session Locking
Rob Tweed

EWD 3 Training Course Part 33: Configuring QEWD to use CORS
EWD 3 Training Course Part 33: Configuring QEWD to use CORSEWD 3 Training Course Part 33: Configuring QEWD to use CORS
EWD 3 Training Course Part 33: Configuring QEWD to use CORS
Rob Tweed

EWD 3 Training Course Part 32: Configuring QEWD to use SSL/HTTPS
EWD 3 Training Course Part 32: Configuring QEWD to use SSL/HTTPSEWD 3 Training Course Part 32: Configuring QEWD to use SSL/HTTPS
EWD 3 Training Course Part 32: Configuring QEWD to use SSL/HTTPS
Rob Tweed

EWD 3 Training Course Part 29: Running QEWD as a Service
EWD 3 Training Course Part 29: Running QEWD as a ServiceEWD 3 Training Course Part 29: Running QEWD as a Service
EWD 3 Training Course Part 29: Running QEWD as a Service
Rob Tweed

EWD 3 Training Course Part 28: Integrating Legacy Mumps Code with QEWD
EWD 3 Training Course Part 28: Integrating Legacy Mumps Code with QEWDEWD 3 Training Course Part 28: Integrating Legacy Mumps Code with QEWD
EWD 3 Training Course Part 28: Integrating Legacy Mumps Code with QEWD
Rob Tweed

EWD 3 Training Course Part 27: The QEWD Session
EWD 3 Training Course Part 27: The QEWD SessionEWD 3 Training Course Part 27: The QEWD Session
EWD 3 Training Course Part 27: The QEWD Session
Rob Tweed

EWD 3 Training Course Part 26: Event-driven Indexing
EWD 3 Training Course Part 26: Event-driven IndexingEWD 3 Training Course Part 26: Event-driven Indexing
EWD 3 Training Course Part 26: Event-driven Indexing
Rob Tweed

EWD 3 Training Course Part 25: Document Database Capabilities
EWD 3 Training Course Part 25: Document Database CapabilitiesEWD 3 Training Course Part 25: Document Database Capabilities
EWD 3 Training Course Part 25: Document Database Capabilities
Rob Tweed

EWD 3 Training Course Part 24: Traversing a Document's Leaf Nodes
EWD 3 Training Course Part 24: Traversing a Document's Leaf NodesEWD 3 Training Course Part 24: Traversing a Document's Leaf Nodes
EWD 3 Training Course Part 24: Traversing a Document's Leaf Nodes
Rob Tweed


More from Rob Tweed (19)

QEWD Update
QEWD UpdateQEWD Update
QEWD Update

Data Persistence as a Language Feature
Data Persistence as a Language FeatureData Persistence as a Language Feature
Data Persistence as a Language Feature

LNUG: Having Your Node.js Cake and Eating It Too
LNUG: Having Your Node.js Cake and Eating It TooLNUG: Having Your Node.js Cake and Eating It Too
LNUG: Having Your Node.js Cake and Eating It Too

EWD 3 Training Course Part 45: Using QEWD's Advanced MicroService Functionality
EWD 3 Training Course Part 45: Using QEWD's Advanced MicroService FunctionalityEWD 3 Training Course Part 45: Using QEWD's Advanced MicroService Functionality
EWD 3 Training Course Part 45: Using QEWD's Advanced MicroService Functionality

EWD 3 Training Course Part 43: Using JSON Web Tokens with QEWD REST Services
EWD 3 Training Course Part 43: Using JSON Web Tokens with QEWD REST ServicesEWD 3 Training Course Part 43: Using JSON Web Tokens with QEWD REST Services
EWD 3 Training Course Part 43: Using JSON Web Tokens with QEWD REST Services

QEWD.js, JSON Web Tokens & MicroServices
QEWD.js, JSON Web Tokens & MicroServicesQEWD.js, JSON Web Tokens & MicroServices
QEWD.js, JSON Web Tokens & MicroServices

QEWD.js: Have your Node.js Cake and Eat It Too
QEWD.js: Have your Node.js Cake and Eat It TooQEWD.js: Have your Node.js Cake and Eat It Too
QEWD.js: Have your Node.js Cake and Eat It Too

EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 4
EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 4EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 4
EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 4

EWD 3 Training Course Part 39: Building a React.js application with QEWD, Part 3
EWD 3 Training Course Part 39: Building a React.js application with QEWD, Part 3EWD 3 Training Course Part 39: Building a React.js application with QEWD, Part 3
EWD 3 Training Course Part 39: Building a React.js application with QEWD, Part 3

EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 2
EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 2EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 2
EWD 3 Training Course Part 38: Building a React.js application with QEWD, Part 2

EWD 3 Training Course Part 35: QEWD Session Locking
EWD 3 Training Course Part 35: QEWD Session LockingEWD 3 Training Course Part 35: QEWD Session Locking
EWD 3 Training Course Part 35: QEWD Session Locking

EWD 3 Training Course Part 33: Configuring QEWD to use CORS
EWD 3 Training Course Part 33: Configuring QEWD to use CORSEWD 3 Training Course Part 33: Configuring QEWD to use CORS
EWD 3 Training Course Part 33: Configuring QEWD to use CORS

EWD 3 Training Course Part 32: Configuring QEWD to use SSL/HTTPS
EWD 3 Training Course Part 32: Configuring QEWD to use SSL/HTTPSEWD 3 Training Course Part 32: Configuring QEWD to use SSL/HTTPS
EWD 3 Training Course Part 32: Configuring QEWD to use SSL/HTTPS

EWD 3 Training Course Part 29: Running QEWD as a Service
EWD 3 Training Course Part 29: Running QEWD as a ServiceEWD 3 Training Course Part 29: Running QEWD as a Service
EWD 3 Training Course Part 29: Running QEWD as a Service

EWD 3 Training Course Part 28: Integrating Legacy Mumps Code with QEWD
EWD 3 Training Course Part 28: Integrating Legacy Mumps Code with QEWDEWD 3 Training Course Part 28: Integrating Legacy Mumps Code with QEWD
EWD 3 Training Course Part 28: Integrating Legacy Mumps Code with QEWD

EWD 3 Training Course Part 27: The QEWD Session
EWD 3 Training Course Part 27: The QEWD SessionEWD 3 Training Course Part 27: The QEWD Session
EWD 3 Training Course Part 27: The QEWD Session

EWD 3 Training Course Part 26: Event-driven Indexing
EWD 3 Training Course Part 26: Event-driven IndexingEWD 3 Training Course Part 26: Event-driven Indexing
EWD 3 Training Course Part 26: Event-driven Indexing

EWD 3 Training Course Part 25: Document Database Capabilities
EWD 3 Training Course Part 25: Document Database CapabilitiesEWD 3 Training Course Part 25: Document Database Capabilities
EWD 3 Training Course Part 25: Document Database Capabilities

EWD 3 Training Course Part 24: Traversing a Document's Leaf Nodes
EWD 3 Training Course Part 24: Traversing a Document's Leaf NodesEWD 3 Training Course Part 24: Traversing a Document's Leaf Nodes
EWD 3 Training Course Part 24: Traversing a Document's Leaf Nodes


Recently uploaded

ThaiPy meetup - Indexes and Django
ThaiPy meetup - Indexes and DjangoThaiPy meetup - Indexes and Django
ThaiPy meetup - Indexes and Django
akshesh doshi

NYGGS 360: A Complete ERP for Construction Innovation
NYGGS 360: A Complete ERP for Construction InnovationNYGGS 360: A Complete ERP for Construction Innovation
NYGGS 360: A Complete ERP for Construction Innovation
NYGGS Construction ERP Software

11 Top Cross Browser Testing Tools to Know About.pdf
11 Top Cross Browser Testing Tools to Know About.pdf11 Top Cross Browser Testing Tools to Know About.pdf
11 Top Cross Browser Testing Tools to Know About.pdf
kalichargn70th171

當測試開始左移
當測試開始左移當測試開始左移
當測試開始左移
Jersey (CHE-PING) Su

bangalore Girls call 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
bangalore Girls call  👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Deliverybangalore Girls call  👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
bangalore Girls call 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
sunilverma7884

Artificial intelligence in customer services or chatbots
Artificial intelligence  in customer services or chatbotsArtificial intelligence  in customer services or chatbots
Artificial intelligence in customer services or chatbots
kayash1656

The Ultimate Guide to Phone Spy Apps: Everything You Need to Know
The Ultimate Guide to Phone Spy Apps: Everything You Need to KnowThe Ultimate Guide to Phone Spy Apps: Everything You Need to Know
The Ultimate Guide to Phone Spy Apps: Everything You Need to Know
onemonitarsoftware

Odoo E-commerce website development guides
Odoo E-commerce website development guidesOdoo E-commerce website development guides
Odoo E-commerce website development guides
jhkdigitalmarketing

🚂🚘 Premium Girls Call Ranchi 🛵🚡000XX00000 💃 Choose Best And Top Girl Service...
🚂🚘 Premium Girls Call Ranchi  🛵🚡000XX00000 💃 Choose Best And Top Girl Service...🚂🚘 Premium Girls Call Ranchi  🛵🚡000XX00000 💃 Choose Best And Top Girl Service...
🚂🚘 Premium Girls Call Ranchi 🛵🚡000XX00000 💃 Choose Best And Top Girl Service...
bahubalikumar09988

TEQnation 2024: Sustainable Software: May the Green Code Be with You
TEQnation 2024: Sustainable Software: May the Green Code Be with YouTEQnation 2024: Sustainable Software: May the Green Code Be with You
TEQnation 2024: Sustainable Software: May the Green Code Be with You
marcofolio

Introduction to Cloud computing for Internet of Things
Introduction to Cloud computing for Internet of ThingsIntroduction to Cloud computing for Internet of Things
Introduction to Cloud computing for Internet of Things
NachuSubramanian1

welcome to presentation on Google Apps
welcome to   presentation on Google Appswelcome to   presentation on Google Apps
welcome to presentation on Google Apps
AsifKarimJim

Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech.Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech

Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
revolutionary575

Shivam Pandit working on Php Web Developer.
Shivam Pandit working on Php Web Developer.Shivam Pandit working on Php Web Developer.
Shivam Pandit working on Php Web Developer.
shivamt017

Folding Cheat Sheet #7 - seventh in a series
Folding Cheat Sheet #7 - seventh in a seriesFolding Cheat Sheet #7 - seventh in a series
Folding Cheat Sheet #7 - seventh in a series
Philip Schwarz

Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
confluent

Cisco Live Announcements: New ThousandEyes Release Highlights - July 2024
Cisco Live Announcements: New ThousandEyes Release Highlights - July 2024Cisco Live Announcements: New ThousandEyes Release Highlights - July 2024
Cisco Live Announcements: New ThousandEyes Release Highlights - July 2024
ThousandEyes

Private Girls Call Navi Mumbai 🛵🚡9820252231 💃 Choose Best And Top Girl Servic...
Private Girls Call Navi Mumbai 🛵🚡9820252231 💃 Choose Best And Top Girl Servic...Private Girls Call Navi Mumbai 🛵🚡9820252231 💃 Choose Best And Top Girl Servic...
Private Girls Call Navi Mumbai 🛵🚡9820252231 💃 Choose Best And Top Girl Servic...
902basic

Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
45unexpected


Recently uploaded (20)

ThaiPy meetup - Indexes and Django
ThaiPy meetup - Indexes and DjangoThaiPy meetup - Indexes and Django
ThaiPy meetup - Indexes and Django

NYGGS 360: A Complete ERP for Construction Innovation
NYGGS 360: A Complete ERP for Construction InnovationNYGGS 360: A Complete ERP for Construction Innovation
NYGGS 360: A Complete ERP for Construction Innovation

11 Top Cross Browser Testing Tools to Know About.pdf
11 Top Cross Browser Testing Tools to Know About.pdf11 Top Cross Browser Testing Tools to Know About.pdf
11 Top Cross Browser Testing Tools to Know About.pdf

當測試開始左移
當測試開始左移當測試開始左移
當測試開始左移

bangalore Girls call 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
bangalore Girls call  👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Deliverybangalore Girls call  👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
bangalore Girls call 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery

Artificial intelligence in customer services or chatbots
Artificial intelligence  in customer services or chatbotsArtificial intelligence  in customer services or chatbots
Artificial intelligence in customer services or chatbots

The Ultimate Guide to Phone Spy Apps: Everything You Need to Know
The Ultimate Guide to Phone Spy Apps: Everything You Need to KnowThe Ultimate Guide to Phone Spy Apps: Everything You Need to Know
The Ultimate Guide to Phone Spy Apps: Everything You Need to Know

Odoo E-commerce website development guides
Odoo E-commerce website development guidesOdoo E-commerce website development guides
Odoo E-commerce website development guides

🚂🚘 Premium Girls Call Ranchi 🛵🚡000XX00000 💃 Choose Best And Top Girl Service...
🚂🚘 Premium Girls Call Ranchi  🛵🚡000XX00000 💃 Choose Best And Top Girl Service...🚂🚘 Premium Girls Call Ranchi  🛵🚡000XX00000 💃 Choose Best And Top Girl Service...
🚂🚘 Premium Girls Call Ranchi 🛵🚡000XX00000 💃 Choose Best And Top Girl Service...

TEQnation 2024: Sustainable Software: May the Green Code Be with You
TEQnation 2024: Sustainable Software: May the Green Code Be with YouTEQnation 2024: Sustainable Software: May the Green Code Be with You
TEQnation 2024: Sustainable Software: May the Green Code Be with You

Introduction to Cloud computing for Internet of Things
Introduction to Cloud computing for Internet of ThingsIntroduction to Cloud computing for Internet of Things
Introduction to Cloud computing for Internet of Things

welcome to presentation on Google Apps
welcome to   presentation on Google Appswelcome to   presentation on Google Apps
welcome to presentation on Google Apps

Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech.Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech.

Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...

Shivam Pandit working on Php Web Developer.
Shivam Pandit working on Php Web Developer.Shivam Pandit working on Php Web Developer.
Shivam Pandit working on Php Web Developer.

Folding Cheat Sheet #7 - seventh in a series
Folding Cheat Sheet #7 - seventh in a seriesFolding Cheat Sheet #7 - seventh in a series
Folding Cheat Sheet #7 - seventh in a series

Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...

Cisco Live Announcements: New ThousandEyes Release Highlights - July 2024
Cisco Live Announcements: New ThousandEyes Release Highlights - July 2024Cisco Live Announcements: New ThousandEyes Release Highlights - July 2024
Cisco Live Announcements: New ThousandEyes Release Highlights - July 2024

Private Girls Call Navi Mumbai 🛵🚡9820252231 💃 Choose Best And Top Girl Servic...
Private Girls Call Navi Mumbai 🛵🚡9820252231 💃 Choose Best And Top Girl Servic...Private Girls Call Navi Mumbai 🛵🚡9820252231 💃 Choose Best And Top Girl Servic...
Private Girls Call Navi Mumbai 🛵🚡9820252231 💃 Choose Best And Top Girl Servic...

Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...


EWD 3 Training Course Part 4: Installing & Configuring QEWD

  • 1. Copyright © 2016 M/Gateway Developments Ltd EWD 3 Training Course Part 4 Installing & Configuring QEWD Rob Tweed Director, M/Gateway Developments Ltd Twitter: @rtweed
  • 2. Copyright © 2016 M/Gateway Developments Ltd QEWD • Complete EWD 3 run-time back-end environment for applications: – Interactive browser-based applications – Interactive React Native mobile applications – HTTP Web Services – REST services • Built using EWD 3 modules • Extensible
  • 3. Copyright © 2016 M/Gateway Developments Ltd Pre-packaged EWD 3 Platform • Ideal if you want to build and run applications: – Interactive browser-based desktop apps – Mobile apps using React Native – REST and Web Service back-ends • with a Node.js back-end • Particularly if you want to use Caché, Redis or GT.M • All the necessary EWD 3 modules have been integrated for you – Very simple installation & configuration
  • 4. Copyright © 2016 M/Gateway Developments Ltd Getting Started on Windows with Caché • Pre-requisites – Windows 7 or later – Decent modern browser • Chrome recommended – Decent text editor • eg Notepad++ – Caché installed and running
  • 5. Copyright © 2016 M/Gateway Developments Ltd Step 1 • Install Node.js – Go to https://nodejs.org – Download latest version of Node.js • LTS version recommended • Currently 6.9.x – Invoke the downloaded msi installer file – Check using Command Prompt windows • node –v – Should report v6.9.3
  • 6. Copyright © 2016 M/Gateway Developments Ltd Step 2 • Create a directory for all QEWD work: – eg C:qewd
  • 7. Copyright © 2016 M/Gateway Developments Ltd Step 3 • Install QEWD and qewd-monitor: cd qewd npm install qewd qewd-monitor Ignore any warnings On completion you should find a new directory: C:qewdnode_modules
  • 8. Copyright © 2016 M/Gateway Developments Ltd Step 4 • Get and install the latest cache.node for Node.js 6.x: – Move/copy from Downloads directory to: • C:qewdnode_modules – Rename to cache.node https://s3-eu-west-1.amazonaws.com/cache.node/build-124/win64/cache610.node
  • 9. Copyright © 2016 M/Gateway Developments Ltd Step 5 (a) • Set up and configure QEWD – Copy: • C:qewdnode_modulesqewdexampleewd-xpress.js – To: • C:qewdqewd.js
  • 10. Copyright © 2016 M/Gateway Developments Ltd Step 5 (b) • Edit C:qewdqewd.js – eg using Notepad++ – Specify your Caché mgr path within the config object, eg: var config = { managementPassword: 'keepThisSecret!', serverName: 'New QEWD Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr' } } };
  • 11. Copyright © 2016 M/Gateway Developments Ltd Step 5 (b) • Edit C:qewdqewd.js – eg using Notepad++ – Specify your Caché mgr path within the config object, eg: Note the double back-slashes Note the comma! var config = { managementPassword: 'keepThisSecret!', serverName: 'New QEWD Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr' } } };
  • 12. Copyright © 2016 M/Gateway Developments Ltd Step 6 • Set up qewd-monitor – Create new directories: • C:qewdwww • C:qewdwwwqewd-monitor – Copy all the files in: • c:qewdnode_modulesqewd-monitorwww – To: • c:qewdwwwqewd-monitor
  • 13. Copyright © 2016 M/Gateway Developments Ltd Step 7 • Start up QEWD: – In a Command Prompt window: cd qewd node qewd C:ewd3>node qewd webServerRootPath = C:qewd/www/ Worker Bootstrap Module file written to node_modules/ewd-qoper8-worker.js ======================================================== ewd-qoper8 is up and running. Max worker pool size: 1
  • 14. Copyright © 2016 M/Gateway Developments Ltd Step 8 • In your browser, enter the URL: – http://127.0.0.1:8080/qewd-monitor/index.html – When prompted for the management password, enter: • keepThisSecret! • QEWD and qewd-monitor should now be fully working!
  • 15. Copyright © 2016 M/Gateway Developments Ltd QEWD startup file • C:qewdqewd.js – Can be renamed if you wish • Define a config object • Invoke the QEWD start() function – Passing in the config object as an argument
  • 16. Copyright © 2016 M/Gateway Developments Ltd QEWD startup config object var config = { managementPassword: 'keepThisSecret!', serverName: 'New QEWD Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr’ } }};
  • 17. Copyright © 2016 M/Gateway Developments Ltd QEWD startup var config = { managementPassword: 'keepThisSecret!', serverName: 'New EWD Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr’ } }}; var qewd = require('qewd').master; qewd.start(config);
  • 18. Copyright © 2016 M/Gateway Developments Ltd QEWD startup config object var config = { managementPassword: 'keepThisSecret!', serverName: 'New QEWD Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr’ } }}; The management password that You enter when you start up qewd-monitor application
  • 19. Copyright © 2016 M/Gateway Developments Ltd QEWD startup config object var config = { managementPassword: 'keepThisSecret!', serverName: 'My EWD App Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr’ } }}; Used in qewd-monitor to display the name of this instance of QEWD Useful if you have more than one instance running
  • 20. Copyright © 2016 M/Gateway Developments Ltd QEWD startup config object var config = { managementPassword: 'keepThisSecret!', serverName: 'My EWD App Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr’ } }}; Port on which Express listens for incoming requests
  • 21. Copyright © 2016 M/Gateway Developments Ltd QEWD startup config object var config = { managementPassword: 'keepThisSecret!', serverName: 'My EWD App Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr’ } }}; Maximum number of worker processes to be started by QEWD to handle demand
  • 22. Copyright © 2016 M/Gateway Developments Ltd QEWD startup config object var config = { managementPassword: 'keepThisSecret!', serverName: 'New EWD Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr’ } }}; What database do you want to connect to your worker processes? - cache - gtm
  • 23. Copyright © 2016 M/Gateway Developments Ltd QEWD startup config object var config = { managementPassword: 'keepThisSecret!', serverName: 'New EWD Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr’ } }}; If Caché, where is its mgr directory located?
  • 24. Copyright © 2016 M/Gateway Developments Ltd QEWD startup config object var config = { managementPassword: 'keepThisSecret!', serverName: 'New EWD Server', port: 8080, poolSize: 1, database: { type: 'cache', params: { path: 'c:InterSystemsCache2015-2mgr’ } }}; Other Caché database params available: - username (_SYSTEM) - password (SYS) - namespace (USER) Only need to be specified if different values from defaults required
  • 25. Copyright © 2016 M/Gateway Developments Ltd QEWD is ready • You can now try developing your own applications • Can use any JavaScript framework – Including your own manually created JavaScript code
  • 26. Copyright © 2016 M/Gateway Developments Ltd Installing QEWD on Linux • The QEWD repository includes an installer folder – Contains a set of pre-written installer scripts – Designed for use with Ubuntu 16.04 • "virgin" system without: – Node.js or a database (GT.M, Cache or Redis) • Easily adapted for use with other Linux versions • Can be used as a starting point for "non-virgin" systems
  • 27. Copyright © 2016 M/Gateway Developments Ltd Using the Installers • Pre-requisites / assumptions: – Freshly-installed Ubuntu 16.04 system: • Physical server • Virtual Machine • Cloud image (EC2, Digital Ocean, etc) – SSH access – Port 8080 externally accessible
  • 28. Copyright © 2016 M/Gateway Developments Ltd Linux Installers: • QEWD + NVM + Node.js • Choice of database: – GT.M (Free, Open Source) – GlobalsDB (Free, Proprietary, Deprecated) – Cache (Proprietary/Commercial): • Use installer file as a guide only • You must have a valid Cache license
  • 29. Copyright © 2016 M/Gateway Developments Ltd Using the Installers • See instructions at: – https://github.com/robtweed/qewd/tree/master/installers
  • 30. Copyright © 2016 M/Gateway Developments Ltd Installing QEWD on RPi • QEWD can also be installed and run on a Raspberry Pi – Using Redis (ewd-redis-globals) • A pre-built installer can be found in the /installers folder • See instructions at: – https://github.com/robtweed/qewd/tree/master/installers
  • 31. Copyright © 2016 M/Gateway Developments Ltd Docker versions of QEWD • Pre-built containers in Docker.io: – rtweed/qewd: • QEWD for Intel x64 machines – rtweed/rpi-qewd • QEWD for Raspberry Pi • See the separate slide deck on using the Docker versions of QEWD for more information
