CHRISTOPHER SCHMITT            @teleject




ADAPTIVE IMAGES
IN RESPONSIVE WEB DESIGN

                HTML5tx 2013
CHRISTOPHER SCHMITT
WHY DON’T WE ASK
THE BROWSER?

             (cc) flic.kr/p/vUBHv
Mozilla/1.0 (Win3.1)

http://www.useragentstring.com/




                                  (cc) flic.kr/p/vUBHv
Mozilla/1.0 (Win3.1)
Mozilla/1.22 (compatible;
MSIE 2.0; Windows 95)
http://www.useragentstring.com/




                                  (cc) flic.kr/p/vUBHv
Mozilla/5.0 (Macintosh; Intel Mac
OS X 10_7_3) AppleWebKit/
534.55.3 (KHTML, like Gecko)
Version/5.1.5 Safari/534.55.3
http://www.useragentstring.com/




                                  (cc) flic.kr/p/vUBHv
Mozilla/5.0 (Macintosh; Intel Mac
OS X 10_7_3) AppleWebKit/
534.55.3 (KHTML, like Gecko)
Version/5.1.5 Safari/534.55.3
http://webaim.org/blog/user-agent-string-history/




                                     (cc) flic.kr/p/vUBHv
FEATURE TESTING
vs. BROWSER SNIFFING

1

2

3
FEATURE TESTING
vs. BROWSER SNIFFING

1    Browser width

2

3
A scripting approach
        var myWidth = 0, myHeight = 0;
        if( typeof( window.innerWidth ) == 'number' ) {
          //Non-IE
          myWidth = window.innerWidth;
          myHeight = window.innerHeight;
        } else if( document.documentElement &&
          ( document.documentElement.clientWidth ||
          document.documentElement.clientHeight ) ) {
          //IE 6+ in 'standards compliant mode'
          myWidth = document.documentElement.clientWidth;
          myHeight = document.documentElement.clientHeight;
        }


http://www.howtocreate.co.uk/tutorials/javascript/browserwindow
The jQuery approach
       // returns width of browser viewport
       $(window).width();
       // returns height of browser viewport
       $(window).height();

       // returns width of HTML document
       $(document).width();
       // returns height of HTML document
       $(document).height();


http://api.jquery.com/width/ & http://api.jquery.com/height/
CSS media queries
// default, mobile-1st CSS rules devices go here

@media screen and (min-width: 480px) { ... }

@media screen and (min-width: 600px) { ... }

@media screen and (min-width: 768px) { ... }

@media screen and (min-width: 910px) { ... }
(cc) flic.kr/p/8Lo5Gk
BROWSER WIDTH
GIVES US FRAME,
NOT THE CANVAS
FEATURE TESTING
vs. BROWSER SNIFFING

1    Browser width

2    Screen resolution

3
72            PPI
HAS SERVED US WELL
                (cc) flic.kr/p/6tjjRP
72 points-per-inch =
72 pixels-per-inch
96            PPI
IF A WINDOWS USER
72 points-per-inch
x [1+(1/3)]
= 96 PPI
“RETINA” DISPLAYS
          300ppi at 12 inches from the eyes
                                              78μm




                                              78μm
goo.gl/zpkFy
240

    144

72 PPI
“   [In 2013, Intel sees their
    product line] offer a higher
    resolution experience than a
    top-of-the-line 1080p HDTV.”




    http://liliputing.com/2012/04/intel-retina-laptop-
    desktop-displays-coming-in-2013.html
72 PPI
240
240 PPI
240 PPI
72 PPI
RETINA DISPLAYS =
LARGER IMAGES,
LARGER FILE SIZES
FEATURE TESTING
vs. BROWSER SNIFFING

1    Browser width

2    Screen resolution

3    Bandwidth
SPEED TESTS
HINDER SPEED,
USER EXPERIENCE
             (cc) flic.kr/p/4DziUN
“   Testing for speed of an
    internet connection is like
    stepping in front of a car to see
    how fast it is.”




                               (cc) flic.kr/p/4DziUN
“   Testing for speed of an
    internet connection is like
    stepping in front of a car to see
    how fast it is.”




“   But, Christopher, you only
    have to test it once.”

                               (cc) flic.kr/p/4DziUN
Speed test image




https://github.com/adamdbradley/foresight.js
Speed test image



              +50k

https://github.com/adamdbradley/foresight.js
Native speed test
   // @Modernizr's network-connection.js
   connection = navigator.connection || {
               type: 0 }, // polyfill

   isSlowConnection = connection.type == 3
              || connection.type == 4
              | /^[23]g$/.test(connection.type);


http://davidbcalhoun.com/2010/using-navigator-connection-android
GIMME THAT OLD SCHOOL

1

2

3
GIMME THAT OLD SCHOOL

1    .htaccess

2

3
Filament .htaccess
# Responsive Images
# Mobile-First images that scale responsively and responsibly
# Copyright 2010, Scott Jehl, Filament Group, Inc
# Dual licensed under the MIT or GPL Version 2 licenses.
# //Start Responsive Images
RewriteEngine On
# direct image requests to temp
RewriteCond %{QUERY_STRING} full=(.*)&?
RewriteRule (.*)rwd-router/.*.(jpe?g|png|gif|webp) $1%1 [L]
# ignore trap for non-image requests, rewrite URL without trap segment
RewriteRule (.*)rwd-router/(.*)$ $1$2
# //End Responsive Images

   https://github.com/filamentgroup/Responsive-Images
Filament .htaccess
<script src="responsiveimgs.js"></script>

<img src="sample-content/running-sml.jpg?
full=sample-content/running-lrg.jpg" />




              4+                        8+
“   ...the server has no way to
    know what resolution the
    client’s device is, so it can’t
    send the appropriately sized
    embeded images.”



    http://mattwilcox.net/archive/entry/id/1053/
http://adaptive-images.com/
ADD .HTACCESS, JS,
PHP 5, GD lib*, &
THEN <IMG>
GIMME THAT OLD SCHOOL

1    .htaccess

2    <picture> and/or srcset

3
media queries in HTML
<video controls>
  <source type="video/mp4" src="video/windowsill_small.mp4"
media="all and (max-width: 480px), all and (max-device-width:
480px)">
  <source type="video/webm" src="video/windowsill_small.webm"
media="all and (max-width: 480px), all and (max-device-width:
480px)">
  <source type="video/mp4" src="video/windowsill.mp4">
  <source type="video/webm" src="video/windowsill.webm">
    <!-- proper fallback content goes here -->
</video>

http://www.w3.org/community/respimg/2012/03/15/polyfilling-
                picture-without-the-overhead/
<picture> patch
  <picture alt="A giant stone face at The Bayon temple in Angkor Thom,
 Cambodia">
      <!-- <source src="small.jpg"> -->
      <source src="small.jpg">
      <!-- <source src="medium.jpg" media="(min-width: 400px)"> -->
      <source src="medium.jpg" media="(min-width: 400px)">
      <!-- <source src="large.jpg" media="(min-width: 800px)"> -->
      <source src="large.jpg" media="(min-width: 800px)">
      <!-- Fallback content for non-JS browsers. Same src as the initial
 source element. -->
      <noscript><img src="small.jpg" alt="A giant stone face at The Bayon
 temple in Angkor Thom, Cambodia"></noscript>
 </picture>
http://www.w3.org/community/respimg/2012/03/15/polyfilling-
                picture-without-the-overhead/
ADD IF-ELSE HTML, JS,
BORROW <VIDEO>, &
THEN <IMG>
@srcset standard?

  <h1><img alt="The Breakfast Combo"
      src="banner.jpeg"
      srcset="banner-HD.jpeg 2x,
            banner-phone.jpeg 100w,
            banner-phone-HD.jpeg 100w 2x">
  </h1>


http://www.whatwg.org/specs/web-apps/current-work/multipage/
           embedded-content-1.html#attr-img-srcset
GIMME THAT OLD SCHOOL

1    .htaccess

2    <picture>

3    HiSRC
Set, forget it HiSRC
<script src="https://ajax.googleapis.com/ajax/
libs/jquery/1.7.2/jquery.min.js"></script>
<script src="hisrc.js"></script>
<script>
  $(document).ready(function(){
      $(".hisrc img").hisrc();
  });
</script>
Set, forget it HiSRC
<div class="hisrc">
 <img src="halloween-mobile-1st.png"
   data-1x="halloween-x1.png"
   data-2x="halloween-x2.jpg"
   alt="Celebrating Halloween in style" />
</div>
Set, forget it HiSRC
<div class="hisrc">
 <img src="halloween-mobile-1st.png"
   data-1x="halloween-x1.png"
   data-2x="halloween-x2.jpg"
   alt="Celebrating Halloween in style" />
</div>
SERIES OF CHECKS TO
FIND OUT RESPONSIVE
PATH FOR IMAGES...
DO NATIVE SPEED
          TEST FOR MOBILE
          DEVICES FIRST...
http://davidbcalhoun.com/2010/using-navigator-connection-android
Check pixel density...
$.hisrc.devicePixelRatio = 1;
 if(window.devicePixelRatio !==
 undefined) {
   $.hisrc.devicePixelRatio =
   window.devicePixelRatio
 };

          https://gist.github.com/2428356
Force speed test



              +50k

https://github.com/adamdbradley/foresight.js
LESS THAN 4G MEANS
MOBILE IMAGES LEFT
IN PLACE
BETWEEN 4G &
300 Kbps MEANS
REGULAR DESKTOP
IMAGES SWAPPED IN
FAST SPEED & HIGH
DENSITY, RETINA
IMAGES SWAPPED IN
https://github.com/crdeutsch/hisrc/tree/v2
2 TRICK PONY
CSS IS CORE.
WE USE CSS MEDIA
QUERIES FOR DESIGN
http://mediaqueri.es/
CSS media queries
// default, mobile-1st CSS rules devices go here

@media screen and (min-width: 480px) { ... }

@media screen and (min-width: 600px) { ... }

@media screen and (min-width: 768px) { ... }

@media screen and (min-width: 910px) { ... }
Single pixel GIF
Single pixel GIF
Single pixel GIF
Single pixel GIF
Single pixel GIF


 $.hisrc.defaults = {
     useTransparentGif: true,




http://www.w3.org/community/respimg/2012/04/06/responsive-
   content-images-using-a-spacer-png-and-background-image/
Single pixel GIF
$.hisrc.defaults = {
    useTransparentGif: true,
gif;base64,R0lGODlhAQABAIAAAMz/
AAAAACH5BAEAAAAALAAAAAABAAE
AAAICRAEAOw==',

   17+      9+   11.6+   5+   8+
Single pixel GIF

$.hisrc.defaults = {
    useTransparentGif: true,
    transparentGifSrc: 'http://
example.com/spg.gif',



   17+      9+    11.6+    5+     6+
2 APPROACHES,
1 SIMPLE SOLUTION.

    https://github.com/teleject/hisrc
2 APPROACHES,
1 SIMPLE SOLUTION.
HEART WEB DESIGN
    https://github.com/teleject/hisrc
WORKAROUNDS &
TRICKS

1

2

3


          (cc) flic.kr/p/64fGf6
WORKAROUNDS &
TRICKS

1   background-size: auto

2

3


                    (cc) flic.kr/p/64fGf6
http://fittextjs.com/
background-size: 100%
<a href="example.com/link">Download on Github</a>

.download a {
   padding: .095em .8em;
  background: url(../img/arrow.png) no-repeat;
  background-size: 100%;
  margin-left: .4em;
  -webkit-transition: margin 0.15s ease-out;
  -moz-transition: margin 0.15s ease-out;
  text-decoration: none;
}



        17+           9+          11.6+          5+   9+
WORKAROUNDS &
TRICKS

1   background-size: auto

2   SVG

3


                    (cc) flic.kr/p/64fGf6
Native SVG




http://caniuse.com/#search=SVG%20in%20HTML%20img%20element
PNG 16kb
           SVG 7kb

17+   9+    11.6+   5+   9+
HTML5 Boilerplate
<!doctype html>
<!--[if lt IE 7]> <html class="no-js lt-ie9 lt-ie8 lt-ie7"
lang="en">
<![endif]-->
<!--[if IE 7]> <html class="no-js lt-ie9 lt-ie8" lang="en">
<![endif]-->
<!--[if IE 8]> <html class="no-js lt-ie9" lang="en"> <!
[endif]-->
<!--[if gt IE 8]><!--> <html class="no-js" lang="en"> <!--<!
[endif]-->
<head>
jQuery check
var checkBrowser =
 $('html').hasClass('lt-ie9');



<div class="svgswap">
  <img src="example.svg"
  data-svgswap="example.png">
</div>

       https://github.com/teleject/svg-swap
http://raphaeljs.com/
WORKAROUNDS &
TRICKS

1   background-size: auto

2   SVG

3   font-based solutions


                     (cc) flic.kr/p/64fGf6
“   ...if you use <meta
    charset="utf-8"> (you should
    be for HTML5), you’re adding
    common Unicode characters
    like and ✆, and you don’t
    need a specific font’s version...
    just copy and paste them into
    your HTML.”
Font-based RWD




http://ilovetypography.com/2012/04/11/designing-type-systems/
http://css-tricks.com/examples/IconFont/
Font-based icons
<style>
 [data-icon]:before {
   font-family: 'icon-font';
   content: attr(data-icon);
 }
</style>

<a href="http://example.com/cloud/save/">
  <span data-icon="C" aria-hidden="true"></span>
 Save to Cloud
</a>
WORKAROUNDS &
TRICKS

1   background-size: auto

2   SVG

3   font-based solutions

4   compressed JPEGs
                     (cc) flic.kr/p/64fGf6
GIMME THAT NEW SCHOOL

1

2

3
GIMME THAT NEW SCHOOL

1    simple design for users

2

3

           #rwdimg
GIMME THAT NEW SCHOOL

1    simple design for users

2   browser, server handshake

3

           #rwdimg
GIMME THAT NEW SCHOOL

1    simple design for users

2   browser, server handshake

3   same, several formats

           #rwdimg
#rwdimg
#rwdimg
#rwdimg
#rwdimg
#rwdimg
#rwdimg
#rwdimg
<link rel="shortcut icon" href="/assets/favicon.ico" />




                        #rwdimg
<link rel="apple-touch-icon-precomposed" sizes="144x144"
   href="apple-touch-icon-144x144-precomposed.png" />
<link rel="apple-touch-icon-precomposed" sizes="114x114"
   href="apple-touch-icon-114x114-precomposed.png" />
<link rel="apple-touch-icon-precomposed" sizes="72x72"
   href="apple-touch-icon-72x72-precomposed.png" />
<link rel="apple-touch-icon-precomposed"
   href="apple-touch-icon-precomposed.png" />
<link rel="shortcut icon" href="/assets/favicon.ico" />



                          #rwdimg
#rwdimg
THANK YOU!
CHRISTOPHER SCHMITT                                    @teleject


                http://goo.gl/gSYmS
The Non Breaking Space Podcast - http://nonbreakingspace.tv/

More Related Content

What's hot

Optimizing Sites for Mobile Devices
Optimizing Sites for Mobile DevicesOptimizing Sites for Mobile Devices
Optimizing Sites for Mobile Devices
jameswillweb

Responsive webdesign
Responsive webdesignResponsive webdesign
Responsive webdesign
Bart De Waele

Make JavaScript Faster
Make JavaScript FasterMake JavaScript Faster
Make JavaScript Faster
Steve Souders

Performance.now() fast but not furious
Performance.now()   fast but not furiousPerformance.now()   fast but not furious
Performance.now() fast but not furious
Anna Migas

CSS Lessons Learned the Hard Way (Generate Conf)
CSS Lessons Learned the Hard Way (Generate Conf)CSS Lessons Learned the Hard Way (Generate Conf)
CSS Lessons Learned the Hard Way (Generate Conf)
Zoe Gillenwater

Advanced workflows for mobile web design and development
Advanced workflows for mobile web design and developmentAdvanced workflows for mobile web design and development
Advanced workflows for mobile web design and development
brucebowman

Measuring Web Performance (HighEdWeb FL Edition)
Measuring Web Performance (HighEdWeb FL Edition)Measuring Web Performance (HighEdWeb FL Edition)
Measuring Web Performance (HighEdWeb FL Edition)
Dave Olsen

Responsive design: techniques and tricks to prepare your websites for the mul...
Responsive design: techniques and tricks to prepare your websites for the mul...Responsive design: techniques and tricks to prepare your websites for the mul...
Responsive design: techniques and tricks to prepare your websites for the mul...
Andreas Bovens

Beyond Squishy: The Principles of Adaptive Design
Beyond Squishy: The Principles of Adaptive DesignBeyond Squishy: The Principles of Adaptive Design
Beyond Squishy: The Principles of Adaptive Design
Brad Frost

Responsive Design Workflow: Mobilism 2012
Responsive Design Workflow: Mobilism 2012Responsive Design Workflow: Mobilism 2012
Responsive Design Workflow: Mobilism 2012
Stephen Hay

Progressive Enhancement & Mobile [Funka 2012]
Progressive Enhancement & Mobile [Funka 2012]Progressive Enhancement & Mobile [Funka 2012]
Progressive Enhancement & Mobile [Funka 2012]
Aaron Gustafson

Accessible web applications
Accessible web applicationsAccessible web applications
Accessible web applications
Wojtek Zając

Responsive websites. Toolbox
Responsive websites. ToolboxResponsive websites. Toolbox
Responsive websites. Toolbox
Wojtek Zając

The Server Side of Responsive Web Design
The Server Side of Responsive Web DesignThe Server Side of Responsive Web Design
The Server Side of Responsive Web Design
Dave Olsen

Responsive Web Design: buzzword or revolution?
Responsive Web Design: buzzword or revolution?Responsive Web Design: buzzword or revolution?
Responsive Web Design: buzzword or revolution?
Wojtek Zając

Rapid Testing, Rapid Development
Rapid Testing, Rapid DevelopmentRapid Testing, Rapid Development
Rapid Testing, Rapid Development
mennovanslooten

Raiders of the Fast Start: Frontend Performance Archaeology - Performance.now...
Raiders of the Fast Start: Frontend Performance Archaeology - Performance.now...Raiders of the Fast Start: Frontend Performance Archaeology - Performance.now...
Raiders of the Fast Start: Frontend Performance Archaeology - Performance.now...
Katie Sylor-Miller

Atomic Design - An Event Apart San Diego
Atomic Design - An Event Apart San DiegoAtomic Design - An Event Apart San Diego
Atomic Design - An Event Apart San Diego
Brad Frost

Plugins at WordCamp Phoenix
Plugins at WordCamp PhoenixPlugins at WordCamp Phoenix
Plugins at WordCamp Phoenix
Andrew Ryno

How fast are we going now?
How fast are we going now?How fast are we going now?
How fast are we going now?
Steve Souders


What's hot (20)

Optimizing Sites for Mobile Devices
Optimizing Sites for Mobile DevicesOptimizing Sites for Mobile Devices
Optimizing Sites for Mobile Devices

Responsive webdesign
Responsive webdesignResponsive webdesign
Responsive webdesign

Make JavaScript Faster
Make JavaScript FasterMake JavaScript Faster
Make JavaScript Faster

Performance.now() fast but not furious
Performance.now()   fast but not furiousPerformance.now()   fast but not furious
Performance.now() fast but not furious

CSS Lessons Learned the Hard Way (Generate Conf)
CSS Lessons Learned the Hard Way (Generate Conf)CSS Lessons Learned the Hard Way (Generate Conf)
CSS Lessons Learned the Hard Way (Generate Conf)

Advanced workflows for mobile web design and development
Advanced workflows for mobile web design and developmentAdvanced workflows for mobile web design and development
Advanced workflows for mobile web design and development

Measuring Web Performance (HighEdWeb FL Edition)
Measuring Web Performance (HighEdWeb FL Edition)Measuring Web Performance (HighEdWeb FL Edition)
Measuring Web Performance (HighEdWeb FL Edition)

Responsive design: techniques and tricks to prepare your websites for the mul...
Responsive design: techniques and tricks to prepare your websites for the mul...Responsive design: techniques and tricks to prepare your websites for the mul...
Responsive design: techniques and tricks to prepare your websites for the mul...

Beyond Squishy: The Principles of Adaptive Design
Beyond Squishy: The Principles of Adaptive DesignBeyond Squishy: The Principles of Adaptive Design
Beyond Squishy: The Principles of Adaptive Design

Responsive Design Workflow: Mobilism 2012
Responsive Design Workflow: Mobilism 2012Responsive Design Workflow: Mobilism 2012
Responsive Design Workflow: Mobilism 2012

Progressive Enhancement & Mobile [Funka 2012]
Progressive Enhancement & Mobile [Funka 2012]Progressive Enhancement & Mobile [Funka 2012]
Progressive Enhancement & Mobile [Funka 2012]

Accessible web applications
Accessible web applicationsAccessible web applications
Accessible web applications

Responsive websites. Toolbox
Responsive websites. ToolboxResponsive websites. Toolbox
Responsive websites. Toolbox

The Server Side of Responsive Web Design
The Server Side of Responsive Web DesignThe Server Side of Responsive Web Design
The Server Side of Responsive Web Design

Responsive Web Design: buzzword or revolution?
Responsive Web Design: buzzword or revolution?Responsive Web Design: buzzword or revolution?
Responsive Web Design: buzzword or revolution?

Rapid Testing, Rapid Development
Rapid Testing, Rapid DevelopmentRapid Testing, Rapid Development
Rapid Testing, Rapid Development

Raiders of the Fast Start: Frontend Performance Archaeology - Performance.now...
Raiders of the Fast Start: Frontend Performance Archaeology - Performance.now...Raiders of the Fast Start: Frontend Performance Archaeology - Performance.now...
Raiders of the Fast Start: Frontend Performance Archaeology - Performance.now...

Atomic Design - An Event Apart San Diego
Atomic Design - An Event Apart San DiegoAtomic Design - An Event Apart San Diego
Atomic Design - An Event Apart San Diego

Plugins at WordCamp Phoenix
Plugins at WordCamp PhoenixPlugins at WordCamp Phoenix
Plugins at WordCamp Phoenix

How fast are we going now?
How fast are we going now?How fast are we going now?
How fast are we going now?


Similar to [html5tx] Adaptive Images in Responsive Web Design

[refreshaustin] Adaptive Images in Responsive Web Design
[refreshaustin] Adaptive Images in Responsive Web Design[refreshaustin] Adaptive Images in Responsive Web Design
[refreshaustin] Adaptive Images in Responsive Web Design
Christopher Schmitt

[convergese] Adaptive Images in Responsive Web Design
[convergese] Adaptive Images in Responsive Web Design[convergese] Adaptive Images in Responsive Web Design
[convergese] Adaptive Images in Responsive Web Design
Christopher Schmitt

[HEWEBAR 2012] Adaptive Images in Responsive Web Design
[HEWEBAR 2012] Adaptive Images in Responsive Web Design[HEWEBAR 2012] Adaptive Images in Responsive Web Design
[HEWEBAR 2012] Adaptive Images in Responsive Web Design
Christopher Schmitt

[CSSDevConf] Adaptive Images in Responsive Web Design 2014
[CSSDevConf] Adaptive Images in Responsive Web Design 2014[CSSDevConf] Adaptive Images in Responsive Web Design 2014
[CSSDevConf] Adaptive Images in Responsive Web Design 2014
Christopher Schmitt

[cssdevconf] Adaptive Images in Responsive Web Design
[cssdevconf] Adaptive Images in Responsive Web Design[cssdevconf] Adaptive Images in Responsive Web Design
[cssdevconf] Adaptive Images in Responsive Web Design
Christopher Schmitt

[HEWEBFL] Adaptive Images in Responsive Web Design
[HEWEBFL] Adaptive Images in Responsive Web Design[HEWEBFL] Adaptive Images in Responsive Web Design
[HEWEBFL] Adaptive Images in Responsive Web Design
Christopher Schmitt

[rwdsummit] Adaptive Images in Responsive Web Design
[rwdsummit] Adaptive Images in Responsive Web Design[rwdsummit] Adaptive Images in Responsive Web Design
[rwdsummit] Adaptive Images in Responsive Web Design
Christopher Schmitt

[refreshpitt] Adaptive Images in Responsive Web Design
[refreshpitt] Adaptive Images in Responsive Web Design[refreshpitt] Adaptive Images in Responsive Web Design
[refreshpitt] Adaptive Images in Responsive Web Design
Christopher Schmitt

[psuweb] Adaptive Images in Responsive Web Design
[psuweb] Adaptive Images in Responsive Web Design[psuweb] Adaptive Images in Responsive Web Design
[psuweb] Adaptive Images in Responsive Web Design
Christopher Schmitt

[wcatx] Adaptive Images in Responsive Web Design
[wcatx] Adaptive Images in Responsive Web Design[wcatx] Adaptive Images in Responsive Web Design
[wcatx] Adaptive Images in Responsive Web Design
Christopher Schmitt

[peachpit] Adaptive Images in Responsive Web Design
[peachpit] Adaptive Images in Responsive Web Design[peachpit] Adaptive Images in Responsive Web Design
[peachpit] Adaptive Images in Responsive Web Design
Christopher Schmitt

[drupalcampatx] Adaptive Images in Responsive Web Design
[drupalcampatx] Adaptive Images in Responsive Web Design[drupalcampatx] Adaptive Images in Responsive Web Design
[drupalcampatx] Adaptive Images in Responsive Web Design
Christopher Schmitt

[parisweb] Adaptive Images in Responsive Web Design
[parisweb] Adaptive Images in Responsive Web Design[parisweb] Adaptive Images in Responsive Web Design
[parisweb] Adaptive Images in Responsive Web Design
Christopher Schmitt

The specs behind the sex, mobile-friendly layout beyond the desktop
The specs behind the sex, mobile-friendly layout beyond the desktopThe specs behind the sex, mobile-friendly layout beyond the desktop
The specs behind the sex, mobile-friendly layout beyond the desktop
betabeers

Christopher Schmitt, "Adaptive Images for Responsive Web Design"
Christopher Schmitt, "Adaptive Images for Responsive Web Design"Christopher Schmitt, "Adaptive Images for Responsive Web Design"
Christopher Schmitt, "Adaptive Images for Responsive Web Design"
WebVisions

Pinkoi Mobile Web
Pinkoi Mobile WebPinkoi Mobile Web
Pinkoi Mobile Web
mikeleeme

[funka] Adaptive Images in Responsive Web Design
[funka] Adaptive Images in Responsive Web Design[funka] Adaptive Images in Responsive Web Design
[funka] Adaptive Images in Responsive Web Design
Christopher Schmitt

Presentation Tier optimizations
Presentation Tier optimizationsPresentation Tier optimizations
Presentation Tier optimizations
Anup Hariharan Nair

VizEx View HTML5 Workshop
VizEx View HTML5 WorkshopVizEx View HTML5 Workshop
VizEx View HTML5 Workshop
Larson Software Technology

VizEx View HTML5 Workshop
VizEx View HTML5 WorkshopVizEx View HTML5 Workshop
VizEx View HTML5 Workshop
David Manock


Similar to [html5tx] Adaptive Images in Responsive Web Design (20)

[refreshaustin] Adaptive Images in Responsive Web Design
[refreshaustin] Adaptive Images in Responsive Web Design[refreshaustin] Adaptive Images in Responsive Web Design
[refreshaustin] Adaptive Images in Responsive Web Design

[convergese] Adaptive Images in Responsive Web Design
[convergese] Adaptive Images in Responsive Web Design[convergese] Adaptive Images in Responsive Web Design
[convergese] Adaptive Images in Responsive Web Design

[HEWEBAR 2012] Adaptive Images in Responsive Web Design
[HEWEBAR 2012] Adaptive Images in Responsive Web Design[HEWEBAR 2012] Adaptive Images in Responsive Web Design
[HEWEBAR 2012] Adaptive Images in Responsive Web Design

[CSSDevConf] Adaptive Images in Responsive Web Design 2014
[CSSDevConf] Adaptive Images in Responsive Web Design 2014[CSSDevConf] Adaptive Images in Responsive Web Design 2014
[CSSDevConf] Adaptive Images in Responsive Web Design 2014

[cssdevconf] Adaptive Images in Responsive Web Design
[cssdevconf] Adaptive Images in Responsive Web Design[cssdevconf] Adaptive Images in Responsive Web Design
[cssdevconf] Adaptive Images in Responsive Web Design

[HEWEBFL] Adaptive Images in Responsive Web Design
[HEWEBFL] Adaptive Images in Responsive Web Design[HEWEBFL] Adaptive Images in Responsive Web Design
[HEWEBFL] Adaptive Images in Responsive Web Design

[rwdsummit] Adaptive Images in Responsive Web Design
[rwdsummit] Adaptive Images in Responsive Web Design[rwdsummit] Adaptive Images in Responsive Web Design
[rwdsummit] Adaptive Images in Responsive Web Design

[refreshpitt] Adaptive Images in Responsive Web Design
[refreshpitt] Adaptive Images in Responsive Web Design[refreshpitt] Adaptive Images in Responsive Web Design
[refreshpitt] Adaptive Images in Responsive Web Design

[psuweb] Adaptive Images in Responsive Web Design
[psuweb] Adaptive Images in Responsive Web Design[psuweb] Adaptive Images in Responsive Web Design
[psuweb] Adaptive Images in Responsive Web Design

[wcatx] Adaptive Images in Responsive Web Design
[wcatx] Adaptive Images in Responsive Web Design[wcatx] Adaptive Images in Responsive Web Design
[wcatx] Adaptive Images in Responsive Web Design

[peachpit] Adaptive Images in Responsive Web Design
[peachpit] Adaptive Images in Responsive Web Design[peachpit] Adaptive Images in Responsive Web Design
[peachpit] Adaptive Images in Responsive Web Design

[drupalcampatx] Adaptive Images in Responsive Web Design
[drupalcampatx] Adaptive Images in Responsive Web Design[drupalcampatx] Adaptive Images in Responsive Web Design
[drupalcampatx] Adaptive Images in Responsive Web Design

[parisweb] Adaptive Images in Responsive Web Design
[parisweb] Adaptive Images in Responsive Web Design[parisweb] Adaptive Images in Responsive Web Design
[parisweb] Adaptive Images in Responsive Web Design

The specs behind the sex, mobile-friendly layout beyond the desktop
The specs behind the sex, mobile-friendly layout beyond the desktopThe specs behind the sex, mobile-friendly layout beyond the desktop
The specs behind the sex, mobile-friendly layout beyond the desktop

Christopher Schmitt, "Adaptive Images for Responsive Web Design"
Christopher Schmitt, "Adaptive Images for Responsive Web Design"Christopher Schmitt, "Adaptive Images for Responsive Web Design"
Christopher Schmitt, "Adaptive Images for Responsive Web Design"

Pinkoi Mobile Web
Pinkoi Mobile WebPinkoi Mobile Web
Pinkoi Mobile Web

[funka] Adaptive Images in Responsive Web Design
[funka] Adaptive Images in Responsive Web Design[funka] Adaptive Images in Responsive Web Design
[funka] Adaptive Images in Responsive Web Design

Presentation Tier optimizations
Presentation Tier optimizationsPresentation Tier optimizations
Presentation Tier optimizations

VizEx View HTML5 Workshop
VizEx View HTML5 WorkshopVizEx View HTML5 Workshop
VizEx View HTML5 Workshop

VizEx View HTML5 Workshop
VizEx View HTML5 WorkshopVizEx View HTML5 Workshop
VizEx View HTML5 Workshop


More from Christopher Schmitt

Keeping Colors from Killing Your Product
Keeping Colors from Killing Your ProductKeeping Colors from Killing Your Product
Keeping Colors from Killing Your Product
Christopher Schmitt

[Austin WordPress Meetup] Adaptive Images in Responsive Web Design
[Austin WordPress Meetup] Adaptive Images in Responsive Web Design[Austin WordPress Meetup] Adaptive Images in Responsive Web Design
[Austin WordPress Meetup] Adaptive Images in Responsive Web Design
Christopher Schmitt

[artifactconf] Github for People Who Don't Code
[artifactconf] Github for People Who Don't Code[artifactconf] Github for People Who Don't Code
[artifactconf] Github for People Who Don't Code
Christopher Schmitt

GitHub for People Who Don't Code
GitHub for People Who Don't CodeGitHub for People Who Don't Code
GitHub for People Who Don't Code
Christopher Schmitt

[sxsw2013] Extremely Compressed JPEGs
[sxsw2013] Extremely Compressed JPEGs[sxsw2013] Extremely Compressed JPEGs
[sxsw2013] Extremely Compressed JPEGs
Christopher Schmitt

[amigos] HTML5 and CSS3
[amigos] HTML5 and CSS3[amigos] HTML5 and CSS3
[amigos] HTML5 and CSS3
Christopher Schmitt

[cssdevconf] Adaptive Images in RWD
[cssdevconf] Adaptive Images in RWD[cssdevconf] Adaptive Images in RWD
[cssdevconf] Adaptive Images in RWD
Christopher Schmitt

[convergefl] Adaptive Images in Responsive Web Design
[convergefl] Adaptive Images in Responsive Web Design[convergefl] Adaptive Images in Responsive Web Design
[convergefl] Adaptive Images in Responsive Web Design
Christopher Schmitt

[rwdsummit2012] Adaptive Images in Responsive Web Design
[rwdsummit2012] Adaptive Images in Responsive Web Design[rwdsummit2012] Adaptive Images in Responsive Web Design
[rwdsummit2012] Adaptive Images in Responsive Web Design
Christopher Schmitt

[HEWEBAR 2012] Beyond Desktop Browsing (HTML5)
[HEWEBAR 2012] Beyond Desktop Browsing (HTML5)[HEWEBAR 2012] Beyond Desktop Browsing (HTML5)
[HEWEBAR 2012] Beyond Desktop Browsing (HTML5)
Christopher Schmitt

[O'Reilly] HTML5 Design
[O'Reilly] HTML5 Design[O'Reilly] HTML5 Design
[O'Reilly] HTML5 Design
Christopher Schmitt

[heweb11] CSS3 Makeover
[heweb11] CSS3 Makeover[heweb11] CSS3 Makeover
[heweb11] CSS3 Makeover
Christopher Schmitt

[heweb11] HTML5 Makeover
[heweb11] HTML5 Makeover[heweb11] HTML5 Makeover
[heweb11] HTML5 Makeover
Christopher Schmitt

[edUi] HTML5 Workshop
[edUi] HTML5 Workshop[edUi] HTML5 Workshop
[edUi] HTML5 Workshop
Christopher Schmitt


More from Christopher Schmitt (14)

Keeping Colors from Killing Your Product
Keeping Colors from Killing Your ProductKeeping Colors from Killing Your Product
Keeping Colors from Killing Your Product

[Austin WordPress Meetup] Adaptive Images in Responsive Web Design
[Austin WordPress Meetup] Adaptive Images in Responsive Web Design[Austin WordPress Meetup] Adaptive Images in Responsive Web Design
[Austin WordPress Meetup] Adaptive Images in Responsive Web Design

[artifactconf] Github for People Who Don't Code
[artifactconf] Github for People Who Don't Code[artifactconf] Github for People Who Don't Code
[artifactconf] Github for People Who Don't Code

GitHub for People Who Don't Code
GitHub for People Who Don't CodeGitHub for People Who Don't Code
GitHub for People Who Don't Code

[sxsw2013] Extremely Compressed JPEGs
[sxsw2013] Extremely Compressed JPEGs[sxsw2013] Extremely Compressed JPEGs
[sxsw2013] Extremely Compressed JPEGs

[amigos] HTML5 and CSS3
[amigos] HTML5 and CSS3[amigos] HTML5 and CSS3
[amigos] HTML5 and CSS3

[cssdevconf] Adaptive Images in RWD
[cssdevconf] Adaptive Images in RWD[cssdevconf] Adaptive Images in RWD
[cssdevconf] Adaptive Images in RWD

[convergefl] Adaptive Images in Responsive Web Design
[convergefl] Adaptive Images in Responsive Web Design[convergefl] Adaptive Images in Responsive Web Design
[convergefl] Adaptive Images in Responsive Web Design

[rwdsummit2012] Adaptive Images in Responsive Web Design
[rwdsummit2012] Adaptive Images in Responsive Web Design[rwdsummit2012] Adaptive Images in Responsive Web Design
[rwdsummit2012] Adaptive Images in Responsive Web Design

[HEWEBAR 2012] Beyond Desktop Browsing (HTML5)
[HEWEBAR 2012] Beyond Desktop Browsing (HTML5)[HEWEBAR 2012] Beyond Desktop Browsing (HTML5)
[HEWEBAR 2012] Beyond Desktop Browsing (HTML5)

[O'Reilly] HTML5 Design
[O'Reilly] HTML5 Design[O'Reilly] HTML5 Design
[O'Reilly] HTML5 Design

[heweb11] CSS3 Makeover
[heweb11] CSS3 Makeover[heweb11] CSS3 Makeover
[heweb11] CSS3 Makeover

[heweb11] HTML5 Makeover
[heweb11] HTML5 Makeover[heweb11] HTML5 Makeover
[heweb11] HTML5 Makeover

[edUi] HTML5 Workshop
[edUi] HTML5 Workshop[edUi] HTML5 Workshop
[edUi] HTML5 Workshop


Recently uploaded

"Scaling RAG Applications to serve millions of users", Kevin Goedecke
"Scaling RAG Applications to serve millions of users",  Kevin Goedecke"Scaling RAG Applications to serve millions of users",  Kevin Goedecke
"Scaling RAG Applications to serve millions of users", Kevin Goedecke
Fwdays

Mutation Testing for Task-Oriented Chatbots
Mutation Testing for Task-Oriented ChatbotsMutation Testing for Task-Oriented Chatbots
Mutation Testing for Task-Oriented Chatbots
Pablo Gómez Abajo

GNSS spoofing via SDR (Criptored Talks 2024)
GNSS spoofing via SDR (Criptored Talks 2024)GNSS spoofing via SDR (Criptored Talks 2024)
GNSS spoofing via SDR (Criptored Talks 2024)
Javier Junquera

What is an RPA CoE? Session 1 – CoE Vision
What is an RPA CoE?  Session 1 – CoE VisionWhat is an RPA CoE?  Session 1 – CoE Vision
What is an RPA CoE? Session 1 – CoE Vision
DianaGray10

LF Energy Webinar: Carbon Data Specifications: Mechanisms to Improve Data Acc...
LF Energy Webinar: Carbon Data Specifications: Mechanisms to Improve Data Acc...LF Energy Webinar: Carbon Data Specifications: Mechanisms to Improve Data Acc...
LF Energy Webinar: Carbon Data Specifications: Mechanisms to Improve Data Acc...
DanBrown980551

Session 1 - Intro to Robotic Process Automation.pdf
Session 1 - Intro to Robotic Process Automation.pdfSession 1 - Intro to Robotic Process Automation.pdf
Session 1 - Intro to Robotic Process Automation.pdf
UiPathCommunity

Poznań ACE event - 19.06.2024 Team 24 Wrapup slidedeck
Poznań ACE event - 19.06.2024 Team 24 Wrapup slidedeckPoznań ACE event - 19.06.2024 Team 24 Wrapup slidedeck
Poznań ACE event - 19.06.2024 Team 24 Wrapup slidedeck
FilipTomaszewski5

GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge GraphGraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
Neo4j

Apps Break Data
Apps Break DataApps Break Data
Apps Break Data
Ivo Velitchkov

inQuba Webinar Mastering Customer Journey Management with Dr Graham Hill
inQuba Webinar Mastering Customer Journey Management with Dr Graham HillinQuba Webinar Mastering Customer Journey Management with Dr Graham Hill
inQuba Webinar Mastering Customer Journey Management with Dr Graham Hill
LizaNolte

Principle of conventional tomography-Bibash Shahi ppt..pptx
Principle of conventional tomography-Bibash Shahi ppt..pptxPrinciple of conventional tomography-Bibash Shahi ppt..pptx
Principle of conventional tomography-Bibash Shahi ppt..pptx
BibashShahi

QA or the Highway - Component Testing: Bridging the gap between frontend appl...
QA or the Highway - Component Testing: Bridging the gap between frontend appl...QA or the Highway - Component Testing: Bridging the gap between frontend appl...
QA or the Highway - Component Testing: Bridging the gap between frontend appl...
zjhamm304

How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdfHow to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
Chart Kalyan

zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
Alex Pruden

Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-EfficiencyFreshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
ScyllaDB

Astute Business Solutions | Oracle Cloud Partner |
Astute Business Solutions | Oracle Cloud Partner |Astute Business Solutions | Oracle Cloud Partner |
Astute Business Solutions | Oracle Cloud Partner |
AstuteBusiness

"NATO Hackathon Winner: AI-Powered Drug Search", Taras Kloba
"NATO Hackathon Winner: AI-Powered Drug Search",  Taras Kloba"NATO Hackathon Winner: AI-Powered Drug Search",  Taras Kloba
"NATO Hackathon Winner: AI-Powered Drug Search", Taras Kloba
Fwdays

Y-Combinator seed pitch deck template PP
Y-Combinator seed pitch deck template PPY-Combinator seed pitch deck template PP
Y-Combinator seed pitch deck template PP
c5vrf27qcz

Crafting Excellence: A Comprehensive Guide to iOS Mobile App Development Serv...
Crafting Excellence: A Comprehensive Guide to iOS Mobile App Development Serv...Crafting Excellence: A Comprehensive Guide to iOS Mobile App Development Serv...
Crafting Excellence: A Comprehensive Guide to iOS Mobile App Development Serv...
Pitangent Analytics & Technology Solutions Pvt. Ltd

“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
Edge AI and Vision Alliance


Recently uploaded (20)

"Scaling RAG Applications to serve millions of users", Kevin Goedecke
"Scaling RAG Applications to serve millions of users",  Kevin Goedecke"Scaling RAG Applications to serve millions of users",  Kevin Goedecke
"Scaling RAG Applications to serve millions of users", Kevin Goedecke

Mutation Testing for Task-Oriented Chatbots
Mutation Testing for Task-Oriented ChatbotsMutation Testing for Task-Oriented Chatbots
Mutation Testing for Task-Oriented Chatbots

GNSS spoofing via SDR (Criptored Talks 2024)
GNSS spoofing via SDR (Criptored Talks 2024)GNSS spoofing via SDR (Criptored Talks 2024)
GNSS spoofing via SDR (Criptored Talks 2024)

What is an RPA CoE? Session 1 – CoE Vision
What is an RPA CoE?  Session 1 – CoE VisionWhat is an RPA CoE?  Session 1 – CoE Vision
What is an RPA CoE? Session 1 – CoE Vision

LF Energy Webinar: Carbon Data Specifications: Mechanisms to Improve Data Acc...
LF Energy Webinar: Carbon Data Specifications: Mechanisms to Improve Data Acc...LF Energy Webinar: Carbon Data Specifications: Mechanisms to Improve Data Acc...
LF Energy Webinar: Carbon Data Specifications: Mechanisms to Improve Data Acc...

Session 1 - Intro to Robotic Process Automation.pdf
Session 1 - Intro to Robotic Process Automation.pdfSession 1 - Intro to Robotic Process Automation.pdf
Session 1 - Intro to Robotic Process Automation.pdf

Poznań ACE event - 19.06.2024 Team 24 Wrapup slidedeck
Poznań ACE event - 19.06.2024 Team 24 Wrapup slidedeckPoznań ACE event - 19.06.2024 Team 24 Wrapup slidedeck
Poznań ACE event - 19.06.2024 Team 24 Wrapup slidedeck

GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge GraphGraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph

Apps Break Data
Apps Break DataApps Break Data
Apps Break Data

inQuba Webinar Mastering Customer Journey Management with Dr Graham Hill
inQuba Webinar Mastering Customer Journey Management with Dr Graham HillinQuba Webinar Mastering Customer Journey Management with Dr Graham Hill
inQuba Webinar Mastering Customer Journey Management with Dr Graham Hill

Principle of conventional tomography-Bibash Shahi ppt..pptx
Principle of conventional tomography-Bibash Shahi ppt..pptxPrinciple of conventional tomography-Bibash Shahi ppt..pptx
Principle of conventional tomography-Bibash Shahi ppt..pptx

QA or the Highway - Component Testing: Bridging the gap between frontend appl...
QA or the Highway - Component Testing: Bridging the gap between frontend appl...QA or the Highway - Component Testing: Bridging the gap between frontend appl...
QA or the Highway - Component Testing: Bridging the gap between frontend appl...

How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdfHow to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf

zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...

Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-EfficiencyFreshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency

Astute Business Solutions | Oracle Cloud Partner |
Astute Business Solutions | Oracle Cloud Partner |Astute Business Solutions | Oracle Cloud Partner |
Astute Business Solutions | Oracle Cloud Partner |

"NATO Hackathon Winner: AI-Powered Drug Search", Taras Kloba
"NATO Hackathon Winner: AI-Powered Drug Search",  Taras Kloba"NATO Hackathon Winner: AI-Powered Drug Search",  Taras Kloba
"NATO Hackathon Winner: AI-Powered Drug Search", Taras Kloba

Y-Combinator seed pitch deck template PP
Y-Combinator seed pitch deck template PPY-Combinator seed pitch deck template PP
Y-Combinator seed pitch deck template PP

Crafting Excellence: A Comprehensive Guide to iOS Mobile App Development Serv...
Crafting Excellence: A Comprehensive Guide to iOS Mobile App Development Serv...Crafting Excellence: A Comprehensive Guide to iOS Mobile App Development Serv...
Crafting Excellence: A Comprehensive Guide to iOS Mobile App Development Serv...

“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...


[html5tx] Adaptive Images in Responsive Web Design

  • 1. CHRISTOPHER SCHMITT @teleject ADAPTIVE IMAGES IN RESPONSIVE WEB DESIGN HTML5tx 2013
  • 3.
  • 4. WHY DON’T WE ASK THE BROWSER? (cc) flic.kr/p/vUBHv
  • 6. Mozilla/1.0 (Win3.1) Mozilla/1.22 (compatible; MSIE 2.0; Windows 95) http://www.useragentstring.com/ (cc) flic.kr/p/vUBHv
  • 7. Mozilla/5.0 (Macintosh; Intel Mac OS X 10_7_3) AppleWebKit/ 534.55.3 (KHTML, like Gecko) Version/5.1.5 Safari/534.55.3 http://www.useragentstring.com/ (cc) flic.kr/p/vUBHv
  • 8. Mozilla/5.0 (Macintosh; Intel Mac OS X 10_7_3) AppleWebKit/ 534.55.3 (KHTML, like Gecko) Version/5.1.5 Safari/534.55.3 http://webaim.org/blog/user-agent-string-history/ (cc) flic.kr/p/vUBHv
  • 10. FEATURE TESTING vs. BROWSER SNIFFING 1 Browser width 2 3
  • 11. A scripting approach var myWidth = 0, myHeight = 0; if( typeof( window.innerWidth ) == 'number' ) { //Non-IE myWidth = window.innerWidth; myHeight = window.innerHeight; } else if( document.documentElement && ( document.documentElement.clientWidth || document.documentElement.clientHeight ) ) { //IE 6+ in 'standards compliant mode' myWidth = document.documentElement.clientWidth; myHeight = document.documentElement.clientHeight; } http://www.howtocreate.co.uk/tutorials/javascript/browserwindow
  • 12. The jQuery approach // returns width of browser viewport $(window).width(); // returns height of browser viewport $(window).height(); // returns width of HTML document $(document).width(); // returns height of HTML document $(document).height(); http://api.jquery.com/width/ & http://api.jquery.com/height/
  • 13. CSS media queries // default, mobile-1st CSS rules devices go here @media screen and (min-width: 480px) { ... } @media screen and (min-width: 600px) { ... } @media screen and (min-width: 768px) { ... } @media screen and (min-width: 910px) { ... }
  • 15. BROWSER WIDTH GIVES US FRAME, NOT THE CANVAS
  • 16. FEATURE TESTING vs. BROWSER SNIFFING 1 Browser width 2 Screen resolution 3
  • 17. 72 PPI HAS SERVED US WELL (cc) flic.kr/p/6tjjRP
  • 18. 72 points-per-inch = 72 pixels-per-inch
  • 19. 96 PPI IF A WINDOWS USER
  • 21. “RETINA” DISPLAYS 300ppi at 12 inches from the eyes 78μm 78μm goo.gl/zpkFy
  • 22.
  • 23. 240 144 72 PPI
  • 24. [In 2013, Intel sees their product line] offer a higher resolution experience than a top-of-the-line 1080p HDTV.” http://liliputing.com/2012/04/intel-retina-laptop- desktop-displays-coming-in-2013.html
  • 26. 240
  • 30. RETINA DISPLAYS = LARGER IMAGES, LARGER FILE SIZES
  • 31. FEATURE TESTING vs. BROWSER SNIFFING 1 Browser width 2 Screen resolution 3 Bandwidth
  • 32. SPEED TESTS HINDER SPEED, USER EXPERIENCE (cc) flic.kr/p/4DziUN
  • 33. Testing for speed of an internet connection is like stepping in front of a car to see how fast it is.” (cc) flic.kr/p/4DziUN
  • 34. Testing for speed of an internet connection is like stepping in front of a car to see how fast it is.” “ But, Christopher, you only have to test it once.” (cc) flic.kr/p/4DziUN
  • 36. Speed test image +50k https://github.com/adamdbradley/foresight.js
  • 37. Native speed test // @Modernizr's network-connection.js connection = navigator.connection || { type: 0 }, // polyfill isSlowConnection = connection.type == 3 || connection.type == 4 | /^[23]g$/.test(connection.type); http://davidbcalhoun.com/2010/using-navigator-connection-android
  • 38. IMG GIMME THAT OLD SCHOOL 1 2 3
  • 39. IMG GIMME THAT OLD SCHOOL 1 .htaccess 2 3
  • 40. Filament .htaccess # Responsive Images # Mobile-First images that scale responsively and responsibly # Copyright 2010, Scott Jehl, Filament Group, Inc # Dual licensed under the MIT or GPL Version 2 licenses. # //Start Responsive Images RewriteEngine On # direct image requests to temp RewriteCond %{QUERY_STRING} full=(.*)&? RewriteRule (.*)rwd-router/.*.(jpe?g|png|gif|webp) $1%1 [L] # ignore trap for non-image requests, rewrite URL without trap segment RewriteRule (.*)rwd-router/(.*)$ $1$2 # //End Responsive Images https://github.com/filamentgroup/Responsive-Images
  • 41. Filament .htaccess <script src="responsiveimgs.js"></script> <img src="sample-content/running-sml.jpg? full=sample-content/running-lrg.jpg" /> 4+ 8+
  • 42. ...the server has no way to know what resolution the client’s device is, so it can’t send the appropriately sized embeded images.” http://mattwilcox.net/archive/entry/id/1053/
  • 44. ADD .HTACCESS, JS, PHP 5, GD lib*, & THEN <IMG>
  • 45. IMG GIMME THAT OLD SCHOOL 1 .htaccess 2 <picture> and/or srcset 3
  • 46. media queries in HTML <video controls> <source type="video/mp4" src="video/windowsill_small.mp4" media="all and (max-width: 480px), all and (max-device-width: 480px)"> <source type="video/webm" src="video/windowsill_small.webm" media="all and (max-width: 480px), all and (max-device-width: 480px)"> <source type="video/mp4" src="video/windowsill.mp4"> <source type="video/webm" src="video/windowsill.webm"> <!-- proper fallback content goes here --> </video> http://www.w3.org/community/respimg/2012/03/15/polyfilling- picture-without-the-overhead/
  • 47. <picture> patch <picture alt="A giant stone face at The Bayon temple in Angkor Thom, Cambodia"> <!-- <source src="small.jpg"> --> <source src="small.jpg"> <!-- <source src="medium.jpg" media="(min-width: 400px)"> --> <source src="medium.jpg" media="(min-width: 400px)"> <!-- <source src="large.jpg" media="(min-width: 800px)"> --> <source src="large.jpg" media="(min-width: 800px)"> <!-- Fallback content for non-JS browsers. Same src as the initial source element. --> <noscript><img src="small.jpg" alt="A giant stone face at The Bayon temple in Angkor Thom, Cambodia"></noscript> </picture> http://www.w3.org/community/respimg/2012/03/15/polyfilling- picture-without-the-overhead/
  • 48. ADD IF-ELSE HTML, JS, BORROW <VIDEO>, & THEN <IMG>
  • 49. @srcset standard? <h1><img alt="The Breakfast Combo" src="banner.jpeg" srcset="banner-HD.jpeg 2x, banner-phone.jpeg 100w, banner-phone-HD.jpeg 100w 2x"> </h1> http://www.whatwg.org/specs/web-apps/current-work/multipage/ embedded-content-1.html#attr-img-srcset
  • 50. IMG GIMME THAT OLD SCHOOL 1 .htaccess 2 <picture> 3 HiSRC
  • 51. Set, forget it HiSRC <script src="https://ajax.googleapis.com/ajax/ libs/jquery/1.7.2/jquery.min.js"></script> <script src="hisrc.js"></script> <script> $(document).ready(function(){ $(".hisrc img").hisrc(); }); </script>
  • 52. Set, forget it HiSRC <div class="hisrc"> <img src="halloween-mobile-1st.png" data-1x="halloween-x1.png" data-2x="halloween-x2.jpg" alt="Celebrating Halloween in style" /> </div>
  • 53. Set, forget it HiSRC <div class="hisrc"> <img src="halloween-mobile-1st.png" data-1x="halloween-x1.png" data-2x="halloween-x2.jpg" alt="Celebrating Halloween in style" /> </div>
  • 54. SERIES OF CHECKS TO FIND OUT RESPONSIVE PATH FOR IMAGES...
  • 55. DO NATIVE SPEED TEST FOR MOBILE DEVICES FIRST... http://davidbcalhoun.com/2010/using-navigator-connection-android
  • 56. Check pixel density... $.hisrc.devicePixelRatio = 1; if(window.devicePixelRatio !== undefined) { $.hisrc.devicePixelRatio = window.devicePixelRatio }; https://gist.github.com/2428356
  • 57. Force speed test +50k https://github.com/adamdbradley/foresight.js
  • 58. LESS THAN 4G MEANS MOBILE IMAGES LEFT IN PLACE
  • 59. BETWEEN 4G & 300 Kbps MEANS REGULAR DESKTOP IMAGES SWAPPED IN
  • 60. FAST SPEED & HIGH DENSITY, RETINA IMAGES SWAPPED IN https://github.com/crdeutsch/hisrc/tree/v2
  • 62. CSS IS CORE. WE USE CSS MEDIA QUERIES FOR DESIGN
  • 64. CSS media queries // default, mobile-1st CSS rules devices go here @media screen and (min-width: 480px) { ... } @media screen and (min-width: 600px) { ... } @media screen and (min-width: 768px) { ... } @media screen and (min-width: 910px) { ... }
  • 69. Single pixel GIF $.hisrc.defaults = { useTransparentGif: true, http://www.w3.org/community/respimg/2012/04/06/responsive- content-images-using-a-spacer-png-and-background-image/
  • 71. Single pixel GIF $.hisrc.defaults = { useTransparentGif: true, transparentGifSrc: 'http:// example.com/spg.gif', 17+ 9+ 11.6+ 5+ 6+
  • 72. 2 APPROACHES, 1 SIMPLE SOLUTION. https://github.com/teleject/hisrc
  • 73. 2 APPROACHES, 1 SIMPLE SOLUTION. HEART WEB DESIGN https://github.com/teleject/hisrc
  • 74. WORKAROUNDS & TRICKS 1 2 3 (cc) flic.kr/p/64fGf6
  • 75. WORKAROUNDS & TRICKS 1 background-size: auto 2 3 (cc) flic.kr/p/64fGf6
  • 77.
  • 78. background-size: 100% <a href="example.com/link">Download on Github</a> .download a { padding: .095em .8em; background: url(../img/arrow.png) no-repeat; background-size: 100%; margin-left: .4em; -webkit-transition: margin 0.15s ease-out; -moz-transition: margin 0.15s ease-out; text-decoration: none; } 17+ 9+ 11.6+ 5+ 9+
  • 79. WORKAROUNDS & TRICKS 1 background-size: auto 2 SVG 3 (cc) flic.kr/p/64fGf6
  • 81. PNG 16kb SVG 7kb 17+ 9+ 11.6+ 5+ 9+
  • 82. HTML5 Boilerplate <!doctype html> <!--[if lt IE 7]> <html class="no-js lt-ie9 lt-ie8 lt-ie7" lang="en"> <![endif]--> <!--[if IE 7]> <html class="no-js lt-ie9 lt-ie8" lang="en"> <![endif]--> <!--[if IE 8]> <html class="no-js lt-ie9" lang="en"> <! [endif]--> <!--[if gt IE 8]><!--> <html class="no-js" lang="en"> <!--<! [endif]--> <head>
  • 83. jQuery check var checkBrowser = $('html').hasClass('lt-ie9'); <div class="svgswap"> <img src="example.svg" data-svgswap="example.png"> </div> https://github.com/teleject/svg-swap
  • 85. WORKAROUNDS & TRICKS 1 background-size: auto 2 SVG 3 font-based solutions (cc) flic.kr/p/64fGf6
  • 86. ...if you use <meta charset="utf-8"> (you should be for HTML5), you’re adding common Unicode characters like and ✆, and you don’t need a specific font’s version... just copy and paste them into your HTML.”
  • 89. Font-based icons <style> [data-icon]:before { font-family: 'icon-font'; content: attr(data-icon); } </style> <a href="http://example.com/cloud/save/"> <span data-icon="C" aria-hidden="true"></span> Save to Cloud </a>
  • 90. WORKAROUNDS & TRICKS 1 background-size: auto 2 SVG 3 font-based solutions 4 compressed JPEGs (cc) flic.kr/p/64fGf6
  • 91.
  • 92.
  • 93.
  • 94.
  • 95.
  • 96. IMG GIMME THAT NEW SCHOOL 1 2 3
  • 97. IMG GIMME THAT NEW SCHOOL 1 simple design for users 2 3 #rwdimg
  • 98. IMG GIMME THAT NEW SCHOOL 1 simple design for users 2 browser, server handshake 3 #rwdimg
  • 99. IMG GIMME THAT NEW SCHOOL 1 simple design for users 2 browser, server handshake 3 same, several formats #rwdimg
  • 107. <link rel="shortcut icon" href="/assets/favicon.ico" /> #rwdimg
  • 108. <link rel="apple-touch-icon-precomposed" sizes="144x144" href="apple-touch-icon-144x144-precomposed.png" /> <link rel="apple-touch-icon-precomposed" sizes="114x114" href="apple-touch-icon-114x114-precomposed.png" /> <link rel="apple-touch-icon-precomposed" sizes="72x72" href="apple-touch-icon-72x72-precomposed.png" /> <link rel="apple-touch-icon-precomposed" href="apple-touch-icon-precomposed.png" /> <link rel="shortcut icon" href="/assets/favicon.ico" /> #rwdimg
  • 110. THANK YOU! CHRISTOPHER SCHMITT @teleject http://goo.gl/gSYmS The Non Breaking Space Podcast - http://nonbreakingspace.tv/
